Tree MCT-3 User manual

Professional Weighing Equipment
MCT SERIES intelligent weighing scale
MID COUNTING SCALE
WITH CHECK-WEIGHING FUNCTION
Operation Manual

MCT Operation Manual
2
Rev 3, 07.07.2016
Table of Contents
Section Page
Declaration of Conformity 3
Customer Service 4
Introduction 4
Safety 5
Weight Scale 6
Functions 7
Features 8-9
Application & Conformity 9
Getting Started 10
Delivery 10
Assembly & Installation 11
Application Menu 12
Program Options 13
Calibration 13-14
Maintenance & Service 14
Transport & Storage 15
Warranty 15

MCT Operation Manual
3
Rev 3, 07.07.2016
Declaration of Conformity
Declaration of conformity for apparatus with CE mark
We hereby declare that the product to which this declaration refers conforms to the
following standards.
Electronic scale: MCT Mid Counting Scales
Mark applied
EU Directive
Standards
2004/108/EC
EN 61326-1: 2006
Signature:
Boon Lim, R & D Manager
Date: 06. 28. 2016
LW Measurements LLC, 620 Carlson Court, Rohnert Park, CA 94928
Imperial version
Metric version
MCT-3
MCT-1500
MCT-7
MCT-3000
MCT-16
MCT-7500
MCT-33
MCT-15000
MCT-66
MCT-30000

MCT Operation Manual
4
Rev 3, 07.07.2016
Customer Service
USA
LW Measurements LLC, 620 Carlson Court
Rohnert Park, CA 94928
USA
Tel: [phone]
FAX: [phone]
http://lwmeasurements.com
EUROPE
LW Measurements Europe Ltd
Chalkwell Park House 700 London Road
Westcliff-on-Sea Essex SS0 9HQ
United Kingdom
Tel: [phone]
Fax: [phone]
http://lwmeasurements.com
Introduction
What you should know about these Operating Instructions:
Tree® Professional Weighing Equipment products are simple to operate.
Nevertheless, you should read through these operating instructions in their entirety, so
that you can make optimum use of the full potential and the diverse possibilities of the
weighing scale in your daily work.
These operating instructions contain guidance in the form of pictograms and keyboard
diagrams, which should help you in finding the required information:
For the labelling of potential hazards and advice, please see Safety below.

MCT Operation Manual
5
Rev 3, 07.07.2016
Safety
Representations & Symbols
Important instructions, which involve safety, are highlighted with the appropriate mark:
Safety recommendations
When using the weighing equipment in surroundings with increased safety
requirements, the corresponding regulations must be observed.
The weighing scale may only be used with the power adapter supplied.
Before connecting the power adapter to the scale, the user must ensure that the
operating voltage stated on the power adapter is compliant with the mains voltage.
If not, please contact Customer Service at the address above.
If the power adapter or its cable is damaged, the weighing scale must immediately be
disconnected from the electricity supply (pull out the power adapter).
If there should be any reason to believe that it is no longer safe to operate the scale, it
should be immediately unplugged from the electricity supply (pull out power adapter)
and secured against inadvertent operation.
In carrying out maintenance work, it is essential to follow the recommendations set out
in maintenance and servicing.
The weighing scale must not be operated in an area subject to explosion risks.
Care must be taken when weighing liquids to ensure that no liquid is spilled into the
inside of the scale or into connections on the rear of the equipment or the power
adapter. If liquid is spilled on the scale, it must immediately be unplugged from the main
electricity supply (pull out power adapter).
The weighing scale may be operated after it has first been inspected by a service
technician.
These operating instructions must be read by each user and should be easily
accessible at the workplace at all times.

