Trace2O HT1000 User manual

HydroTest Photometer
HT1000

Contents
1.0 Introduction..................................................................................5
2.0 Operation......................................................................................6
2.1.1 Set up ...........................................................................................6
2.1.2 Saving data –Important Information ..........................................6
2.1.3 Replacement of batteries.............................................................6
2.1.4 Instrument (exploded drawing):..................................................7
2.1 Overview of function keys ...........................................................8
2.1.1 Overview.......................................................................................8
2.1.2 Displaying time and date: ............................................................9
2.1.3 User countdown...........................................................................9
2.3 Operationmode .........................................................................10
2.3.1 Automatic switch off..................................................................10
2.3.2 Selecting a method ....................................................................10
2.3.2.1 Method Information (F1) .............................................................10
2.3.3 Differentiation ............................................................................11
2.3.4 Overview of test procedure ......................................................11
2.3.5 Changing chemical species .......................................................12
2.3.8 Storingresults ............................................................................12
2.3.9 Printing results (Infra-Red Interface Module) (optional) ...........13
2.3.10 Perform additional measurements.........................................13

HT1000_15/12/2015
3
2.3.11 Selecting a new method .........................................................14
2.3.12 Measure absorbance...............................................................14
2.4 Photometer settings: Table of Mode Functions ........................15
2.4.1 Instrument basic settings 1 .......................................................16
2.4.2 Printing of stored results............................................................20
2.4.3 Recall / delete stored results......................................................25
2.4.4 Lab function ...............................................................................33
2.4.5 User operations ..........................................................................35
2.4.6 Specialfunctions ........................................................................37
2.4.7 Instrument basic settings 2 .......................................................39
2.4.8 Instrument special functions /service .......................................40
2.5 Data transfer...............................................................................41
2.5.1 Data Printing ..............................................................................41
2.5.2 Data transfer to a personal computer........................................41
2.5.3 Internet Updates ........................................................................41
Part 3..........................................................................................................42
Enclosure....................................................................................................42
3.1 Unpacking ..................................................................................42
3.2 Delivery contents .......................................................................42
3.3 Technical data ............................................................................43
3.4 Abbreviations .............................................................................44

4
HT1000_0.5 09/2015
3.5 Troubleshooting ........................................................................45
3.5.1 Operating messages in the display / error display ....................45
3.5.2 General .......................................................................................47

HT1000_15/12/2015
5
1.0 Introduction
The HT1000 is part of the HydroTest range of instruments based on optical measurement technology
for the analysis of a range of chemical parameters in aqueous samples.
The HT1000 is a photometric analyser using 6 indivdual selective wavelengths to measure the colour
change produced by a reagent when reacted with the analyte of interest.
The photometer employs the methods defined in the American Standard Methods for water analysis.
This instruction manual outlines the functions and operations of the photometric instrument only.
Instructions specific to each test are included with the reagent packs as purchased from Trace2o Ltd.
The instrument has been designed and optimized to work solely with Trace2o reagents. A complete
list of available parameters is included in Appendix 1.0
The instrument has been designed for use in an outdoor environment and is rugged and waterproof
however the optical system should also be checked for cleanliness before use particularly
condensation build up in the cell chamber.

6
HT1000_0.5 09/2015
2.0 Operation
2.1.1 Set up
Before working with the photometer it may be necessary to insert the batteries if supplied
separately. See chapter 2.1.2 Saving data –Important information, 2.1.3 Replacement of
batteries.
Before using the photometer perform the following settings in the Mode-Menu:
• MODE 10: select language
• MODE 12: set date and time
• MODE 34: perform “Delete data“
• MODE 69: perform “User m. init” to initialise the userpolynomial system
See chapter 2.4 Photometer settings.
2.1.2 Saving data –Important Information
During replacement of the battery the data in the HT1000 is saved for 2 minutes. If the
change time exceeds 2 minutes all stored data and settings are lost. It is recommended to have
the replacement batteries to hand to expediate fitment.
2.1.3 Replacement of batteries
See chapter 2.1.2 "Saving data - important Information" before replacing batteries.
1. Switch the instrument off.
2. If necessary remove vial from the sample chamber.
3. Place the instrument upside down on a clean and even surface.
4. Unscrew the four screws (A) of the battery compartment cover (B).
5. Lift off battery compartment cover at the notch (C).
6. Remove old batteries (D).
7. Insert 4 new batteries ensuring the correct polarity!
8. Replace the battery compartment cover.
Check the seal ring (E) of the notch to make sure it is a tight fit. If the seal appears
stretched or damaged then a replacement should be obtained to ensure the waterproof
seal is maintained.
9. Tighten the screws carefully.
.

