Agilent U2722A/U2723A USB
Modular Source Measure Unit
Voltage and current programming
and readback
Data Sheet
The Agilent U2722A/U2723A USB modular source measure unit
is more than just a power supply – it has fast response time, and
voltage and current programming/readback with high accuracy
measurement capabilities. The U2722A and its enhanced version,
the U2723A, are capable of four-quadrant operation, acting as
a current source as well as the current sink (load) with both
polarities of the output voltage. The U2723A offers additional
features such as embedded test scripts to simplify automated
testing, and faster rise time to help improve throughput during
mass testing of semiconductor components.

2
Features
• Three-channel SMU
• Four-quadrant operation
(±20 V, ±120 mA)
• Maximum current output of
120mA per channel
• Embedded test script that is able
to support three channels with
coherent source and measurement
capabilities (for U2723A)
• IV Curve application support in the
Agilent Measurement Manager
software (for U2723A)
• High measurement sensitivity of
100 pA with 16-bit resolution
• 0.1% basic accuracy
• Low current measurement
capability down to nA levels
• High-speed USB 2.0 and
USBTMC-USB488 standards
• Standalone and modular
• SCPI and IVI-COM supported
Increase the efficiency of your
tests
With a high measurement sensitivity
of 100 pA at 16-bit resolution for
pico-level measurement and 0.1%
accuracy, the U2722A/U2723A
USB modular source measure unit
provides more detailed and accurate
analysis and measurement results.
U2722A/U2723A supports SCPI and
IVI-COM. The SMU is compatible
with a ride range of Application
Development Environments, minimiz-
ing your work time and increasing
your software options. Save time
and effort with the bundled Agilent
Measurement Manager (AMM) soft-
ware, which coverts SCPI commands
into snippets of VEE, VB, C++ and
C# code with the command logger
function.
Pre-define test configurations
and execute commands
automatically
The U2723A USB modular source
measure unit provides an embedded
test script to help you pre-define test
configurations or duplicate tests eas-
ily without spending too much time
on programming.
Each channel in the U2723A USB
modular SMU is allocated two
memory lists, each capable of storing
up to 200 commands and results indi-
vidually. Stored commands in active
memory will be executed accord-
ingly while the measurement results
obtained are automatically stored in
the result buffer.
Four-quadrant operations with
high measurement sensitivity
and accuracy
The U2722A/U2723A SMU is a
versatile device that allows you to
perform sweep and measurement
from different operating regions
without needing extra configura-
tions. The four-quadrant operation
(±20V, ±120mA) makes the
U2722A/U2723A SMU well suited
for a wide range of test applications,
including leakage measurement, solar
cell measurement, forward/reverse
voltage and curve tracer transistors.
The U2722A/U2723A SMU also offers
high measurement sensitivity with
16-bit resolution and accuracy that
allows you to obtain more accurate
analysis and measurement results.
Introduction
+120 mA
–120 mA
+20 V–20 V

3
Product outlook and
dimensions
Front view
117.00 mm
180.00 mm
66.00 mm
Rear view
Top view
Product characteristics and general specifications
Remote interface • Hi-Speed USB 2.0*
• USBTMC-USB4881
Power consumption • +12 VDC, 3 A maximum
• Isolated ELV supply source
Operating environment • Operating temperature from 0 °C to +50 °C
• Relative humidity at 20% to 85% RH (non-condensing)
• Altitude up to 2000 meters
• Pollution Degree 2
• For indoor use only
Storage compliance –20 °C to 70 °C
Safety compliance Certified with:
• IEC 61010-1:2001/EN 61010-1:2001 (2nd Edition)
• USA: ANSI/UL 61010-1:2004
• Canada: CSA C22.2 No.61010-1:2004
EMC compliance • IEC 61326-1:2005/EN61326-1:2006
• Canada: ICES-001:2004
• Australia/New Zealand: AS/NZS CISPR 11:2004
Shock and vibration Tested to IEC/EN 60068-2
IO connector Output connectors
Dimension (W × D × H) Module dimension:
• 120.00 mm x 183.00 mm x 66.00 mm (with bumpers)
• 105.00 mm x 175.00 mm x 50.00 mm (without bumpers)
Weight Module dimension:
• 700 g (with bumpers)
• 650 g (without bumpers)
Warranty One year for U2722A/U2723A
Three months for standard shipped accessories
1. Compatible with Microsoft®Windows®operating systems only.
* If remote connections are necessary, a E5813A USB/LAN hub can be used. Please go to the
product’s user guide for more information.
Standard shipped accessories
• 12 V, 3 A AC/DC Power adapter
• Power cord
• Plug-in connectors and cable casing
• USB Standard-A to Mini-B interface cable
• L-Mount kit (used with modular product chassis)
• Quick Start Guide
• Agilent Measurement Manager Quick Reference Card
• Reference CD-ROM
• Agilent Automation-Ready CD-ROM (contains the Agilent IO Libraries Suite)
• Certificate of Calibration
U2722A/U2723A USB Modular Source Measure Unit

