Toyota VSS 1 User manual

Vehicle Security System
VSS 1
Owner’s manual
Bedienungsanleitung
Mode d’emploi
Gebruikershandleiding
Manuale dell’utente
Manual del propietario
Εγχειρίδιο κατόχου
Manual do proprietário
Kullanıcı El Kitabı
Brugsanvisning
Omistajan käsikirja
Brukerhåndbok
Användarhandbok
Přiručka uživatele
Kezelési útmutató
Instrukcja użytkownika
Руководство по эксплуатации
Priročnik za lastnika
Пociбник з експлуатації
Kasutaja käsiraamat
Lietotāja rokasgrāmata
Instrukcija vartotojui

VSS1 1
Read this manual thoroughly before using the VSS1.
Always keep this owner’s manual in the vehicle.
Lesen Sie diese Anleitung vor Benutzung der VSS1 gründlich.
Bewahren Sie diese Anleitung immer im Fahrzeug auf.
Lisez ce manuel dans son intégralité avant d’utiliser le VSS1.
Conservez toujours ce mode d'emploi dans le véhicule.
Lees deze handleiding grondig voordat u de VSS1 gebruikt.
Bewaar deze gebruikshandleiding altijd in uw voertuig.
Leggere con attenzione e per intero questo manuale prima di utilizzare il VSS1.
Tenere sempre nel veicolo il presente manuale d’uso.
Lea completamente este manual antes de usar VSS1.
Guarde siempre este Manual del Propietario en el vehículo.
Διαβάστε το παρόν εγχειρίδιο διεξοδικά πριν χρησιμοποιήσετε το VSS1.
Διατηρείτε το παρόν εγχειρίδιο κατόχου πάντοτε στο όχημα.
Leia atentamente este manual antes de usar o VSS1.
Mantenha sempre este manual do proprietário no veículo.
VSS1 kullanmadan önce bu El Kitabını iyice okuyunuz.
Kullanıcı El Kitabı daima araçta bulundurulmalıdır.
Læs denne vejledning grundigt, før VSS1 tages i brug.
Opbevar altid denne vejledning i køretøjet.
Lue tämä käyttöopas huolellisesti ennen VSS1 -pysäköintitutkan käyttämistä.
Säilytä tätä Omistajan käsikirjaa autossa.
Les denne håndboken grundig før du bruker VSS1.
Oppbevar alltid denne brukerhåndboken i kjøretøyet.
Läs den här instruktionsboken noggrant innan du använder VSS1.
Förvara alltid denna instruktionsbok i bilen.
Než začnete používat VSS1, pozorně si přečtěte tento návod k použití.
Návod k použití mějte stále uložený ve svém vozidle.
Olvassuk el gondosan ezt az útmutatót, mielőtt a VSS1 berendezést használatba vennénk.
Mindig tartsuk a kezelési útmutatót a gépkocsiban.
Przed rozpoczęciem użytkowania systemu wspomagania parkowania VSS1 prosimy uważnie przeczytać niniejszą
instrukcję.
Niniejszą instrukcję użytkownika należy zawsze przechowywać w samochodzie.
Внимательно прочитайте это руководство перед использованием системы VSS1.
Постоянно храните это руководство по эксплуатации в автомобиле.
Pred uporabo aparata VSS1 skrbno preberite ta priročnik.
Ta uporabniški priročnik naj bo vedno v vozilu.
Уважно прочитайте цей посібник перед використанням VSS1.
Завжди зберігайте цей посібник користувача в транспортному засобі.
Lugege enne VSS1 kasutamist hoolikalt seda kasutusjuhendit.
Hoidke alati seda kasutusjuhendit sõidukis.
Pirms VSS1 izmantošanas rūpīgi izlasiet šo rokasgrāmatu.
Vienmēr glabājiet šo lietotāja rokasgrāmatu transportlīdzeklī.
Atidžiai perskaitykite šią instrukciją prieš naudojantis VSS1 įranga.
Visada šią instrukciją laikykite automobilyje.

