Transition Networks C/HSTR-CF-01(SC) User manual

MEDIA CONVERTER TECHNICAL SPECIFICATIONS
Standards IEEE 802.5, 802.5t
Delay 400ns round trip
Case dimensions 4.7" x 3.0" x 1.0" (119mm x 76mm x 25mm)
Shipping Weight 3 lbs (0.9 kg)
Environment Temperature: 0-40°C (32° to 104° F )
Humidity 10-90%, non condensing
Altitude 0-10,000 feet
Maximum number
media converters in series: 2
Warranty Five years
CAUTION: RJ connectors are NOT INTENDED FOR CONNECTION TO THE
PUBLIC TELEPHONE NETWORK. Failure to observe this caution could result in
damage to the public telephone network.
Compliance Information
UL Listed
C-UL Listed (Canada)
CISPR/EN55022 Class A
FCC Regulations
This equipment has been tested and found to comply with the limits for a class A digital device, pursuant
to part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful
interference when the equipment is operated in a commercial environment. This equipment generates,
uses, and can radiate radio frequency energy and, if not installed and used in accordance with the
instruction manual, may cause harmful interference to radio communications. Operation of this
equipment in a residential area is likely to cause harmful interference, in which case the user will be
required to correct the interference at the user’s own expense.
Canadian Regulations
This digital apparatus does not exceed the Class A limits for radio noise for digital apparatus set out on
the radio interference regulations of the Canadian Department of Communications.
European Regulations
Warning
This is a Class A product. In a domestic environment this product may cause radio interference in which
case the user may be required to take adequate measures.
Copyright Restrictions
© 1999 TRANSITION Networks.
All rights reserved. No part of this work may be reproduced or used in any form or by any means –
graphic, electronic, or mechanical – without written permission from TRANSITION Networks.
Trademark Notice
All registered trademarks and trademarks are the property of their respective owners. 33106.A
Der Anschluss dieses Gerätes an ein öffentlickes Telekommunikationsnetz in den EG-Mitgliedstaaten
verstösst gegen die jeweligen einzelstaatlichen Gesetze zur Anwendung der Richtlinie 91/263/EWG zur
Angleichung der Rechtsvorschriften der Mitgliedstaaten über Telekommunikationsendeinrichtungen
einschliesslich der gegenseitigen Anerkennung ihrer Konformität.
The TRANSITION Networks slide-in-module media converters, designed to be
installed in the TRANSITION Networks Media Conversion Center, E-MCC-1600,
connect unshielded or shielded High-Speed Token Ring twisted-pair copper cable
to High-Speed Token Ring multimode fiber-optic cable OR to High-Speed Token
Ring singlemode fiber-optic cable.
Minneapolis, MN 55344 USA
High-Speed Token Ring Copper/Fiber
Media Converter Slide-In Module
C/HSTR-CF-01(SC), C/HSTR-CF-01(SM)
USER’S GUIDE
C/TR-CF-01
Fiber Twisted Pair
Token Ring
Singlemode OR Multimode
Fiber
UTP or STP
Copper
C/HSTR-CF-01
Provides a Token Ring RJ-45 twisted-
pair connector and an RX (receive) and
a TX (transmit) ST connector to
multimode fiber-optic cable for fiber
network extension distances up to 2
kilometers.
C/HSTR-CF-01(SM)
Provides a Token Ring RJ-45 twisted-
pair connector and an RX (receive) and
a TX (transmit) ST connector to
singlemode fiber-optic cable for fiber
network extension distances up to 15
kilometers.
Status LEDs:
Power Illuminated green LED indicates connection to external AC power.
SDF Signal Detect/Fiber: Steady green LED indicates fiber port is
connected to device.
SDC Signal Detect/Copper: Steady green LED indicates
RJ-45 port is connected to device.
RXC Receive/Copper: Flashing green LED
indicates packets are seen on RJ-45
port.
RXF Receive/Fiber: Flashing green LED
indicates packets are seen on fiber port.
