Transition Networks J/FE-CF-03(LH) User manual

USER’S GUIDE
J/FE-CF-03
Stand-Alone media converter
•Fast Ethernet™
• Copper to Fiber
• 100Base-TX to 100Base-FX
Transition Networks J/FE-CF-03 Fast
Ethernet™ media converter connects 100
Mb/s twisted-pair copper cable to a duplex
100 Mb/s fiber-optic cable.
Use the J/FE-CF-03 series media converter
(or up to two media converters in series)
to extend over fiber, the distance between two 100BASE-TX devices (hub, switch,
workstation, etc.).
Part Number Port One - Copper Port Two - Duplex Fiber-Optic
J/FE-CF-03 RJ-45, 100Base-TX
100 m (328 ft)*
ST, 100Base-FX, 1300 nm multimode
2 km (1.2 miles)*
J/FE-CF-03(SC) RJ-45, 100Base-TX
100 m (328 ft)*
SC , 100Base-FX, 1300 nm multimode
2 km (1.2 miles)*
J/FE-CF-03(SM) RJ-45, 100Base-TX
100 m (328 ft)*
SC, 100Base-FX, 1300 nm singlemode
20 km (12.4 miles)*
J/FE-CF-03(LH) RJ-45, 100Base-TX
100 m (328 ft)*
SC, 100Base-FX, 1300 nm singlemode
40 km (24.9 miles)*
Part Number Port One - Copper Port Two - Duplex Fiber-Optic
J/FE-CF-03-100 RJ-45, 100Base-TX
100 m (328 ft)*
SC, 1310 mn TX/1550 nm RX, 20 km
(12.4 miles)*
J/FE-CF-03-101 RJ-45, 100Base-TX
100 m (328 ft)*
SC, 1550 mn TX/1310 nm RX, 20 km
(12.4 miles)*
*Typical maximum cable distance. Actual distance is dependent upon the physical
characteristics of the network installation.
Note: Install the J/FE-CF-03-100 and the J/FE-CF-03-101 in the same network as local
and remote peers.
Installation . . . . . . . . . . . . . . . . . . . . .2
Operation . . . . . . . . . . . . . . . . . . . . . .5
Cable Specifications . . . . . . . . . . . . .6
Technical Specifications . . . . . . . . . .7
Troubleshooting . . . . . . . . . . . . . . . .8
Contact Us . . . . . . . . . . . . . . . . . . . . .9
Compliance Information . . . . . . . . .11
Single Fiber Optic (install as a pair)

2
J/FE-CF-03
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Part Number Description
WMBS Optional Wall Mount Brackets
Length: 3.2 in. (81 mm), Fits converter length: 3.9 in. (99 mm)
SPS-1872-SA Optional External Power Supply; 18-72VDC Stand-Alone Wide-Input;
Output: 12.6VDC, 1.0 A
SPS-1872-CC Optional External Power Supply; 18-72VDC Piggy-Back Wide-Input;
Output: 12.6VDC, 1.0 A
Options Accessories (sold separately)
Installation
Installing the Cable
Fiber
1. Locate or build 100Base-FX compliant fiber cable with male, two-stranded TX
to RX connectors installed at both ends.
2. Connect the fiber cables to J/FE-CF-03 media converter as described:
• Connect the male TX cable connector the female TX port.
• Connect the male RX cable connector to the female RX port.
3. Connect the fiber cables to the other device (another media converter, hub,
etc.) as described:
• Connect the male TX cable connector the female RX port.
• Connect the male RX cable connector to the female TX port.
3
[email protected] -- Click the “Transition Now” link for a live Web chat.
Set the Two-Position Switch
A two-position switch (located on the back of the media monverter) allows
selection of Auto-Negotiation and Full- or Half-Duplex. Use a small, flat-blade
screwdriver (or a similar device) to set the switch according to the site requirements
see the drawing below.
Auto-Negotiation:
UP Enable Auto-Negotiation
DOWN Disable Auto-Negotiation
Full/Half Duplex:
UP Full Duplex -- Advertises 100 Mb/s full-duplex only during Auto-
Negotiation.
DOWN Half Duplex -- Used primarily when connecting to a hub. Operates at
100 Mb/s in duplex mode of the attached device.
Full/Half Duplex - UP=Full
Auto-Negotiation - UP=Enable
Installation -- Continued
Copper
1. Locate or build 100Base-TX compliant copper cables with male, RJ-45
connectors installed at both ends.
2. Connect the RJ-45 connector at one end of the cable to the RJ-45 port on the
J/FE-CF-03 media converter.
3. Connect the RJ-45 connector at the other end of the cable to the RJ-45 port on
the other device (switch, workstation, etc.).