2VSS1
OPERATING INSTRUCTIONS .................................................................Page 3
BEDIENUNGSANLEITUNG .....................................................................Seite 16
MODE D’EMPLOI ..................................................................................Page 29
BEDIENINGSHANDLEIDING ..................................................................Pagina 42
ISTRUZIONI PER L’USO .........................................................................Pagina 55
INSTRUCCIONES DE SERVICIO ..............................................................Página 68
ΟΔΗΓΙΕΣ ΛΕΙΤΟYΡΓΙΑΣ ........................................................................... Σελίδα 81
INSTRUÇÕES DE FUNCIONAMENTO .................................................... Página 94
İȘLETME TALİΜATI ...................................................................................Sayfa 107
BETJENINGSVEJLEDNING .......................................................................Side 120
KÄYTTÖOHJEET......................................................................................Sivu 133
BRUKERVEILEDNING ..............................................................................Side 146
INSTRUKTIONSBOK ...............................................................................Sida 159
NÁVOD K POUŽITÍ ................................................................................Strana 172
ÜZEMELTETÉSI ÚTMUTATÓ ...................................................................Oldal 185
INSTRUKCJA OBSŁUGI ...........................................................................Strona 198
ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ ...........................................................Страница 211
NAVODILA ZA UPORABO ......................................................................Stran 224
ІНСТРУКЦІЯ З ЕКСПЛУАТАЦІЇ ..................................................................Стор. 237
KASUTUSJUHEND .................................................................................. Lk. 250
NAUDOJIMOSI INSTRUKCIJOS .............................................................. Puslapis 263
LIETOŠANAS INSTRUKCIJAS .................................................................. Lappuse 276

VSS1 3
Dear Customer,
Congratulations on your purchase of this alarm system which has been designed and
manufactured to the highest automotive standards utilising the latest technology for total reliability
as per the European Community directives.
Please read this manual to get the full benefit of the system.
We suggest you to keep this manual in the car. It will be easier for you to find the information in
the event of emergency. Your authorised retailer will be pleased to clarify any queries you may have
with the system or its operation if you cannot find the information you need in this manual or in
the chapter ‘Troubleshooting guide’.
Immunity information
– If any loss is caused by fire, action of a third party, or other accidents, or the user’s deliberate or
accidental misuse, incorrect use, or use under abnormal conditions, repair of the product will
be charged to the user.
– Toyota Motor Europe NV/SA is not liable for any incidental loss caused by the use or non-use of
this product.
– Toyota Motor Europe NV/SA is not liable for any damages or incidents following the intentional
use, accidental misuse, or third party use of the device.
– The alarm system will not prevent the car from being stolen.

4VSS1
Content
Immunity information ............................................................................................................. 3
Introduction ........................................................................................................................... 5
1. Arm / Disarm ..................................................................................................................... 6
1.1 To ARM the alarm system .......................................................................................... 6
1.2 To DISARM the alarm system ..................................................................................... 7
1.3 Boot release .............................................................................................................. 7
1.4 Stop the siren sounding ............................................................................................ 7
1.5 Arm without intrusion sensor .................................................................................... 8
1.6 Automatic re-arming ................................................................................................. 9
1.7 Alarm status light (LED) ............................................................................................. 9
2. Features ............................................................................................................................ 10
2.1 Door ajar warning ..................................................................................................... 10
2.2 Alarm override .......................................................................................................... 10
2.3 Automatic door locking ............................................................................................. 10
2.4 Passive arming .......................................................................................................... 10
2.5 Alarm memory .......................................................................................................... 11
2.6 Alarm with car horn sound ........................................................................................ 11
2.7 Garage mode ............................................................................................................ 11
2.8 Arming buzzer .......................................................................................................... 12
2.9 Installation check mode ............................................................................................ 12
3. Technical specifications ..................................................................................................... 13
4. Troubleshooting guide ...................................................................................................... 14

