The TRANSITION Networks J/E-CF-01 10BASE-T/10BASE-FL media
converters connect either unshielded or shielded 10BASE-T twisted-pair
copper to 10BASE-FL multimode fiber.
For network installation, the J/E-CF-01 media converter provides an RJ-45
twisted pair connector and a set of RX (receive) and TX (transmit) ST
connectors to 850 nm multimode fiber-optic cable.
CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE
PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in
damage to the public telephone network.
Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-Mitgliedstaaten
verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der Richtlinie 91/263/EWG zur
Angleichung der Rechtsvorschriften der Mitgliedstaaten über Telekommunikationsendeinrichtungen
einschliesslich der gegenseitigen Anerkennung ihrer Konformität.
Minneapolis, MN 55344 USA
10BASE-T/10BASE-FL Media Converters
J/E-CF-01
USER’S GUIDE
RX
TX
LINK
ACTIVITY
10BASE-T 10BASE-FL
J/E-CF-01
J/E-CF-01 in the Network . . . . . .2
Installation . . . . . . . . . . . . . . . . .3
Operation . . . . . . . . . . . . . . . . . .4
Fault Isolation and Correction . .5
Cable Specifications . . . . . . . . . .6
Technical Specifications . . . . . . .7
Compliance Information . . . . . . .8

J/E-CF-01 IN THE NETWORK
Use the J/E-CF-01 media converter (or two J/E-CF-01 media converters in pairs)
to connect a workstation to a remote hub or to connect two hubs.
TECHNICAL SPECIFICATIONS
Standards IEEE 802.3
Case Dimensions 3.8" x 2.4" x 1.0" (97mm x 61mm x 25mm)
Environment Temperature: 0-50°C (32°to 122°F )
Humidity 5-95%, non condensing
Altitude 0-10,000 feet
Warranty Lifetime
Power Supply Requirements Replace power supply with only the equivalent
input rating (see below) and output rating (regulated 12VDC at 500 mA).
TN PN Requirement Location
25010 240 volts, 50 hertz United Kingdom
25009 230 volts, 50 hertz Europe
25007 120 volts, 60 hertz USA/Canada/Mexico
25020 100 volts, 50-60 hertz Japan
25023 240 volts, 50 hertz Australia
DECLARATION OF CONFORMITY
Name of Mfg: Transition Networks
6475 City West Parkway, Minneapolis MN 55344 USA
Model: 10BASE-T/10BASE-FL Media Converter
Part Number: J/E-CF-01
Regulation: EMC Directive 89/336/EEC
Purpose: To declare that the J/E-CF-01 to which this declaration refers is in
conformity with the following standards.
EMC-CISPR 22: 1985 Class A; EN 55022: 1988 Class A; EN 50082-1:1992;
EN 60950 A4:1997; IEC 801.2, IEC 801.3, and IEC 801.4; IEC 950
I, the undersigned, hereby declare that the equipment specified above conforms to the
above Directive(s) and Standard(s).
_June 7, 1999_____
Stephen Anderson, Vice-President of Engineering Date
2 kilometers - 850 nM multimode
100 meters
100 meters
20 kilometers - 1300 nM singlemode
5 kilometers - 1300 nM multimode