4
J/FE-CF-03
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Installation -- Continued
Power the media converter
AC power:
1. Install the power adapter cord to the back of the media converter.
2. Connect the power adapter plug to AC power.
3. Verify that the media converter is powered by observing the illuminated LED
power indicator light.
DC power:
Consult the User’s Guide for the Transition Networks SPS1872-xx DC External
Power Supply for powering the media converter.
5
[email protected] -- Click the “Transition Now” link for a live Web chat.
RX
TX
100Base-FX 100Base-TX
Power
Copper
Fiber
Operation
Using status LEDs
Use the status LEDs to monitor the media converter operation in the network.
Power Steady LED indicates connection to external AC power.
Fiber Steady LED indicates fiber link connection.
Copper Steady LED indicates copper link connection.
Auto-Negotiation
The Auto-Negotiation feature allows the media converter to be used with 100Base-
TX ports. Using Auto-Negotiation, the media converter brings up the copper links
in the highest speed and mode possible for all attached network devices.
Full-Duplex network
In a full-duplex network, maximum cable lengths are determined by the type of
cables that are used. See page 1 (front cover) for the cable specifications for the
different J/FE-CF-03 models. (The 512-Bit Rule does not apply in a full-duplex
network.)
Half-Duplex network (512-Bit Rule)
In a half-duplex network, the maximum cable lengths are determined by the round
trip delay limitations of each Fast Ethernet™ collision domain. (A collision domain
is the longest path between any two terminal devices, e.g. a terminal, switch, or
router.)
The 512-Bit Rule determines the maximum length of cable permitted by calculating
the round-trip delay in bit-times (BT) of a particular collision domain. If the result
is less than or equal to 512 BT, the path is good.
For more information on the 512-Bit Rule, see the white paper titled “Collision
Domains” on the Transition Networks website at:
http://www.transition.com/learning/whitepapers/colldom_wp.htm

