TP-Link RE455 User manual

©2020 TP-Link
7106508585 REV1.1.0
Plug the extender into a power outlet next to your router. Wait until its
POWER LED turns solid on.
Power On
Set Up
2
Method 3: Via the WPS Button
1. Press the WPS button on your router.
The WPS button might
look like one of these:
3. Launch the Tether app, and select your extender.
Create a password to log in.
Quick Installation Guide
Range Extender
RE455
2. Launch a web browser, and enter
http://tplinkrepeater.net or http://192.168.0.254
in the address bar. Create a password to log in.
Note: If the login window does not appear, refer to FAQ > Q1.
http://tplinkrepeater.net
Start
Conrm Password
Create Password
Low Middle High
My Devices
Local Device
RE455
XX-XX-XX-X X-X X-XX
1
Next to
Solid On
Enjoy!
Connect your devices to the extender wirelessly or via an Ethernet cable, then
enjoy the internet.
Tip: You can also set up the extender in Access Point mode to transform your existing wired network
to a wireless one. For details, refer to the user guide at https://www.tp-link.com/support.
Laptop
Smartphone
Tablet
Smart TV
Game Console
Desktop
Solid On
4. Follow app instructions to complete the setup.
The LED should turn solid on, indicating
successful connection to your router.
Note: If the LED does not turn solid on, refer to FAQ > Q2.
Solid On
3. Follow web instructions to complete the setup.
The LED should turn solid on, indicating
successful connection to your router.
Note: If the LED does not turn solid on, refer to FAQ > Q2.
Relocate
3
1. Plug in the extender about halfway between your router and the Wi-Fi dead
zone. The location you choose must be within the range of your router.
2. Wait for about 2 minutes until the LED turns solid blue. If it doesn't, relocate
the extender closer to the router to achieve better signal quality.
Router Devices
Halfway
Tip: For more intuitive location assistance, access extender settings via the Tether app and go to Tools > Location Assistant.
Blue: Suitable location
Red: Too far from router
Note: If the LED does not turn solid on, try again or use Method 1
or 2.
2. Within 2 minutes, press the WPS button on the
extender for 1 second. The LED should change
from blinking to solid on, indicating successful
connection.
Blinking
Solid On
3. If the extender connects to a dual band router but
only the 2.4GHz or 5GHz LED is on, repeat steps 1
and 2 above to connect to the other band.
Extended Network Names:
Same as your router
Passwords:
Same as your router
Note: If you want to change the extended network
names, refer to Manage the Extender on the back page.
Solid On
Setup with videos
Scan QR code or visit
https://www.tp-link.com/download/RE455.html
Set up your extender via any of the methods below.
Method 2: Via a Web Browser
1. Connect your computer or smartphone to the
extender’s network. If you are using a computer,
unplug the Ethernet cable if any.
Note: If you can not find the extender’s network, follow FAQ > Q3
to reset the extender.
TP-Link_Extender_2.4GHz
TP-Link_Extender_5GHz
Method 1: Via the Tether App
1. Get the up-to-date Tether app.
2. Connect your smartphone to the extender’s
network.
Note: If you can not find the extender’s network, follow FAQ > Q3
to reset the extender.
TP-Link_Extender_2.4GHz
TP-Link_Extender_5GHz
Scan for Tether Tether
or

Method 2: Via a Web Browser
Method 1: Via the Tether App
1. Connect your computer or smartphone to the extender’s network . If you are
using a computer, unplug the Ethernet cable if any.
2. Launch a web browser, enter http://tplinkrepeater.net in the address bar, and
log in.
Note: If the login window does not appear, refer to FAQ > Q1.
3. Manage the extender as needed.
1. Connect your smartphone to the extender‘s or router’s network.
2. Launch the Tether app, select your extender, and log in.
3. Manage the extender as needed.
Manage the Extender LED Explanation
LED Status Indication (For Range Extender Mode)
The extender is connected or not connected to the 5GHz
wireless network of your router.
5GHz On/O
The extender is connected or not connected to the 2.4GHz
wireless network of your router.
2.4GHz On/O
The extender is on or o.
The system is starting up or rmware upgrade is in progress.
POWER
On/O
Blinking
The extender is connected to your router’s wireless
network and is in a suitable location.
The extender is receiving a weak signal. Try relocating it
closer to your router.
WPS connection is in progress.
No wireless connection is established.
(Signal)
Solid blue
Solid red
Blinking
O
Q1. What should I do if I cannot access the extender’s web
management page?
Make sure your computer or smartphone has connected to the extender’s
network, and not that of your router. If your router and extender share the same
network name, connect your computer to the extender via an Ethernet cable, or
use the Tether app.
If you are using a computer, make sure it is set to obtain an IP address and DNS
server address automatically.
Verify that http://tplinkrepeater.net or http://192.168.0.254 is correctly entered
in the web browser and press Enter. Note that http://192.168.0.254 applies only
for extenders with factory default settings.
Use another web browser and try again.
Reboot or reset the extender and try again.
If you are still having problems, contact our technical support.
Q2. What should I do if the LED doesn’t turn solid on after
completing setup via the Tether app or web browser?
You may have entered incorrect Wi-Fi passwords for your host networks during
the conguration. Check the passwords and try again.
Make sure the extender is close to your router, preferably within 16 feet, and
away from large electrical appliances.
If you have enabled wireless MAC ltering, wireless access control, or access
control list (ACL) on your router, disable them rst, then follow any method on the
front page to complete the conguration.
Try setting up via the WPS button.
Reset the extender and go through the conguration again.
If you are still having problems, contact our technical support.
Q3. How do I reset the extender?
With the extender powered on, use a pin to press the Reset button for 1 second.
The extender will reboot.
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device.
Do not use the device where wireless devices are not allowed.
The socket-outlet shall be installed near the equipment and shall be easily accessible.
Please read and follow the above safety information when operating the device. We cannot
guarantee that no accidents or damage will occur due to improper use of the device.
Please use this product with care and operate at your own risk.
TP-Link hereby declares that the device is in compliance with the essential requirements
and other relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011/65/EU and
(EU) 2015/863. The original EU declaration of conformity may be found at
https://www.tp-link.com/en/ce.
Reset
For technical support, the user guide and other information, please
visit https://www.tp-link.com/support, or simply scan the QR code.
If you have any suggestions or needs on the product guides, welcome to email
[e-mail].
To ask questions, find answers, and communicate with TP-Link users or engineers,
please visit https://community.tp-link.com to join TP-Link Community.
Tether
http://tplinkrepeater.net
http://tplinkrepeater.net
Note: If your extender and router use the same network name, Method 1 is recommended.
After setup, you can manage the extender via any of the methods below. You
can reselect host network, change extended network settings and more.
POWER
Signal
2.4GHz
5GHz
Button Explanation
LED button: Press for 1 second to turn on or turn o all LEDs.
Power button: Press for 1 second to turn on or turn o the extender.
