Treasure Garden AG25T Installation instructions

AG25T/AG25TSQ
11.5’
OC /10’ SQ
Cantilever
Assembly and Operation Guide
www.treasuregarden.com
©2018 Treasure Garden, Inc. - All Rights Reserved. 8/18
ARRANTY:
Treasure Garden warrants this product
(in residential use) to be free from
defects in original materials and
workmanship for a period of 1 year from
the date of purchase. If a defect in the
original material or workmanship
appears during the warranty period;
Treasure Garden will (at its option) repair
or replace the product without charge.
Simply contact your original authorized
Treasure Garden dealer with a
description of the defect. The dealer will
verify the defect and work closely with
Treasure Garden to obtain the necessary
service. In many cases, simple problems
can be solved with a replacement part
that can be shipped directly to the dealer
for professional installation / repair.
In the event that warranted factory
service is required, Treasure Garden will
assume the responsibility of the return
freight charges on warranted product for
the first year only.
Returned product that (upon receipt and
inspection) is deemed to be “not
covered” under our warranty, will be
shipped / billed at your expense.
This warranty gives you specific legal
rights, and you may have other rights
which vary from state to state.
RUST: Rust is a natural part of the
aging process of steel or iron based
materials, and is therefore NOT
considered a defect.
NOTE: Failure caused by unreasonable
or abusive use, or failure caused by
neglect of reasonable and necessary
care are not covered by this warranty.
Additionally, acts of nature (including but
not limited to wind, hurricanes,
tornadoes, and storms) are not covered
by this warranty.

Thank you for purchasing Treasure Garden’s AG25T Cantilever Umbrella.
Please remove all contents from the package, inspect and review checklist.
CAUTION: To reduce personal injury and damage to your umbrella, read and follow this
assembly and operation guide. We recommend a two-person team for assembly and
disassembly. Save information for future reference.
61
CHECKLIST
To ATTACH Umbrella Lig t:
Loosen the light adapter built into the lower hub by turning counter-clockwise
(Fig. 14). After loosening, pull down light adapter post (Fig. 15) to attach the
umbrella light (Fig. 16 and 17) (sold separately).
To REMOVE Umbrella Lig t and CLOSE adapter:
Remove umbrella light, and gently push up the light adapter post back into umbrella runner
and tighten turning clockwise (Fig. 14).
(Fig. 14) (Fig. 15) (Fig. 16) (Fig. 17)
Features
A - 360° Rotating Hub H - Tilt Degree Scale
B - Foot Pedal I - Crank Handle
C - Hardware J - Canopy Support Beam
D - ain Frame K - Finial
E - Adjustment Knob L - Canopy - Single or Double Wind Vent
F - Open/Close echanism M- Spring Loaded Rib End Cap
G - Tilt echanism N - Light Adapter (light sold separately)
CloseOpen
RightLeft
Open
Max
0˚
Max
K
L
D
J
M
N
A
B
E
C
6mm Hexagon
Wrench
FG
H
I
SAFETY PRECAUTIONS:
• Close the umbrella in windy conditions or when a storm approaches.
Never allow the umbrella to flap in the wind; this could damage the canopy.
• Properly store umbrella when not in use. Close umbrella, tie string around canopy and
cover umbrella with provided protective cover.
• Do not leave open umbrella unattended. If damage occurs, this is not covered
by the warranty.
• When adjusting the umbrella, make sure that no person(s) or item(s) are close to the
umbrella. This is important to prevent injury or material damage.
CARE AND MAINTENANCE:
• When not in use, close and cover umbrella with a protective cover.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Allow a wet canopy to dry slightly opened, but do not leave unattended.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry place.
After the Winter:
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.

25
(Fig. 1)
NOTE: REFER TO SEPARATE BASE-13, BASE-AKZ OR MOUNT KIT MANUAL
FOR BASE/MOUNT ASSEMBLY PRIOR TO PROCEEDING.
S T E P 4 360° Rotating Hub Swivel
Place your foot on the foot pedal of the rotating hub and step-on the pedal to release
rotating lock (Fig. 10). Place hands on the main frame and rotate the umbrella frame in
either direction, in 90° increments. To lock position, step off the foot pedal to engage
rotating lock.
Foot Pedal
Main Frame
Rotating Hub
360
(Fig. 10)
S T E P 5 Closing Canopy
Insert crank handle into “Open/Close” socket in crank mechanism (Fig. 11). Turn crank
handle counter clockwise until the canopy is closed (Fig. 12). Turn adjustment
knob counter clockwise and slide downward until umbrella is in closed position.
Tie string around canopy to secure canopy. Cover umbrella with provided protective cover
when not in use (Fig. 13).
S T E P 1 Umbrella Assembly
Two-persons recommended for team lift and to complete assembly.
With base cover in place or mount kit installed, lift umbrella up and insert the main frame
onto the installed rotating hub (Fig. 1). Secure umbrella into place by inserting the (2) bolts
and (2) washers and tighten using 6mm hexagon wrench provided (Fig. 2).
REMOVE ALL PLASTIC PACKAGING MATERIAL FROM ALL PARTS PRIOR TO
OPENING UMBRELLA. CHECK UNDER CANOPY FOR PACKAGING AROUND RIBS.
Your umbrella is now ready to operate!
(Fig. 2)
ClOpen
RightLeft
Open
Max
0˚
Max
(Fig. 11)
(Fig. 12) (Fig. 13)

