TP-Link Auranet EAP120 User manual

Installation Guide
Wireless N Gigabit Access Point
EAP120 / EAP220

CONTENTS
About This Installation Guide
This guide is designed to familiarize you with the general layout of the EAP,
describe how to perform the hardware installation for EAP Series, and how to
configure the EAP in your network. Your EAP has more features and functionalities
which can be found in the User Guide.
Conventions
The EAP or the device mentioned in this guide stands for Wireless N Gigabit Access
Point EAP120 and EAP220.
EAP Topology ——————————————————————— 01
Overview ————————————————————————— 02
Hardware Installation ——————————————————— 04
1. Installation Requirements ....................................................... 04
2. Mounting Bracket ................................................................... 04
3. Installation ............................................................................ 05
4. Powering Mode ...................................................................... 09
Getting Started with EAP—————————————————— 11
Q&A ——————————————————————————— 14
Specications ——————————————————————— 15
Technical Support ————————————————————— 16

01
EAP Topology
A typical network topology for the EAP is shown below.
Router
Internet
Switch
Master EAP Member EAPMember EAP
Enwuvgt
The EAP120 and EAP220 provide two management modes: Cluster and Standalone.
By default, the management mode is Cluster. In this mode, all EAPs in the same
LAN (Local Area Network) form a cluster, and a Master EAP will be selected to
manage other Member EAPs.
To deploy an EAP in your local network, a DHCP server is required to assign IP
address to the EAP. Typically, a router acts as the DHCP server.
The EAP can be powered directly by a Power over Ethernet (PoE) switch through
the Ethernet port, or the provided power adapter.

02
Hardware Overview
■LED
System LED
LED Status Indication
Flashing green System initialization is complete.
Solid green The device is working properly.
Flashing red System errors. RAM, Flash, Ethernet, WLAN or
firmware may be malfunctioning.
Flashing yellow Firmware update is in progress. Do not disconnect
or power off the device.
Alternating red/green/yellow twice The device is being reset to its factory default
settings.
■Interface Panel
RESET CONSOLE ETHERNET ON/OFF POWER
ARROW 1
The interface panel components of the EAP, from left to right, are described in the
following list:
Kensington Security Slot
Secure the lock (not provided) into the security slot to prevent the device from
being stolen.

03
RESET
With the device powered on, press and hold the RESET button for about 8 seconds
until the LED ashes red/green/yellow alternatively twice, then release the button.
The device will restore to factory default settings.
CONSOLE
This port is used to connect to the serial port of a computer or a terminal to check
and monitor system information of the device.
Note: CLI commands are not available in current software version. We will release
a new version supporting CLI commands soon. Please pay close attention to our
ofcial website.
ETHERNET
This port is used to connect to a router to transmit data or to a PSE (Power
Sourcing Equipment), such as a PoE switch, for both data transmission and Power
over Ethernet (PoE) through Ethernet cable.
ON/OFF
Press this button to turn on/off the device.
POWER
The power port is used to connect the device to an electrical wall outlet via power
adapter. Please only use the provided power adapter. Refer to Powering Mode to
learn how to power the device via PoE or power adapter.
ARROW 1
This arrow is used to align with ARROW 2 on the mounting bracket to lock the EAP
into place. Please refer to Mounting Bracket to locate ARROW 2.

04
Hardware Installation
The EAP can be wall or ceiling-mounted and can be powered via a PSE device
or the provided power adapter. Please suitably arrange your wire layout before
mounting the EAP.
1. Installation Requirements
Before installation, check the package contents for the following items:
Other installation equipments may require, including a pencil, ruler, drill, drill bit,
hammer, screwdriver and a ladder.
2. Mounting Bracket
The following figure describes the structure of the mounting bracket.
Locking clip
ARROW 2 is used to align
with ARROW 1 under the
interface panel
Ceiling mounting slot
Wall mounting slot
Mounting Bracket
EAP120/EAP220 Mounting Bracket Installation Guide
Wing Nuts (3) Washers (3) Plastic Wall
Anchors (3)
Self-tapping
Screws (3)
Pan-head
Screws (3)

05
3. Installation
■Ceiling Mounting
Note:
■Make sure the thickness of the ceiling is less than 18mm and
the ceiling can bear at least five kilograms.
■It is NOT recommended to mount the EAP on a low-strength
material, such as gypsum ceiling panel. If no other choice is
available, make sure you add a piece of strong material under
the wing nuts to ensure the EAP is mounted solidly.
1. Remove the ceiling tile.
2. Place the mounting bracket in the center of the ceiling tile. Mark the positions
of the three mounting slots and a hole for the Ethernet cable to feed through.
L≈40mm
L
Mark of the Hole for Ethernet
cable to feed through

06
3. Use a drill with the appropriate size drill bit to drill three 4mm holes for
the pan-head screws, and drill a 10mm hole for the Ethernet cable to feed
through.
10mm hole for Ethernet cable feed
4mm hole for mounting bracket
4. Secure the mounting bracket to the ceiling tile using the pan-head screws (3),
washers (3) and wing nuts (3), as shown below.
Hole to feed the Ethernet cable
Hole to feed the screw
Pan head screw
Wing nut
Washer

07
5. Attach the EAP to the mounting bracket by aligning ARROW 1 with ARROW 2,
as shown below.
RESET CONSOLE ETHERNET ON/OFF POWER
ARROW 2
ARROW 1
6. Turn the EAP clockwise until it locks into place.

