TP-Link Jetstream Series User manual

Business Networking Solution
Installation Guide
Jetstream Smart Switch

About this Installation Guide
This Installation Guide describes the hardware characteristics, installation methods and the
points that should be attended to during the installation. This Installation Guide is structured as
follows:
Chapter 1 Introduction
This chapter describes the external components of the switch.
Chapter 2 Installation
This chapter illustrates how to install the switch.
Chapter 3 Connection
This chapter illustrates how to do the physical connection of the switch.
Appendix A Troubleshooting
Appendix B Hardware Specifications
Audience
This Installation Guide is for:
Network Engineer Network Administrator
Conventions
• Some models featured in this guide may be unavailable in your country or region. For local sales
information, visit https://www.tp-link.com.
• The figures in Chapter 2 and Chapter 3 are for demonstration purposes only. Your switch may
differ in appearance from that depicted.
• PoE budget calculations are based on laboratory testing. Actual PoE power budget is not
guaranteed and will vary as a result of client limitations and environmental factors.
• This guide uses the specific formats to highlight special messages. The following table lists the
notice icons that are used throughout this guide.
Remind to be careful. A caution indicates a potential which may result in device damage.
Remind to take notice. The note contains the helpful information for a better use of the
product.
Related Document
The User Guide and CLI Reference Guide of the product are provided on the resource CD. To
obtain the latest product information, visit the official website: https://www.tp-link.com

Contents
Chapter 1 Introduction ——————————— 01
1.1 Product Overview ...........................................................01
1.2 Appearance.......................................................................01
Chapter 2 Installation ——————————— 08
2.1 Package Contents ..........................................................08
2.2 Safety Precautions .........................................................08
2.3 Installation Tools..............................................................10
2.4 Product Installation ........................................................10
Chapter 3 Connection ——————————— 12
3.1 Ethernet Port ....................................................................12
3.2 SFP/SFP+ Port..................................................................12
3.3 Verify Installation.............................................................12
3.4 Power On............................................................................13
3.5 Initialization........................................................................13
3.6 Accessing the Switch....................................................13
Appendix A Troubleshooting ———————— 14
Appendix B Specications ————————— 15

JetStream Smart Switch
01Introduction
Chapter 1 Introduction
1.1 Product Overview
Designed for workgroups and departments, TP-Link JetStream Smart Switch provides wire-speed
performance and abundant L2 management features. It provides a variety of service features and
multiple powerful functions with high security.
The EIA-standardized framework and smart configuration capacity can provide flexible solutions for
a variable scale of networks. QoS and IGMP snooping/filtering optimize voice and video application.
Link aggregation increases aggregated bandwidth, optimizing the transport of business critical
data. SNMP, RMON, WEB and CLI Login bring abundant management policies. TP-Link Gigabit Smart
Switch integrates multiple functions with excellent performance, and is friendly to manage, which
can fully meet the need of the users demanding higher networking performance.
T1500-28PCT/T1600G-52PS (TL-SG2452P)/TL-SG2210MP/TL-SG2428P is also a Power Sourcing
Equipment (PSE*). Some of the RJ45 ports on the switch support Power over Ethernet (PoE*)
function, which can automatically detect and supply power to those powered devices (PDs*)
complying with IEEE 802.3af and IEEE 802.3at.
*PSE: a device (switch or hub for instance) that provides power through an Ethernet cable.
*PoE: a technology describes a system to transmit electrical power, along with data, to remote
devices over standard twisted-pair cable in an Ethernet.
*PD: a device powered by a PSE and thus consumes energy. Examples include powering network
cameras, wireless LAN access points, IP telephones, network hubs, embedded computers etc.
1.2 Appearance
■Front Panel
The front panel of T1500-28TC (TL-SL2428) is shown as the following figure.
Figure 1-1 Front Panel of T1500-28TC (TL-SL2428)
LEDs Reset SFP Port10/100 Mbps RJ45
Port
10/100/1000 Mbps
RJ45 Port
The front panel of T1500-28PCT (TL-SL2428P) is shown as the following figure.
Figure 1-2 Front Panel of T1500-28PCT (TL-SL2428P)
LEDs Reset SFP Port10/100/1000 Mbps
RJ45 Port
10/100 Mbps RJ45
Port and PoE Port
LED Mode
Switch Button

