TRENDnet TEW-IA06D User manual

TRENDnet’s TEW-IA06D Directional Antenna provides
more power and farther distance range for your wireless
network. As an optional antenna for your IEEE 802.11b/g
2.4GHz wireless network equipments, it improves signal
strength/signal quality and increases the coverage area.
You can simply place the antenna on level surface or
secure it on the wall. Unleash the power of your wireless
products with TRENDnet’s TEW-IA06D antenna. Will work
with any brand with Reverse SMA Male Connector!
* This Figure does not include cable loss
TEW-IA06D
6 dBi Directional Indoor Antenna
TEW-IA06D (02-18-2005)
TRENDnet
TRENDware, USA
What's Next in Networking
SPECIFICATIONS
Frequency range:
• 2400 MHz ~ 2500MHz
Gain:
• 6 dBi
VSWR: 2.0 :
• 1.5 : 1 Max.
Polarization:
• Linear, Vertical
HPBW / horizontal:
• 80°
HPBW / vertical:
• 80°
Front to back ratio:
12 dBi
•
Impedance:
• 50 Ohms
Connector:
• Reversed Female SMA Plug
Cable:
• ULA-316 ; 100 cm (3.3 ft)
Weight:
• 110 g (4 oz.)
Temperature:
• -10° C ~ 55° C (14° F ~ 131° F)
Humidity:
• 95% at 25° C (77° F)
Power Handling:
• 20 W (cw)
Warranty:
• 3 Years
Certification:
• CE, FCC

RELATED PRODUCT
To Order Please Call:
1-888-326-6061
TEW-IA04O:
4 dBi Directional Indoor Antenna
TEW-OA08OK:
8dBi Outdoor Omni-Directional Antenna Kit
TEW-OA14DK:
14dBi Outdoor Directional Antenna with 6ft. (2M)
Reverse SMA Cable (with bracket mounting kit)
PATTERN
Networking Solution
TRENDnet is a registered trademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this
document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit ____________________
http://www.TRENDNET.com.
©
Copyright TRENDware International, Inc. 2005. All Rights Reserved.
TRENDware International, Inc.
3135 Kashiwa Street
Torrance, CA. 90505. USA
Tel: [phone]
Fax: [phone]
Web:
Email: [email protected]
www.TRENDNET.com
ORDERING INFORMATION
TRENDnet
TRENDware, USA
R
TEW-IA06D
TEW-IA06D
6 dBi Directional Indoor Antenna
6 dBi Directional Indoor Antenna
54Mbps 802.11g
Wireless Access Point
(TEW-430APB)
6dBi Indoor Directional Antenna
(TEW-IA06D)
Workstation with
54Mbps 802.11g Wireless PCI Adapter
(TEW-423PI)
Workstation with
54Mbps 802.11g Wireless PCI Adapter
(TEW-423PI)
Notebook with
54Mbps 802.11g
Wireless PC Card)
(TEW-421PC)
Cable/DSL 4-Port
Broadband Router
(TW100-S4W1CA)
Cable/DSL
Modem
Internet
10/100Mbps
54Mbps
6dBi Indoor Directional Antenna
(TEW-IA06D)