08
7. Feed the Ethernet cable through the hole and set the ceiling tile back into
place.
8. Connect the Ethernet cable to the Ethernet port.
■Wall Mounting
There are two wall-mounting slots on the back of the mounting bracket. To mount
the EAP on a wall, please follow the steps below.
1. Make two small pencil marks on the wall. Make sure the two marks are level
and should be 98.6mm apart.
2. Use a drill with the appropriate size drill bit to drill two 4mm holes through the
center of your marks.
Wall
4mm hole
3. Insert the plastic wall anchors (2) into the 4mm holes and drive the self-
tapping screws (2) into the anchors. The screws should protrude about 0.5
centimeter (1/5 inch) from the wall.

09
4. Attach the EAP to the mounting bracket by aligning ARROW 1 with ARROW 2.
RESET CONSOLE ETHERNET ON/OFF POWER
ARROW 2
ARROW 1
5. Turn the EAP clockwise until it locks into place.
6. Hang the EAP on the screws. Make sure the EAP is firmly seated against the
wall.
7. Connect the Ethernet cable to the Ethernet port on the EAP.
4. Powering Mode
The EAP can be powered via a PSE device (e.g., a PoE switch) or its power adapter.

10
■Via PSE Device
EAP220 TL-SG3424P
2
1
1. Connect the EAP and the PSE device through an Ethernet cable.
2. Press the ON/OFF button on the interface panel of the EAP.
■Via Power Adapter
TL-SG2008
EAP220
Socket Socket
1. Plug one end of the provided power adapter into the power port of the EAP,
and the other end to a standard electrical wall socket.
2. Press the ON/OFF button on the interface panel of the EAP.

11
Getting Started with EAP
The following content will guide you to quickly set up a wireless network
connection with several EAPs, and login to the management page to configure
the EAPs. The management host can connect to the Master EAP wirelessly or with
wires. Wireless Login is conveniently recommended.
Option 1: Wireless Login
Router
Switch
Master EAP Member EAP
Cluster
Management Host
Member EAP
Internet
Step 1: Power on
Power on the EAPs. The EAP that first completes system initialization will be
selected as the Master EAP.

12
Step 2: Wireless Access
1. Make sure the management host is set to obtain an IP address
automatically.
2. Join the wireless network using the default SSID TP-LINK_2.4GHz_XXXXXX or
TP-LINK_5GHz_XXXXXX, where XXXXXX represents the last 6 characters of
the EAP's MAC address. Password is not required.
Step 3: Quick Setup
1. Open a web browser and type in http://tplinkeap.net to access the EAP's
web management page. Use admin (all lowercase) for both username and
password to login. Please note that in Cluster mode, the login will be directed
to the Master EAP.
2. Create a new user name and password.
3. Follow the step-by-step instructions to complete the Quick Setup. Any
configurations you make to the Master EAP will automatically synchronize to all
the other EAPs.
Note: If you change the default SSID and password during the Quick Setup, you
will need to reconnect to the EAP using the new SSID and password to perform
more advanced configurations.
Congratulations! Now you can enjoy the wireless network with TP-LINK EAP Series.
Option 2: Wired Login
Router
Switch
Master EAP Member EAPMember EAP
Cluster
Management Host
Internet

13
Step 1: Power on
Power on the EAPs. The EAP that first completes system initialization will be
selected as the Master EAP.
Step 2: Wired Access
1. Make sure the management host is set to obtain an IP address
automatically.
2. Access your DHCP server and locate the IP address of the EAPs.
Step 3: Quick Setup
1. Open a web browser and type in the IP address of the Master EAP to login
to the web server. The default user name and password are admin (all
lowercase). In the Cluster mode, the login will be directed to the Master EAP.
2. Create a new user name and password.
3. Follow the step-by-step instructions to complete Quick Setup. Any
configurations you make to the Master EAP will automatically synchronize to all
the other EAPs.
Congratulations! Now you can enjoy the wireless network with TP-LINK EAP Series.

14
Q&A
Q1. Can Master EAP work as an access point?
Yes. In addition to managing and monitoring Member EAPs, the Master EAP
can also function as an access point, providing wireless access to clients.
Q2. What is the maximum number of EAPs in a cluster?
The maximum number of EAPs in a cluster is 24.
Q3. Can EAP120 and EAP 220 be deployed in the same cluster?
No. Only the EAPs of the same model can be clustered.