HT1000_0.5 09/2015
7
2.1.4 Instrument (exploded drawing):
(A) screws
(B) battery compartment cover
(C) notch
(D) batteries: 4 batteries (AA/LR6)
(E) seal ring
(F) instrumentback
(B) battery
compartment
cover
(E) seal ring
(F) instrumentback
(A) screws
(C) notch
(D) batteries
CAUTION:
To ensure that the instrument is water proof:
• seal ring (E) must be in position
• battery compartment cover (B) must be fixed with the four screws

8
HT1000_0.5 09/2015
2.1 Overview of function keys
2.1.1 Overview
Switching the photometer on or off
Press shift key to achieve figures key 0-9.
Keep the shift key depressed and press desired figures key.
e.g.: [Shift] + [1][1]
Returning to selection of methods or previous menu
Function key: description in the text if key available
Function key: description in the text if key available
Function key: description in the text if key available
Confirming
Menu of photometer settings and further functions
Moving the cursor up or down
Storing of displayed test result
Performing Zero
Performing Test
Displaying date and time / user countdown
Decimal point

9
Countdown
02:00
start:
0
2
0
0
Esc
Shift
F1
Countdown
mm : ss
99 : 99
2.1.2 Displaying time and date:
Press [“clock”] key.
19:30:22 2012-06-15 The display shows:
After 15 seconds the photometer reverts to the previous
display automatically
or press [ ] key or [ESC].
2.1.3 User countdown
With this function the operator is able to define his own countdown.
Press [“clock”] key.
19.30.20 2012-06-15 The display shows time and date:
Press [“clock”] key.
The display shows:
Either press [ ] key to accept the last used user countdown.
or
press any number key to start entering a new value
The entry comprises two digits each.
Enter minutes and seconds,
e.g.: 2 minutes, 0 seconds = [Shift] + [0][2][0][0].
Confirm with [ ] key.
The display shows:
Start countdown with [ ] key.
After countdown has finished the photometer reverts to the
previous display automatically.
2.1.4 Display backlight
Press the [Shift] + [F1] key to turn the display backlight on
or off. The backlight is switched off automatically during the
measurement.

10
HT1000_0.5 09/2015
Shift
8
0
>> 35 Alkalinity-p
40 Aluminium
100 Chlorine
0.02-6 mg/l Cl2
Tablet
24 mm
DPD No 1
DPD No 3
2.3 Operationmode
selftest ...
Switch the photometer on by pressing the [ON/OFF] key.
The photometer performs an electronic self-test.
2.3.1 Automatic switch off
The instrument switches off automatically after 20 minutes. This is indicated 30 seconds before
by a beeper. Press any key to avoid the instrument switching off.
As long as the instrument is working (for example countdown or printing) the automatic switch
off is inactive.
2.3.2 Selecting a method
The display shows a selection:
There are two possibilities to select the required method:
a) enter method-number directly
e.g.:[Shift] + [8] [0] to select Bromine
b) press arrow key [ ] or [ ] to select the required method
from the displayed list.
Confirm with [ ] key.
2.3.2.1 Method Information (F1)
Use [F1] key to switch between the compact and the detailed list for method selection.
Example:
Line 1: Method number, Method name
Line 2: Range
Line 3: Kind of reagent
Line 4: Vial
Line 5-7: Used reagent
tube = reagent vial contained in tube test
ON
OFF

11
Zero
320 Phosphate LR T 0.05-
4 mg/l PO4
0.02-1.3 mg/l P
0.04-3 mg/l P2O5
Chlorine
>> diff
free
total
prepareZero
press ZERO
Zero accepted
prepare Test
press TEST
2.3.2.2 Chemical Species Information
Pressing the [F2] key the display shows a list with availablechemical species and
corresponding ranges. Changing chemical species see chapter 2.3.5 page 12.
Line 1: Method number, Method name
Line 2: Range with chemical species 1
Line 3: Range with chemical species 2
Line 4: Range with chemical species 3
2.3.3 Differentiation
Differentiation is possible in some methods (e.g.
Chlorine). The photometer then requires the type of
determination.
Press arrow key [ ] or [ ] to select the required
determina- tion.
Confirm with [ ] key.
2.3.4 Overview of test procedure
The display shows:
Prepare a clean vial as described in “Method“ and place
the vial in the sample chamber making sure that the
marks are aligned.
Press [ZERO] key.
The display
shows:
F1
F2
F2
F1
ChemicalSpecies
Information
Information
Methods
Information
Method List
F2
F1
Method

