Transmitter Solutions Wi-Enterprise Instruction Manual

3
Contents
6
Installation Diagrams
9
8
System Overview
4
Installation Instructions
12
Network Diagrams
Wiring Diagrams
21
Fingerprint Enrollment
Operation Instructions
Wi-Enterprise
Controller
www.transmittersolutionssmart.com Installation & User Manual

2
27
Technical Specification
Power Supply 230 VAC
Current consumption 30mA
Fuse Rating 230VAC 315mA T
Moisture Resistance Indoor Use Only
Dimensions W. 260mm D. 262mm H. 55mm
Technical Specs - Wi-Enterprise Controller
Power Supply 12 DC
Current consumption 110mA
Current consumption with load (max) 145mA
Relay Contact Rating 5 Amps /230V ac
Operating Temperature - 20 C to +60 C
Moisture Resistance IP 67 ( IP65 on Wi-Bio )
Dimensions - Flush Mount W. 87mm D. 21mm H. 119mm
- Surface Mount W. 87mm D. 35mm H. 119mm
Technical Specs - Wi- Enterprise Door Controls
Features
Doors controlled
Users
User Groups
Time Zones
Door Groups
Reporting Facility
Challenge Facility
Logging
Input/Output Mapping
Supports Wireless & RS485 Networks
Automatic Backup Facility
Database Encryption
20
20000
128
128
128
Yes
Yes
Unlimited
CCTV & Lift control
Yes
Yes
Yes
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Ctrl Door No. Door Type Door Location Name Walk Test
2
3
Installation Records

3
26 Installation Record
Installation Steps
Step Description Page
1 Install the Controller using the Installation Diagrams 4-5
2 Wire the Controller using the Wiring Diagrams 8
3 Install and wire each Door Control. Refer to the Door Control
Manual for instructions.
4 Connect the Controller to the PC using Network Diagrams 9-11
5 Restoring Factory Defaults 11
6 Setting up TCP-IP 12
7 Phase 1- Setting up the Controller via the PC application 14
8 Phase 2 - Configuring the Controller via the PC application 15
9 Phase 3 - Defaulting Door Controls 16
10 Phase 4 - Enrolling Door Controls 16-18
11 Phase 5 - Configuring Users 19
12 Phase 6 - Configuring Access Levels 20
13 Phase 7 - Downloading Configuration 20
14 Enrolling User Fingerprints 21
15 Correct Finger Placement techniques 22-25
Installation Steps
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
1
2
3
4
5
6
7
8
9
10
Ctrl Door No. Door Type Door Location Name Walk Test
1
2

Control Panel opening
remove screw cap remove retaining
screw
to remove cover pull
out on right and slide left
to remove cover pull
out on right and slide left
to remove cover
pull forward on
right and slide left
4 Installation Diagrams
Incorrect Finger Placement
25
Finger Placement Wi-BIO

Control Panel features
mount with 4 x 1.5 inch
No. 8 Security Type screws
rear tamper
switch
cable
entry
cable
entry
cable
entry
cable
entry
spare cap
access to rear
void for wiring
spirit level
mains pcb
mount holemount hole
mount hole
5
Installation Diagrams
Correct Finger Placement
24 Finger Placement Wi-BIO

6 System Overview
RS485 Connection to Door Controls
Door Control
#1
Door Control
#2
Door Control
#3
Door Control
#4 - 20
RS485 Network to Door Controls
Max Cable Length 1.4 km.
Daisy Chain Configuration Only.
Controller
#1
Controller
#2 - 3
Note: If using a single Controller,
an RS232 cable may be used.
Max cable length 10 meters
Place a 120ohm
Termination Resistor
across A & B on the last
Door Control in the chain.
Place a 120ohm
Termination Resistor
across A & B on the
Controller
TCP-IP connection to Controllers
or
RS485 Network to Controllers
Max number of Controllers 3
Max Cable Length 1.4 km
Incorrect Finger Placement
23
Finger Placement Wi-BIO
Poor Quality Image
Note: Poor Quality image, No Fingerprint
core on sensor window.
This can result in poor template quality that
can lead to false rejection issues later when
the user is trying to gain access.
Note: Incorrect placement : finger does not
fully cover the sensor window.

