TP-Link Archer A20 User manual

AC4000
MU-MIMO Tri-Band
Wi-Fi Router
Superior Processing Power
Ultimate Tri-Band Performance
1625 Mbps + 1625 Mbps
+ 750 Mbps Tri-Band MU-MIMO RangeBoost
1.8 GHz
64-bit CPU
Airtime
Fairness

The powerful 1.8 GHz 64-bit CPU, three co-processors and 512 MB of RAM
work together to power your network.
Powerful 1.8 GHz 64-bit CPU
1.8 GHz 64-bit CPU
Co-Processors
With one 2.4 GHz and two 5 GHz bands, the Archer A20 keeps all your devices
connected without slowing down your network. Now, you can game and
stream in 4K on multiple devices at the same time.
TP-Link AC4000 MU-MIMO Tri-Band Wi-Fi Router A20
Tri-Band for Multiple Connections
Highlights
Regular Router
Tri-Band
Tri-Band
Archer A20
Regular Router
750 Mbps 2.4 GHz
1625 Mbps 5 GHz-1
1625 Mbps 5 GHz-2
450 Mbps 2.4 GHz

Highlights
RangeBoost greatly improves the ability of the router to detect devices that are
further away or low-powered while Beamforming boosts wireless signal strength
toward them, giving your network even greater coverage.
Far-Reaching Wi-Fi Coverage
TP-Link AC4000 MU-MIMO Tri-Band Wi-Fi Router A20
MU-MIMO technology serves up to multiple devices at once, reducing wait
time, increasing Wi-Fi throughput for every device and making each stream
more ecient.
MU-MIMO for Multiple Connections
MU-MIMO Router
Simultaneously sends data to multiple devices
Traditional Router
Sends data to one device at a time

Highlights
TP-Link AC4000 MU-MIMO Tri-Band Wi-Fi Router A20
Airtime Fairness
Equally divides attention between new devices like your gaming rig and older
devices to improve Wi-Fi performance and reliability without limiting your
network.
Time
Time
The slower clients take up too much time
Time is fairly delivered to clients
Normal
Airtime
Fairness
Smart Connect for Ecient Performance
5G
2.4G
Intelligently selects the best available Wi-Fi band for each device to keep
connection at top-speed—without worry of weak or dropped connections.

Highlights
Create a customized and more secure Wi-Fi network with TP-Link HomeCareTM .
Antivirus, Parental Controls and QoS powered by Trend Micro® give you the
tools you need to fully manage your network.
HomeCare™ for the Most Comprehensive Home
Wi-Fi Security
Antivirus protects your devices
from viruses and malware.
Powerful Parental Controls keep
your family safe while online.
Quality of Service prioritizes devices
and applications for a faster network.
TP-Link AC4000 MU-MIMO Tri-Band Wi-Fi Router A20
Link aggregation accelerates data transfer to network-attached storage (NAS)
devices by combining two separate Ethernet ports into a 2 Gbps connection.
High-Speed Transmission Powered by
Link Aggregation
Traditional Router NAS
1 Gbps
Archer A20 NAS
2 Gbps
Link Aggregation

· Ultimate Wireless Speed – Wireless speeds up to 1625 Mbps
on 5 GHz-1, 1625 Mbps on 5 GHz-2, and 750 Mbps on 2.4 GHz
· NitroQAM Technology – Uses NitroQAM (1024- QAM)
modulation scheme for higher data throughput, boosting
wireless speeds by up to 25%
· MU-MIMO Technology – Simultaneously exchanges data with
several devices, achieving speeds which are 3x faster than
standard AC routers
· Support 802.11 ac – Provides a data transfer rate 3 times faster
than 802.11n for each stream
· 1.8 GHz CPU – 1.8 GHz 64-bit CPU and 3 co-processors make
multi-tasking easy and boost data transfer rate
· Ultimate Range Wi-Fi – 6 high-performance antennas with a
high-powered amplier ensure the widespread Wi-Fi coverage
and a stable connection
· Wi-Fi with Beamforming – Beamforming technology locates the
connected devices and further improves the Archer A20’s range
and the signal strength to each mobile device, delivering a more
reliable and ecient wireless connection
Speed Wi-Fi Range Reliability
· Simultaneous Triple Band – Separate Wi-Fi bands enable more
devices to connect to your network without a drop in
performance
· Easy Bandwidth Management – Advanced QoS makes it easier
for you to manage the bandwidth of connected devices
· Smart Connect Technology – Smart Connect technology
automatically selects the best Wi-Fi band for each device
· Airtime Fairness Technology – Airtime Fairness optimizes the
time usage to improve overall Wi-Fi performance
Features
TP-Link AC4000 MU-MIMO Tri-Band Wi-Fi Router A20