15
Specifications
Models EAP120 EAP220
HARDWARE FEATURES
Interface 10/100/1000Mbps Ethernet port (RJ-45)
Console port (RJ-45)
Power connector (DC-2)
Kensington lock slot
Buttons RESET
ON/OFF (for power supply)
PoE Compatible 802.3af
Power Supply PoE (36~57VDC, 0.2A Max)
or External 12VDC/1A Power
Supply
PoE (36-57VDC, 0.4A Max)
or External 12VDC/1.5A
Power Supply
Maximum Power Consumption 4.4W 9.6W
Antenna 2*4dBi Embedded 4*4dBi Embedded
Mounting Ceiling/Wall mounting (Kits included)
Certication CE
FCC
RoHS
Operating Temperature 0℃~40℃(32℉~104℉)
Operating Humidity 10%~90% non-condensing
WIRELESS FEATURES
Wireless Frequency 2.4GHz 2.4GHz & 5GHz
Wi-Fi Standard IEEE 802.11b/g/n IEEE 802.11a/b/g/n
Maximum Data Rate Up to 300Mbps Up to 600Mbps
Max RF Transmission Power(1) 23dBm 2.4GHz:23dBm
5GHz:20dBm
Multiple SSIDs Up to eight per radio
Captive Portal Authentication Support
Wireless Security WEP
WPA/WPA2-personal
WPA/WPA2-enterprise
Cluster Support, up to 24 APs in a cluster
Maximum transmission power may vary in different countries or regions.

16
Technical Support
■For more help, please go to: http://www.tp-link.com/en/support/faq
■To download the latest firmware, driver, utility and user guide, please go to:
http://www.tp-link.com/en/support/download
■For all other technical support, please contact us using the information below:
Global Tel: [phone]
Fee: Depending on rate of different carriers, IDD.
E-mail: [email protected]
Service time: 24hrs, 7 days a week
Australia/New Zealand Tel: AU 1300 87 5465 (Depending on 1300 policy.)
NZ 0800 87 5465 (Toll Free)
E-mail: [email protected] (Australia)
[email protected] (New Zealand)
Service time: 24hrs, 7 days a week
Brazil Toll Free: 0800 608 9799 (Portuguese Service)
E-mail: [email protected]
Service time: Monday to Saturday, 09:00 to 20:00; Saturday, 09:00 to 15:00
France Tel: [phone] (French service)
Fee: 0.118 EUR/min from France
Email: [email protected]
Service time: Monday to Friday 9:00 to 18:00 *Except French Bank holidays
Germany/Austria Tel: [phone] (German Service)
+49 1805 TPLINK
[phone]
Fee: Landline from Germany: 0.14EUR/min.
Landline from Austria: 0.20EUR/min.
E-mail: [email protected]
Service time: Monday to Friday, 9:00 to 12:30 and 13:30 to 17:30. GMT+ 1
or GMT+ 2 (DST in Germany) *Except bank holidays in Hesse
Indonesia Tel: [phone]
Fee: Depending on rate of different carriers.
E-mail: [email protected]
Service time: Monday to Friday 9:00 to 18:00 *Except public holidays
Italy Tel: [phone]
Fee: Depending on rate of different carriers.
E-mail: [email protected]
Service time: Monday to Friday, 9:00 to13:00 and 14:00 to 18:00
Malaysia Toll Free: 1300 88 875 465
Email: [email protected]
Service time: 24hrs, 7 days a week
Poland Tel: [phone]
[phone] (if calls from mobile phone)
Fee: Depending on rate of different carriers.
E-mail: [email protected]
Service time: Monday to Friday 9:00 to 17:00. GMT+1 or GMT+2 (DST)

17
Russian Federation Tel: [phone] (Moscow NO.)
8 [phone] (Toll-free within RF)
E-mail: [email protected]
Service time: From 09:00 to 21:00 (Moscow time)
*Except weekends and holidays in RF
Singapore Tel: [phone]
Fee: Depending on rate of different carriers.
E-mail: [email protected]
Service time: 24hrs, 7 days a week
Switzerland Tel: [phone] (German Service)
Fee: 4-8 Rp/min, depending on rate of different time.
E-mail: [email protected]
Service time: Monday to Friday, 9:00 to 12:30 and 13:30 to 17:30. GMT+ 1
or GMT+ 2 (DST)
Turkey Tel: [phone] (Turkish Service)
Fee: Depending on rate of different carriers.
E-mail: [email protected]
Service time: 9:00 to 21:00, 7 days a week
UK Tel: [phone]
Fee: Landline: 1p-10.5p/min, depending on the time of day.
Mobile: 15p-40p/min, depending on your mobile network.
E-mail: [email protected]
Service time: 24hrs, 7 days a week
Ukraine Tel: [phone]
Fee: Free for Landline; Mobile: Depending on rate of different carriers.
E-mail: [email protected]
Service time: Monday to Friday 10:00 to 22:00
USA/Canada Toll Free: [phone]
E-mail: [email protected]
Service time: 24hrs, 7 days a week