JetStream Smart Switch
02 Introduction
The front panel of T1600G-18TS (TL-SG2216) is shown as the following figure.
Figure 1-3 Front Panel of T1600G-18TS (TL-SG2216)
LEDs Reset 10/100/1000 Mbps RJ45 Port SFP Port
The front panel of T1600G-28TS is shown as the following figure.
Figure 1-4 Front Panel of T1600G-28TS
10/100/1000 Mbps RJ45 PortLEDs Reset SFP Port
The front panel of T1600G-52TS (TL-SG2452) is shown as the following figure.
Figure 1-5 Front Panel of T1600G-52TS (TL-SG2452)
Reset
PWR
SYS
T1600G-52TS
Smart Switch
F
Reset LEDs 10/100/1000 Mbps RJ45 Port SFP Port
The front panel of T1600G-52PS (TL-SG2452P) is shown as the following figure.
Figure 1-6 Front Panel of T1600G-52PS (TL-SG2452P)
Reset
Speed
PWR
SYS
PoEMax
FAN
PoE
PoE
DeliveringPower Over Budget Fault
Speed
activity1000Mbps 10/100Mbps
T1600G-52PS
Smart PoE Switch
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50 51 52
F
Reset LED Mode Switch
Button
LEDs 10/100/1000 Mbps RJ45 Port SFP Port
The front panel of T1700G-28TQ is shown as the following figure.
Figure 1-7 Front Panel of T1700G-28TQ
LEDs Unit ID LED Reset 10/100/1000 Mbps RJ45 Port SFP+ Port

JetStream Smart Switch
03Introduction
The front panel of T1700X-16TS is shown as the following figure.
Figure 1-8 Front Panel of T1700X-16TS
ResetLEDs 100 M/1000 M/10 Gbps
RJ45 Port
1 G/10 Gbps SFP+ PortLEDs Indication
The front panel of TL-SG2210MP is shown as the following figure.
Figure 1-9 Front Panel of TL-SG2210MP
TL-SG2210MP
8-Port Gigabit Smart PoE+ Switch with 2 SFP Slots
LEDs LED Mode
Switch Button
Reset 10/100/1000 Mbps
RJ45 Port and PoE Port
SFP Port
The front panel of TL-SG2428P is shown as the following figure.
Figure 1-10 Front Panel of TL-SG2428P
TL-SG2428P
24-Port Gigabit Smart PoE+ Switch with 4 SFP Slots
LEDs Reset 10/100/1000 Mbps
RJ45 Port
SFP PortLED Mode
Switch Button
LEDs
For T1500-28TC (TL-SL2428)/T1600G-18TS (TL-SG2216)/T1600G-28TS/T1600G-52TS
(TG-SG2452)/T1700G-28TQ/T1700X-16TS
LED Indication
PWR
On: The switch is powered on.
Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal.
SYS Flashing: The switch works properly.
On or Off: The switch works improperly.
10/100M
Link/Act
On: A device is connected to the corresponding port but no activity.
Flashing: Data is being transmitted or received.
Off: No device is connected to the corresponding port.
Note: 10/100M for T1500-28TC. Link/Act for T1600G-18TS (TL-SG2216)/T1700G-28TQ.

