Tracmaster CAMON TC12 Instruction Manual

CAMON
No liability will be accepted for any damage
caused to persons or property through failure
to observe the operating and safety instructions.
TURF CUTTER
TC12
OPERATING
INSTRUCTIONS
&
SAFETY NOTES
OPERATING
INSTRUCTIONS
&
SAFETY NOTES
VIBRATION & SOUND LEVELS
2
Machine RPM Vibration m/sec Sound Level
3 Axis dB(A)
TC12 Turf Cutter 2800 9.3 86.0
Tracmaster Ltd, Teknol House, Victoria Road, Burgess Hill RH15 9LH
Tel: [phone] Fax: [phone]
Website: www.tracmaster.co.uk E-mail: [e-mail]
© Tracmaster Ltd 2006.
Specifications are subject to change without prior notice.
OP/TC12/0906
Serial
number
Fuel filler
cap Lift / lower
lever
Operating
lever
Ignition
switch
GRP
cover
Blade
Oil filler
plug
Fuel tap Choke
lever
Starter
handle
WEAR EAR
PROTECTION WEAR SAFETY
FOOTWEAR
WEAR EYE
PROTECTION
READ CAREFULLY
IMPORTANT

S A F E T Y
TO START PETROL ENGINE
ALWAYSstarttheengineintheopenair
DONOTsmokewhenrefuelling
DONOTmixOILwiththefuel
ALWAYS stop the engine before making any adjustments,
refuelling, moving or cleaning, or when the unit is
unattended
USE ONLY unleaded petrol from fuel containers designed for
this purpose - refuel outdoors only and replace the tank cap
securely
IN CASE of petrol spillage move the machines away from the
area of spillage and allow the petrol vapours to dissipate
beforestartingtheengine
DONOTremoveanysafetyguardsthatarefitted
DO NOT touch any moving parts or attempt any maintenance
whilst the machine is running - KEEP HANDS AND FEET
AWAY
BEFORE starting work clear the work area of any objects that
coulddamagethemachine
DO NOT allow children or anyone uninstructed to operate the
machine-KEEP ANIMALS AWAY o
DONOTuseonslopesorbanksofmorethan20
ALWAYS wear suitable clothing to give personal protection
includingfootwearthatoffersagoodgrip
AVOIDwearingloosegarmentsthatmaycatchinmovingparts
KNOWhowtostopthemachineinanemergency
NEVERinterferewithanycontrolsettingsontheengine
IF A FAULT develops DO NOT attempt any repair - immediately
contactthesupplierfromwhomthemachinewasobtained
VISUALLYINSPECTthemachinebeforeuse
KEEP IN MIND the operator is responsible for accidents or
hazardsoccurringtopeopleorproperty
WEAReyeandearprotectionandprotectivefootwear
Using the dipstick provided, check the engine oil level. Top up with
10w/40oilifnecessary(ifthedipstickisclearofoil).
Check fuel level. Only use unleaded petrol from a clean container.
Neverre-fuelwhentheengineishot or running. Leave1”airspacein
thefueltank.
Switchignitionto‘ON’position.
Iftheengineiscoldsetthechokeleverto‘ON’position.
Turnthefueltapto‘ON’position.
Pull the recoil start handle gently until it engages then give it a good
strongpulltostarttheengine.
When the engine has started, release the choke lever after a few
secondsandreturnthethrottlelevertoidleposition.
OPERATION
TO STOP ENGINE
OPERATING HINTS
MAINTENANCE GUIDE
AligntheTurfCutteronthelawn.
Raisetheoperatingleverfully.
Gently push down on the lifting lever to lower the blade into the
ground.
Although the machine has assisted drive to the rear wheels, a gentle
continuous pushing of the machine is required for the machine to
advanceatamediumwalkingpace.
At the end of a row, keep the operating lever fully engaged and lift the
handlebars. This will allow the blade to cut out of the ground and the
handlebarswillautomaticallylockintotheraisedposition.
Release the operating lever for the engine to return to tick-over. The
cutturfmaynowberolledup.
Ifalargeareaistobecutitmaybepreferablenottolifttheturfuntilthe
secondorthirdpass has beenmade. Thisissothe wheels onthecut
side are rolling on the full width of the tread and not on only half the
width. Thiswillmaintainaneventhicknessofcutturf.
Should the machine encounter an immovable object in the ground,
release the operating lever at once and switch the engine off. Lift the
handlebars to the raised position and pull the machine back far
enoughfortheturftobecutwithaspadeandtheobjectremoved. Re-
starttheengineandcommenceworkasbefore.
o
DO NOT work on slopes of more than 20 . If you are working on a
o
slope of less than 20 always work across the slope. Use wheel
chocksonaslopeifthemachineisleftunattended.
DO NOT work the machine across long grass, mow the area first to
leavethegrassnomorethan1”high.
DO NOT work the machine on very hard, dry ground conditions. If
necessarymoistenthelawnwithasprinklerfirst.
For engine maintenance please refer to engine manufacturers
manual.
Releasetheoperatinglever.
Switch the ignition to ‘OFF’ position.
Turn the fuel tap to ‘OFF’ position.
WARNING: THE EXHAUST COVER MAY BE HOT - DO NOT
TOUCH
After every hour of operation stop the engine and remove the spark
plugcap. Checkengineoillevel(recommendedoilSAE10w/40).
Donotturnthemachineonitssideforcleaning.
Replacethesparkplugcap.
Ensure that the blade is sharp as a blunt blade will result in poor
performance.
