TRENDnet TVP-SP5G User manual

TVP-SP5G
Quick Installation Guide

Table of Contents
Table of Contents
Version 09.28.2006
English .....................................................................................................
Troubleshooting ........................................................................................
1
1
4
2
6
10
9
1. Before You Start
2. How to Install .....................................................................................
3.
4.
5.
................................................................................
Answering Phone Calls .....................................................................
Making Phone Calls .......................................................................
Quick Reference Sheet ......................................................................

System Requirements
TVP-SP5G
CD-ROM drive
Skype Version 1.1.079 or higher Installed
Computer With An Available USB 1.1 or 2.0 Port
CPU: Pentium 300MHz or Above
Memory: 256 MB or Above
Hard Drive Space: 8MB or Above
Windows 2000/XP
Broadband Internet
Phone jack
Package Contents
1. Before You Start
English
1
Quick Installation Guide
Utility & Driver CD-ROM
RJ-11 Cable
1 Meter USB Cable (mini-USB to
A-type connector)
Note: Skype must be installed before beginning the installation process.
Please visit www.Skype.com for more details.
ClearLink™ VoIP USB
Phone Adapter
(TVP-SP5G)
to ClearLink Skype Phone
TM TM
to Clear
TM
Skype Speakerphone
TM
Link
TM ®
ClearSky Bluetooth
VoIP Phone Kit
TM
(for Skype )

English
2
1. Insert the Utility & Driver
CD-ROM into your computer's
CD-ROM Drive and then click
Install Utility.
2. Click Next.
2. How to Install
3. Follow the InstallShield Wizard
instructions and then click Finish.
4. Select Allow this program to use
Skype. Click OK.

English
3
5. Connect the included USB cable
into the phone, and then connect
the USB cable into an available
USB port on your computer.
7. Click Yes to restart your computer
(Windows 2000).
8. Connect the phone into the port
labeled Phone.
9. Connect the provided RJ-11 cable
into a phone jack and into the port
labeled Line.
6. Drivers will install automatically.
Note: If the computer is on and the device is connected to your phone line, the
device defaults to phone line mode
Your installation is now complete.
For detailed information regarding the TVP-SP5G configuration and advanced
settings, please refer to the User's Guide included on the Utility & Driver
CD-ROM or TRENDnet's website at www.trendnet.com

English
4
2. Pick up the receiver.
4. Pick up the receiver.
1. When the phone rings, the PLED
will be solid white.
3. When the phone rings, the device
will switch automatically to Skype
mode. The VLED will be lit.
3. Answering Phone Calls
Note: This option requires you to follow step 9 in Section 2.
Answering a Call Thorough the Phone Line
(Telephone Mode)
Answering a Call Through Skype (Skype Mode)

English
5
Answering a Regular Phone Call While on a Skype
Phone Call
Answering a Skype Phone Call While on a Regular
Phone Call
7. The PLED will be lit.
11. The VLED will be lit.
5. Listen for ring in the telephone
receiver.
9. Listen for ring in the telephone
receiver.
6. Press #1 on the telephone dial pad
to switch to the incoming call.
10. Press #1 on the telephone dial
pad to switch to the incoming call.
8. Press #1 on the telephone dial pad
to switch back to the Skype call.
12. Press #1 on the telephone dial
pad to switch back to the regular
phone call.

English
6
4. Making Phone Calls
1. If your computer is on, make sure
the PLED on the USB Phone
adapter is solid white.
3. To make a local call, use the
following dialing sequence:
1 + Area Code + Telephone
Number
For example: 1 310 891 1100
2. Pick up the phone receiver and
wait for the dial tone.
4. To make an international call, use
the following dialing sequence:
International Dialing Number +
Country Code + Area Code +
Telephone Number
For example: 011 49 310 891 1100
Note: This option requires you to follow step 9 in Section 2.
Phone to Landline or Cell (Telephone Mode)

English
7
6. Press ## on the telephone dial pad
to switch to Skype mode. Make
sure the VLED is lit. Note: If you
did not plug a RJ-11 cable from
your phone line into the port
labeled, LINE, the device will
already be in Skype mode.
5. Pick up the phone receiver and
wait for the dial tone.
7. To make a call, use the following
dialing sequence:
00 + Country Code + Area Code +
Telephone Number + *
For example: 00 49 310 891 1100 *
Phone to Landline or Cell (Skype Mode)

9. Press ## on the telephone dial pad
to switch to Skype mode. Make
sure the V LED is lit.
8. Pick up the phone receiver and
wait for the dial tone.
10. To make call to a Skype contact,
assign a speed dial number to the
contact in the Skype program,
then use the following dialing
sequence: Speed Dial Number *
For Example: 22*
Phone to Skype Contact
English
8
For more information regarding the TVP-SP5G's advanced functions, please
refer to the User's Guide included on the Utility and Driver CD-ROM or
TRENDnet's website at www.trendnet.com

English
9
5. Quick Reference Sheet
Icon Function
Description
Hold
Voicemail
Call on hold
Exit Voicemail mode
Conference Initiates a conference call
Voicemail
Voicemail
Voicemail
Voicemail
Repeat current message
Delete current message
Move to next message
Keep current message
Move to next message
Power LED Solid light indicates device is receiving
power
Skype LED
PSTN LED
Solid light indicates device is in Skype
mode
Solid light indicates device is in PSTN
mode
Delete all message
Switches to Skype mode. V LED
illuminates.
Exit Voicemail mode
Access your Skype voicemail. This
feature must be purchased from Skype.
Serves as an enter key once you type in
the access code and the phone number.
Initiates a Skype call after you type in the
phone number
Voicemail
Skype
##
#1
#2
*
1
2
3
Skype
Voice mail
Toll Bypass
4
V
P

10
Troubleshooting
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
Q5:
A5:
My computer does not detect the TVP-SP5G. What should I do?
First, make sure your computer meets the minimum requirements as specified in Section 1 of
this Quick Installation Guide. Second, make sure the USB cable is physically plugged in as
described in Section 2. Third, try installing the TVP-SP5G to a different USB port of your computer.
Does my computer need to be on in order to make or receive phone calls through my PSTN
phone line?
No it does not. Make sure everything is plugged in correctly (refer to Section 2).
I am unable to make a call through Skype. What should I do?
First, make sure that you have Internet connectivity. Second, make sure that you have signed
into your Skype™ account. Third, make sure that you see the TVP-SP5G Utility software icon
located on the system tray . If you do not see this icon, go to Start > Program Files >
TRENDnet TVP-SP5G > TVP-SP5G Utility. Fourth, make sure the V LED is lit on the USB
Phone Adapter. If it is not, press # # on your phone's dial pad.
I am unable to make a call through my regular phone line. What should I do?
First, verify the phone line is working properly by connecting the phone directly to the phone
jack. Second, make sure the RJ-11 cables are connected to the proper ports on the USB Phone
Adapter (refer to Section 2). Third, make sure you get a dial tone. Fourth, if the computer is on,
make sure the P LED is lit. If it is not lit, hang up the phone. Fifth, try replacing the RJ-11 cables.
After I finish installing the TVP-SP5G, the Skylook installation window appears. What should I
do?
Skylook is an optional bonus program which integrates with Microsoft® Outlook® (required). It
allows you to manage your Skype™ contacts from Outlook®. To install the program, select Install
Skylook (recommended) and click Next. Then follow the Install Wizard directions to complete the
installation. If you do not want to install the program, select Don't Install.
If you still encounter problems or have any questions regarding the TVP-SP5G, please refer to the User's
Guide included on the Utility & Driver CD-ROM or contact TRENDnet's Technical Support Departme

Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.
