TradeQuip 2081T User manual

03/20 Product Code: 2081T
Made in China to TQB Brands Pty Ltd specifications.
Visit us at www.tqbbrands.com.au
About the TradeQuip brand
The 'TradeQuip' brand of workshop equipment, is designed for use in a demanding workshop
environment by professional users. With proven and trusted “Made for the
Trade” reliability, 'TradeQuip' branded products offer the very best in performance for an
affordable price. All backed by a 1year trade guarantee across 1,000+ distributors Australia wide.
TRANSMISSION
ENGINE CRANE
LIFTER
Product Code: 2081T
Specifications
Safe Working Capacity: 800kg
Minimum Height: 160mm
Maximum Height: 790mm
Cradle Dimensions: 235x235mm
Cradle Dimensions: 335x335mm (Fingers Extended)
Forward Tilt: 55°
Backward Tilt: 6°
Right Tilt: 6°
Left Tilt: 12.5°
Chassis: 940x475mm
Nett Weight: 51.5kg
Carton: 975 x 485 x 215mm
Gross Weight: 54kg

03/20 Product Code: 2081T
Made in China to TQB Brands Pty Ltd specifications. Page | 2
Visit us at www.tqbbrands.com.au
WARNING
IMPORTANT: READ ALL INSTRUCTIONS BEFORE USE
WARNING
The instructions and warnings contained in this manual should be read and understood before using or operating this equipment.
Do not allow anyone to use or operate this equipment until they have read this manual and have developed a thorough
understanding of how this equipment works. Failure to observe any of the instructions contained in the manual could result in
severe personal injury to the user or bystanders, or cause damage to the equipment and property. Keep this manual in a
convenient and safe place for future reference.
Whilst every effort has been made to ensure accuracy of information contained in this manual, the TQB Brands Pty Ltd policy of
continuous improvement determines the right to make modifications without prior warning.
CONTENT
WARNING ..................................................................................................................................................................................................................2
CONTENT ...................................................................................................................................................................................................................2
STANDARD OPERATING PROCEDURE ........................................................................................................................................................................3
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE...........................................................................................................................................4
PARTS DIAGRAM........................................................................................................................................................................................................5
PARTS LIST .................................................................................................................................................................................................................6
TROUBLESHOOTING ..................................................................................................................................................................................................6
WARRANTY................................................................................................................................................................................................................7

03/20 Product Code: 2081T
Made in China to TQB Brands Pty Ltd specifications. Page | 3
Visit us at www.tqbbrands.com.au
PRE-OPERATIONAL SAFETY CHECKS
Save these instructions. For your safety, read, understand, and follow the information provided with and on this 800kg
Transmission Lifter before using.
DO NOT exceed the maximum lifting load capacity of 800kg.
Only use this transmission lifter on a surface that is stable, level, smooth, dry and capable of sustaining the load. Keep
the surface free from unrelated materials and ensure that there is adequate lighting.
DO NOT use on tarmac, or any other soft surface as the transmission lifter may sink or topple.
Vehicle must be properly and adequately supported before commencing work with this transmission lifter.
This transmission lifter is used as an aid in the removal and installation of a transmission or a differential as individual
components. DO NOT use it for any other purpose than it is designed for.
Always centre the load on the saddle of this transmission lifter and be sure the transmission is stable and secure before
raising or lowering.
DO NOT use the transmission lifter to lift or support a heavy load such as a differential with axle or a transmission with
bell housing which is bulky and difficult to balance, and may cause the transmission lifter to tip over and lead to
equipment damage and/or serious personal injury.
Never move this transmission lifter with a load any higher off the ground than necessary and always move it slowly and
carefully.
Transfer the load immediately to appropriate support device for service or repair.
DO NOT operate this transmission lifter when you are tired or under the influence of alcohol, drugs or any intoxicating
medication.
DO NOT allow untrained persons to operate this product and DO NOT make any modifications to this product.
DO NOT tamper with the safety valve.
DO NOT expose the transmission lifter to rain or any other kind of inclement weather.
When servicing, use only TradeQuip identical replacement parts. Use of any other parts will void the warranty.
Use the right product for the job. There are certain applications for which this Transmission Lifter was designed. Do not
modify the Transmission Lifter and do not use the Transmission Lifter for a purpose for which it was not intended.
Warning:
Vehicle must be properly and adequately supported before commencing work with this Transmission Jack.
INTENDED USE
Designed for the removal, installation and transportation (in the lowered position) of passenger vehicle transmissions that are
raised by an in-ground or above-ground lift.
STANDARD OPERATING PROCEDURE
DO NOT use this machine unless you have been trained and assessed to a competent level in its sate use and operation, and
have been given permission to use this
Safety glasses must be worn when operating this
equipment
Long loose hair must be contained when operating
this equipment
Safety footwear must be worn when operating
this equipment
Close fitting/protective clothing must be worn
when operating this equipment
Rings and jewellery must not be worn when
operating this equipment