4
Product Specifications
Model U2722A/U2723A
Number of outputs 3
Output ratings (at 0 °C to 50 °C)
Voltage –20 V to 20 V
Current –120 mA to 120 mA
Performance specification
U2722A/U2723A Range Accuracy1Resolution
Voltage programming
12 months (at 25 °C ± 3 °C), ±(% of output + offset)
±2 V 0.075% + 1.5 mV 0.1 mV
±20 V 0.05% + 10 mV 1 mV
Current programming
12 months (at 25 °C ± 3 °C), ±(% of output + offset)
±1 μA 0.085% + 0.85 nA 100 pA
±10 μA 0.085% + 8.5 nA 1 nA
±100 μA 0.075% + 75 nA 10 nA
±1 mA 0.075% + 750 nA 100 nA
±10 mA 0.075% + 7.5 μA 1 μA
±120 mA 0.1% + 100 μA 20 μA
Voltage readback
12 months (over USB with respect to the actual output at 25 °C ± 3 °C),
±(% of output + offset)
±2 V 0.075% + 1.5 mV 0.1 mV
±20 V 0.05% + 10 mV 1 mV
Current readback
12 months (over USB with respect to the actual output at 25 °C ± 3 °C),
±(% of output + offset)
±1 μA 0.085% + 0.85 nA 100 pA
±10 μA 0.085% + 8.5 nA 1 nA
±100 μA 0.075% + 75 nA 10 nA
±1 mA 0.075% + 750 nA 100 nA
±10 mA 0.075% + 7.5 μA 1 μA
±120 mA 0.1% + 100 μA 20 μA
1. Accuracy measurements are based on NPLC 10.

5
Product Specifications (continued)
Performance characteristics
Rise/fall time (ms)1U2722A U2723A
For resistive measurement2
±1 μA 170.0 15.0
±10 μA 18.0 5.0
±100 μA 6.0 1.0
±1 mA 1.0 1.0
±10 mA 1.0 1.0
±120 mA 1.0 1.0
Remote sense operating range Ensure that the maximum voltage between the OUTPUT+ and SENSE+,
OUTPUT–, and SENSE– does not exceed 3 V
Temperature coefficient Maximum change in output/readback per °C after a 30-minute warm-up is 0.15
Guard output resistance 0.2 kΩ
Noise 10 Hz to 20 MHz (peak-peak) 100 mV typical into a resistive load (floating mode)
Output voltage overshoot, ±(% of output + offset)2During turn-on or turn-off, the output plus overshoot < 0.1% + 10 mV
Programming language SCPI (Standard Commands for Programmable Instruments)
Maximum sense lead resistance 1 MΩ for rated accuracy
Voltage line regulation 0.01% of range
Voltage load regulation 0.01% + 100 μV
Current line regulation 0.04% of range
Current load regulation 0.04% + 100 μA
Recommended calibration interval One year
Maximum input capacitance load 10 nF
1. Drive 50% of 1 V or 10 V output with a resistive load. Rise time is from 10% to 90% of program voltage change at maximum current.
Fall time is from 90% to 10% of program voltage change at maximum current.
2. Measurements obtained are per default bandwidth setting.
NOTE
• All channels are isolated from the ground and from each other. Isolation is +60 VDC, Category 1.
• All specifications are based on a three-hour warm-up time.
• The measurement accuracy value is x ( 1 + a * y ), where,
◦ x = accuracy specification at room temperature,
◦ a = temperature coefficient, and
◦ y = temperature change from room temperature in °C
Noise 10 Hz to 20 MHz (Peak-peak)
Voltage range
Current range
1 μA 10 μA 100 μA 1 mA 10 mA 120 mA
2 V 50 mV 50 mV 50 mV 50 mV 30 mV 30 mV
20 V 50 mV 50 mV 50 mV 50 mV 30 mV 30 mV