JetStream Smart Switch
04 Introduction
LED Indication
1000Mbps
On: Running at 1000 Mbps.
Off: Running at 10/100 Mbps or no device is linked to the corresponding port.
Note: For T1600G-18TS (TL-SG2216)/1700G-28TQ.
1000M
10/100/1000Mbps
Green On: Running at 1000 Mbps, but no activity.
Green Flashing: Running at 1000 Mbps and is transmitting or receiving data.
Yellow On: Running at 10/100 Mbps, but no activity.
Yellow Flashing: Running at 10/100 Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: 1000M for T1500-28TC. 10/100/1000Mbps for port 1–24 of T1600G-28TS and
port 1–48 of T1600G-52TS (TL-SG2452).
100Base-FX
1000Base-X
Green On: A 1000 Mbps device is connected to the corresponding port but no
activity.
Green Flashing: A 1000 Mbps device is linked to the corresponding port and data is
being transmitted or received.
Yellow On: A 10/100 Mbps device is connected to the corresponding port but no
activity.
Yellow Flashing: A 10/100 Mbps device is linked to the corresponding port and is
transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: 1000Base-X for port 25–28 of T1600G-28TS. 100Base-FX/1000Base-X for
port 49–52 of T1600G-52TS (TL-SG2452).
Port 49–52 of T1600G-52TS (TL-SG2452) doesn't support 10 Mbps devices.
25–28
Link/Act
Green On: Running at 10 Gbps, but no activity.
Green Flashing: Running at 10 Gbps and is transmitting or receiving data.
Yellow On: Running at 1000 Mbps, but no activity.
Yellow Flashing: Running at 1000 Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: 25–28 for T1700G-28TQ. Link/Act for port 13–16 of T1700X-16TS.
Link/Act
Green On: Running at 10 Gbps, but no activity.
Green Flashing: Running at 10 Gbps and is transmitting or receiving data.
Yellow On: Running at 100/1000 Mbps, but no activity.
Yellow Flashing: Running at 100/1000 Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: Only for port 1–12 of T1700X-16TS.
Master
On: The switch works as master in the stack system, or does not join any stack
system.
Off: The switch works as stack member in the stack system.
Note: Only for T1700G-28TQ.
Fan
Green: All the fans work properly.
Yellow: Not all the fans work properly.
Off: The switch is working abnormally.
Note: Only for T1700X-16TS.

JetStream Smart Switch
05Introduction
T1500-28PCT (TL-SL2428P)/T1600G-52PS (TL-SG2452P)/TL-SG2210MP/TL-SG2428P has an LED
mode switch button which is used to switch the LED status indication. When the Speed LED is on, the
port LED is indicating the data transmission rate. When the PoE LED is on, the port LED is indicating
the power supply status. By default the Speed LED is on. Pressing the mode switch button, the
Speed LED will turn off and the PoE LED will light up. Then the PoE LED will turn off after being on for
60 seconds and the Speed LED will light up again.
LED Indication
PWR
On: The switch is powered on.
Off: The switch is powered off or power supply is abnormal.
Flashing: Power supply is abnormal.
SYS Flashing: The switch works properly.
On or Off: The switch works improperly.
FAN Green: All the fans work properly.
Yellow: Not all the fans work properly.
PoE Max
(When the PoE LED
is on)
On: The remaining PoE power is ≤ 7 W.
Flashing: The remaining PoE power keeps ≤ 7 W after this LED is on for 2 minutes.
Off: The remaining PoE power is > 7 W.
10/100M or PoE
(When the Speed
LED is on)
Green On: Running at 100 Mbps, but no activity.
Green Flashing: Running at 100 Mbps and is transmitting or receiving data.
Yellow On: Running at 10 Mbps, but no activity.
Yellow Flashing: Running at 10 Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: Only for T1500-28PCT.
1000M
Speed or PoE
(When the Speed
LED is on)
Green On: Running at 1000 Mbps, but no activity.
Green Flashing: Running at 1000 Mbps and is transmitting or receiving data.
Yellow On: Running at 10/100 Mbps, but no activity.
Yellow Flashing: Running at 10/100 Mbps and is transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note: 1000M for T1500-28PCT. Speed or PoE for TL-SG2210MP, port 1–24 of TL-
SG2428P and port 1–48 of T1600G-52PS (TL-SG2452P)
10/100M or PoE
Speed or PoE
(When the PoE LED
is on)
Green On: The port is supplying power normally.
Green Flashing: The supply power exceeds the correponding port's maximum power.
Yellow On: Overload or short circuit is detected.
Yellow Flashing: Power-on self-test failed.
Off: Not providing PoE power on the port.
Note: 10/100M or PoE for T1500-28PCT. Speed or PoE for TL-SG2210MP, port 1–24 of
TL-SG2428P and port 1–48 of T1600G-52PS (TL-SG2452P)