Cable Specifications
The physical characteristics must meet or exceed IEEE 802.3™ specifications.
Fiber cable
Bit Error Rate: <10-9
Singlemode fiber (recommended): 9 μm
Multimode fiber (recommended): 62.5/125 μm
Multimode fiber (optional): 100/140, 85/140, 50/125 μm
J/FE-CF-03 1300 nm multimode
Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm
Link Budget: 11.0 dB
J/FE-CF-03(SC) 1300 nm multimode
Fiber Optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber Optic Receiver Sensitivity: min: -30.0 dBm max: -14.0 dBm
Link Budget: 11.0 dB
J/FE-CF-03(SM) & (LH) 1300 nm singlemode
Fiber-optic Transmitter Power: min: -15.0 dBm max: -8.0 dBm
Fiber-optic Receiver Sensitivity: min: -31.0 dBm max: -8.0 dBm
Link Budget: 16.0 dB
J/FE-CF-03-100 1310 nm (TX)/1550 nm (RX) simplex
J/FE-CF-03-101 1550 nm (TX)/1310 nm (RX) simplex
Fiber-optic Transmitter Power: min: -13.0 dBm max: -6.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.0 dBm max: -3.0 dBm
Link Budget: 19.0 dB
Copper cable
Category 5:
Gauge: 24 to 22 AWG
Attenuation: 22.0 dB/100m @ 100 MHz
Maximum Cable Distance: 100 meters
•Straight-Through or Crossover cable may be used.
• Shielded Twisted-Pair (STP) or Unshielded Twisted-Pair (UTP) may be used.
• Pins 1&2 and 3&6 are the two active pairs in an Ethernet™ network .
• Use only dedicated wire pairs for the active pins:
(e.g., blue/white & white/blue, orange/white & white/orange, etc.)
• Do not use flat or silver satin wire.
6
J/FE-CF-03
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600 7 [email protected] -- Click the “Transition Now” link for a live Web chat.
Technical Specifications
For use with Transition Networks Model J/FE-CF-03 or equivalent
Product is certified by the manufacturer to comply with DHHS Rule 21/CFR,
Subchapter J applicable at the date of manufacture.
Standards: IEEE 802.3™
Data Rate: 100 Mb/s
Case Dimensions: 3.9" x 3.0" x 1.0" (100mm x 76mm x 25mm)
Shipping Weight: 2 pounds (0.9 kilograms)
Power Consumption: 2.8 watts, 200 mA @ 13.9 VDC
Power Supply DC Output: 12 VDC, 0.4 A (minimum)
minimum output regulation: 5%
Connector: 2.1mm barrel, center pin positive
MTBF* 48,135 hours
(MIL217F2 V5.0) (MIL-HDBK-217F)
128,553 hours (Bellcore7 V5.0)
Environment:
Tmra**: 0 to 60°C (32 to 140°F)
Storage Temp: -20 to 85°C (-4 to 185°F)
Humidity: 5-95%, non-condensing
Altitude: 0-10,000 feet
Warranty: Lifetime
**Manufacturer’s rated ambient temperature.
WARNING: Visible and invisible laser radiation when open. Do not stare into the
beam or view the beam directly with optical instruments. Failure to observe this
warning could result in an eye injury or blindness.
WARNING: Use of controls, adjustments or the performance of procedures other than
those specified herein may result in hazardous radiation exposure.
CAUTION: Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB, RS232,
RS422, RS485, DS1, DS3, Video Coax, etc., are intended to be connected to intra-
building (inside plant) link segments that are not subject to lightening transients or
power faults. Copper based media ports, e.g., Twisted Pair (TP) Ethernet, USB,
RS232, RS422, RS485, DS1, DS3, Video Coax, etc., are NOT to be connected to inter-
building (outside plant) link segments that are subject to lightening transients or power
faults. Failure to observe this caution could result in damage to equipment.
*MTBF is estimated using the predictability method. This method is based on MIL-
217F at 25°C ambient temperature, typical enclosure heat rise of 10°C, and nominal
operating conditions and parameters. Installation and configuration specific MTBF
estimates are available upon request. Contact Technical Support.

8
J/FE-CF-03
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Troubleshooting
If the media converter fails, isolate and correct the failure by determining the answers
to the following questions and then taking the indicated action:
1. Is the Power LED on the media converter illuminated?
NO
• Is the power adapter the proper type of voltage and cycle frequency for
the AC outlet?
• Is the power adapter properly installed in the media converter and in the
outlet?
• Contact Technical Support at [phone].
YES
• Proceed to step 2.
2. Is the Copper LED illuminated?
NO
• Check the copper cable for proper connection.
• Contact Technical Support at [phone].
YES
• Proceed to step 3.
3. Is the Fiber LED illuminated?
NO
• Check the fiber cables for proper connection.
• Verify that the TX and RX cables on the media converter are connected to
the RX and TX ports, respectively, on the other 100BASE-FX device.
• Contact Technical Support at [phone].
YES
• Contact Technical Support at [phone].
9
[email protected] -- Click the “Transition Now” link for a live Web chat.
Contact Us
Technical support
Technical support is available 24 hours a day.
US and Canada: 1-800-260-1312
International: 00-1-952-941-7600
Transition NOW
Chat live via the Web with Transition Networks Technical Support.
Log onto www.transition.com and click the Transition Now link.
Web-Based seminars
Transition Networks provides seminars via live web-based training.
Log onto www.transition.com and click the Learning Center link.
E-Mail
Ask a question anytime by sending an e-mail to our technical support staff.
[email protected]
Address
Transition Networks
6475 City West Parkway
Minneapolis, MN 55344, U.S.A.
telephone: [phone]
toll free: 800-526-9267
fax: [phone]