12
HT1000_0.5 09/2015
Shift
1
0
0
0
0
0
Store
Code-No.:
_ _ _ _ _ _
Stored!
2.3.5 Changing chemical species
For some methods there is a possibility to change the chemical species of the test result.
If the test result is displayed press arrow key [ ] or [ ].
Example:
320 Phosphate LR T -----[ ]----> 320 Phosphate LR T <---- [ ] ----- 320 Phosphate LR T
0.05-4 mg/l PO4 0.02-1.3 mg/l P 0.04-3 mg/l P2O5
<---- [ ] ----- ------ [ ] ---->
1.00 mg/l PO4 0.33 mg/l P 0.75 mg/l P2O5
If the species of a test result is changed the displayed range is adjusted automatically. For an
already stored result it is not possible to change the chemical species. The last displayed chemical
species is kept by the instrument and will be displayed if this method is used the next time. If there
is the possibility to change the chemical species for a method it is described in the manual. The
arrows indicate the possible chemical species and are printed below the notes of the method:
PO
4
P
P2O5
2.3.8 Storingresults
Press [STORE] key while the test result is displayed.
The display shows:
• We advise you to enter a numeric code (up to 6 places).
(A Code No. can contain references to the operator or
the sampling location.)
After entering confirm with [ ] key.
• If a code number is not necessary confirm by pressing
[ ] directly. (The assignment for the Code No. is then 0
automatically.)
The entire data set is stored with date, time, Code No., method
and test result.
The display shows:
The test result is then shown again.

HT1000_0.5 09/2015
13
F3
Test
Test
Zero
Storage: 900
free records left
Storage: only 29
free records left
Zero accepted
prepare Test
press TEST
prepareZero
press ZERO
Note:
The display shows the number of free data sets.
If there are less than 30 data sets free the display shows:
Clear the memory as soon as possible (see “Deleting stored
results”). If memory capacity is used up it is impossible to save
additional test results.
2.3.9 Printing results (T2o PC-Link) (optional)
If the PC-Link module (see chapter 2.5) is switched on and the printer is connected, it is possible to
print out the test results (without saving it beforehand).
Press [F3] key.
The entire data set is printed with date, time, Code No.,
method and test result. Printing example:
The test No. is an internal number that is set automatically
if a test result is stored. It appears only on the print out.
2.3.10 Perform additional measurements
To perform additional tests using the same method:
• Press [TEST] key
The display shows:
Confirm with [TEST] key
or
• Press [ZERO] key to perform a new zero calibration.
The display shows:
100 Chlorine T
0.02-6 mg/l Cl2
Profi-Mode: no
2009-07-01 14:53:09
Test No.: 1
Code-Nr.: 007
4.80 mg/l Cl
2

14
HT1000_0.5 09/2015
Esc
1
6
0
900 mAbs 430 nm
-2600mAbs -+2600mAbs
prepare Zero
press ZERO
Zero accepted
prepare Test
press TEST
2.3.11 Selecting a new method
Press [ESC] key to return to method selection.
Or enter the required method number directly,
e.g. [Shift] + [1][6][0] for CyA-TEST (Cyanuric acid).
Confirm with [ ] key.
2.3.12 Measure absorbance
Range: –2600 mAbs to +2600 mAbs
Method-No.
Title
900
mAbs 430 nm
910
mAbs 530 nm
920
mAbs 560 nm
930
mAbs 580 nm
940
mAbs 610 nm
950
mAbs 660 nm
Select the desired wavelength from the method list or by entering the corresponding method
number directly.
The display shows e.g.:
Always carry out zeroing using a filled (e.g. deionised water)
vial.
The display shows:
Carry out measurement of the sample.
500 mAbs The display shows e.g.:
TIP:Toensurecompletereaction timestheusercountdownmaybehelpful(chapter2.2.3, page
290).

HT1000_0.5 09/2015
15
2.4 Photometer settings: Table of Mode Functions
MODE-Function
No.
Description
Page
Calibration
40
Special method calibration
30
Clear calibration
46
Deleting user calibration
32
Clock
12
Setting date and time
17
Countdown
13
Switching the countdown on/off to ensure reaction
times
18
Delete data
34
Deleting all stored results
29
Key beep
11
Switching the acoustic signal on/off to indicate key-
pressing
17
Langelier
70
Calculation of Langelier saturation Index
(Water Balance)
37
Language
10
Selecting language
16
LCD contrast
80
Setting the display contrast
39
LCD brightness
81
Setting the display brightness
39
Method list
60
User method list, adaption
35
M list all on
61
User method list, switching on all methods
36
M list all off
62
User method list, switching off all methods
36
OTZ
55
One Time Zero (OTZ)
34
Print
20
Printing all stored results
20
Print, code no.
22
Print only results of a selected Code No. range
22
Print, date
21
Print only results of a selected time period
21
Print, method
23
Print only results of one selected method
23
Printing parameters
29
Setting of printing options
24
Profi-Mode
50
Switching the detailed operator instructions on/off
33
Signal beep
14
Switching the acoustic signal on/off to indicate end
of reading
19
Storage
30
Displaying all stored results
25
Stor., code
32
Displaying only results of a selected Code No. range
27
Stor., date
31
Displaying only results of a selected time period
26
Stor., method
33
Displaying only results of one selected method
28
System info
91
Information about the instrument
e.g. current software version
40
Temperature
71
Selection of °C or °F for Langelier Mode 70
38