6
Agilent Measurement Manager
The Agilent Measurement Manager
(AMM) is an application data
viewer software that comes with the
standard purchase of the U2700A
Series USB modular instruments. This
software is designed to help you per-
form quick device configuration, data
logging and data acquisition using the
products.
Supported features found in the
U2722A/U2723A USB modular source
unit:
• Command logger to allow the
capture of configuration commands
that can be easily converted to
snippets of VEE, VB, C++ and C#
code
• Self-test
• Self-calibration
• Option to save the current
instrument configuration to a file
• Data logging and export feature to
CSV, HTML and text only format
files that can be printed
• Trigger settings between modules
in the instrument chassis with Star
trigger and Master/Slave trigger
Agilent Measurement Manager prerequisites
Prior to installing the Agilent Measurement Manager software, ensure that
your PC meets the following minimum system requirements for installation and
operation.
Hardware requirements
Processor 1.6 GHz Pentium IV or higher
Operating system One of the following Microsoft Windows versions:
• Windows XP Professional or Home edition (Service Pack 1
or later)
• Windows Vista 32-bit (Business, Ultimate, Enterprise, Home
Basic and Home Premium edition)
• Windows 7 32-bit (Home Basic, Home Premium,
Professional, Enterprise and Ultimate edition)
Hard disk space 1 GB
RAM 512 MB or higher recommended
Video Super VGA (800 x 600), 256 colors or more
Software requirements
Agilent IO Libraries Suite 15.1 and above1
Agilent T&M Toolkit Runtime version 2.12
Agilent T&M Toolkit Redistributable Package 2.1 patch2
Microsoft .NET Framework version 2.02
1. Available on the Agilent Automation-Ready CD-ROM
2. Bundled with Agilent Measurement Manager software application installer

7
U2942A Parametric Measurement Manager Pro Software
Measure and analyze with ease
Agilent Parametric Measurement
Manager Pro (PMM Pro) is a
VEE-based software designed to
perform basic semiconductor testing.
The software specializes in the analy-
sis of discrete semiconductor devices
such as diodes, bipolar junction
transistors and field effect transistors.
Designed for use with the Agilent
U2722A/U2723A USB source mea-
sure unit and the U2941A parametric
test fixture, Agilent PMM Pro controls
the instruments to take parametric
measurements such as voltage or
current. The software then plots,
displays and logs the results in an IV
curve.
Agilent PMM Pro allows users to
carry out measurements and display
results without the need for prior pro-
gramming experience. The software
operates through an intuitive user-
interface that is easy to understand
and configure, and includes test
sequence automation to further ease
your task.
Features
• Uses an intuitive GUI that is easy to configure and simplifies testing
• Comes with predefined test profiles for diode, bipolar junction transistors and
field effect transistors, removing the need for programming experience
• Allows users to define and configure test profiles
• Automates test sequencing for parametric analysis
• Plots, displays and logs parametric measurements in an IV curve
• Includes built-in math functions such as addition, subtraction and division for
quick analysis of results
Figure 1. Intuitive GUI that features both pre-defined and user-defined test profile.
Figure 2. Plots, displays and logs parametric measurements in
an IV curve.