VSS1 5
Introduction
This alarm system is operated by the original high security remote control or smart key described
in the car’s owner’s manual. To programme extra remote controls consult your Toyota authorised
retailer.
The alarm system can only be armed and disarmed with original car remote control. The
protection of your car is assured by interior movement and perimetric sensors. The alarm system is
self-protected against system attack.
During an alarm, the alarm siren, the vehicle horn (if applicable on your car), the blinkers, and the
interior light are activated.
Product functions
The Alarm system performs the following functions:
• Perimetricprotection(doors,boot,andbonnet).
• Interiorandwindowbreakageprotection(byinteriormovementsensor).
• Alarmsystemtamperingprotection.
• Unauthorisedenginestartingcarprotection.
• Self-poweredalarmsystem.
• Acousticandvisualalarmsignalization.
• Alarmsystemstatusanddiagnosticindicationlight(LED).
• Additionalprotectionfeaturescanbeadded(Lift-upmonitormodule).
Alarm operation
The alarm is activated in the following situations:
• Alockeddoororbootisopenedinanywayotherthanusingthesmartentryfunctionor
original remote control.
• Thebonnetisopenedwhilethecarislocked.
• Theintrusionsensorisactivated:Whenthesensordetectssomethingmovinginsidethecar,or
a window is broken.
• Thebatteryterminalisdisconnectedwhilethealarmsystemisactivated.
Remarks
The intrusion sensor may be triggering by any of the following:
• Danglingaccessories.
• Automaticorhighpressurecarwashes.
• Theimpactofhail,lightningstrikes,orotherkindsofimpactorcontinuousvibrations.
• Anyopenwindoworslidingroof.
The intrusion sensor can be deactivated as you can read in paragraph 1.5.

6VSS1
1. Arm / Disarm
The alarm system will be armed at the same time as you lock the car, and disarmed when
unlocking the car.
1.1 To ARM the alarm system
Important:
To prevent false alarm, check that there is no one in the car, and that all windows and sliding
roofs are closed before locking the car (see how to deactivate the interior intrusion sensor in
paragraph 1.5).
Action Hazard Light indication Alarm status light (LED)
Remote control: Press Lock
Button once.
Flashes once. ON for 30 seconds, then
starts flashing.
Smart key: Press Lock Button
once or Push door handle Lock
Button.
Flashes once. ON for 30 seconds, then
starts flashing.
NOTE:
– The car LED blinks to inform you that the immobiliser is set (no link with alarm system).
– If any door, the boot and/or bonnet is opened within 30 seconds, the system will be disarmed.
– If any door is not securely closed, a beep will sound (car will not be locked, and alarm will not
be armed). (Not applicable on all car models.)
– The system will be armed 30 seconds after the lock button is pressed (pre-arm time).
LOCK
(Arm)
UNLOCK
(Disarm)
Boot
release
LOCK
(Arm)
UNLOCK
(Disarm)

VSS1 7
1.2 To DISARM the alarm system
Action Hazard Light indication Alarm status light (LED)
Remote control:PressUnlock
Button once.
Flashes twice. Stops flashing.
Smart key: PressUnlock
Button once or grasp the door
handle.
Flashes twice. Stops flashing.
NOTE:
– If no door is opened within 30 seconds after disarming, the system will re-arm automatically
and the doors will be locked again.
WARNING:
When the system is armed, do not unlock any door using the key as this will make the siren sound.
1.3 Boot release
When the boot release button (if present) is pressed on the remote control, the system is disarmed.
The system will automatically re-arm when the boot is closed again and car is locked.
1.4 Stop the siren sounding
Unlockthedoorbytheremotecontrolorsmartkey.Thesirenwillstopandthesystemwillbe
disarmed.
Note:
– If after this, no door is opened within 30 seconds, all doors will automatically lock and the
system will re-arm.

