TPI 510 User manual

Test Products International, Inc.
TPI 510
Solar Power Meter
User’s Manual
HB2TM2060001
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

- 1 -
CONTENTS
1. Foreword………………………………….………………………………………….2
2. Safety Precautions and Procedures…….………………………………………...2
3. Caution..…………………….………………………………………………………..2
4. Applications………………….………………………………………………………3
5. Features…………………….……………………………………………………….3
6. Description and Function………..………………………………………………...4
7. Specifications……………………………………………………………………….8
8. Safety and Maintenance…………………………………………………………..9
9. Battery Replacment………………………………………………………………..9
10. Warranty………………………….………………………………………………….9
11. End of Life Disposal………….…………………………………………………….9
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

- 2 -
1. FOREWORD
Thank you for purchasing TPI brand products. The TPI Solar Meter is state of
the art and easy to use. It is designed to measure solar power in W/m2or BTU
(ft2*h).
2. SAFETY PRECAUTIONS AND PROCEDURES
This instrument conforms with safety Standard EN 61010-1 related to
electronic measuring instruments.
For your own safety and to avoid damaging the instrument follow the
procedures described in this instruction manual and read carefully all notes
preceded by this symbol .
CAUTION
For your own safety and to avoid damaging the instrument
follow the procedures described in this instruction manual
and read carefully all notes preceded by this symbol .
When taking measurements:
Avoid performing measurements in humid or wet places and in areas
where explosive gas, combustible gas, steam or excessive dust is
present.
3. CAUTION:
CAUTION - refer to the instruction manual - improper use may
damage the instrument or its components
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

- 3 -
4. APPLICATIONS
Suitable for measuring the effectiveness of solar film.
Solar radiation measurement.
Car windows light intensity measurement.
Optimal incident angle for solar panels.
Measurement of the sun’s transmission through transparent and film
glass
5. FEATURES

Convenient, no need to adjust, data displayed clearly.

Measurable light sources, including all visible light.

Overload display “OL” when measurement is out of range.

Select either W/m2 or BTU / (ft2*h) units
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

- 4 -
6. DESCRIPTION AND FUNCTION
6.1.LCD DISPLAY:
1. Data hold .
2. Max. value.
3. Min. value.
4. Decimal point.
5. numeral screen.
6. W/m2W/m2
7. BTU (ft2*h)
8. Low battery indicator
6.2.BUTTONS: 1. Power button
2. Max. / Min button
3. W/m2 / BTU (ft2*h) button
4. Data Hold button
5. Auto
Range button
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

- 5 -
6.2.1. Power button :
Press the “ ” button to turn the power on.
Press the “ ” button again to turn the power OFF and the meter will
go into sleep mode.
6.2.2. Max. and Min button:
Press the “ ” button to display the max. or min. reading.
Press and hold the “ ” button for 1 second to read the max. value.
Press the button one more time to read the min. value.
Press and hold the “ ” button for more than 1 second, and max.
and min. mode turns off and the 510 returns to normal operation.
When the “ ” button is active, the “ ” button is disabled.
6.2.3. BTU (ft2*h) / W/m2button :
Press the “ ” button to turn power on. The screen displays BTU
(ft2*h). Press the “ ” button to switch from BTU (ft2*h) to W/m2.
Pressing the button again returns the unit to BTU.
6.2.4 Data hold button :
Press the “ ” button to go into hold mode, and “ D-H ” appears
on the screen and the data on the display is frozen. Press this button
once again to deactivate data hold and return to normal operation.
6.2.5 Auto Range button :
The ” button allows the range to be changed from 199.9 to 1999
and back again. If a measurement is being made and “OL” is displayed,
press the button to switch to the higher range.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

- 6 -
6.3.TEST PROCEDURE
Measuring your car headlights:
Turn the car headlights on. Turn on the 510 solar meter, and “00.0”
appears on the screen. Put the 510 down close to the headlights. Switch
between high beam and low beam, and the light intensity values appear
on the display. Test both the right and left headlights and write the values
down for reference. (Refer to Picture 2)
Measure the effect of solar insulation of your vehicle’s windows:
Press the “ ” button to turn the 510 solar meter on and “00.0”
appears on the screen. Aim the 510 at the sun holding it close to a
window and the intensity value appears on the display. Open the window
and aim the device at the sun. Compare the value against that acquired
when the window is closed to understand the efficiency of the window’s
solar film. (Refer to Picture 2)
NOTE.：When the light sensor cover is not attached “CAP” is indicated.
Make sure that it is attached. If performing the zero adjustment after
powering on, several digits may not disappear. In this case, perform the
zero adjustment again.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

- 7 -
Picture 2:
Picture 3
Measure the solar insulation effect of your house’s windows:
Close the window. Press the “ ” button on your 510 solar meter, and
“00.0” comes up on the screen. Put the device close to the window and
aim it at the sun. Compare the value against that acquired when the
window is open and the device is placed at the same position, in order to
understand the window’s heat efficiency. (Refer to Picture 3)
To test the sun’s intensity,
p
ut the device up close to
the window Turn ON the headlights and put
the device down close to them
to test their intensity
To test the sun’s intensity, put the
device close to the window
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

- 8 -
7. SPECIFICATIONS
Battery life: approx. 100 hr.
Accuracy：typically within ± 10W/m2[ ±3 BTU / (ft2*h) ] or ±5% , whichever
is greater in sunlight; Additional temperature induced error ±0.38W/m2 /
oC [ ±0.12 BTU / (ft2*h)/ oC] from 25oC
Operating temp. & RH: 5oC~40oC, below 80%RH.
Storage temp. & RH: -10oC ~60oC, below 70%RH.
DISPLAY：3-1/2 digits LCD with maximum reading 1999.
Sampling Time：Approx. 0.25 second
Resolution：0.1W/m2、0.1 BTU /(ft2*h).
Over-input：Display shows" OL".
Range：1999W/m 2 、634 BTU /(ft 2 * h).
Dimensions & weight: 132(L) x 60(W) x 38 (H)mm, approx. 150g.
EMC: this instrument is EMC-compliant and has undergone compatibility
tests according to EN61326 (1997) + A1 (1998) + A2 (2001).
ACCESSORIES
User manual.
9V battery(NEDA 1604 IEC 6F 22 JIS 006P)*1
carrying case.
www.GlobalTestSupply.com
Find Quality Products Online at: [e-mail]

- 9 -
8. SAFETY AND MAINTENANCE
Operating altitude: below 2,000m.
Operating environment: for indoor use, exposure to pollution level II.
This is a precision device. Observe use and storage specifications to
prevent possible damage.
Do not store this device in direct sunlight or where it is hot and/or damp.
Remember to turn the power off after use. For long term storage, remove
the battery to prevent the battery from leaking and causing damage to the
parts inside.
Clean the device with a dry soft cloth.
9. BATTERY REPLACEMENT
When the " " symbol is displayed the battery is in need of replacement.
Unscrew the battery cover and remove the battery. Insert a new battery of
the same type (9V NEDA1604, JIS006P, IEC6F22) observing the proper
polarity, re-screw the battery cover and reposition the protective holster.
10. WARRANTY
Your TPI instrument is guaranteed free from defects in materials and
workmanship for 1 year from the date of purchase. This guarantee does not
affect your statuary rights. For additional information please refer to the
included warranty card.
11. END OF LIFE
Caution: this symbol indicates that equipment and its
accessories shall be subject to a separate collection and
correct disposal