8
U2942A Parametric Measurement Manager Pro Software (continued)
Minimum system requirements for PMM Pro
System requirements
Operating system Microsoft Windows XP SP3 or higher • Microsoft Windows 7 (Professional, Ultimate, Enterprise)
• Microsoft Windows Vista®SP1 (Business, Ultimate,
Enterprise) or higher
Architecture x86 (32-bit), 64-bit for Windows 7 supportability1
Prerequisite • Agilent IO Libraries Suite 15.0 or higher2
• Agilent VEE Pro 9.0 or higher (Runtime version)3
• Microsoft.NET Framework version 1.1 and 2.03
Processor • 450 MHz Pentium II or higher required
• 800 MHz recommended
1 GHz required, 2 GHz recommended
Available memory • 128 MB minimum
• 256 MB or higher recommended
1 GB minimum, 2 GB recommended
Available disk space 1 GB hard disk free space
Video Super VGA (800x600) display or higher
resolution monitor with 256 colors or more
Support for DirectX 9 graphics with 128 MB graphics
memory recommended (Super VGA graphics is supported)
Browser Microsoft Internet Explorer 6.0 or higher Microsoft Internet Explorer 7 or higher
1. 32-bit application running on WOW64 (Windows-on-Windows) emulator.
2. Available on the Agilent Automation-Ready CD-ROM.
3. Bundled with the Agilent SMU PMM Pro software installer.

9
U2941A Parametric Test Fixture
Increase your parametric test
efficiency and usability
The Agilent U2941A parametric test
fixture is designed to complement
usage of the Agilent U2722A/U2723A
USB modular source measure unit in
the testing of semiconductor com-
ponents, including SMT and DIP ICs.
The U2941A comes with three input
channels, a common ground, and five
types of socket modules of various
pin configurations.
The bundled Agilent Parametric
Measurement Manager (PMM)
software also supports the Agilent
U2751A USB modular switch matrix
when used with the U2722A. The
PMM software allows for out-of-box
configuration of instruments for easy
set-up, simplifying discrete package
component testing and enabling data
recording.
Figure 3. Sample setup of the U2941A connected directly to the U2722A source measure
unit and fastened with the DIP socket module.
Black plastic fasteners
Socket modules
Figure 4. Socket modules are interchangeable to match pin configuration of
device-under-test (DUT).
Features
• Closed lid minimizes ESD on sensitive circuits and components
• Up to 3 source/measure channels supported
• Different socket modules to match a wide variety of pin configurations
• Assembly PTFE plate for low-current measurements
• Comes with the Agilent Parametric Measurement Manager software

10
Specifications and System Requirements
The following specifications are valid for 23 °C ±5 °C and < 70% relative humidity.
Specifications
Electrical specifications Electrical specifications
Voltage rating 60 VDC
Current rating 1 A
Environmental specifications
Operating temperature 0 °C to 50 °C
Storage temperature –20 °C to 70 °C
Operating humidity 20% to 85% RH non-condensing
Storage humidity 5% to 90% RH non-condensing
Altitude Up to 2000 m
Physical specifications
Dimensions (W×D×H) 250 mm × 200 mm × 120 mm
Weight 1.33 kg (approximate)
Warranty 3 months
Minimum system requirements
Hardware
Processor 1.6 GHz Pentium IV or higher
RAM 512 MB (1.0 GB or higher recommended)
Hard disk space 1 GB free disk space at runtime
Display resolution 1024 × 768 recommended
Operating system and browser
Operating system • Windows XP Professional or Home Edition, Service Pack 1 or later; or
• Windows 2000 Professional, Service Pack 4 or later
Browser Microsoft Internet Explorer 5.01 (6.0 or higher recommended)
Software
Agilent IO Libraries Suite1Version 15.0 or higher
Agilent VEE2Runtime version 8.5, patch 8.5.1
Agilent Measurement Manager3Version 1.6 or higher
Microsoft .NET Framework1Version 1.1 and 2.0
1. Available on Agilent Automation-Ready CD
2. Bundled with Agilent Parametric Measurement Manager CD
3. Bundled with Agilent U2722A USB modular source measure unit or Agilent U2751A USB modular switch matrix
Top view Front view
250 mm
200 mm
53 mm
120 mm