Wireless Connection to Door Controls
Door Control
#1
Door Control
#2
Door Control
#3
Door Control
#5 - 20
TCP-IP connection to Controllers
or
RS485 Network to Controllers
Max number of Controllers 3
Max Cable Length 1.4 km
Controller
#1
Controller
#2 - 3
Door Control
#4
Note: Door Controls can be installed within 30 meters
of the Controller or within 30 meters of any other Door Control
as each Door Control will function as a repeater. Each Door Control
transmits data to/from the Controller. These distances are a guideline.
The actual communication range depends on building shape and
construction methods used.
7
System Overview
Note: If using a single Controller,
an RS232 cable may be used.
Max cable length 10 meters
Correct Finger Placement
22 Finger Placement Wi-BIO
Note: Good Quality image, Fingerprint core
is center of sensor window
Note: Ensure that the core of finger is
centered on the sensor window during
the enrollment process. This will increase
the quality of the fingerprint template.
Ensure a value of at least 90% is achieved.
Good Quality Image
Note: The System does not store the finger
print. It uses an algorithm to generate a
binary representation using sample points
from the fingerprint. It uses this information
to then validate each users fingerprint.

Note : Used ONLY for
Wired 485 Network
Connections.
A B COM TX RX
PC Network
PC Direct
PC Network Connections
can be used for multiple
controllers See page
10 for wiring
Wiring Diagrams
8 Wiring Diagrams
Door Network
A B COM
1 2 3 4
OFF
ON
TCP_IP
3V Lithium
Inputs/outputs
IP1
IP2
0V
IP3
IP4
12V
OP1
OP2
OP3
OP4
0V
VOUT
DAT
CLK
SEN
Inputs/outputs
Cable Tie
Fuse Rating : 230VAC 315mA
Warning : Installation should only be carried out
by a suitably qualified person only.
Cable Tie
retaining
clips
Main Input Cable
230VAC
Neutral
Earth
Live
Remove Battery Tab
Pull
21
Operation Instructions
Enrolling User FingerPrints
Step Description
Note: Make sure the USB Fingerprint reader is attached to the PC
1. On the Users Tab , Select a User for fingerprint enrolment
2. Click on the ‘Fingerprints’ button.
3. Click on ‘+’ button to begin and place finger on the enrolment reader. An
image of the fingerprint will appear on the screen. Ensure that the image
quality is good and a value of at least 90% is achieved. Refer to section
‘Finger Placement’ for correct finger placement and example of good
quality image. Repeat this process if this is not achieved on first attempt.
Two fingerprint templates can be saved for each user.
4. Click ‘Save’ using a good quality template only. Poor Quality templates can
lead to false rejections later when trying to gain access