43
(Fig. 4)
S T E P 2 Opening Canopy
In the closed position, turn adjustment knob counter clockwise (Fig. 3) and slide
the adjustment knob upward (Fig. 4). Turn adjustment knob clockwise to tighten
and secure in place.
S T E P 3 Tilting Canopy
Tilting Front to Back
Turn adjustment knob counter clockwise (Fig. 7) and slide car up and downward
until desired height and angle is reached (Fig. 8). Tighten the adjustment knob clockwise
to lock its position. Note: Do not use tilt function during winds.
(Fig. 9)
ClOpen
Right Left
Open
Max
0˚
Max
Insert crank handle into “Open/Close” socket in crank mechanism (Fig. 5). Turn crank
handle clockwise until the canopy is fully open (Fig. 6). CAUTION: Stop turning
the crank handle as soon as the umbrella canopy is completely open and the sleeve on
the umbrella center pole has reached its maximum height.
(Fig. 5)
(Fig. 6)
(Fig. 8)
Tilting Left to Rig t
Insert crank handle into “Right/Left” socket in crank mechanism (Fig. 9). To tilt canopy right,
turn crank handle counter clockwise. To tilt canopy left, turn crank handle
clockwise.
(Fig. 3)
RightLeft
Max
0˚
Max
CloseOpen
Open
(Fig. 7)

43
(Fig. 4)
S T E P 2 Opening Canopy
In the closed position, turn adjustment knob counter clockwise (Fig. 3) and slide
the adjustment knob upward (Fig. 4). Turn adjustment knob clockwise to tighten
and secure in place.
S T E P 3 Tilting Canopy
Tilting Front to Back
Turn adjustment knob counter clockwise (Fig. 7) and slide car up and downward
until desired height and angle is reached (Fig. 8). Tighten the adjustment knob clockwise
to lock its position. Note: Do not use tilt function during winds.
(Fig. 9)
ClOpen
Right Left
Open
Max
0˚
Max
Insert crank handle into “Open/Close” socket in crank mechanism (Fig. 5). Turn crank
handle clockwise until the canopy is fully open (Fig. 6). CAUTION: Stop turning
the crank handle as soon as the umbrella canopy is completely open and the sleeve on
the umbrella center pole has reached its maximum height.
(Fig. 5)
(Fig. 6)
(Fig. 8)
Tilting Left to Rig t
Insert crank handle into “Right/Left” socket in crank mechanism (Fig. 9). To tilt canopy right,
turn crank handle counter clockwise. To tilt canopy left, turn crank handle
clockwise.
(Fig. 3)
RightLeft
Max
0˚
Max
CloseOpen
Open
(Fig. 7)

25
(Fig. 1)
NOTE: REFER TO SEPARATE BASE-13, BASE-AKZ OR MOUNT KIT MANUAL
FOR BASE/MOUNT ASSEMBLY PRIOR TO PROCEEDING.
S T E P 4 360° Rotating Hub Swivel
Place your foot on the foot pedal of the rotating hub and step-on the pedal to release
rotating lock (Fig. 10). Place hands on the main frame and rotate the umbrella frame in
either direction, in 90° increments. To lock position, step off the foot pedal to engage
rotating lock.
Foot Pedal
Main Frame
Rotating Hub
360
(Fig. 10)
S T E P 5 Closing Canopy
Insert crank handle into “Open/Close” socket in crank mechanism (Fig. 11). Turn crank
handle counter clockwise until the canopy is closed (Fig. 12). Turn adjustment
knob counter clockwise and slide downward until umbrella is in closed position.
Tie string around canopy to secure canopy. Cover umbrella with provided protective cover
when not in use (Fig. 13).
S T E P 1 Umbrella Assembly
Two-persons recommended for team lift and to complete assembly.
With base cover in place or mount kit installed, lift umbrella up and insert the main frame
onto the installed rotating hub (Fig. 1). Secure umbrella into place by inserting the (2) bolts
and (2) washers and tighten using 6mm hexagon wrench provided (Fig. 2).
REMOVE ALL PLASTIC PACKAGING MATERIAL FROM ALL PARTS PRIOR TO
OPENING UMBRELLA. CHECK UNDER CANOPY FOR PACKAGING AROUND RIBS.
Your umbrella is now ready to operate!
(Fig. 2)
ClOpen
Right Left
Open
Max
0˚
Max
(Fig. 11)
(Fig. 12) (Fig. 13)

