TP-Link TL-SX105 User manual

Installation Guide
© 2020 TP-Link
7106508979 REV1.0.0
5-Port 10G Multi-Gigabit Desktop Switch
Note:
The images in this guide are only for example and may not reect your actual experience.
On: Power on
O: Power o
Panel Explanation
Power
Connection
Ethernet Ports (1–5)
Router
LAN PortWAN Port
TL-SX105
Power Adapter
Port
When one of the LED is on/ashing:
On: Connecting to a device but no activity.
Flashing: Transmitting or receiving data.
Left LED (10G/5G):
Green: Running at 10 Gbps.
Amber: Running at 5 Gbps.
Right LED (2.5G/1G/100M):
Green: Running at 2.5 Gbps.
Amber: Running at 100/1000 Mbps.
10G/5G 2.5G/1G/100M
Internet
Kensington Security Slot
Secure the lock (not provided) into
the security slot to prevent the
device from being stolen.
10G
NAS/Server
Gaming
Computer
Workstation 2.5G
Wi-Fi 6 AP
8K Video

Standard
Protocol
Interface
EU declaration of conformity
TP-Link hereby declares that the device is in compliance with the essential requirements and other relevant
provisions of directives 2014/30/EU, 2014/35/EU, 2009/125/EC, 2011/65/EU and (EU)2015/863.
The original EU declaration of conformity may be found at https://www.tp-link.com/en/ce.
Specications
General Specications
Network Media (Cable)
MAC Address Table
Switching Capacity
Transfer Method
MAC Address Learning
Operating Temperature
Storage Temperature
Operating Humidity
Storage Humidity
Environmental and Physical Specications
0 ˚C to 40 ˚C (32 ˚F to 104 ˚F)
-40 ˚C to 70 ˚C (-40 ˚F to 158 ˚F)
10% to 90%RH non-condensing
5% to 90%RH non-condensing
IEEE802.3, IEEE802.3u, IEEE802.3ab, IEEE802.3an
IEEE802.3bz, IEEE802.3x, IEEE802.1p
CSMA/CD
100BASE-TX:
2-pair UTP/STP of Cat. 5 or above (maximum 100 m)
1000BASE-T:
4-pair UTP/STP of Cat. 5e or above (maximum 100 m)
2.5GBASE-T:
4-pair UTP/STP of Cat. 5e or above (maximum 100 m)
5GBASE-T:
4-pair UTP/STP of Cat. 5e or above (maximum 100 m)
10GBASE-T:
4-pair UTP of Cat 6 (maximum 55 m) or STP of Cat 6,
6a, 7 (maximum 100 m)
5 100M/1G/2.5G/5G/10G RJ45 Ports
Auto-Negotiation/Auto MDI/MDIX
32K
100 Gbps
Store-and-Forward
Automatically learning, automatically aging
QoS (802.1p/DSCP), 802.3x ow control
100Base-TX: 148810 pps/port
1000Base-TX: 1488095 pps/port
2.5GBase-TX: 3720238 pps/port
5GBase-TX: 7440476 pps/port
10GBase-TX:14880952 pps/port
Q1. Why is the Power LED not lit?
Q2. Why are the right and left LEDs not lit when a device is
connected to the corresponding port?
Frequently Asked Questions (FAQ)
The Power LED should be lit when the power system is working
normally. If the Power LED is not lit, check as follows:
A1: Make sure the power adapter is connected to the switch with
power source properly.
A2: Make sure the voltage of the power supply meets the requirements
of the input voltage of the switch.
A3: Make sure the power source is on.
It is recommended that you check the following items:
A1: Make sure that the cable connectors are rmly plugged into the
switch and the device.
A2: Make sure the connected device is turned on and works normally.
A3: Make sure the cable category and length meet the standards listed
in General Specications.
For technical support and other information, please visit
https://www.tp-link.com/support, or simply scan the QR
code.
If you have any suggestions or needs on the product
guides, welcome to email [e-mail].
To ask questions, find answers, and communicate with TP-Link users
or engineers, please visit https://community.tp-link.com to join
TP-Link Community.
Safety Information
Keep the device away from water, re, humidity or hot environments.
Do not attempt to disassemble, repair, or modify the device. If you need service, please contact us.
Do not use damaged charger or USB cable to charge the device.
Do not use any other chargers than those recommended.
Adapter shall be installed near the equipment and shall be easily accessible.
Place the device with its bottom surface downward.
The plug on the power supply cord is used as the disconnect device, the socket-outlet shall be easily
accessible.
Use only power supplies which are provided by manufacturer and in the origin packing of this
product. If you have any questions, please don’t hesitate to contact us.
Advanced Feature
Frame Forwarding Rate