8VSS1
1.5 Arm without intrusion sensor
If you have to lock the car with somebody inside (passenger, children, dog, …), you must
deactivate the Intrusion Sensor.
Central Door Lock
(Located on the driver’s door)
Activation steps Hazard light
indication
Alarm status
light (LED)
Buzzer
1 Open the driver’s
door.
–––
2 Operate the Central
Power Door Lock
switch to the
lock and unlock
positions 3 times
with the driver’s
door open (interval
between each press
should be less than
5 seconds).
– LED indication
will flash rapidly
for 5 minutes, or
until you arm the
system.
2 beeps sound
when the sensors
are deactivated.
3 Close all doors,
bonnet and boot,
then lock the car
by remote control
or smart key within
5 minutes.
Flashes once. ON for 30 seconds,
then start flashing.
–
NOTE:
– The interior sensor is deactivated for 1 use only. On the next arming the interior sensor will be
activated again.
Unlock Lock

VSS1 9
1.6 Automatic re-arming
If the car is unlocked using the remote control, and the boot or doors are not opened within
30 seconds, the security system will automatically re-arm when the car automatically relocks.
1.7 Alarm status light (LED)
The status LED is used to give information to the user, during normal operation, and as a
diagnostic tool.
Condition Alarm status light (LED)
Disarm state: LED off.
Pre-arm state (30 sec
arming time):
LED on.
Arm state: LED blinking.
Alarm state: LED on.
Intrusion sensor exclusion
activated:
LED fast blinking until car locked by remote or smart key, or
5 minutes passed.
Open bonnet: LEDon(forAuris,Camry,CorollaSDN,Rav4,UrbanCruiser,Yaris
only).
Door open during passive
arming:
LED on.
Programming mode
selection:
LED on (until timeout or selection performed).

10 VSS1
2. Features
As well as the alarm function, some extra features are available which can be activated/deactivated.
To activate or deactivate any of them, please contact your authorised retailer.
2.1 Door ajar warning
This option is enabled as default.
If any door or the boot is opened when the lock button is pressed, the buzzer will sound for
10 seconds. The buzzer will stop sounding when all doors are closed, or if the remote control
unlock button is pushed.
In case the bonnet is opened when the lock button is pressed, the buzzer will sound 3 times with
3 beeps.
Note:
– The alarm system will NOT arm if a door is open.
– This function is already implemented for smart key equipped cars.
– This option is not available on all car models.
2.2 Alarm override
This function is used if the user loses the remote, or the remote battery is flat.
When the engine is started by the original key, the alarm will disarm after 5 seconds.
2.3 Automatic door locking
This option is disabled as default. This feature can only be enabled if the car does not have this
function as original equipment. To enable this function, please contact your authorised retailer.
When all doors are closed and you start driving, the system will lock the doors.
The alarm system will unlock all doors when ignition has been switched off.
2.4 Passive arming
This option is disabled as default.
Passive arming mode arms the alarm system automatically without the car being locked. It protects
your car in case you forget to lock it.

VSS1 11
When this option is activated, it will arm the alarm system after following these steps:
1. The engine is stopped, and the key is removed from the ignition.
2. A door has been opened and all doors have been closed again.
3. No door has been opened for 30 consecutive seconds (counter restarts when all doors are
closed again).
If any door is opened when the alarm system is in passive arming, the siren will sound after
14 seconds unless the engine is started or the remote control pressed.
When a door opens, a beep will inform you that passive arming is active, and the alarm status light
(LED) will turn on.
Note:
– During passive mode, volumetric sensors are deactivated.
– If you lock the car by remote control, the alarm system shifts to normal arming mode.
Remark:
– The system does NOT lock any doors, only arms the alarm system.
2.5 Alarm memory
If the alarm went off during your absence, the hazard lights will flash 5 times when the doors are
unlocked, and the buzzer will sound 3 times.
The system memorizes the last three alarm causes. They can be identified at your authorised retailer.
Note:
– If you suspect that the alarm system is sounding due to false alarms, please contact your
authorised retailer.
2.6 Alarm with car horn sound
This option is enabled as default. To disable it, please contact your authorised retailer.
In addition to the standard siren, the car horn can be activated to sound or it can be deactivated.
Note:
– This option is not available on all car models.
2.7 Garage mode
If you have to bring your car to your authorised retailer and do not want to provide the remote
controlled key, you can deactivate the alarm system for a limited period of time.
During garage mode, all the alarm system functions are inhibited.