16
HT1000_0.5 09/2015
Mode
0
1
<Language>
Deutsch
>> English
Francais
MODE-Function
No.
Description
Page
User calibration
45
Storage of user calibration
31
The selected settings are kept by the photometer even when switched off. To change photometer
settings a new setting is required.
2.4.1 Instrument basic settings 1
Selecting a language
Press [MODE], [Shift] + [1][0] keys.
Confirm with [ ] key.
The display shows:
Press arrow key [ ] or [ ] to select the required language
from the displayed list.
Confirm with [ ] key.

HT1000_0.5 09/2015
17
1
1
Mode
<Key-Beep>
ON: 1
OFF: 0
0
1
Note:
Mode
2
1
<clock>
yy-mm-dd hh:mm
_ _-_ _-_ _ _ _:_ _
yy-mm-dd hh:mm
09-05-14 _ _:_ _
yy-mm-dd hh:mm
09-05-14 15:07
Key beep
Press [MODE], [Shift] + [1][1] keys.
Confirm with [ ] key.
The display shows:
• Press [Shift] + [0] keys to switch the key beep off.
• Press [Shift] + [1] keys to switch the key beep on.
Confirm with [ ] key.
In the case of methods with reaction periods, an acoustic signal still sounds during the last 10
seconds of the countdown even if the key beep is switched off.
Setting date and time
Press [MODE], [Shift] + [1][2] keys.
Confirm with [ ] key.
The display shows:
The entry comprises two digits each.
Enter year, month and day,
e.g.: 14. May 2009 = [Shift] + [0][9][0][5][1][4]
Enter hours and minutes
e.g.:3.07p.m.=[Shift]+[1][5][0][7]
Confirm with [ ] key.
Note:
While confirming date and time with [ ] key the seconds are adjusted to zero automatically.

18
HT1000_0.5 09/2015
0
Mode
3
1
1
<Countdown>
ON:1 OFF:0
Countdown(Ensuring reactionperiods)
Some methods require a reaction period. This reaction period is incorporated in the method as
standard with the countdown function.
It is possible to switch the countdown off for all methods:
Press [MODE], [Shift] + [1][3] keys.
Confirm with [ ] key.
The display shows:
• Press [Shift] + [0] keys to switch the countdown off.
• Press [Shift] + [1] keys to switch the countdown on.
Confirm with [ ] key.
Notes:
1. It is possible to interrupt the working countdown by pressing the [ ] key (application e.g.
serial analysis).
The “user countdown”is also available if the countdown is switched off.
2. If the countdown function is switched off, the operator is responsible for ensuring the
necessary reaction period.
Non-compliance with reaction periods leads to incorrect test results.

HT1000_0.5 09/2015
19
0
Mode
4
1
1
<Signal-Beep>
ON:1 OFF:0
Signal beep
Performing a zero or a measurement takes 8 seconds. The photometer indicates the end of
zeroing or measuring by a short beep.
Press [MODE], [Shift] + [1][4] keys.
Confirm with [ ] key.
The display shows:
• Press [Shift] +[0] keys to switch the signal beep off.
• Press [Shift] + [1] keys to switch the signal beep on.
Confirm with [ ] key.
Note:
In the case of methods with reaction periods, an acoustic signal still sounds during the last 10
seconds of the countdown even if the key beep is switched off.

20
HT1000_0.5 09/2015
<Print>
Print all Data
Start:
cancel:
ESC
Mode
0
2
2.4.2 Printing of stored results
Printing all results
Press [MODE], [Shift] + [2][0] keys.
Confirm with [ ] key.
The display shows:
Press [ ] key for printing out all stored test results.
TestNo.: The display shows e.g.:
After printing the photometer goes back to <Mode-Menu>
automatically.
Note:
It is possible to cancel the entry by [ESC].
All stored data are printed out.
See chapter 2.5.1 Data Printing.