9
Network Diagrams for Single Controller
A
B
0V
TX
RX
A
B
0V
Door Network
PC Network
Connect DB9 cable
to serial port on PC
Maximum cable
length 10 meters
Direct Connect - All Dip Switches OFF
PC Direct
DB9 Female
Serial Cable
PC Direct Connection can be used, when
using ONLY one GSD Controller.
Set the Direct address to
ALL dip switches OFF
(see below )
Network Diagrams
OFF
ON
1 2 3 4
1
5
2
3
4
9
8
7
6
See page 11 on “Configuring Controller Communication” to setup the application
for serial communications
20 Operation Instructions
Phase 7 - Downloading Configuration
Phase 6 - Configuring Access Levels
Step Description
Access Levels are controlled by creating UserGroups and assigning the
UserGroup to a User as described in section ‘Configuring Users’.
1. UserGroups are created by combining pairs of DoorGroups with
Timezones. Each UserGroup can have up to 6 pairs of DoorGroups and
Timezones. Select DoorGroups and Timezones from the drop-down menus
to add to the current UserGroup.
2. Timezones are the periods of time for each day of the week that access
will be granted. Select times and tick the days of the week this time is valid.
4 time periods can be created for each timezone. Select ‘Holiday Access’
to grant access for holiday periods. Double click on the ‘Holiday Access’ to
add days to the holiday periods. Use the calendar to select these days.
3. DoorGroups are created by grouping doors together. e.g. all the entry and
exit doors could be grouped together as ‘Peremiter Doors’. Select a Door
from the ‘All Available Doors’ window and drag it to the ‘Doors in Current
Group’ to add it to the Door Group. Repeat for adding doors as desired.
Step Description
After all users, access levels and door control settings have been finalised,
a full download to the controller should be carried out.
1. Go to the ‘Settings’ tab and click on ‘Download Configuration’. A pop-up
window will appear, tracking the status of the download. All settings will be
downloaded to the Controller and Door Controls.

10 Network Diagrams
Network Diagrams for Multiple Controllers
19200 9600
12V - 1
0V - 2
B - 3
A - 4
A
B
0V
TX
RX
PC Direct
12V
PC Network
Connect using RS232-RS485
cable to serial port on PC
PC Network Connections, when using more
than one GSD Controller.
Daisy chain the PC network A , B , 0V to each controller.
Set an individual address for each controller
between 1 & 3 using the dip switches
(see below )
RS485 Converter
A
B
0V
TX
RX
PC Direct
Controller 1
Controller 2
PC Network
Address 1 - Set SW1 ON Address 2 - Set SW2 ON Address 3 - Set SW3 ON
Controller 1 Controller 2
Set Baud Rate to 19200 Daisy Chain
each controller
A
B
0V
1 2 3 4
Controller 3
OFF
ON
1 2 3 4
OFF
ON
1 2 3 4
OFF
ON
Phase 5 - Configuring Users
Step Description
1. Enable a User by ticking the ‘Enabled’ box for each User
2. Assign a Name to the User
3. Assign a UserGroup from the drop-down menu. The UserGroup will
determine the access levels for this User. Refer to section on page 20
‘Configuring Access Levels’ for information on User Groups.
4. Assign a Card , PIN number and enroll FingerPrints for the User. Refer to
section FingerPrint Enrolment on page 21
Click ‘save’ to transmit these changes to the Controller.
19
Operation Instructions

Setting the Controller address
Direct Connect - All OFF Address 1 - Set SW1 ON Address 2 - Set SW2 ON
Note: Address 3 - Set SW3 ON only
The Controller Address is set by configuring the Dip switches as shown below.
Configuring Controller Communications
Step Description
1. On the “Controller” Tab, set the “Connection - Type” to “Serial”
2. On the “Settings” tab in the communications section, Select the Serial Port
number from the drop-down list connected to the Controller.
OFF
ON
1 2 3 4
OFF
ON
1 2 3 4
OFF
ON
1 2 3 4
11
Network Diagrams
Restoring Factory Settings
Example: All Dip Switches are set to the ON position.
To restore the factory default setting , Set ALL Dip
Switches 1,2,3 & 4 to the ON position and then
power-up the Controller.
OFF
ON
1 2 3 4
Note: Factory Default settings will be restored after
powering up the controller with All dip-switches ON. The
dip-switches’s should then be set to the controller
address as shown above in section “Setting the
controller address”
18 Operation Instructions
Phase 4 - Enrolling Door Controls
Step Description
4. Once all Door Controls are enrolled onto the network – go back to the
PC application and click ‘Secure Network’ button.
–this safeguards the systems and secures the network.
4. Select each Door on the application and configure individual settings such
as Door Name, Timed Actions, Relay Times, Ajar Times, Door Option and
Alarm Options etc.
Timed Actions:
IMPORTANT: A timezone must be selected in ‘Timed Actions’ for one of the
options: Card and PIN, Any Card, Card or PIN , or PIN only.
If all of these are set to ‘inactive’ then access will be denied for all cards
and PINs on that Door Control.
Example: To Enable PIN codes only on a Wi-PIN&Prox:
Set the Timed Action “Card or PIN” to “Inactive” and set the Timed
Action “PIN Only” to “All day,Every Day”. This will grant access for PIN
codes and deny access for cards and fobs.