JetStream Smart Switch
06 Introduction
LED Indication
100Base-FX
1000Base-X
SFP1, SFP2
Green On: A 1000 Mbps device is linked to the corresponding port, but no activity.
Green Flashing: A 1000 Mbps device is linked to the corresponding port and data is
being transmitted or received.
Yellow On: A 10/100 Mbps device is linked to the corresponding port, but no activity.
Yellow Flashing: A 10/100 Mbps device is linked to the corresponding port and is
transmitting or receiving data.
Off: No device is linked to the corresponding port.
Note:
1000Base-X for port 25–28 of TL-SG2428P. 100Base-FX/1000Base-X for port
49–52 of T1600G-52PS (TL-SG2452P)
. SFP1/SFP2 for TL-SG2210MP.
100Base-FX and 1000Base-X ports don't support 10 Mbps device.
LED Mode Switch Button
Press this button to switch the LED status indication between Speed and PoE.
Reset
With the switch powered on, press Reset button for 5 seconds to reset the switch to its factory default
settings.
Unit ID LED
Designed to display the stack Unit ID of the switch. For the switch that does not join any stack system, it
displays its default Unit ID. To modify the default unit number, please log on to the GUI of the switch and
go to Stack→Stack Management→Stack Cong page and congure the New Unit ID. The new Unit ID
will take eect after you reboot the switch.
10/100 Mbps RJ45 Port
Designed to connect to the device with a bandwidth of 10 Mbps or 100 Mbps.
10/100/1000 Mbps RJ45 Port
Designed to connect to the device with a bandwidth of 10 Mbps, 100 Mbps or 1000 Mbps.
SFP Port
Designed to install the SFP module. For products except T1700X-16TS, the switch features some slots
that are shared with the associated RJ45 ports. The associated two ports are referred as a "Combo"
port, which means they cannot be used simultaneously, otherwise only SFP port works.
SFP+ Port
Designed to install the SFP module. For T1700G-28TQ and T1700X-16TS, the switch supports 1 G or
10 G SFP module connection.
Port Feature
Model 100M/1000 M/10Gbps
RJ45 Port
10/100/1000 Mbps
RJ45 Port
10/100 Mbps RJ45
Port SFP Port SFP+ Port
T1500-28TC / 4 24 2 /
T1500-28PCT / 4 24 2 /
T1600 G-18TS /16 / 2 /
T1600G-28TS /24 / 4 /
T1600G-52TS /48 / 4 /
T1600G-52PS /48 / 4 /

JetStream Smart Switch
07Introduction
Model 100M/1000 M/10Gbps
RJ45 Port
10/100/1000 Mbps
RJ45 Port
10/100 Mbps RJ45
Port SFP Port SFP+ Port
T1700G-28TQ /24 / / 4
T1700X-16TS 12 / / / 4
TL-SG2210MP / 8 / 2 /
TL-SG2428P /24 / 4 /
■Rear Panel
The rear panel is shown as the following figure. Here we take T1600G-28TS as an example.
Figure 1-11 Rear Panel
Power SocketGrounding TerminalKensington Security slot
Kensington Security Slot
Secure the lock (not provided) into the security slot to prevent the device from being stolen.
Grounding Terminal
The switch already comes with lightning protection mechanism. You can also ground the switch through
the PE (Protecting Earth) cable of AC cord or with Ground Cable. For detailed lightning protection
measures, go to https://www.tp-link.com/support, search the model number of your switch and go to
the product Support web page, refer to the Lightning Protection Guide from the Related Documents:
https://www.tp-link.com/us/conguration-guides/lightning_protection_guide/.
Power Socket
Connect the female connector of the power cord here, and the male connector to the AC power outlet.
Make sure that the voltage of the power supply meets the requirement of the input voltage (100–240 V~
50/60 Hz).
Caution:
You should use the provided power cord.