12 VSS1
This mode has to be manually activated by following this procedure:
1. Disarm by remote control.
2. Insert the key into the ignition and turn to IG ON.
3. Open and close the door 7 times within 30 seconds.
4. Turn the key to IG OFF.
The hazards will flash once (confirmation).
After 5 engine starts, the garage mode will be cancelled. The hazards will turn on twice.
2.8 Arming buzzer
This option is disabled as default. To enable it, please contact your authorised retailer.
You can activate the buzzer to sound when you arm/disarm the system.
Remark:
– This can only be done in accordance with local regulations.
2.9. Installation check mode
The system can confirm correct installation or if a sensor is not working correctly.
If you suspect that a sensor is not working correctly, please contact your authorised retailer.

VSS1 13
3. Technical Specifications
Nominal rated operating voltage: +12 V DC
Operating voltage range: +8 to +16 V DC
Maximum overvoltage: +24 V DC per 1 minute
Maximum reverse voltage: −18 V DC per 1 minute
Current consumption
(max values at 23°C):
– Disarm state < 0.5 mA (+12 V DC)
– Arm state < 1.0 mA (+12 V DC)
– Alarm state < 300 mA (+12 V DC)
Maximum operating temperature: +85°C
Minimum operating temperature: −40°C
IP grade: IP 40 or IPX5
Alarm’s siren sound pressure level: > 111dB in open field (1m)

14 VSS1
4. Troubleshooting guide
Problem Possible causes Possible solutions
System is beeping
1 long 1 door/boot is open. Check that all doors are correctly
closed.
3 short repeating Bonnet is open. Check that bonnet is correctly
closed.
3 beeps at unlock Alarm went off while system was
armed.
Contact authorised retailer to find
cause.
5 beeps Interior movement sensors broken. Check and/or change interior
movement sensors.
5 beeps Wire harness connection problem/
Siren failure.
Contact authorised retailer to find
cause.
False alarm
Intrusion sensors are broken,
detached, or incorrectly orientated.
Check and contact authorized
retailer.
Passive arming ON. Read the passive arming chapter.
Deactivate passive arming (not
applicable for Belgium).
Opened window / sliding roof. Close all windows and sliding roof.
If you wish to keep any open,
deactivate the interior movement
sensors (see chapter 1.5).
Hanging clothes/ dangling
accessories.
Remove them.
People/animals inside. Deactivate the Interior movement
sensors (see chapter 1.5).
Defective door / bonnet / boot
switch.
Contact authorized retailer.

VSS1 15
Problem Possible causes Possible solutions
LED
Always ON Bonnet is open. Check that bonnet is correctly
closed.
System is in alarm state. Unlock.
You are in programming mode. IG OFF ON or wait 30 sec.
Any door is opened in passive arm
state (entry delay time).
Unlockbyremote,orIGON.
Always OFF System problem. Check No arming.
30 seconds ON System is still in pre-arm phase. Wait 30 sec to enter arm state.
Blinking fast Intrusion sensors excluded. Lock and unlock the car to
deactivate.
Blinking slow Alarm system is activated.
No arming
Fuse is broken. Check dome lamp fuse.
Siren is broken or disconnected. Contact authorized retailer.
Wire harness is damaged. Contact authorized retailer.

