TP-Link RE815XE User manual

©2022 TP-Link
7106509576 REV1.0.0
Plug the extender into a power outlet next to your router. Wait until
its Power LED turns solid on.
Note: For safety, only plug the extender in the direction as shown below.
Power On
Quick Installation Guide
Range Extender
1
Next to
Relocate
3
Set Up
1. Plug in the extender about halfway between your router and the Wi-Fi dead
zone. The location you choose must be within the range of your router.
2. Wait for about 2 minutes until the LED turns solid blue. If it doesn't,
relocate the extender closer to the router to achieve better signal quality.
Enjoy!
Connect your devices to the extender wirelessly or via an Ethernet cable,
then enjoy the internet. The passwords of your extended networks are
the same as your host router.
Tip: You can also set up the extender in Access Point mode to transform your existing wired
network to a wireless one. For details, refer to the user guide at https://www.tp-link.com/support.
Router Devices
Halfway
Blue: Suitable location
Red: Too far from router
Via the Tether App
1. Get the up-to-date Tether app from the
Apple App Store or Google Play, or simply
scan the QR code.
Note: If the LED does not turn solid on, please
refer to FAQ > Q2.
2. Launch the Tether app and log in with your
TP-Link ID. If you don’t have an account,
create one first.
Welcome to Tether
Log In
TP-Link ID (Email)
Sign Up Forgot Password?
Password
3. Tap the button and select Range Extender.
Tether
Scan for Tether
or
Note: If you cannot find your device, please refer to
FAQ > Q1.
For more details, please refer to the user guide at
https://www.tp-link.com/support/download.
More Setup Methods
1. Connect your computer or smartphone to
the extender’s network TP-Link_Extender.
2. Visit http://www.tplinkrepeater.net or
http://192.168.0.254 in a web browser.
Create a password to log in.
3. Follow web instructions to complete the setup.
Via a Web Browser
Extended Network Names:
Router’s network name with
EXT at the end
or
Same as your OneMesh router
(See back for OneMesh details)
Passwords:
Same as your router
2
4. Follow app instructions to complete the setup.
The LED should turn solid on, indicating
successful connection to your router.
2. Within 2 minutes, press the WPS button on the
extender for 1 second. The LED should
change from blinking to solid on, indicating
successful connection.
1. Press the WPS button on your router.
Via the WPS Button
Note: WPA3 required for 6 GHz bands does not allow WPS
connection. To connect to a router’s 6 GHz band, please
connect via the Tether app or web browser.
Setup with videos
Scan the QR code, or visit
https://www.tp-link.com/support/setup-video/#range-extenders
and search for the setup video of your model.
Solid On
Solid On
* Images may differ from your actual product.
Tip: To place the extender for optimal Wi-Fi performance, access extender settings
via the Tether app and go to Tools >Location Assistant, or simply scan the QR code
to visit https://www.tp-link.com/support/faq/3103/.
My Devices
No devices found.
Choose Your Device Type
Wireless Router
Gaming Router
Range Extender
Laptop
Smartphone
Tablet
Smart TV
Game Console
Desktop

TP-Link OneMesh router and extenders work together to form one unied Wi-Fi
network. Walk through your home and stay connected with the fastest possible
speeds thanks to OneMesh’s seamless coverage.
OneMeshTM with Seamless Roaming
Seamless Roaming
Devices automatically switch between your router and extenders as you move through your
home for the fastest possible speeds.
Unied Wi-Fi Network
Router and extenders share the same wireless settings, including network name, password,
access control settings and more.
Easy Setup and Management
Set up a OneMesh network with a push of WPS buttons. Manage all network devices on the
Tether app or at your router’s web management page.
To check full list of TP-Link OneMesh devices, scan the QR code,
or visit https://www.tp-link.com/onemesh/compatibility.
LED Explanation
LED Status Indication (For Range Extender Mode)
The extender is connected or not connected to the 5 GHz
wireless network of your router.