JetStream Smart Switch
08 Installation
Chapter 2 Installation
2.1 Package Contents
Make sure that the package contains the following items. If any of the listed items is damaged or
missing, please contact your distributor.
One Switch Installation Guide
Installation Guide
BusinessNetworking Solution
Two mounting brackets, eight
screws and four rubber feet
One Resouce CD
One Power Cord
2.2 Safety Precautions
To avoid any device damage and bodily injury caused by improper use, you should observe the
following rules.
■Safety Precautions
■Keep the power off during the installation.
■Wear an ESD-preventive wrist strap, and make sure that the wrist strap has a good skin contact and is
well grounded.
■Use only the power cord provided with the switch.
■Make sure that the supply voltage matches the specifications indicated on the rear panel of the
switch.
■Ensure that the switch is installed in a well-ventilated environment and its ventilation hole is not
blocked.
■Do not open or remove the cover of the switch.
■Before cleaning the device, cut off the power supply. Do not clean it by the waterish cloth, and never
use any other liquid cleaning method.
■Place the device with its bottom surface downward.
■Site Requirements
Temperature/Humidity
40
°C
0°C

JetStream Smart Switch
09Installation
Keep the equipment room at an appropriate level of temperature and humidity. Too much or too
little humidity may lead to bad insulation, leakage of electricity, mechanical property changes,
and corrosion. High temperatures may accelerate aging of the insulation materials, significantly
shortening the service life of the device. To find out the best temperature and humidity conditions
for the device, check the following table.
Environment Temperature Humidity
Operating 0 °C to 50 °C (for TL-SG2210MP/TL-SG2428P)
0 °C to 40 °C (for other switches) 10% to 90%RH Non-condensing
Storage -40 °C to 70 °C 5% to 90%RH Non-condensing
Clearness
The dust accumulated on the switch can be absorbed by static electricity and result in poor contact
of metal contact points. Some measures have been taken for the device to prevent static electricity,
but too strong static electricity can cause deadly damage to the electronic elements on the internal
circuit board. To avoid the effect of static electricity on the operation of the Switch, attach much
importance to the following items:
■Dust the device regularly, and keep the indoor air clean.
■Keep the device well grounded and ensure that the static electricity has been transferred.
Electromagnetic Interference
Electronic elements including capacitance and inductance on the device can be affected by external
interferences, such as conducted emission by capacitance coupling, inductance coupling, and
impedance coupling. To decrease the interferences, make sure to take the following measures:
■Use the power supply that can effectively filter interference from the power grid.
■Keep the device far from high-frequency and strong-current devices such as radio transmitting
station.
■Use electromagnetic shielding when necessary.
Lightning Protection

JetStream Smart Switch
10 Installation
Extremely high voltage currents can be produced instantly when lightning occurs and the air in the
electric discharge path can be instantly heated up to 20,000 °C. As this instant current is strong
enough to damage electronic devices, more effective lightning protection measures should be
taken.
■Ensure that the rack and the device are well earthed.
■Make sure the power socket has a good contact with the ground.
■Keep a reasonable cabling system and avoid induced lightning.
■Use the signal SPD (Surge Protective Device) when wiring outdoor.
Note: For detailed lightning protection measures, go to https://www.tp-link.com/support,
search the model number of your switch and go to the product Support web page, refer to the
Lightning Protection Guide from the Related Documents:
https://www.tp-link.com/us/conguration-guides/lightning_protection_guide/
Installation Site
When installing the device on a rack or a flat workbench, attach much importance to the following
items:
■The rack or workbench is flat, stable, and sturdy enough to support the weight of 5.5 kg at least.
■The rack or workbench has a good ventilation system. The equipment room is well ventilated.
■The rack is well grounded. Keep the device less than 1.5 meters away from the power socket.
2.3 Installation Tools
■Phillips screwdriver
■ESD-preventive wrist wrap
■Cables
Note:
These tools are not included with our product. If needed, you can purchase them separately.
2.4 Product Installation
■Desktop Installation
To install the device on the desktop, follow the steps:
1. Set the device on a flat surface which is strong enough to support the entire weight of the device
with all fittings.
2. Remove the adhesive backing papers from the rubber feet.
3. Turnover the device and attach the supplied rubber feet to the recessed areas on the bottom at
each corner of the device.