12 Operation Instructions
Setting up TCP-IP - DHCP
Step Description
1. Default the Controller. See Restore Factory settings on page 11. The
default TCP/IP mode will then be set to DHCP.
2. Set the Controller address to address 1. See page 11 for details.
Connecting the Controller to your DHCP LAN.
1. Connect the Controller to your LAN using an ethernet cable. The Controller
will be assigned an IP address automatically by your DHCP server.
2. Open the GSDWin application. On the Controller tab, Select TCP/IP
with the DHCP option and enter the MAC address of the Controller and
click “Apply”.
The MAC address of the controller can be found on the box or printed on
the Controller PCB. The Controller icon will turn blue when it comes online.
17
Operation Instructions
Phase 4 - Enrolling Door Controls
Note: For Wired 485 Door Controls, right click on the Controller on the
right hand side of the application and select ‘Manually Assign Address’
from the drop down menu.
Once all new Door Controls are found by the Controller they will all
‘beep’ with the number of the next available address/door position on the
Controller.
e.g. if door 2 is the next available address then all Door Controls will beep
at the same time with 2 beeps. This is basically saying that any door can
be assigned to this address – it’s up to the installer to decide which one.
Also – you will notice that the Key back light of the keypad Door Controls
will be illuminated with the next available address as well.
i.e. Key 2 will be illuminated for this example.
3. Go to the Door control that you want to make door 2 on the network
system (it should be beeping 2 times). Press any key on this keypad and
the system will automatically assign this door control to door 2 address on
the system. Present a card if the Door Control is Prox Only.
Note: All other Door Controls will now start beeping with the next
available address i.e. ‘3 beeps’ (address 3) in this instance and so on
every time you enroll a new Door Control. The key back light will also
correspond to each address as the system fills up. E.g. The 3 key will light
up to indicate address 3.
Step Description
2. The controller is now ready to allow Door Controls to enroll onto the
Network – Go to the ‘Controllers’ tab and Click on ‘Wireless Network’
and then click “Allow Doors to Join”. This opens the network and starts
the controller scanning for any new doors that do not already have an
address – only Door Controls without an address can be enrolled.

