Tracmaster CAMON TC07 Instruction Manual

CAMON
No liability will be accepted for any damage
caused to persons or property through failure
to observe the operating and safety instructions.
TURF CUTTER
TC07
VIBRATION & SOUND LEVELS
2
Machine RPM Vibration m/sec Sound Level
3 Axis dB(A)
2
TC07 Turf Cutter 2800 <3m/sec 86.0
Tracmaster Ltd, Teknol House, Victoria Road, Burgess Hill RH15 9LH
Tel: [phone] Fax: [phone]
Website: www.tracmaster.co.uk E-mail: [e-mail]
© Tracmaster Ltd 2007.
Specifications are subject to change without prior notice.
OP/TC07/1207
2
4
3
8
9
7
6
1
5
1 - Ignition switch
2 - Choke lever
3 - Fuel tap
4 - Recoil start handle
5 - Operating lever
6 - Lifting lever
7 - Cutting depth adjustment knob
8 - Wheel drive lever
9 - RH guard
10 - LH guard
10
WEAR EAR
PROTECTION
WEAR SAFETY
FOOTWEAR
WEAR EYE
PROTECTION
READ CAREFULLY
IMPORTANT
OPERATING
INSTRUCTIONS
&
SAFETY NOTES

S A F E T Y
TO START PETROL ENGINE
ALWAYS start the engine in the open air
DO NOT smoke when refuelling
DO NOT mix OIL with the fuel
ALWAYS stop the engine before making any adjustments,
refuelling, moving or cleaning, or when the unit is
unattended
USE ONLY unleaded petrol from fuel containers designed for
this purpose - refuel outdoors only and replace the tank cap
securely
IN CASE of petrol spillage move the machines away from the
area of spillage and allow the petrol vapours to dissipate
before starting the engine
DO NOT remove any safety guards that are fitted - ensure that all
guards are fitted before using the machine
DO NOT touch any moving parts or attempt any maintenance
whilst the machine is running - KEEP HANDS AND FEET
AWAY
BEFORE starting work clear the work area of any objects that
could damage the machine
DO NOT allow children or anyone uninstructed to operate the
machine - KEEP ANIMALS AWAY
o
DO NOT use on slopes or banks of more than 20
ALWAYS wear suitable clothing to give personal protection
including footwear that offers a good grip
AVOID wearing loose garments that may catch in moving parts
KNOW how to stop the machine in an emergency
NEVER interfere with any control settings on the engine
IF A FAULT develops DO NOT attempt any repair - immediately
contact the supplier from whom the machine was obtained
VISUALLY INSPECT the machine before use
KEEP IN MIND the operator is responsible for accidents or
hazards occurring to people or property
WEAR eye and ear protection and protective footwear
Using the dipstick provided, check the engine oil level. Top up with
10w/40 oil if necessary (if the dipstick is clear of oil).
Check fuel level. Only use unleaded petrol from a clean container.
Never re-fuel when the engine is hot or running. Leave 1” air space in
the fuel tank.
Switch ignition to ‘ON’ position (1).
If the engine is cold set the choke lever to ‘ON’ position (2).
Turn the fuel tap to ‘ON’ position (3).
Pull the recoil start handle gently until it engages then give it a good
strong pull to start the engine (4).
When the engine has started, release the choke lever after a few
seconds and return the throttle lever to idle position.
OPERATION
TO STOP ENGINE
OPERATING HINTS
MAINTENANCE GUIDE
Start the engine.
Align the Turf Cutter on the lawn.
Set the thickness of the turf required by moving the knob (7) up or
down and locking into position.
Raise the operating lever (5) fully to start the cutting blade.
Hold the handlebar and gently push the lifting lever (6) down to lower
the blade into the ground.
Move the wheel drive lever (8) to ‘I’ position to engage the drive to the
rear wheels and commence work.
At the end of a row lift the lifting lever (6) to raise the blade out of the
ground.
Release the operating lever (5) and disconnect the wheel drive by
moving the drive lever (8) to ‘O’ position.
Position the Turf Cutter to cut the next strip of turf.
If a large area is to be cut it may be preferable not to lift the turf until the
second or third pass has been made. This is so the wheels on the cut
side are rolling on the full width of the tread and not on only half the
width. This will maintain an even thickness of cut turf.
Should the machine encounter an immovable object in the ground,
release the operating lever at once and switch the engine off. Lift the
handlebars to the raised position and pull the machine back far
enough for the turf to be cut with a spade and the object removed. Re-
start the engine and commence work as before.
o
DO NOT work on slopes of more than 20 . If you are working on a
o
slope of less than 20 always work across the slope. Use wheel
chocks on a slope if the machine is left unattended.
DO NOT work the machine across long grass, mow the area first to
leave the grass no more than 1” high.
DO NOT work the machine on very hard, dry ground conditions. If
necessary moisten the lawn with a sprinkler first.
For engine maintenance please refer to engine manufacturers
manual.
Release the operating lever (5).
Set wheel drive lever to ‘O’ position (8).
Switch the ignition to ‘OFF’ position (1).
Turn the fuel tap to ‘OFF’ position (3).
WARNING: THE EXHAUST COVER MAY BE HOT - DO NOT
TOUCH
After every hour of operation stop the engine and remove the spark
plug cap. Check engine oil level (recommended oil SAE 10w/40).
Do not turn the machine on its side for cleaning.
Ensure that the blade is sharp as a blunt blade will result in poor
performance.
Replace the spark plug cap.
Lubricate the sliding clutch, shaft, and drive chain after every use.
Do not pressure wash the transmission assembly.