MCT Operation Manual
6
Rev 3, 07.07.2016
Weight Scale
The weighing scale consist of certain parts
Weighing scale body (1)
The scale-pan (2)
The adapter (3)
Operation manual
Figure 2.1 Your weighing scale
2
3
2
1

MCT Operation Manual
7
Rev 3, 07.07.2016
Functions
The MCT Series are high-quality electronic precision weighing scales designed to
function as counting scales and check-weights with the following specifications.
Imperial weight unit version
Model number
Capacity
Division
Weighing pan Size
MCT-3
3 lb
0.0001 lb
185 x 255mm
MCT-7
7 lb
0.0002 lb
185 x 255mm
MCT-16
16 lb
0.0005 lb
185 x 255mm
MCT-33
33 lb
0.001 lb
185 x 255mm
MCT-66
66 lb
0.002 lb
185 x 255mm
Package
(Standard carton)
27.5×19×21(cm3)
Package
(Master carton)
4 Units in one box: 64.5×38×36(cm3)
Operating
Temperature
0-40℃(32-104℉)
Power source
Rechargeable batteries or AC/DC
Adapter 10V/500mA
Metric weight unit version
Model number
Capacity
Division
Weighing pan Size
MCT-1500
1500 g
0.05 g
185 x 255mm
MCT-3000
3000 g
0.1 g
185 x 255mm
MCT-7500
7500 g
0.2 g
185 x 255mm
MCT-15k
15 kg
0.0005 kg
185 x 255mm
MCT-30k
30 kg
0.001 kg
185 x 255mm
Package
(Standard carton)
27.5×19×21(cm3)
Package
(Master carton)
4 Units in one box: 64.5×38×36(cm3)
Operating Temperature
0-40℃(32-104℉)
Power source
Rechargeable batteries or AC/DC
Adapter 10V/500mA

MCT Operation Manual
8
Rev 3, 07.07.2016
FEATURES
Auto zero tracking
Intelligent applications: weight unit conversion, parts counting
Low battery indication
Large bright backlit LCD
Large heavy gauge stainless steel square pan
Stability indication
Auto calibration
Selectable auto back light
Selectable auto shut off
Unit switching kg ,g, lb, oz, lb:oz
Variable kg or lb reference weight calibration software
Pieces counting
1.3 million internal resolution
30,000 display resolution
24 bit A/D processor
Highest quality sensor used
Figure 2.2 Details of your weighing scale
Weighing pan
Bright back-lit display
Level bubble
Main power connection
Label

MCT Operation Manual
9
Rev 3, 07.07.2016
Application & Conformity
The Following are instructions of how to correctly use the weight scale:
The weighing scale may only be used for the weighing of solid-materials and of liquids
filled into secure containers.
The maximum capacity load of the weighing scale must never be exceeded, otherwise
the weighing scale may be damaged.
In using the weighing scale in combination with other devices as well as with devices
produced by other manufacturers, the appropriate regulations for the safe use of the
relevant attachments and their application in accordance with instructions must be
observed.
The weighing scale has been manufactured and tested in accordance with the
standards and recommendations set out in the declaration of conformity.
The power adapter supplied for the weighing scale complies with the appropriate
electrical protection class.
The following applies to all MCT series weighing scales
Power supply:
Input: 110V or 230V AC (+/-15-20%); 50Hz to 60Hz
Output: 10v DC 500mA
Allowable ambient conditions
Temperature: 0°C - 40°C
Relative humidity: 25% - 85%, non-condensing
If you have any questions on the technical data or require detailed technical information
on your balance, please contact your technical representative.
Battery compartment cover
Hard switch
Battery compartment
(Rechargeable battery
included)
Leveling feet

MCT Operation Manual
10
Rev 3, 07.07.2016
Getting Started
The scale is packaged in an environmentally-friendly carton, which provides optimum
protection for the balance during transportation.
We suggest that you keep the original packaging in order to avoid damage if you are
shipping or transporting the scale to a different location. It is also the best way to keep it
in the best conditions if it will not be used for an extended period of time.
In order to avoid damage, please follow the instructions provided below, when
unpacking the scale:
Unpack the scale carefully.
When outside temperatures are very low, the scale should be stored for a couple
hours and kept in its box in a dry room at normal temperature, so that no
condensation settles on the unit when opening the box.
Check the scale immediately after unpacking for any external visual damage. If
there is any damage on scale, contact customer service immediately.
If the scale is not to be used immediately after purchase, it should be stored in a
dry place where fluctuations in temperature are low. (Reference pg.15).
Read through these operating instruction, before you work with the unit and pay
attention to the Safety recommendations (reference Safety pg. 6).
Delivery
Inspect delivery for completeness immediately on unpacking all components.
Checklist for complete delivery
Component delivered present yes / no
Weighing unit body
Weighing pan
Power adapter
Operating manual

