TPL VISION SQUARE LIGHT RGB User manual

www.tpl-vision.com
TPL VISION
IS AN ISO9001
CERTIFIED MANUFACTURER
[phone] [e-mail]
Brenchley House, School Road
Charing, Kent TN27 0JW
United Kingdom
User gUideUser gUide P4/4
Features and presentations liable to changes without notice. Ref.UG-060401-B4, 2022/12 edition.
Preamble
This notice includes all the advice and warnings that enables a correct set up and a safe use of the product.
TPLVision can not be responsible for the bad use of the notice. If so, TPL Vision cancels the guarantee’s effects.
risk class
The EN-62471 norm about lighting uxes enables the classication of led lightings in 4 distinct groups, according to their
hazardousness degree. Please nd below an indicative table, recapitulating the classes of risk for our standard products.
Colour Class Risk
White WHI, Green 525 nm, Red 630 nm 0none
UV 405 nm, Blue 470 nm, IR 850 nm 1low
UV 365 nm 2moderate
UV 385 nm 3high
In all cases, TPL Vision recommends
the use of the protection glasses
that are listed in its catalog.
For more information about photo-
biological risks, do not hesitate to
contact us.
UnPacking
Products are packed in our factory, using suitable materials for a safe transport through the usual means of transpor-
tation, in France and internationally. However, a damaged package must be reported to the carrier on delivery. Hand-
written reservations must be indicated on the delivery order. Moreover, please send a letter or an email to TPL Vision as
soon as possible (up to 24 hours after the delivery). If the transportation damage has not been stipulated on the delivery
order and reported to TPL Vision in time, the package will not be taken back nor exchanged. To open the package, donot
use any cutting blade to avoid damaging the product(s). Please use the delivered accessories, if needed (do not use any
other products or equivalents to replace the delivered accessories).

connection
User gUide
M5 4 male points RGB
CONTINUOUS MODE CONNECTION
FRONT VIEW OF THE PRODUCT’S CONNECTOR
2
4
black
+ 24 V
red
1
brown
+24 V
green
3blue
white
1
2
3
4
GND
+24 V
blue
+ 24 V green
+ 24 V blue
+ 24 V red
GND
P2/4 P3/4
User secUrity
Do respect the power supply voltages and the connection terminals.
Do not modify or dismantle all or part of the product.
Do not connect or clean when power is on.
Do not watch the lighting source directly, and follow the advice below :
• If the workstation enables it, interpose a lter that will stop the lighting radiation under xed or adjustable frame
between the source and the operator.
• When these measures cannot be implemented, supply the operators with glasses (class 4) available for sale at
TPLVision.
• Forbid or limit the direct access to the lighting source (exposure into the radiation axis).
• Establish a security perimeter so as to prevent the operators from approaching the lighting source beyond
therecommendations of the manufacturer, as for eye irritation is concerned.
• In any case, ensure that the chosen means properly reduce the exposition quantities (features of screens or
glasses to be chosen, according to the wavelengths that the operators are exposed to).
eqUiPment maintenance
CLEANING (when the product is switched off)
Please use a soft and dry cloth. Do not use any abrasive material.
Do not use any cleaning solvent or aggressive chemical product.
TPL Vision recommends to use isopropyl alcohol.
During the set up, the light has to be switched off
and unplugged. Please use the xing holes designed
for that purpose (see scheme above). We recommend
the using of M3 screws (not supplied) with a tighte-
ning torque from 0.5 to 1.5 Nm. We also recommend
the use of a threadlocker (not supplied) to avoid any
risk of loosening.
fixing
dimensions
Length
(mm)
Width
(mm)
Height
(mm)
A B C
SQUARE
LIGHT 100 100 50
The Square Light RGB has to be plugged to a TPL Drive RGB. For more information, please read the dedicated techsheet.
oPerating conditions
Not for outdoor use.