Setting up TCP-IP - Static IP
Step Description
1. Default the Controller. See Restore Factory settings on page 11. The
Controllers default IP address is 169.254.1.1.
2. Set the Controller address to address 1. See page 11 for details.
3. Connect the Controller directly to a PC to using an ethernet cable.
Connecting the Controller directly to a PC using default IP address..
4. Connect an Ethernet cable between the Controller and the PC. (The default
IP address of the Controller is 169.254.1.1)
5. Set the IP address on the PC to a similar IP address e.g. 169.254.1.2
Note: If there is no LED activity on your PC’s ethernet interface then the PC
requires a cross-over cable between the PC and the Controller.
6. Open the GSDWin application.
On the Controller tab, Select TCP/IP with Static option and enter the
default Controller IP address of 169.254.1.1 and click apply. The
Controller icon will turn blue when it comes online. A new IP address can
then be sent to the Controller using the “Controller TCP/IP Configuration”
button.
Sending a new IP address to the Controller e.g. 192.168.1.26.
7. Make sure the controller is online and click on the
“Controller TCP/IP Configuration” button.
8. Choose Static IP mode and enter the IP address,
Netmask and Default Gateway assigned by your
network administrator. Click “Send new settings
to Controller”. The Controller will now go offline as
the new IP Address settings are applied.
9. Connect the PC and Controller to your LAN
and enter the new IP address to allow the
application to communicate with the
Controller.
Note: Reset the IP address on your PC to its
original setting for your LAN.
13
Operation Instructions
16 Operation Instructions
Phase 3 - Defaulting Door Controls
Step Description
All Door Controls should be installed at this point and powered up.
1. All Door Controls must be defaulted before joining a network.
Note: Door Controls will be shipped with their factory default settings.
Enter Engineer mode on each Keypad Door Control in the following way
A. Press X followed by 6666
B. Enter 55 –to default
C. Press the tick to confirm – the keypad will now go through the
process of defaulting itself.
D. The process could take 20-30 seconds. The LED will flash once every
second when it is complete
E. Repeat the process for all keypad Door Controls
Enter Engineer mode on each Wi-Bio Door Control in the following way
A. Enter 6666
B. Enter 55 –to default
C. Scan Finger to confirm – the Door Control will now go through the
process of defaulting itself.
D. The process could take 20-30 seconds. The LED will flash once every
second when it is complete.
E. Repeat the process for all Wi-Bio Door Controls
Enter Engineer mode on each Prox Only Door Control in the following way
A. Add a programming card to the Door Control by presenting a card
twice on power-up. The security wing must be removed first!
B. Present this new programming card to enter Engineer mode.
C. Present the programming card again to select “Default mode”.
D. Present any other card once to default the Door Control.
E. The process could take 20-30 seconds. The LED will flash once every
second when it is complete

14 Operation Instructions
Phase 1 - Setting up the GSD Controller
Step Description
1. Install the main TS SMART Controller and power up
2. Begin by Defaulting/Restore Factory Settings on the controller via the
dip switch settings (see instructions on page 11)
3. Important! Once powered up and the controller has completed the default
the process – reset the dip switches to the correct address positions.
(see instructions on page 11)
4. Follow instructions on the CD provided to install the GSD PC application.
To download the latest drivers, enter the following link in your web browser.
http://www.globalsecurity.ie/userfiles/files/GSDWin Access en-US.zip
Note: Make sure the USB enrollment reader is not connected to the PC
before the GSD application is installed.
5. Launch the application:
A. Launch the application by clicking the GSDWin icon on the desktop. The
“Site Database Management” will appear.
B. Click on “Create New Site”, then click “Create New Wi-Enterprise Site”
and save the name of the new installation site. The application will then
launch.
C. Log in to the application as the Engineer (not the administrator) with the
password 6666.
D. Connect to the Controller. Refer to page 12 & 13 for setting up DHCP
or Static IP addresses
E. The Controller icon will change colour from gray (off-line) to
green (on-line) to show that the Controller is communicating with the
application.
F. Go to the 'Current Events' tab to view the current log messages from
the Controller
15
Operation Instructions
Phase 2 - Configuring the GSD Controller
Step Description
1. Open the ‘Doors’ tab in the main menu to add the required number of new
doors to be part of this network. One door will already be added by default.
Click on the “+” button to add new doors. “-” to remove doors.
2. Make sure all doors are “Enabled” and then click “Save”.
3. Open the Settings Tab and do a “Configuration Download” to the Controller
– this gives the Controller a clean set of instructions before beginning to
enroll doors onto the network.
4. Create a New Wireless Network.
WARNING! A New Network should only be created on first installation.
Creating a new network will overwrite any existing network information
and any enrolled Door Controls will be un-enrolled. All Door Controls will
have to be defaulted and re-enrolled on the new network that has just
been created!
A new network is now ready to be created.
Go to the ‘Controllers’ tab and Click on ‘Wireless Network’ and then click
on ‘Create New Network’.
Click Yes on the pop-up to proceed.
Note: It will take about 20 - 60 seconds to complete. a pop-up will appear
when the network has been created.