MCT Operation Manual
11
Rev 3, 07.07.2016
Assembly & Installation
The weighing scale is delivered in a partly dismantled condition. Assemble the individual
components in the following sequence:
Place your machine on a level, clean, and dry surface to obtain accurate
readings.
Place the plastic platter on top of the scale, flat side facing up so the platter
sits firmly on the machine with the four “legs” inserted into the corresponding
four receptacles.
Place the stainless steel platter on top of the plastic platter with the flat side
facing up.
Connecting the AC Adapter
The following Safety recommendations must be observed when connecting the balance
The Scale should only be connected to the mains voltage socket with the power adapter
supplied. Check before connecting the power adapter to the mains socket, that the
operating voltage stated on the power adapter complies with the local mains voltage.
If the operating voltage is not the same as the mains voltage, the power adapter must
not be connected to the mains socket and contact customer service.
Placement of Scale
The location in which the scale is placed is very important in order for the scale to work
to its full potential. Certain conditions can affect the capabilities of the scale, conditions
like: the presence of air flow, variations in temperature, and direct sunlight. Please
follow the recommendations given below in choosing a location to place your scale.
Place the scale on a solid, firm and preferably vibration-proof, horizontal base
Make sure that the weighing machine cannot be shaken or knocked over
Protect from direct solar radiation
Avoid drafts and excessive temperature fluctuations
Avoid placing the scale near or on any magnetic surfaces.
The scale is fitted with one bubble level, and adjustable feet for level-control that allow
for small height differences or any unevenness in the surface on which the balance is
placed.
The screw feet must be adjusted so that the air bubble is precisely in the center of the
sight glass of the bubble level (see Fig. 1)

MCT Operation Manual
12
Rev 3, 07.07.2016
Place the scale horizontally and keep the bubble inside the bubble level aligned with the
circle (Fig.1). In order to get exact measurements, the balance must be carefully leveled
after each re-location.
Fig. 1 Correct leveling with the aid of the bubble level and adjusting feet.
ER Application Menu
Display messages
The STABLE icon indicates when the readings stabled.
The ZERO icon indicates when the weights tared to zero.
The LO-BAT icon indicates when running out of battery.
The PCS icon indicates when pieces counting function applied.
Key Functions
On/Off (icon) key turns the weighing scale on or off
MODE key changes the weight units, kg, g, lb, oz, lb:oz
ZERO key sets display to zero or subtract the container weight
SET key for function settings

MCT Operation Manual
13
Rev 3, 07.07.2016
PCS key for pieces counting function
Program Options
Pieces counting
Press the On/Off key to turn on the scale
Wait for "0" to appear on the display.
If necessary, press “Zero” key to set the display to “0”
Press the “PCS”key to enter “PCS”mode, the display will show P=X X
Press “Mode” key to select XX value (10, 20, 50, and 100)
Place a given number of samples on the pan (Samples should be 10, 20, 50 or
100 pieces).
Press “PCS”key to confirm sample quantity.
Start counting by adding weight on the scale
Press “Mode” key to return to the weighing mode.
Auto shut off
Press and hold the “Mode” key, and then press the “On/Off” key to turn on the scale,
the display will show A_ON or A_OFF. Press the “Zero” key to select A_ON (that will
activate the auto shut off function) or A_OFF (that will deactivate the auto shut off
function).
Auto backlight
Press and hold the “Mode” key, and then press the “On/Off” (icon) key to turn on the
scale, the display will show A_ON or A_OFF. Press “Mode” key, the display will
show L_ON or L_OFF, press the “Zero” key to select L_ON, L_OFF or L_AU (auto).
Press the “On/Off” key to turn off the scale and then turn it on again to return to
normal operation. Calibration
Using an External Calibration Weight:
Calibration is required when the weighing scale is initially installed or if the scale is
moved to a substantial distance from the original location.
Turn the scale on, let it warm up for about 10 minutes, and then turn the scale
off.
Press and hold the “Set” key, and then press the “On/Off” key to turn on the scale,
the display will show “CAPu=”

