Treasure Garden Vega-L Installation instructions

Vega-L
Umbrella Light
Assembly and Operation Guide
www.treasuregarden.com
©2017 Treasure Garden, Inc. - All Rights Reserved. Rev 6/17

1
A - On/Off Button C - Battery ack (Batteries included)
B - Clamp Release Button D - Battery Charger
A
B
Battery Charger (1)
Battery Pack (1)
C
D
Size: 9” diameter
Lights: 36 LED lights
AC Charger: 110V
Charge time: 6 Hrs.
(Lights up to 4-6 hrs. with a full charged batter .)
SAFETY PRECAUTIONS:
• If unit is exposed to light moisture, light to medium rain; allow unit to air dry for 24
hours before reuse.
WARNING: The VEGA™umbrella light is not waterproof. If the light is immersed in a
pool or spa or exposed to heavy rain the unit will be damaged and negate the 1 year
warranty.
WARRANTY:
Treasure Garden warrants this product
(in residential use) to be free from
defects in original materials and
workmanship for a period of 1 year from
the date of purchase.
If a defect in the original material or
workmanship appears during the
warranty period; Treasure Garden will (at
its option) repair or replace the product
without charge.
Simply contact your original authorized
Treasure Garden dealer with a
description of the defect.
The dealer will verify the defect and
work closely with Treasure Garden to
obtain the necessary service.
In many cases, simple problems
can be solved with a replacement part
that can be shipped directly
to the dealer for professional installation
/ repair.
In the event that warranted factory
service is required, Treasure Garden will
assume the responsibility of the return
freight charges on warranted product for
the first year only.
Returned product that (upon receipt and
inspection) is deemed to be “not
covered” under our warranty, will be
shipped / billed at your expense.
This warranty gives you specific legal
rights, and you may have other rights
which vary from state to state.
NOTE: Failure caused by unreasonable
or abusive use, or failure caused by
neglect of reasonable and necessary
care are not covered by this warranty.
Additionally, acts of nature (including but
not limited to wind, hurricanes,
tornadoes, and storms) are not covered
by this warranty.
6
Thank you for purchasing Treasure Garden’s VEGA-L Umbrella Light.
lease remove all contents from the package, inspect and review checklist.
CAUTION: To reduce personal injury and damage to your umbrella light, read and
follow this assembly and operation guide.
VEGA-L CHECKLIST

Charger Input
Battery Compartment
On/Off Button
Battery Pack
Battery
Release Button
Clamp Release
Button
Battery Pack
25
To OPEN th VEGA Umbr lla Light:
Open the VEGA umbrella light by holding firmly with one hand and then depress the clamp
release button with the other hand to release the clamp lock (Fig. 1).
To CHARGE/RECHARGE th VEGA Umbr lla Light:
With the VEGA umbrella light opened, slide back the battery release button to remove the
battery pack from its compartment (Fig. 2). After removing the battery pack, plug the
charger into the battery input (Fig. 3), then plug charger into 110V electrical outlet for 6
hours to fully charge. After battery charging is complete, gently slide battery pack back into
compartment until battery pack snaps into place. NOTE: Only use the supplied battery
charger, charging the light with a substitute charger may damage the battery pack or cause
overheating, which could result in personal injury and/or other damages.
To TURN ON and TURN OFF th VEGA Umbr lla Light:
Depress the On/Off button to turn on and turn off LED lights.
(Fig. 1) (Fig. 2)
(Fig. 3)
To ATTACH VEGA Umbrella Light to Cantilever Umbrella:
Loosen the VEGA light adapter built into the umbrella runner by turning counter-clockwise
(Fig. 4). After loosening, pull down light adapter post (Fig. 5) to attach the VEGA
umbrella light (sold separately).
To OPEN and ATTACH VEGA:
Open the VEGA umbrella light by holding firmly with one hand and then depress the clamp
release button with the other hand to release the clamp lock. Open up the VEGA light and
clasp around the light adapter post (Fig. 6). Snap to close (Fig. 6).
To REMOVE VEGA and CLOSE ada ter:
Hold the VEGA umbrella light, depress the clamp release button to release the clamp lock.
Remove VEGA umbrella light, and gently push up the light adapter post back into umbrella
runner and tighten turning clockwise (Fig. 6).
(Fig. 4) (Fig. 5)
(Fig. 6) (Fig. 7)
Additional Features S T E P 1 Assembly
No assembly is required for the VEGA™battery rechargeable light however, you must
fully charge the VEGA battery prior to first use.