10
J/FE-CF-03
24-hour Technical Support: 1-800-260-1312 -- International: 00-1-952-941-7600
Declaration Of Conformity
Name of Mfg: Transition Networks
6475 City West Parkway, Minneapolis MN 55344 U.S.A.
Model: J/FE-CF-03 Series Media Converters
Part Number(s): J/FE-CF-03, J/FE-CF-03(SC), J/FE-CF-03(SM), J/FE-CF-03(SH),
J/FE-CF-03(LH), J/FE-CF-03-100, J/FE-CF-03-101
Regulation: EMC Directive 89/336/EEC
Purpose: To declare that the J/FE-CF-03 to which this declaration refers is in conformity
with the following standards.
EN 55022:1994; EN 55024:1998; FCC Part 15 Class A; EN 60950 A4:1997; UL 1950 (Power
Supply); 21 CFR subpart J
I, the undersigned, hereby declare that the equipment specified above conforms to the
above Directive(s) and Standard(s).
July 18, 2006_____
Stephen Anderson, Vice-President of Engineering Date
11
[email protected] -- Click the “Transition Now” link for a live Web chat.
Compliance Information
Power Supply is UL Listed
Power Supply is C-UL Listed (Canada)
CISPR22/EN55022 Class A + EN55204
CE Mark
FCC Regulations
This equipment has been tested and found to comply with the limits for a class A digital device,
pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable protection
against harmful interference when the equipment is operated in a commercial environment. This
equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in
accordance with the instruction manual, may cause harmful interference to radio communications.
Operation of this equipment in a residential area is likely to cause harmful interference, in which
case the user will be required to correct the interference at the user's own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set out
on the radio interference regulations of the Canadian Department of Communications.
Le présent appareil numérique n'émet pas de bruits radioélectriques dépassant les limites applicables
aux appareils numériques de la class A prescrites dans le Règlement sur le brouillage
radioélectrique édicté par le ministère des Communications du Canada.
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause radio interference in
which case the user may be required to take adequate measures.
Achtung !
Dieses ist ein Gerät der Funkstörgrenzwertklasse A. In Wohnbereichen können bei Betrieb dieses
Gerätes Rundfunkstörungen auftreten, in weichen Fällen der Benutzer für entsprechende
Gegenmaßnahmen werantwortlich ist.
Attention !
Ceci est un produit de Classe A. Dans un environment domestique, ce produit risque de créer des
interférences radioélectriques, il appartiendra alors à l'utilsateur de prende les measures spécifiques
appropriées.
In accordance with European Union Directive 2002/96/EC of the European Parliament
and of the Council of 27 January 2003, Transition Networks will accept post usage
returns of this product for proper disposal. The contact information for this activity can
be found in the 'Contact Us' portion of this document.
CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE
PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in
damage to the public telephone network.
Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-
Mitgliedstaaten verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der
Richtlinie 91/263/EWG zur Angleichung der Rechtsvorschriften der Mitgliedstaaten über
Telekommunikationsendeinrichtungen einschliesslich der gegenseitigen Anerkennung ihrer
Konformität.

12
Trademark Notice
All trademarks and registered trademarks are the property of their respective owners.
Copyright Restrictions
© 2003 Transition Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any means -
graphic, electronic, or mechanical - without written permission from Transition Networks.
Printed in the U.S.A. 33254.D
J/FE-CF-03