MCT Operation Manual
14
Rev 3, 07.07.2016
Press “Set” key, display will show “CAP”, press “Set” key again, display will show
“CALu=”, press “Mode”key to choose the calibration unit kg. or lb.
Press “Set” key to confirm and the display will show “CALu=”again
Press “Set” key, display will show “CAL”, press “Mode” key to set the calibration
weight, display will show xx with a flashing digit
Press “Mode” key to move flashing digit to right, press “Zero”key to increase the
digit number. (We suggest the calibration weight to be at least 50% or more
within the scale capacity to get an accurate weighing)
Press “Set” key to confirm the setting, display will show “CAL”
Press “PCS”key to start calibration, the display will show the AD value, and wait
for stable indicator displayed, then press “Mode” key, display will show ------ and
then the flashing calibration weight
Place the test weight onto the center of the weighing pan, and wait for stable
indicator displayed, press “Mode” key, after stable indicator displayed again, it
will show the AD value, and now the calibration is completed
Remove the test weight and press the “On/Off” key turn off the scale. Turn it on
again to see if the weight is accurate, if not, repeat above steps
Maintenance & Service
For maintenance-work, the balance must be disconnected from the power supply
(remove power adapter plug from socket). Also ensure that the balance cannot be
connected to the power supply during the work by a third party.
Make sure that no liquid spills into the scale while performing maintenance work. If
liquid is spilled on the scale, it must be inspected by a service technician.
Regularly perform maintenance to the weighing pan and the weighing pan holder by
removing any dirt or dust from under the weighing pan and on the weighing scale
housing. Use a soft brush or a soft, lint-free cloth, moistened with a mild soap solution.
Never use solvents, acids, alkalis, paint thinners, scouring powders or other aggressive
or corrosive chemicals for cleaning; these substances can cause damage to the
surfaces of the scale housing.
Transport & Storage

MCT Operation Manual
15
Rev 3, 07.07.2016
Your weighing machine is a precision instrument, treat it carefully. Avoid shaking,
severe impacts and vibration during the transportation. Make sure that there are no
marked temperature fluctuations during the transportation and that the weighing
machine does not become damp (condensation).
If you would like to take the weighing machine out of service for an extended period,
disconnect it from the electricity supply, clean it thoroughly (refer to Maintenance &
Service) and store it in a place which meets the following conditions:
No violent shaking, no vibrations
Minimum temperature fluctuations
No direct solar radiation
Minimum moisture Warranty
The products are under warranty against factory defects for a period of two (2) years
from the date of shipment.
For Customers within the lower 48 states of the continental United States. LW
Measurements will pay for fright both ways for the first 30 days after purchase. After 30
days expire the customer is responsible for shipping the product back to us. After the
product is received we will inspect it and as necessary we will repair or replace and will
ship the product back to the customer at our expense.
Any new scales returned for warranty must be properly packaged in the original box. If
they are not properly packed an in the original box, the customer pays for shipping cost.
If we determine there is a factory defect, we will pay for the shipping back. If we
determine that it is not a factory defect, the customer will pay shipping.
For Customers outside the lower 48 States, including Mexico, Canada, Puerto Rico,
Hawaii, Alaska and all other countries, customers must pay for shipping.
Our warranty does not cover misuse or neglect including but not limited to battery or
water damage, overloading, and chewed or cut wires. If the product is found to have
been misused or damaged by the customer, LW measurements is not responsible for
the cost of return.
For warranty claims please go online to lwmeasurements.com and fill out the warranty
submission form or call your customer service representative.
