TPL VISION TRING User manual

TPL VISION UK
Brenchley House – School Road – Charing – Kent TN27 0JW – UK
Tel. [phone] – www.tpl-vision.com
User gUideUser gUide P4/4
Features and presentations liable to changes without notice. Ref.UG-030501-D1, 2020/01 edition.
Preamble
This notice includes all the advice and warnings that enables a correct set up and a safe use of the product. TPL
Vision can not be responsible for the bad use of the notice. If so, TPL Vision will cancel the guarantee’s effects.
User secUrity
Do respect the power supply voltages and the connection terminals.
Do not modify or dismantle all or part of the product.
Do not connect or clean when power is on.
Do not watch the lighting source directly, and follow the advice below :
• If the workstation enables it, interpose a lter that will stop the lighting radiation under xed or adjustable
frame between the source and the operator.
• When these measures cannot be implemented, supply the operators with glasses (class 4) available for sale at
TPLVision, or with a dedicated protective mask, that will stop the lighting radiation.
• Forbid or limit the direct access to the lighting source (exposure into the radiation axis).
• Establish a security perimeter so as to prevent the operators from approaching the lighting source beyond
therecommendations of the manufacturer, as for eye irritation is concerned.
• In any case, ensure that the chosen means properly reduce the exposition quantities (features of screens or
glasses to be chosen, according to the wavelengths that the operators are exposed to).
eqUiPment maintenance
CLEANING (when the product is switched off)
Please use a soft and dry cloth. Do not use any abrasive material.
Do not use any cleaning solvent or aggressive chemical product.
TPL Vision recommends to use isopropyl alcohol. risk class
The EN-62471 norm about lighting uxes enables the classication of led lightings in 4 distinct groups, according to their
hazardousness degree. Please nd below an indicative table, recapitulating the classes of risk for our standard products.
Colour Class Risk
White WHI, Green 525 nm, Red 630 nm 0none
UV 405 nm, Blue 470 nm, IR 850 nm 1low
UV 365 nm 2moderate
UV 385 nm 3high
In all cases, TPL Vision recommends
the use of the protection glasses
that are listed in its catalog.
For more information about photo-
biological risks, do not hesitate to
contact us.
UnPacking
Products are packed in our factory, using suitable materials for a safe transport through the usual means of transpor-
tation, in France and internationally. However, a damaged package must be reported to the carrier on delivery. Hand-
written reservations must be indicated on the delivery order. Moreover, please send a letter or an email to TPL Vision as
soon as possible (up to 24 hours after the delivery). If the transportation damage has not been stipulated on the delivery
order and reported to TPL Vision in time, the package will not be taken back nor exchanged. To open the package, donot
use any cutting blade to avoid damaging the product(s). Please use the delivered accessories, if needed (do not use any
other products or equivalents to replace the delivered accessories).

connection
User gUide P2/4 P3/4
M12 4 male points
In STROBE mode:
STROBE entry = 24 V
or 5V TTL –> light on
STROBE MODE CONNECTION
CONTINUOUS MODE CONNECTION
2
4
black
1
brown
+ 24 V
3GND
blue
NC
white
FRONT VIEW OF THE PRODUCT’S CONNECTOR
Automate + 24 V
1
2
3
4
1
2
3
4
Ground
Strobe / Dimming
+ 24 V
Ground
STROBE/
Dimming
strobe modedimming
control
0
20%
40%
60%
80%
100%
0%
1 2 3 4 5 6
VOLTS
Entrée Déclenchement
Sortie Éclairage
Triggering input
Light
Potential dimming between 1.5 and 5 Volts.
Above 5 Volts, the product reaches100%
of its lighting power. Power supply : 24V +/-10%
Strobe input : 24V or 5V TTL
1.5 ms 1 ms
During the set up, the light has to be switched off and
unplugged. Please use the xing holes designed for
that purpose (see scheme above).
We recommend the using of M3 screws (not supplied)
with a tightening torque from 0.5 to 1.5 Nm.
We also recommend the use of a threadlocker (not sup-
plied) to avoid any risk of loosening.
fixing
dimensions
Internal ø
(mm)
External ø
(mm)
Width
(mm)
A B C
TRING 38 66 15
+5V or +24V
Toward STROBE
input
From camera
/automate
+24
R1
3k9
R2
1k potentiometer
C1
optional 0.1 uf
capacitor
STROBE
4.898 V maximum output
+5V or +24V
From camera
/automate
0V
Toward STROBE
input
Resistance value
to be adapted
to the automaton.
Max. 4.7 kΩ
external dimming configuration PnP-like automaton outPut nPn-like automaton outPut