16 VSS1
Sehr geehrter Kunde,
Herzlichen Glückwunsch zum Kauf dieses Alarmsystems, das unter Verwendung der neuesten
Technologie für absolute Zuverlässigkeit gemäß den EU-Richtlinien nach den anspruchsvollsten
Automobilnormen konzipiert und produziert wurde.
Bitte lesen Sie diese Anleitung, damit Sie das System optimal nutzen können.
Wir empfehlen Ihnen, diese Anleitung im Fahrzeug aufzubewahren. So finden sie im Notfall die
benötigten Informationen leichter. Ihr Händler hilft Ihnen bei Fragen zum System oder seiner
Bedienung gerne weiter, wenn Sie die gesuchten Informationen nicht in dieser Anleitung oder im
Kapitel ‘Fehlerbehebung’ finden.
Informationen über Haftung sausschluss
– Sollte es zu Schäden durch Feuer, Handlungen Dritter oder sonstige Unfälle, durch
vorsätzlichen oder fahrlässigen Missbrauch durch den Benutzer, durch unsachgemäße
Benutzung oder Benutzung unter abnormen Bedingungen kommen, werden Reparaturen
des Produkts grundsätzlich dem Benutzer in Rechnung gestellt.
– Toyota Motor Europe NV/SA haftet nicht für Folgeschäden, die durch Benutzung oder
Nichtbenutzung dieses Produkts verursacht werden.
– Toyota Motor Europe NV/SA haftet nicht für Schäden oder Zwischenfälle, die durch
absichtliche Benutzung, versehentlichen Missbrauch oder Benutzung des Gerätes durch
Dritte verursacht werden.
– Das Alarmsystem kann einen Diebstahl des Fahrzeugs nicht verhindern.

VSS1 17
Inhalt
Informationen über Haftungsausschluss ................................................................................... 16
Einleitung ................................................................................................................................ 18
1. Aktivieren/Deaktivieren ...................................................................................................... 19
1.1 AKTIVIEREN des Alarmsystems ..................................................................................... 19
1.2 DEAKTIVIEREN des Alarmsystems ................................................................................. 20
1.3 Kofferraum öffnen ...................................................................................................... 20
1.4 Sirenenton abstellen ................................................................................................... 20
1.5 Aktivieren ohne Einbruchsensor .................................................................................. 21
1.6 Automatische Reaktivierung ....................................................................................... 22
1.7 Alarmstatusleuchte (LED) ........................................................................................... 22
2. Merkmale .......................................................................................................................... 23
2.1 Warnung bei offener Tür ............................................................................................ 23
2.2 Alarmumgehung ........................................................................................................ 23
2.3 Automatische Türverriegelung ................................................................................... 23
2.4 Passive Aktivierung ..................................................................................................... 24
2.5 Alarmspeicher ............................................................................................................ 24
2.6 Alarm mit Ton des (werkseitig verbauten) Signalhorns ................................................ 25
2.7 Werkstattmodus ......................................................................................................... 25
2.8 Aktivieren des Buzzers (interner Lautsprecher) ............................................................ 25
2.9 Installationsprüfmodus ............................................................................................... 25
3. Technische Daten .............................................................................................................. 26
4. Fehlerbehebung ................................................................................................................ 27