JetStream Smart Switch
11Installation
Figure 2-1 Desktop Installation
Feet
Bottom of the Device
Notch
■Rack Installation
To install the device in an EIA standard-sized, 19-inch rack, follow the instructions described below:
1. Check the efficiency of the grounding system and the stability of the rack.
2. Secure the supplied rack-mounting brackets to each side of the device with supplied screws, as
illustrated in the following figure.
Figure 2-2 Bracket Installation
Rack-mounting Bracket
Screw
3. After the brackets are attached to the device, use suitable screws (not provided) to secure the
brackets to the rack, as illustrated in the following figure.
Figure 2-3 Rack Installation
Rack
Caution:
■Leave 5 to 10 cm gaps around the devices for air circulation.
■Avoid placing heavy things on the device.
■Place the device with its bottom facing downwards.
■Mount devices in sequence from the bottom to top of the rack and ensure a certain clearance
between devices for the purpose of heat dissipation.

JetStream Smart Switch
12 Connection
Chapter 3 Connection
3.1 Ethernet Port
Connect an Ethernet port of the switch to the computer by RJ45 cable as the following figure shows.
Figure 3-1 Connecting the RJ45 Port
RJ45 Port
RJ45 Cable
3.2 SFP/SFP+ Port
The following figure demonstrates the connection of SFP port to an SFP module.
Figure 3-2 Inserting the SFP Module
SFP/SFP+ Slot
SFP/SFP+ Module
3.3 Verify Installation
After completing the installation, verify the following items:
■There should be 5 to 10 cm of clearance around the device for ventilation and make sure the air flow
is adequate.
■The voltage of the power supply meets the requirement of the input voltage of the device.
■The power socket, device and rack are well grounded.
■The device is correctly connected to other network devices.

JetStream Smart Switch
13Connection
3.4 Power On
Plug the negative connector of the provided power cord into the power socket of the device and plug
the positive connector into a power outlet as the following figure shows.
Figure 3-3 Connecting to Power Supply
Note:
The gure is to illustrate the application and principle. The provided plug and the socket in your
region may dier from the gures above.
3.5 Initialization
After the device is powered on, it begins the Power-On Self-Test. A series of tests run automatically
to ensure the device functions properly. During this time, its LED indicators will respond in the
following order:
1. The PWR LED indicator lights on all the time. The SYS LED and the LED indicators of all the ports
keep off.
2. (For TL-SG2210MP/TL-SG2428P) After about one minute, all LED indicators will turn green,
and then the FAN indicator and LED indicators of all the ports will turn yellow momentarily.
Subsequently, all LED indicators except the PWR LED will turn off.
(For other switches) After about one minute, the SYS LED and LED indicators of all the ports will
flash momentarily and then turn off.
3. Several seconds later, the SYS LED indicator will flash, which represents a successful initialization.
3.6 Accessing the Switch
After the initializaiton finished, you can access and manage the switch using the GUI (Graphical User
Interface) or using the CLI (Command Line Interface).
■To access the switch using the GUI, open a web browser and type the default management address
http://192.168.0.1 in the address field, then press the Enter key. The default username and password
are both admin in lower case letters.
■To access the switch using the CLI, you can use Telnet and SSH connection.
Note:
For certain devices, you may need to change the password the rst time you log in, which will
better protect your network and devices.
For the detailed configurations, please refer to the Configuration Guide and CLI Reference Guide.
The two guides can both be found on the resource CD or on the download center of our official
website: https://www.tp-link.com/download-center.html

JetStream Smart Switch
14 Appendix A Troubleshooting
Appendix A Troubleshooting
Q1. What could I do if I forgot the username and password of the switch?
Press the Reset button for at least 5 seconds to reset the system. The system will be reset to
the factory default settings, and the default login user name and password are both admin.
Q2. Why does the PWR/Power LED work abnormally?
The PWR/Power LED should be lit up when the power system works normally. If the PWR LED
worked abnormally,try the following:
1. Make sure that the power cable is connected properly, and the power contact is normal.
2. Make sure the voltage of the power supply meets the requirement of the input voltage of the
switch.
Q3. What should I do if I cannot access the web management page?
Try the following:
1. Check every port LED on the switch and make sure the Ethernet cable is connected properly.
2. Try another port on the switch and make sure the Ethernet cable is suitable and works normally.
3. Power off the switch and, after a while, power it on again.
4. Make sure the IP address of your PC is set within the subnet of the switch.
5. If you still cannot access the configuration page, please reset the switch to its factory defaults.
Then the IP address of your PC should be set as 192.168.0.x ("x" is any number from 2 to 254) and
subnet mask as 255.255.255.0.