11
U2722P/U2723P Parametric Measurement Solution
Measure and analyze quickly
and efficiently with all
your essential parametric
measurement tools at your
fingertips
Parametric testing is used across a
variety of application and industries
– from a teaching tool in the educa-
tion sector to manufacturing and
troubleshooting in the semiconductor
industry. Now, you can measure
and analyze quickly and efficiently
in all these areas with the one-stop
Parametric Measurement Solution.
The Parametric Measurement
Solution bundle consists of the
Agilent U2722A/U2723A USB modu-
lar source measurement unit and the
Agilent Parametric Measurement
Manager Pro software, providing you
a basic yet complete parametric mea-
surement test solution that analyzes
the performance of components such
as diodes and transistors without
the need for prior programming
experience. The optional Agilent
U2941A parametric test fixture can
further increase your parametric test
efficiency and usability.
The U2722P/U2723P Parametric
Measurement Solution bundle is only
available in Europe and Asia, exclud-
ing Japan.
Figure 5. Easily configure an I-V characterization test with the
Parametric Measurement Manager Pro software.
Figure 6. Execute the I-V characterization test to view results
instantly.
Figure 7. The test results can also be viewed in tabular format
for quick analysis.

12
Other products in the Agilent USB Modular Test Instruments Family
U2701A/U27012A USB Modular Oscilloscope
Features:
• High sampling rate up to 500MSa/s, enabling accurate measurement
analysis
• Up to 32 MB large memory
• Fast fourier transfer (FFT) and waveform math functions enables easy
waveform calculation
For more information: http://www.agilent.com/find/usbscope
U2741A USB Modular Digital Multimeter (DMM)
Features:
• Fast reading speed (up to 100 Sa/s)
• Wide range of basic measurement functions, including frequency and
temperature measurements
For more information: http://www.agilent.com/find/U2741A
U2751A USB Modular Switch Matrix
Features:
• Minimal cross-talk of -30 dB at 45 MHz wide bandwidth
• High bandwidth at 45 MHz without terminal block
• Capability to test up to four devices-under-test (DUTs)
• Works with other Agilent instruments for multi-point testing
For more information: http://www.agilent.com/find/U2751A
U2761A USB Modular Function/Arbitrary Waveform Generator
Features:
• Direct digital synthesis (DDS) waveform generator
• Pulse generator that can generate pulse signal as stimulus
• Easy customization with Arbitrary Waveform Editor
• Internal modulation capability simplifies test setup
For more information: http://www.agilent.com/find/U2761A
U2781A USB Modular Product Chassis
Features:
• Expansion of channels for each modular product
• Multiple instrument synchronization
• Internal and external 10 MHz reference clock
• High-speed USB 2.0
• SSI/Star trigger bus synchronization between external trigger source and
modules
For more information: http://www.agilent.com/find/U2781A

13
Ordering Information
U2722A USB modular source measure unit
U2723A USB modular source measure unit with embedded test scripts
U2941A Parametric test fixture, shipped with:
• Assembly PTFE plate
• 28-pin dual-in-lin package (DIP) socket module
• 0.1-inch universal socket module
• 0.075-inch universal socket module
• 0.05-inch universal socket module
• Pin plug-topin plug cables, black (4 pcs)
• Pin plug-topin plug cables, red (4 pcs)
• Pin plug-topin plug cables, blue (4 pcs)
• Pin plug-to-miniature clip cables, black (4 pcs)
• Pin plug-to-miniature clip cables, red (4 pcs)
• Pin plug-to-miniature clip cables, blue (4 pcs)
• PCB jumper pin
• BNC to two-wire cable, 1 m (3 pcs)
• Agilent Parametric Measurement Manager CD (includes installation and operation guide)
U2942A Parametric Measurement Manager Pro software
U2722P* U2722A USB modular source measure unit and U2942A Parametric Measurement Manager Pro bundle
U2723P* U2723A USB modular source measure unit and U2942A Parametric Measurement Manager Pro bundle
* Only available in Europe and Asia (excluding Japan)
Optional accessories for the U2700 Series
U2921A-101 USB secure cable, 2 m
Optional accessories for the U2941A parametric test fixture
U2941A-101 Pin plug-to-pin plug cable, black
U2941A-102 Pin plug-to-pin plug cable, red
U2941A-103 Pin plug-to-pin plug cable, blue
U2941A-104 Pin plug-to-miniature clip cables, black
U2941A-105 Pin plug-to-miniature clip cables, red
U2941A-106 Pin plug-to-miniature clip cables, blue
U2941A-107 BNC to two-wire, 1 m
U2941A-201 Assembly PTFE plate
• Insulation board with minimal leakage current; suitable for extremely low-current measurement
U2941A-202 28-pin dual-in-line package (DIP) socket module
• Lever actuated zero insertion force (ZIF) socket
U2941A-203 0.1-inch universal socket module
• 0.1-inch pitch; suitable for virtually any device such as components, DIP IC or small scale circuit
U2941A-204 0.075-inch universal socket module
• 0.075-inch pitch; suitable for virtually any device such as components, DIP IC or small scale circuit
U2941A-205 0.05-inch universal socket module
• 0.05-inch pitch; suitable for any device such as components, DIP IC or small scale circuit