The extender is connected or not connected to the 6 GHz
wireless network of your router.
6 GHz
On/O
5 GHz
On/O
The extender is connected or not connected to the 2.4 GHz
wireless network of your router.
2.4 GHz
On/O
The extender is on or o.
The system is starting up or rmware upgrade is in progress.
On/O
Blinking
The extender is connected to your router’s wireless
network and is in a suitable location.
The extender is receiving a weak signal. Try relocating it
closer to your router.
WPS connection is in progress.
No wireless connection is established.
Solid blue
Solid red
Blinking
O
(Power)
(Signal)
INTERNET
SAME
Network Name & Password
for seamless roaming
Method 2: Via a Web Browser
1. Connect your computer or smartphone to the extender’s network . If you are
using a computer, unplug the Ethernet cable if any.
2. Launch a web browser, enter http://www.tplinkrepeater.net in the address
bar, and log in.
3. View or change extender settings as needed.
Method 1: Via the Tether App
1. Connect your smartphone to the extender‘s or router’s network.
2. Launch the Tether app, select your extender, and log in.
3. View or change extender settings as needed.
Access Extender Settings
After setup, you can access extender settings via any of the methods below.
You can reselect host network, change extended network settings and more.
Note: If your extender and router use the same network name, Method 1 is recommended.
Wi-Fi
Wi-Fi
TP-Link_Extender
CHOOSE A NETWORK...
Other...
< Settings
My Devices
Local Device
RExxx
XX-XX-XX-X X-X X-X X
Q1. What should I do if the Tether app cannot nd my device during
setup?
Try another method by following the steps below:
1. Connect your smartphone to the extender’s network TP-Link_Extender.
2. Launch the Tether app, and select your extender.
3. Follow app instructions to complete the setup.
If you are still having problems, contact our technical support.
Q2. What should I do if the LED doesn’t turn solid on after
completing setup via the Tether app or web browser?
You may have entered incorrect Wi-Fi password for your host router during the
conguration. Check the password and try again.
Make sure the extender is close to your router, preferably within 16 feet, and away
from large electrical appliances.
If you have enabled wireless MAC ltering, wireless access control, or access
control list (ACL) on your router, disable them rst, then follow any method on the
front page to complete the conguration.
Try setting it up via the WPS button.
Reset the extender and go through the conguration again.
If you are still having problems, contact our technical support.
Q3. How do I reset the extender?
With the extender powered on, use a pin to press the Reset button for 1 second.
The extender will reboot.
For technical support, replacement services, user manuals and other information,
please visit https://www.tp-link.com/support, or simply scan the QR code.
If you have any suggestions or needs for our product guides, you are welcome to
email [e-mail].
To communicate with TP-Link users or engineers, please join the TP-Link Community
at https://community.tp-link.com.
Reset
Tip: If you have connected to the extender’s Wi-Fi but still cannot nd your device, try turning o
your cellular data.
Safety Information
• Keep the device away from water, re, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
• Do not use the device where wireless devices are not allowed.
• The socket-outlet shall be installed near the equipment and shall be easily accessible.
This device is restricted to indoor use only.
The operation of this device is prohibited on oil platforms, cars, trans, boats, and aircraft, except that
operation of this device is permitted in large aircraft while ying above 10000 feet. Operation of
transmitters in the 5.925-7.125 GHz band is prohibited for control of or communications with unmanned
aircraft systems.
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of directives 2014/53/EU, 2009/125/EC, 2011 /65/EU and (EU) 2015/863.
The original EU Declaration of Conformity may be found at https://www.tp-link.com/en/support/ce
TP-Link hereby declares that the device is in compliance with the essential requirements and other
relevant provisions of the Radio Equipment Regulations 2017.
The original UK Declaration of Conformity may be found at https://www.tp-link.com/support/ukca
If you need more setup help, please visit
https://www.tp-link.com/support/faq/3074/, or simply scan the QR code.
AXE5400 Tri-Band Wi-Fi 6E Range Extender Model: RE815XE