18 VSS1
Einleitung
Dieses Alarmsystem wird mit der Original-Hochsicherheitsfernbedienung oder dem in der
Betriebsanleitung des Fahrzeugs beschriebenen Smart Key bedient. Zwecks Programmierung
zusätzlicher Fernbedienungen wenden Sie sich bitte an Ihren autorisierten Händler.
Das Alarmsystem lässt sich nur mit der Original-Fernbedienung aktivieren und deaktivieren. Der
Schutz Ihres Fahrzeugs wird durch Bewegungssensoren im Innenraum, sowie durch Außensensoren
gewährleistet. Das Alarmsystem ist gegen Eingriffe gesichert.
Im Falle eines Alarms werden die Alarmsirene, das Signalhorn des Fahrzeugs (sofern für Ihr
Fahrzeug zutreffend), die Blinker und die Innenbeleuchtung aktiviert.
Produktfunktionen
Das Alarmsystem führt folgende Funktionen aus:
• Außenschutz (Türen, Kofferraumklappe und Motorhaube).
• Schutz des Innenraums und der Fenster (durch Bewegungssensoren im Innenraum).
• Schutz des Alarmsystems vor Manipulation.
• Schutz vor unbefugtem Starten des Motors.
• Alarmanlage mit eigener Stromversorgung.
• Akustische und optische Alarmierung.
• Alarmsystemstatus- und Diagnoseanzeigeleuchte (LED).
• Zusätzliche Schutzfunktionen können hinzugefügt werden (Hubmonitor-Modul).
Alarmfunktion
Der Alarm wird in folgenden Situationen aktiviert:
• Eine verriegelte Tür oder Haube wird auf andere Weise geöffnet, als mit dem Smart Key
oder der Original-Fernbedienung.
• Die Motorhaube wird geöffnet, während das Fahrzeug verriegelt ist.
• Der Einbruchsensor wird aktiviert: Wenn der Sensor eine Bewegung innerhalb des
Fahrzeugs erkennt oder wenn ein Fenster eingeschlagen wird.
• Der Batterieanschluss wird abgeklemmt, während das Alarmsystem aktiviert ist.
Bemerkungen
Der Einbruchsensor kann auf folgende Weise ausgelöst werden:
• Schaukelnde Gegenstände im Innenraum.
• Waschen des Fahrzeugs in Waschanlagen oder mit Hochdruckreiniger.
• Einwirkung von Hagel, Blitzschlag oder anderen starken äußeren Einwirkungen und
permanenten Vibrationen.
• Offene Fenster oder offenes Schiebedach.
Der Einbruchsensor kann auf die in Abschnitt 1.5 beschriebene Weise deaktiviert werden.

VSS1 19
1. Aktivieren/Deaktivieren
Das Alarmsystem wird aktiviert, sobald Sie das Fahrzeug verriegeln und deaktiviert, wenn Sie es
entriegeln.
1.1 AKTIVIEREN des Alarmsystems
Wichtig:
Um Fehlalarme zu vermeiden sollten Sie sich vergewissern, dass sich niemand im Fahrzeug befindet
und dass alle Fenster und Schiebedächer geschlossen sind, bevor Sie das Fahrzeug verriegeln
(Deaktivierung des Einbruchsensors siehe Abschnitt 1.5).
Aktion Anzeige der
Warnblinkanlage
Alarmstatusleuchte (LED)
Fernbedienung: Verriegelungs-
taste einmal drücken.
Blinkt einmal. An für 30 Sekunden, beginnt
dann zu blinken.
Smart Key: Verriegelungstaste
einmal drücken oder Türgriff-
Verriegelungstaste drücken.
Blinkt einmal. An für 30 Sekunden, beginnt
dann zu blinken.
HINWEIS:
– Die LED im Fahrzeug blinkt, um anzuzeigen, dass die Wegfahrsperre aktiviert wurde (dies hat
nichts mit dem Alarmsystem zu tun).
– Wenn innerhalb von 30 Sekunden eine Tür, die Kofferraumklappe und/oder Motorhaube
geöffnet wird, wird das System deaktiviert.
– Wenn irgendeine Tür nicht richtig verschlossen ist, ertönt ein Piepen (da das Fahrzeug nicht
verriegelt ist und der Alarm nicht aktiviert wird). (Gilt nicht für alle Fahrzeugmodelle.)
– Das System wird 30 Sekunden nach Betätigung der Verriegelungstaste aktiviert
(Voraktivierungszeit).
Kofferraum
öffnen
VERRIEGELN
(Aktivieren)
ENTRIEGELN
(Deaktivieren)
VERRIEGELN
(Aktivieren)
ENTRIEGELN
(Deaktivieren)