www.agilent.com
www.agilent.com/find/U2722A
www.agilent.com/find/U2723A
Microsoft and Windows are trademarks or
registered trademarks of Microsoft Corporation
in the United States and/or other countries.
Windows Vista is a trademark or registered
trademark of Microsoft Corporation in the
United States and/or other countries.
Agilent Email Updates
www.agilent.com/find/emailupdates
Get the latest information on the
products and applications you select.
www.lxistandard.org
LAN eXtensions for Instruments puts
the power of Ethernet and the Web
inside your test systems. Agilent
is a founding member of the LXI
consortium.
Agilent Channel Partners
www.agilent.com/find/channelpartners
Get the best of both worlds: Agilent’s
measurement expertise and product
breadth, combined with channel
partner convenience.
For more information on Agilent
Technologies’ products, applications or
services, please contact your local Agilent
office. The complete list is available at:
www.agilent.com/find/contactus
Americas
Canada [phone]
Brazil (11) 4197 3600
Mexico 01800 5064 800
United States [phone]
Asia Pacific
Australia 1 800 629 485
China 800 810 0189
Hong Kong 800 938 693
India 1 800 112 929
Japan 0120 (421) 345
Korea 080 769 0800
Malaysia 1 800 888 848
Singapore 1 800 375 8100
Taiwan 0800 047 866
Other AP Countries (65) 375 8100
Europe & Middle East
Belgium 32 (0) 2 404 93 40
Denmark 45 45 80 12 15
Finland 358 (0) 10 855 2100
France 0825 010 700*
*0.125 €/minute
Germany 49 (0) 7031 464 6333
Ireland 1890 924 204
Israel 972-3-9288-504/544
Italy 39 02 92 60 8484
Netherlands 31 (0) 20 547 2111
Spain 34 (91) 631 3300
Sweden 0200-88 22 55
United Kingdom 44 (0) 118 927 6201
For other unlisted countries:
www.agilent.com/find/contactus
Revised: January 6, 2012
Product specifications and descriptions
in this document subject to change
without notice.
© Agilent Technologies, Inc. 2012
Published in USA, May 2, 2012
5990-7416EN
Agilent Advantage Services is committed
to your success throughout your equip-
ment’s lifetime. To keep you competitive,
we continually invest in tools and
processes that speed up calibration and
repair and reduce your cost of ownership.
You can also use Infoline Web Services
to manage equipment and services more
effectively. By sharing our measurement
and service expertise, we help you create
the products that change our world.
www.agilent.com/quality
www.agilent.com/find/advantageservices
www.axiestandard.org
AdvancedTCA®Extensions for
Instrumentation and Test (AXIe) is
an open standard that extends the
AdvancedTCA for general purpose
and semiconductor test. Agilent
is a founding member of the AXIe
consortium.
www.pxisa.org
PCI eXtensions for Instrumentation
(PXI) modular instrumentation
delivers a rugged, PC-based high-
performance measurement and
automation system.
Quality Management SystemQuality Mana
g
ement Sy
s
ISO 9001:2008
Agilent Electronic Measurement Group
DEKRA Certified