03/20 Product Code: 2081T
Made in China to TQB Brands Pty Ltd specifications. Page | 4
Visit us at www.tqbbrands.com.au
ASSEMBLY, OPERATION, PREVENTITIVE MAINTENANCE
1. FEATURES
This TradeQuip 'Made for the Trade' wide chassis floor-style 800kg Transmission Jack features a wide chassis, fully adjustable
4way tilt cradle, four easy-roll castors and a swivel pump handle that can be repositioned in tight spots. The extra-wide base
design lowers the centre of gravity to add stability and the fully adjustable cradle provides convenient adaptability that
conforms to many types of transmission pan configurations and angles. TradeQuip Transmission Jacks hydraulic systems are
powered with a high quality hydraulic oil, to offer better corrosion resistance and high/low temperature flexibility. This jack
is finished in high gloss oil, grease and dirt-resistant paint, for long lasting durability and easy clean-up. The lead-free paint
finish is applied after a thorough chemical wash to ensure a long-lasting gloss and to minimise corrosion.
2. BEFORE USE
Prior to each use conduct a visual inspection by checking for abnormal conditions, such as cracked joints and damaged,
loose, or missing parts.
Purge the hydraulic system to eliminate any air in the system.
1. Remove the oil fill plug from the top of the hydraulic ram.
2. Turn the release valve counter-clockwise to open.
3. Pump the handle up and down quickly several times to purge air from the system.
4. Check the hydraulic oil level and fill to 6mm below the fill port.
5. Replace the oil fill plug and close the release valve by turning it clockwise.
3. OPERATION
Warning: Vehicle must be properly and adequately supported before commencing work with this Transmission Jack.
REMOVING A TRANSMISSION
1. Before each use check the hydraulic oil level and fill to 6mm below the fill port.
2. Once the vehicle is raised and secured on Jack Stands, clear the area underneath the vehicle.
3. Disconnect one end of the chain and allow it to hang free.
4. Move the Transmission Jack underneath the transmission.
5. Close the release valve.
6. Pump the handle to raise the Transmission Jack.
7. Stop just below the transmission and align the cradle to the transmission with the tilt knobs.
8. Continue raising the cradle up to the transmission to determine where you will need to adjust the supports. All four
supports need to grip and make contact with the transmission.
9. After determining where they need to be set, loosen the threaded bolts on each support, and adjust it to the proper
setting for the transmission. Tighten the bolts.
10. Raise the unit again to make contact with the transmission, making sure all of the supports are in firm contact.
11. Wrap the chain securely around the transmission, and hook the chain to the bracket on the other side of the cradle.
12. Once it is securely fastened, release the bolts holding the transmission in place.
13. Make sure the area is clear of people and tools, and check the transmission is securely held in place.
14. Slowly open the release valve to lower the Transmission Jack.
15. Move the Transmission Jack from under the vehicle an perform the necessary maintenance.
RE-INSTALLING A TRANSMISSION
1. Move the Transmission Jack so that the transmission is lined up properly with its connection points.
2. Close the release valve.
3. Pump the handle to gradually raise the Transmission Jack, while guiding the Transmission Jack into place.
4. Secure the transmission into place using its hardware.
5. Ensure the transmission is securely installed.
6. Disconnect one end of the chain and allow it to hang free.
7. Clear the area near the Transmission Jack, and slowly open the release valve to lower the jack.
8. Move the Transmission Jack clear of the vehicle.

03/20 Product Code: 2081T
Made in China to TQB Brands Pty Ltd specifications. Page | 5
Visit us at www.tqbbrands.com.au
4. STORAGE
This Transmission Jack should always be stored with the Lift Arm fully lowered in a dry location on a level surface.
5. MAINTENANCE
Replace or repair damaged parts. Use recommended parts only. Non authorised parts may be dangerous and will
invalidate the warranty.
CHANGING THE HYDRAULIC OIL
1. Change the hydraulic jack oil at least once a year.
2. Fully lower the transmission lifter, remove the oil fill plug on the side of the hydraulic ram.
3. Tip the Transmission Jack to allow the old hydraulic oil to drain out of the housing completely, dispose of the old
hydraulic oil in accordance with local regulations.
4. With the Transmission Jack upright, completely fill the hydraulic ram with a high quality hydraulic oil (not included) until
the oil just begins to run out of the oil fill hole.
5. Open the release valve and pump the handle to bleed air from the system.
6. Reinstall the oil filler plug.
7. Clean with a clean cloth using a mild detergent.
8. Always store the Transmission Jack in a safe, dry location.
6. SERVICE & REPAIR
Any Transmission Jack found damaged in any way, or found to be worn or operates abnormally should be removed from
service until repaired by an authorised service agent. Owners and / or operators should be aware that repair of this product
may require specialised equipment and knowledge. Only authorised parts, labels and decals shall be used on this equipment.
Annual inspection of the Transmission Jack is recommended and can be made by an authorised repair facility to ensure that
your equipment is in optimum condition and that the equipment has the correct decals and safety labels specified by the
manufacturer.
PARTS DIAGRAM