JetStream Smart Switch
15Appendix B Specications
Appendix B Specifications
Item Content
Standards
IEEE 802.3i, IEEE 802.3u, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3z, IEEE
802.3x, IEEE 802.1p, IEEE 802.1q, IEEE 802.1x, IEEE 802.1d, IEEE 802.1s,
IEEE 802.1w
IEEE 802.3ae (For T1700G-28TQ/T1700X-16TS)
IEEE 802.3af, IEEE 802.3at (For T1500-28PCT/TL-SG2210MP/TL-
SG2428P/T1600G-52PS)
Transmission Medium
10Base-T: UTP/STP of Cat. 3 or above
100Base-TX: UTP/STP of Cat. 5 or above
100Base-FX/LX10/BX10: MMF or SMF SFP Module (For T1500-28TC/
T1500-28PCT/TL-SG2210MP)
1000Base-T: 4-pair UTP (≤ 100 m) of Cat. 5e, and Cat. 6 or above
1000Base-SX/LX/LX10/BX10: MMF or SMF SFP Module
10GBASE-SR/LR: MMF or SMF SFP+ Transceiver (For T1700G-28TQ/
T1700X-16TS)
10GBASE-T: 4-pair UTP of Cat.6 (maximum 55 m) or Cat.6a (maximum
100 m), 4-pair STP of Cat.6/Cat. 6a/Cat.7 (maximum 100 m)
(For T1700X-16TS)
LEDs
T1500-28TC: Power, System, 10/100M, 1000M
T1500-28PCT: PWR, SYS, PoE MAX, FAN, 10/100M or PoE, 1000M,
10/100M PoE
TL-SG2210MP: PWR, SYS, PoE MAX, FAN, Speed or PoE, SFP1, SFP2, PoE,
Speed
T1600G-18TS: PWR, SYS, 1000Mbps, Link/Act
T1600G-25TS/T1600G-52TS: PWR, SYS, 10/100/1000Mbps,100Base-
TX/1000Base-X
TL-SG2428P/T1600G-52PS: PWR, SYS, FAN, PoE MAX, Speed, PoE,
100Base-TX/1000BASE-X
T1700G-28TQ: PWR, SYS, Master, Link/Act, 1000M, 25, 26, 27, 28, Unit ID LED
T1700X-16TS: PWR, SYS, FAN, Link/Act
Operating Temperature 0 °C to 50 °C (32 °F to 122 °F) (for TL-SG2210MP/TL-SG2428P)
0 °C to 40 °C (32 °F to 104 °F) (for other switches)
Storage Temperature -40 °C to 70 °C (-40 °F to 158 °F)
Operating Humidity 10% to 90%RH Non-condensing
Storage Humidity 5% to 90%RH Non-condensing

CE Mark Warning
This is a class A product. In a domestic environment, this product may cause radio interference, in
which case the user may be required to take adequate measures.
EU declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and
other relevant provisions of directives 2014/30/EU, 2014/35/EU, 2009/125/EC, 2011/65/EU and
(EU)2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/ce
Продукт сертифіковано згідно с правилами системи УкрСЕПРО на відповідність вимогам
нормативних документів та вимогам, що передбачені чинними законодавчими актами України.
Safety Information
• Keep the device away from water, fire, humidity or hot environments.
• Do not attempt to disassemble, repair, or modify the device.
• Place the device with its bottom surface downward.
Please read and follow the above safety information when operating the device. We
cannotguarantee that no accidents or damage will occur due to improper use of the device.
Please use this product with care and operate at your own risk.

© 2020 TP-Link 7106508628 REV4.2.0
To ask questions, nd answers, and communicate with TP-Link users
or engineers, please visit https://community.tp-link.com to join TP-Link
Community.
For technical support, the user guide and other information, please visit
https://www.tp-link.com/support, or simply scan the QR code.
If you have any suggestions or needs on the product guides, welcome to
email [e-mail].