RX
TX
Fiber UTP/STP
Power
RXC
RXF
SDF
SDC
Power
RXC
RXF
SDF
SDC
UTP OR STP
Copper
Singlemode OR Multimode
Fiber

Switch
100 meters 2 kilometers - multimode
20 kilometers - singlemode
100 meters
1. Is the power LED on the media converter illuminated?
NO • Is the Slide-In-Module properly connected to the Media Conversion Center
chasis backplane?
• Is the Power Supply Module properly connected both to the Media
Conversion Center chasis backplane and to the AC outlet?
• Contact Technical Support at [phone]/ (800) LAN-WANS.
YES • Proceed to step 2.
2. Is the 100BASE-TX Link LED illuminated?
NO • Check UTP cables for proper connection and pin assignment. (See above.)
• Contact Technical Support at [phone]/ (800) LAN-WANS.
YES • Proceed to step 3.
3. Is the fiber Link LED illuminated?
NO • Check fiber cables for proper connection.
• Verify that TX and RX cables on media converter are connected to RX and
TX ports, respectively, on the other 100BASE-FX device.
• Refer to Tech Tips available at: http://www.transition.com
• Contact Technical Support at [phone]/ (800) LAN-WANS.
YES • Contact Technical Support at [phone]/ (800) LAN-WANS.
Troubleshooting
Installing Slide-In-Module(s)
CAUTION: Wear a grounding device and observe electrostatic discharge precautions
when installing Media Converter Slide-in-Module(s) in the 16-Slot Media Conversion
Center. Failure to observe this caution could result in damage to, and subsequent
failure of, the Media Converter Slide-in-Module(s).
NOTE: Slide-in-Modules can be installed in any installation slot, in any order.
To install the Media Converter Slide-in-Module in the E-MCC-1600 chassis:
1. Ensure that switches on circuit board are set correctly for site installation.
2. Remove Media Converter Slide-in-Module protective plate from selected installation slot
by removing two screws that secure plate to front of E-MCC-1600.
3. Carefully slide Media Converter Slide-in-Module into installation slot, aligning
Media Converter Slide-in-Module with installation guides.
NOTE : Ensure that the Media Converter Slide-in-Module is firmly seated against the
backplane.
4. Secure Slide-in-Module to E-MCC-1600 chassis by rotating captive screw attached to
Slide-in-Module clockwise into chassis.
C/HSTR-CF-01
Switch Settings and Cable Requirements
The physical characteristics of the media cable must meet or exceed IEEE 802.5t
specifications.
Token Ring Cable Specifications
Copper Cable Specifications
Category 5 wire or better is required. Either shielded twisted pair (STP) or unshielded
twisted pair (UTP) can be used. DO NOT USE FLAT OR SILVER SATIN WIRE.
Category 5:
Gauge 24 to 22 AWG
Attenuation 22 dB/100’ @ 100 MHz
Differential Characteristic Impedance 100 Ω±15%
Maximum Cable Distance: 100 meters (330 feet)
Fiber Cable Specifications
MULTIMODE
Fiber-optic Cable Recommended: 62.5 / 125 µm multimode fiber
*Optional: 100 / 140 µm multimode fiber
85 / 125 µm multimode fiber
50 / 125 µm multimode fiber
Fiber-optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.5 dBm max: -14.0 dBm
Wavelength: 1300nM
Bit error rate: ≤10-9
Maximum Cable Distance: 2 kilometers
SINGLEMODE
Fiber-optic Cable Recommended: 9 µm singlemode fiber
Wavelength: 1300nM
Bit error rate: ≤10-9
Fiber-optic Transmitter Power: min: -19.0 dBm max: -14.0 dBm
Fiber-optic Receiver Sensitivity: min: -32.5 dBm max: -8.0 dBm
Maximum Cable Distance: 20 kilometers
3
4
5
Twisted
Pair #1 Twisted Pair #2
Straight Through Cable
3
4
5
Twisted pair connection requires two active pairs
configured as straight through. The two active
pairs in a Token Ring network are pins 4 & 5 and
pins 3 & 6. Use only dedicated wire pairs (such
bl / hi hi /bl / hi
Station Lobe
TR-CF-01
Station: Selected when connecting media
converter to terminal device.
Lobe: Selected when connecting media
converter to switch.
NOTE: Use small flatblade screwdriver or similar device to
set recessed switch. Refer to label on top of media converter
for switch settings.
