AG19 TILT LEVER/STEERING ROD REPAIR
STEP 1
Remove AG19 from cross bar stand and lay on soft surface (Fig. 1). Removing canopy is
optional.
(Fig. 1)
STEP 2
Pull down light adapter (Fig. 2). Remove 2 screws with phillips screwdriver and set aside
(Fig. 3). Pull cap off light adapter and set aside (Fig. 4). With the help of a second person,
slightly pull ribs apart and pull cord down from runner. Untie knot from cord (Fig. 5).
(Fig. 2) (Fig. 3)
(Fig. 5)
(Fig. 4)
STEP 9
Pull down light adapter from runner using fingers (Fig. 21). Place cap back onto light adapter
(Fig. 22) and tighten with 2 screws using a phillips screwdriver (Fig. 23). Tighten light adapter
back up in runner (Fig. 24).
(Fig. 21)
(Fig. 22)
(Fig. 23)
(Fig. 24)

25
STEP 3
Remove 3 screws from tilt lever mechanism using a 4mm hexagon wrench (Fig. 6). Set aside
screws and tilt lever mechanism covers (Fig. 7).
STEP 4
Gently pull steering rod out from tilt lever mechanism (Fig. 8). Cut cord (Fig. 9).
(Fig. 6) (Fig. 7)
(Fig. 8) (Fig. 9)
STEP 8
From the runner, cut off old cord where sewn (Fig. 18) and discard old cord. Tie figure 8 knot
in new cord (Fig. 19). Tug on cord from top of runner to allow cord to go back up into runner
(Fig. 20).
(Fig. 18) (Fig. 19)
(Fig. 20)

43
(Fig. 11)
STEP 5
Grab new replacement tilt lever/steering rod (Fig. 10). Using a needle and thread, sew ends
of new and old cord together (Fig. 11). Pull cord through runner until tight (Fig. 12). Turn
crank handle counter clockwise and continue to pull on cord from runner till there is no more
cord left inside steering rod (Fig. 13).
(Fig. 10)
(Fig. 12)
(Fig. 13)
STEP 6
Place rod back into tilt lever mechanism by pushing up into tilt degree mechanism (Fig. 14).
STEP 7
Place 2 covers (Fig. 15) and plastic piece (Fig. 16) back onto tilt lever mechanism and tighten
with 3 screws using 4mm hexagon wrench (Fig. 17).
(Fig. 14)
(Fig. 15)
(Fig. 16)
(Fig. 17)
1
2
2
1
3
3

43
(Fig. 11)
STEP 5
Grab new replacement tilt lever/steering rod (Fig. 10). Using a needle and thread, sew ends
of new and old cord together (Fig. 11). Pull cord through runner until tight (Fig. 12). Turn
crank handle counter clockwise and continue to pull on cord from runner till there is no more
cord left inside steering rod (Fig. 13).
(Fig. 10)
(Fig. 12)
(Fig. 13)
STEP 6
Place rod back into tilt lever mechanism by pushing up into tilt degree mechanism (Fig. 14).
STEP 7
Place 2 covers (Fig. 15) and plastic piece (Fig. 16) back onto tilt lever mechanism and tighten
with 3 screws using 4mm hexagon wrench (Fig. 17).
(Fig. 14)
(Fig. 15)
(Fig. 16)
(Fig. 17)
1
2
2
1
3
3

25
STEP 3
Remove 3 screws from tilt lever mechanism using a 4mm hexagon wrench (Fig. 6). Set aside
screws and tilt lever mechanism covers (Fig. 7).
STEP 4
Gently pull steering rod out from tilt lever mechanism (Fig. 8). Cut cord (Fig. 9).
(Fig. 6) (Fig. 7)
(Fig. 8) (Fig. 9)
STEP 8
From the runner, cut off old cord where sewn (Fig. 18) and discard old cord. Tie figure 8 knot
in new cord (Fig. 19). Tug on cord from top of runner to allow cord to go back up into runner
(Fig. 20).
(Fig. 18) (Fig. 19)
(Fig. 20)
