Transcend JetDrive SSD Upgrade Kit User manual

1
JDM
Installation Guide
Part 1: how to install the JetDrive SSD Upgrade Kit into your Mac
- OS X 10.10 or earlier
- OS X 10.11 (El Capitan)
- OS X 10.13 (High Sierra)
Part 2: how to install the JetDrive SSD into the enclosure
CAUTION!
Please take the following electrostatic discharge
(ESD) precautions during installation:
1. Work on a static-free surface
2. Wear an anti-static wrist strap

2
Part 1:
How to install the JetDrive SSD Upgrade Kit into
your Mac

3
OS X 10.10 or earlier

4
Step 1
Install your JetDrive into the included enclosure. Please see Part 2 for more details.
Step 2
Connect the enclosure to your Mac.

5
Step 3
Turn on your Mac and hold the “Command+R”keys during startup to enter Mac OS
X Utilities.
Step 4
Select “Disk Utility” and click “Continue.”

6
Step 5
Click the “Erase” tab and select “Mac OS Extended (journaled)” as the format. Enter
a name for your JetDrive. Click “Erase.”
※Please make sure that the correct drive is selected before starting to erase.
Step 6
You will see the following warning message before the erase process starts.
Click “Erase” to continue.

7
Step 7
Click the “Restore” tab, select “Macintosh HD” as the source and drag your JetDrive
partition into the destination field. Click “Restore” to start the cloning process. This
step may take a few minutes.
Step 8
After the cloning process has completed, shut down your Mac and remove your
JetDrive from the enclosure.

8
Step 9
Use the included P5 screwdriver to remove the MacBook bottom case and the T5
screwdriver to remove the single screw holding the SSD. Gently remove the original
SSD and insert your JetDrive. Tighten all screws to finish the installation.
※Remember to disconnect the power adapter prior to the installation process.
Step 10
Turn on your Mac, go to System Preferences and click Startup Disk. Select your new
JetDrive as the startup disk and restart your Mac.

9
OS X 10.11 (El Capitan)

10
Step 1
Install your JetDrive into the included enclosure. Please see Part 2 for more details.
Step 2
Connect the enclosure to your Mac.

11
Step 3
Turn on your Mac and hold the "Command+R" keys during startup to enter Mac OS
X Utilities.
Step 4
Select “Disk Utility” and click “Continue.”

12
Step 5
Select JetDrive Transcend in the sidebar and click the "Erase" tab.
Step 6
Enter a name for your JetDrive. Set the Format to OS X Extended (Journaled) and
the Scheme to GUID Partition Map. Click "Erase."

13
Step 7
Go to the upper menu bar, and click "Edit" to find the "Restore" tab.

14
Step 8
Select "Macintosh HD" as the source.
Step 9
Click "Restore" to start the restore process.

15
Step 10
After the cloning process has completed, shut down your Mac and remove your
JetDrive from the enclosure.

16
Step 11
Use the included P5 screwdriver to remove the MacBook bottom case and the T5
screwdriver to remove the single screw holding the SSD. Gently remove the original
SSD and insert your JetDrive. Tighten all screws to finish the installation.
※Remember to disconnect the power adapter prior to the installation process.
Step 12
Turn on your Mac, go to System Preferences and click Startup Disk. Select your new
JetDrive as the startup disk and restart your Mac.

17
OS X 10.13 (High Sierra)

18
Step 1
Install your JetDrive into the included enclosure. Please see Part 2 for more details.
Step 2
Connect the enclosure to your Mac.

19
Step 3
Turn on your Mac and hold the "Command+R" keys during startup to enter Mac OS
X Utilities.
Step 4
Select “Disk Utility” and click “Continue.”

20
Step 5
Click the “View”tab. Select “Show All Devices”.