43
TWO LIGHT DISPLAY OPTIONS:
DOWNLIGHT Position:
lace the VEGA™with LED lights facing down for dining, games, and casual reading.
UPLIGHT Position:
lace the VEGA with LED lights facing up for indirect lighting and mood setting.
Clamp
Release
Button
S T E P 2 O eration
To OPEN and ATTACH th VEGA™Umbr lla Light to Mark t Umbr lla:
Open the VEGA umbrella light by holding the light firmly with one hand and then
depress the clamp release button with the other hand to release the clamp lock.
Open up the VEGA light and clasp around the mid pole. Snap to close.
Additional Features

43
TWO LIGHT DISPLAY OPTIONS:
DOWNLIGHT Position:
lace the VEGA™with LED lights facing down for dining, games, and casual reading.
UPLIGHT Position:
lace the VEGA with LED lights facing up for indirect lighting and mood setting.
Clamp
Release
Button
S T E P 2 O eration
To OPEN and ATTACH th VEGA™Umbr lla Light to Mark t Umbr lla:
Open the VEGA umbrella light by holding the light firmly with one hand and then
depress the clamp release button with the other hand to release the clamp lock.
Open up the VEGA light and clasp around the mid pole. Snap to close.
Additional Features

Charger Input
Battery Compartment
On/Off Button
Battery Pack
Battery
Release Button
Clamp Release
Button
Battery Pack
25
To OPEN th VEGA Umbr lla Light:
Open the VEGA umbrella light by holding firmly with one hand and then depress the clamp
release button with the other hand to release the clamp lock (Fig. 1).
To CHARGE/RECHARGE th VEGA Umbr lla Light:
With the VEGA umbrella light opened, slide back the battery release button to remove the
battery pack from its compartment (Fig. 2). After removing the battery pack, plug the
charger into the battery input (Fig. 3), then plug charger into 110V electrical outlet for 6
hours to fully charge. After battery charging is complete, gently slide battery pack back into
compartment until battery pack snaps into place. NOTE: Only use the supplied battery
charger, charging the light with a substitute charger may damage the battery pack or cause
overheating, which could result in personal injury and/or other damages.
To TURN ON and TURN OFF th VEGA Umbr lla Light:
Depress the On/Off button to turn on and turn off LED lights.
(Fig. 1) (Fig. 2)
(Fig. 3)
To ATTACH VEGA Umbrella Light to Cantilever Umbrella:
Loosen the VEGA light adapter built into the umbrella runner by turning counter-clockwise
(Fig. 4). After loosening, pull down light adapter post (Fig. 5) to attach the VEGA
umbrella light (sold separately).
To OPEN and ATTACH VEGA:
Open the VEGA umbrella light by holding firmly with one hand and then depress the clamp
release button with the other hand to release the clamp lock. Open up the VEGA light and
clasp around the light adapter post (Fig. 6). Snap to close (Fig. 6).
To REMOVE VEGA and CLOSE ada ter:
Hold the VEGA umbrella light, depress the clamp release button to release the clamp lock.
Remove VEGA umbrella light, and gently push up the light adapter post back into umbrella
runner and tighten turning clockwise (Fig. 6).
(Fig. 4) (Fig. 5)
(Fig. 6) (Fig. 7)
Additional Features S T E P 1 Assembly
No assembly is required for the VEGA™battery rechargeable light however, you must
fully charge the VEGA battery prior to first use.

1
A - On/Off Button C - Battery ack (Batteries included)
B - Clamp Release Button D - Battery Charger
A
B
Battery Charger (1)
Battery Pack (1)
C
D
Size: 9” diameter
Lights: 36 LED lights
AC Charger: 110V
Charge time: 6 Hrs.
(Lights up to 4-6 hrs. with a full charged batter .)
SAFETY PRECAUTIONS:
• If unit is exposed to light moisture, light to medium rain; allow unit to air dry for 24
hours before reuse.
WARNING: The VEGA™umbrella light is not waterproof. If the light is immersed in a
pool or spa or exposed to heavy rain the unit will be damaged and negate the 1 year
warranty.
WARRANTY:
Treasure Garden warrants this product
(in residential use) to be free from
defects in original materials and
workmanship for a period of 1 year from
the date of purchase.
If a defect in the original material or
workmanship appears during the
warranty period; Treasure Garden will (at
its option) repair or replace the product
without charge.
Simply contact your original authorized
Treasure Garden dealer with a
description of the defect.
The dealer will verify the defect and
work closely with Treasure Garden to
obtain the necessary service.
In many cases, simple problems
can be solved with a replacement part
that can be shipped directly
to the dealer for professional installation
/ repair.
In the event that warranted factory
service is required, Treasure Garden will
assume the responsibility of the return
freight charges on warranted product for
the first year only.
Returned product that (upon receipt and
inspection) is deemed to be “not
covered” under our warranty, will be
shipped / billed at your expense.
This warranty gives you specific legal
rights, and you may have other rights
which vary from state to state.
NOTE: Failure caused by unreasonable
or abusive use, or failure caused by
neglect of reasonable and necessary
care are not covered by this warranty.
Additionally, acts of nature (including but
not limited to wind, hurricanes,
tornadoes, and storms) are not covered
by this warranty.
6
Thank you for purchasing Treasure Garden’s VEGA-L Umbrella Light.
lease remove all contents from the package, inspect and review checklist.
CAUTION: To reduce personal injury and damage to your umbrella light, read and
follow this assembly and operation guide.
VEGA-L CHECKLIST

Vega-L
Umbrella Light
Assembly and Operation Guide
www.treasuregarden.com
©2017 Treasure Garden, Inc. - All Rights Reserved. Rev 6/17