03/20 Product Code: 2081T
Made in China to TQB Brands Pty Ltd specifications. Page | 6
Visit us at www.tqbbrands.com.au
PARTS LIST
TROUBLESHOOTING
PROBLEM
POSSIBLE CAUSE
ACTION
Transmission Jack does
not operate when
handle is pumped
1. Release valve not closed
tightly.
2. The steel ball is immersed
inside for too long.
3. Air in the hydraulic system.
1. Firmly close the release valve.
2. Open the release valve by turning it counter-clockwise,
pump up the handle 10-15 times.
3. Close the release valve by turning it clockwise, pump up
the handle 5-10 times.
4. Repeat step 1 & 2 x 3 times.
Transmission Jack will
not hold load
1. Release valve not tightly
closed.
2. Malfunction in lifter such as
dirt inside valve mechanism.
1. Firmly close the release valve.
2. Open the release valve by turning it counter-clockwise,
pump up the handle 10-15 times.
3. Close the release valve by turning it clockwise, pump up
the handle 5-10 times.
4. Repeat step 1 & 2 x 3 times.
Transmission Jack
reluctant to lower
when load removed
1. Oil reservoir overfilled.
2. Piston binding.
3. Over extended the ram.
1. Drain oil to correct level.
2. Clean and lubricate moving parts.
3. Replace ram.
Transmission Jack will
not extend to full
range of stroke
1. Low oil level.
1. Add hydraulic oil to the Transmission Jack.
Part
Description
Qty
Part
Description
Qty
1
Handle Grip (incl w/#2)
1
28
Nut M10
1
2
Handle, Black (incl #1)
1
29
Slave Trunnion
1
3
Bolt M8*16
1
30
Cotter Pin 2*25
1
4
Spring
1
31
Adjusting Screw Rod
1
5
Pump Assembly
1
32
Hook
1
6
Bolt 12*25
4
33
Wing Nut M6
1
7
Washer 12
4
34
Bolt
1
8
Washer 25
2
35
Nut M10
6
9
Lift Arm Pin
1
36
Adjusting Screw Rod
1
10
Washer 8 (incl w/#12)
16
37
Stop Bushing
1
11
Nut M8 (incl w/#12)
16
38
Nut M12
2
12
Swivel Castor Assembly
4
39
Washer 22
2
13
Frame Assembly
1
40
Trunnion
1
14
Bolt M8*20 (incl w/#12)
16
41
Finger Base
4
15
Retaining Ring18
4
42
Washer 12
4
16
Trunnion
1
43
Bolt M12*20
4
17
Pin 4*45
1
44
Finger
4
18
Guide Arm
2
45
Bolt Set
1
19
Grease Fitting
1
46
Nut
1
20
Washer 16
4
47
Bolt M10
1
21
Connect Axle
1
48
Connect Axle
1
22
Lift Arm Assembly
1
49
Threaded Trunnion
1
23
Link Rod
2
50
Cradle Assembly
1
24
Pin 4*10
2
51
Safety Chain
1
25
Threaded Trunnion
1
52
Cradle Plate
1
26
Bearings
2
53
Cotter Pin
1
27
Washer 10
7

03/20 Product Code: 2081T
Made in China to TQB Brands Pty Ltd specifications. Page | 7
Visit us at www.tqbbrands.com.au
WARRANTY
TradeQuip products have been carefully tested and inspected before shipment and are guaranteed to be free from defective
materials and workmanship for a period of 12 months from the date of purchase except where tools are hired out when the
guarantee period is ninety days from the date of purchase.
Should the machine develop any fault, please return the complete tool to your nearest authorised warranty repair agent or contact
TQB Brands Pty Ltd Warranty team –[e-mail].
If upon inspection it is found that the fault occurring is due to defective materials or workmanship, repairs will be carried out free
of charge. This guarantee does not apply to normal wear and tear, nor does it cover any damage caused by misuse, careless or
unsafe handling, alterations, accident, or repairs attempted or made by any personnel other than the authorised TQB Brands Pty
Ltd repair agent.
This guarantee applies in lieu of any other guarantee expressed or implied and variations of its terms are not authorised.
Your TQB Brands Pty Ltd guarantee is not effective unless you can produce upon request a dated receipt or invoice to verify your
proof of purchase within the 12 month period.
Consumer Guarantee
Our goods come with a guarantee that cannot be excluded under the Australian Consumer Law. You are entitled to a replacement
or refund for a major failure and compensation for any other reasonably foreseeable loss or damage. You are also entitled to have
the goods repaired or replaced if the goods fail to be of acceptable quality and the failure does not amount to a major failure.
All images and illustrations shown are for reference purposes only. All information, specifications and illustrations in this manual
are based on the latest information available at the time of publication and are subject to change without notice. The
information in this manual is periodically revised to ensure the latest information is included. Download the latest version of this
manual and other related technical documentation from www.tqbbrands.com.au.
