Treasure garden Base-13 Installation instructions

BASE-13

Up to 400 lbs.

Cantilever Base

Assembly and Operation Guide

www.treasuregarden.com

WARRANTY:

reasure Garden warrants this product

(in residential use) to be free from

defects in original materials and

workmanship for a period of 2 year from

the date of purchase. If a defect in the

original material or workmanship

appears during the warranty period;

reasure Garden will (at its option) repair

or replace the product without charge.

Simply contact your original authorized

reasure Garden dealer with a

description of the defect. he dealer will

verify the defect and work closely with

reasure Garden to obtain the necessary

service. In many cases, simple problems

can be solved with a replacement part

that can be shipped directly to the dealer

for professional installation / repair.

In the event that warranted factory

service is required, reasure Garden will

assume the responsibility of the return

freight charges on warranted product for

the first year only.

Returned product that (upon receipt and

inspection) is deemed to be “not

covered” under our warranty, will be

shipped / billed at your expense.

his warranty gives you specific legal

rights, and you may have other rights

which vary from state to state.

RUST: Rust is a natural part of the

aging process of steel or iron based

materials, and is therefore NO

considered a defect.

NOTE: Failure caused by unreasonable

or abusive use, or failure caused by

neglect of reasonable and necessary

care are not covered by this warranty.

Additionally, acts of nature (including but

not limited to wind, hurricanes,

tornadoes, and storms) are not covered

by this warranty.

hank you for your purchase of reasure Garden’s Cantilever Base.

Please remove all contents from the package, inspect and review parts list.

CAUTION: o reduce personal injury and damage to your base or umbrella, read and

follow this instruction manual. We recommend a two-person team for assembly and

disassembly. Save information for future reference.

1 Base Cover 1

2 Steel Base Frame 1

3 Add-On Weight Containers 4

4 Feet 4

5 Screws 4

Wrench 1

Playground Sand (not included) 400 lbs.

BASE-13 PART LIST

Part Description Qty.

CAUTION: Fully assembled, the umbrella weighs over 500 lbs. Moving the umbrella fully

assembled will increase the risk of damage to your umbrella and/or can cause serious injury. We

recommend a two-person team for assembly and disassembly.

6mm Hexagon

Wrench

8mm Hexagon Wrench

Rotating Hub

Main Frame

(Fig. 1)

(Fig. 3)

(Fig. 4)

(Fig. 5)

(Fig. 6)

Base Assembly

Select area to set base frame and place in desired location. NOTE: Moving the umbrella will

be difficult once fully assembled. Screw (4) feet onto bottom of base frame with supplied

(4) screws (Fig. 1). Remove rotating hub from the main frame (sold separately) by removing

the (2) bolts and (2) washers (Fig. 2), set aside bolts and washers for later use. Now, place

rotating hub onto base frame and secure with supplied (5) hub bolts and washers included

with umbrella (Fig. 3). Remove caps from each add-on weight container and fill with dry

playground sand (Fig. 4). he containers hold up to 400 lbs. of sand. Fill each add-on weight

with playground sand. Place each add-on weight container into base frame sections (Fig. 5).

Carefully place base cover onto base frame (Fig. 6). LEVELING: If needed, adjust frame

corners using supplied wrench until frame is level (Fig. 7). Your base is now ready for

umbrella installation.

(Fig. 7)

(Fig. 2)

REQUIRED FOR ASSEMBLY:

• 400 lbs. playground sand (not included).

IMPORTANT: Prior to assembly it is important to decide on the location of the umbrella.

• Allow ample height to avoid damage to your umbrella during assembly and usage.

• Choose a location that is level and sturdy.

• Avoid any sloping or soft ground.

• Consider a location that will maximize the umbrella’s rotating swivel function. Placing

the umbrella between two entertaining areas is ideal.

NOTE: Some parts may be included in the styrofoam packaging.

DO NO discard any packaging or box until assembly is complete.