Thank you for purchasing Treasure Garden’s AG25T Cantilever Umbrella.
Please remove all contents from the package, inspect and review checklist.
CAUTION: To reduce personal injury and damage to your umbrella, read and follow this
assembly and operation guide. We recommend a two-person team for assembly and
disassembly. Save information for future reference.
61
CHECKLIST
To ATTACH Umbrella Lig t:
Loosen the light adapter built into the lower hub by turning counter-clockwise
(Fig. 14). After loosening, pull down light adapter post (Fig. 15) to attach the
umbrella light (Fig. 16 and 17) (sold separately).
To REMOVE Umbrella Lig t and CLOSE adapter:
Remove umbrella light, and gently push up the light adapter post back into umbrella runner
and tighten turning clockwise (Fig. 14).
(Fig. 14) (Fig. 15) (Fig. 16) (Fig. 17)
Features
A - 360° Rotating Hub H - Tilt Degree Scale
B - Foot Pedal I - Crank Handle
C - Hardware J - Canopy Support Beam
D - ain Frame K - Finial
E - Adjustment Knob L - Canopy - Single or Double Wind Vent
F - Open/Close echanism M- Spring Loaded Rib End Cap
G - Tilt echanism N - Light Adapter (light sold separately)
CloseOpen
RightLeft
Open
Max
0˚
Max
K
L
D
J
M
N
A
B
E
C
6mm Hexagon
Wrench
FG
H
I
SAFETY PRECAUTIONS:
• Close the umbrella in windy conditions or when a storm approaches.
Never allow the umbrella to flap in the wind; this could damage the canopy.
• Properly store umbrella when not in use. Close umbrella, tie string around canopy and
cover umbrella with provided protective cover.
• Do not leave open umbrella unattended. If damage occurs, this is not covered
by the warranty.
• When adjusting the umbrella, make sure that no person(s) or item(s) are close to the
umbrella. This is important to prevent injury or material damage.
CARE AND MAINTENANCE:
• When not in use, close and cover umbrella with a protective cover.
• If necessary, clean the fabric with lukewarm water, mild detergent, and a sponge.
• Allow a wet canopy to dry slightly opened, but do not leave unattended.
• Wipe sliding marks on the aluminum poles with a damp cloth.
Winter Storage:
• Store in a dry place.
After the Winter:
• Check the condition and function of the umbrella. Any defects must be repaired by a
professional.

AG25T/AG25TSQ
11.5’
OC /10’ SQ
Cantilever
Assembly and Operation Guide
www.treasuregarden.com
©2018 Treasure Garden, Inc. - All Rights Reserved. 8/18
ARRANTY:
Treasure Garden warrants this product
(in residential use) to be free from
defects in original materials and
workmanship for a period of 1 year from
the date of purchase. If a defect in the
original material or workmanship
appears during the warranty period;
Treasure Garden will (at its option) repair
or replace the product without charge.
Simply contact your original authorized
Treasure Garden dealer with a
description of the defect. The dealer will
verify the defect and work closely with
Treasure Garden to obtain the necessary
service. In many cases, simple problems
can be solved with a replacement part
that can be shipped directly to the dealer
for professional installation / repair.
In the event that warranted factory
service is required, Treasure Garden will
assume the responsibility of the return
freight charges on warranted product for
the first year only.
Returned product that (upon receipt and
inspection) is deemed to be “not
covered” under our warranty, will be
shipped / billed at your expense.
This warranty gives you specific legal
rights, and you may have other rights
which vary from state to state.
RUST: Rust is a natural part of the
aging process of steel or iron based
materials, and is therefore NOT
considered a defect.
NOTE: Failure caused by unreasonable
or abusive use, or failure caused by
neglect of reasonable and necessary
care are not covered by this warranty.
Additionally, acts of nature (including but
not limited to wind, hurricanes,
tornadoes, and storms) are not covered
by this warranty.