· Intuitive Web UI – Ensures quick and simple Installation without
hassle
· Fast Encryption – One-touch WPA wireless security encryption
with the WPS button
· Easy On/O – Turn on/o wireless radio and LEDs separately
using the Wi-Fi On/O and LED On/O buttons
· Power On/O – Conveniently power on or o your router as
required
· Hassle-free Management with Tether App – Network
management is made easy with the TP-Link Tether App,
available on any Android and iOS device
· Guest Network – Keep your main network secure by creating a
separate network for friends and visitors
· Access Control – Establish a whitelist or blacklist to allow or
restrict certain devices to access the Internet
· Homecare™ – Provides a kit of dynamic - Parental Controls, QoS
and Antivirus - to ensure safety, speed and security for everyone
in your network
· VPN Server – PPTP VPN and OpenVPN are supported, making it
easy to set up a secure connection between your private
network and the Internet
· Encryptions for Secure Network – WPA-PSK and WPA2-PSK
encryptions provide active protection against security threats
Ease of Use Security
· Dual USB Ports for Fast Sharing – With one ultra-fast USB 3.0
port and one USB 2.0 port, you can access and share your les
and media locally. Through the router's FTP server, you can also
access your les and media from network devices remotely
· 10x Faster Transfer Speed – The USB 3.0 port provides up to
10x faster USB hard drive access than previous generation USB
2.0 connections
· Built-in Media Server – Allows you to play music, watch videos
and view photos from any device on your network
Easy Sharing
Features
TP-Link AC4000 MU-MIMO Tri-Band Wi-Fi Router A20

Hardware
· Ethernet Ports: 4 10/100/1000 Mbps LAN Ports, 1 10/100/1000 Mbps WAN Port
· USB Ports: 1 USB 3.0 Port, 1 USB 2.0 Port
· Buttons: Wireless On/O Button, LED On/O Button, Power On/O Button, WPS
Button, Reset Button
· Antennas: 6 High Performance Antennas
· External Power Supply: 12V/4A
· Dimensions (W x D x H): 7.9×7.9×1.5 in. (200×200×39 mm)
Wireless
· Wireless Standards: IEEE802.11b/g/n (support QAM1024) 2.4 GHz, IEEE 802.11ac/n/a
5 GHz
· Frequency: 2.4 GHz and 5 GHz
· Signal Rate: 1625 Mbps at 5 GHz-1, 1625 Mbps at 5 GHz-2, 750 Mbps at 2.4 GHz
· CE EIRP: <20 dBm (2.4 GHz), <23 dBm (5 GHz)
· FCC Transmit Power: <30 dBm (2.4 GHz & 5 GHz)
· Reception Sensitivity:
5 GHz:
11a 6 Mbps: -95 dBm, 11a 54 Mbps: -75 dBm
11ac VHT20(MCS0): -95 dBm, 11ac VHT20(MCS11): -63 dBm
11n HT40(MCS0): -92 dBm, 11ac HT40(MCS7): -73 dBm
11ac VHT80(MCS0): -89 dBm, 11ac VHT80(MCS11): -58 dBm
2.4 GHz:
11g 54Mbps: -78 dBm
11n HT20(MCS0): -96 dBm, 11ac VHT20(MCS11): -65 dBm
11n HT40(MCS0): -93 dBm, 11ac VHT40(MCS11): -63 dBm
· Wireless Function: Enable/Disable Wireless Radio, WMM
· Wireless Security: 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA-PSK2 encryptions
Specications
Gigabit
Ethernet
USB 2.0USB 3.0 Power
On/Off
Reset Power
TP-Link AC4000 MU-MIMO Tri-Band Wi-Fi Router A20

Specications
· Certication:
CE, FCC, RoHS
· System Requirements:
Microsoft Windows 98SE/NT/2000/XP/Vista™/7/8/8.1/10, MAC OS,
NetWare, UNIX or Linux
Internet Explorer 11, Firefox 12.0, Chrome 20.0, Safari 4.0, or other
Java-enabled browser
Cable or DSL Modem
Subscription with an Internet Service Provider (for internet access)
· Environment:
Operating Temperature: 0℃~40℃(32℉~104℉)
Storage Temperature: -40℃~70℃(-40℉~158℉)
Operating Humidity: 10%~90% non-condensing
Storage Humidity: 5%~90% non-condensing
· Package Contents
Wireless Router Archer A20
Power Adapter
RJ45 Ethernet Cable
Quick Installation Guide
OthersSoftware
· Quality of Service: WMM
· WAN Type: Dynamic IP, Static IP, PPPoE, PPTP(Dual Access), L2TP(Dual Access),
Bigpond
· Management: Access Control, Local Management, Remote Management
· DHCP: Server, DHCP Client List, Address Reservation
· Port Forwarding: Virtual Server, Port Triggering, UPnP, DMZ
· Dynamic DNS: TP-Link, NO-IP, DynDns
· VPN Server: PPTP, Open VPN
· Access Control: Local Management Control, Host list, Rule Management
· Homecare™: Parental Controls, QoS and Antivirus
· Firewall Security: SPI Firewall, IP and MAC Address Binding
· Protocols: IPv4, IPv6
· USB Sharing: Supports Samba(Storage), FTP Server, Media Server
· Guest Network: 2.4 GHz Guest Network x 1, 5 GHz Guest Network x 2
Attention: This device may only be used indoors in all EU member states and EFTA countries.
Specications are subject to change without notice. TP-Link is a registered trademark of TP-Link Technologies Co., Ltd. Other brands and product names are trademarks or registered trademarks of their respective holders. Copyright ©2019 TP-Link Technologies Co., Ltd. All rights reserved.
* Maximum wireless transmission rates are the physical rates derived from IEEE Standard 802.11 specications. Range and coverage specications are based on test results under normal usage conditions. Actual wireless transmission rate and wireless coverage are not guaranteed, and will vary as a result of
1) environmental factors, including building materials, physical objects and obstacles, 2) network conditions, including local interference, volume and density of trac, product location, network complexity, and network overhead and 3) client limitations, including rated performance, location, connection quality,
and client condition.
*Use of MU-MIMO requires clients to also support MU-MIMO.