CABLE SPECIFICATIONS
The physical characteristics of the media cable must meet or exceed IEEE 802.3
specifications.
Fiber Cable
MULTIMODE
Fiber Optic Cable Recommended: 62.5 / 125 µm multimode fiber
Attentuation: 3.7 dBm/ 1 kilometer @ 850 nm
Maximum Number of Nodes: 2 nodes
Maximum Cable Distance: 2 kilometers (6562 feet) / full-duplex
Media Standards: IEC 793-2, Type A1b, category 3.5 dB/km
Copper Cable and Connector
Category 3 or better twisted-pair copper wire is required. Either shielded
twisted-pair (STP) or unshielded twisted-pair (UTP) can be used. DO
NOT USE FLAT OR SILVER SATIN WIRE.
CATEGORY 3:
Gauge 24 to 22 AWG
Attenuation £11.5 dB/100m @ 5-10 MHz
Maximum Number of Nodes 2 nodes
Maximum Cable Distance 100 meters (200 meters with better cable
RJ-45 Pin-outs Pin 1=TD+, Pin 2=TD-,
Pin 3=RTD+, Pin 6=RD-
Twisted pair connection requires two active pairs configured as straight
through or crossover. The two active pairs in an Ethernet™network are
pins 1 & 2 and pins 3 & 6. Use only dedicated wire pairs (such as
blue/white & white/blue, orange/white & white/orange) for the active pairs.
INSTALLATION
Install Cable
NOTE: See page 6 for cable specifications and configurations.
COPPER
NOTE: KEEP TWISTED PAIR RUNS AS SHORT AS POSSIBLE.
CABLE CONNECTIONS BETWEEN A HUB AND THE MEDIA
CONVERTER MUST BE CONFIGURED AS CROSSOVER . CABLE
CONNECTIONS BETWEEN THE MEDIA CONVERTER AND A
TERMINAL, TRANSCEIVER OR NIC MUST BE CONFIGURED AS
STRAIGHT THROUGH.
•Locate or build 10BASE-T compliant cables with straight-through
or crossover configuration and with male RJ-45 plug connectors.
•Connect male RJ-45 plug connector at one end of cable to Media
Converter RJ-45 jack connector.
•Connect male RJ-45 plug connector at other end of cable to
10BASE-T terminal device RJ-45 jack connector (using straight-
through cable configuration) or to 10BASE-T hub RJ-45 jack
connector (using crossover cable configuration).
FIBER
•Locate or build 10BASE-FL compliant fiber cable with male two-
stranded TX to RX connectors at both ends.
•Connect male TX and RX cable connectors at one end of cable to
TX and RX female connectors, respectively, on Media Converter.
•Connect male TX and RX cable connectors at other end of cable
to RX and TX connectors of 802.3 compliant fiber device.
Connect to Power
•Install Power Adapter cord at back of Media Converter.
•Connect Power Adapter plug to AC power.
•Verify that Media Converter is powered by observing illuminated
LED(s).
Twisted
Pair #1
Twisted
Pair #2
Crossover Cable
Connectors for like devices
Twisted
Pair #1
Twisted
Pair #2
Straight Through Cable
Connectors for unlike devices

OPERATION
After installation, the media converter should function without operator
intervention.
Status LEDs
Use the status LEDs to monitor media converter operation in the network.
LINK (10BASE-T) Dark LED indicates lack of power.
Steady green LED indicates normal
operation.
One (1) blink indicates Link Down.
Five (5) blinks indicates Polarity Reversal.
ACTIVITY (10BASE-T) Flashing amber LED indicates 10BASE-T
activity.
LINK (10BASE-FL) Dark LED indicates lack of power.
Steady green LED indicates normal
operation.
One (1) blink indicates Link Down.
ACTIVITY (10BASE-FL) Flashing amber LED indicates 10BASE-FL
activity.
FAULT ISOLATION and CORRECTION
If the media converter fails, isolate and correct the fault by determining the
answers to the following questions and then taking the indicated action:
1. Are ANY LEDs on the media converter illuminated?
NO
•Is the power adapter the proper voltage and frequency for AC
outlet? NOTE: Refer to “Power Supply Requirements”on page 7.
•Is the power adapter properly installed in the media converter and
in the outlet?
•Contact Technical Support: [phone]/(800) LAN-WANS.
YES
•Proceed to step 2.
2. Does the green10BASE-T LINK LED blink once* and go off?
YES
•Check twisted pair cables for proper connection.
•Check straight-through/crossover cable configuration.
•Contact Technical Support: [phone]/(800) LAN-WANS.
NO
•Proceed to step 3.
3. Does the green10BASE-FL LINK LED blink once and go off?
YES
•Check fiber cables for proper connection.
•Verify that TX and RX cables on media converter are connected to
RX and TX ports, respectively, on other device.
•Contact Technical Support: [phone]/(800) LAN-WANS.
NO
•Proceed to step 4.
4. Is the amber 10BASE-T ACTIVITY LED illuminated?
NO
•Restart the workstation to restart the initialization process.
•Contact Technical Support: [phone]/(800) LAN-WANS.
YES
•Proceed to step 5.
5. Is the amber 10BASE-FL ACTIVITY LED illuminated?
NO
•Restart the workstation to restart the initialization process.
•Contact Technical Support: [phone]/(800) LAN-WANS.
YES
•Contact Technical Support: [phone]/(800) LAN-WANS.
*If 10BASE-T Status LED blinks 5 times, media converter is detecting and
automatically correcting polarity reversal in 10BASE-T cable. No action is
necessary.
LINK
ACTIVITY
10BASE-T 10BASE-FL
