TRENDnet TEW-AO08O User manual

Indoor / Outdoor Antenna,
Antenna Cable & Surge Arrestor
Quick Installation Guide

Table of Contents
Version 02.23.2006
English ........................................................................................................................... 1
1
5
4
6
1. .................................................................
2. ........................................................................
3. .......................................................
4. ..................................................................................
Outdoor Antenna Installation
How to install the surge arrestor
Weatherproof tape for outdoor installations
Indoor Antenna Installation
..............

Before installation, please ensure you have the required products and that the
contents of each product are complete.
One of the following Antennas:
Jumper Cable
Surge Arrestor
TEW-L406 – cable (6 Meter)
TEW-L412 – cable (12 Meter)
TEW-ASAK
TEW-L406/TEW-L412
TEW-AO09D TEW-AO14D TEW-AO19DTEW-AO08O TEW-AO10O
1. Outdoor Antenna Installation
English
1

1. Disconnect the default dipole antenna
from your indoor access point or router.
2. Attach the blue sleeve (Reverse SMA)
of the jumper cable to your Wi-Fi
Device.
3. Connect the black sleeve (N-Type) of
the jumper cable to the surge arrestor.
(Please refer to Section 2: “How to
install the surge arrestor”
English
2

7. Your Outdoor Antenna installation is
now complete.
4. Connect remaining surge arrestor
connector to the blue sleeve (N-Type)
of the antenna cable (TEW-L406/
TEW-L412)
6. Connect the remaining black sleeve
(N-Type) of the Antenna Cable to the
Antenna.
5. Connect the Green wire to grounding
object.
e.g.
1. Earth Driven rod
2. Grounded Electrical System
3. Building frame
English
3

English
4
2. How to install the surge arrestor
1. Before installing the antenna, make
sure the low loss outdoor cable
(TEW-L406/TEW-L412) can reach the
location of access point or router.
Attach the enclosed cable adapter’s
blue sleeve to the Wi-Fi device
(Reverse SMA) and the cable adapters
black sleeve (N-type) to the surge
arrestor.
2. Take out the L-type metal bracket and
mark the mount position on the wall.
3. Screw it to the wall.
4. Seat the arrestor into bracket.
Screw on the nut.
Put on the washer.

English
5
3. Weatherproof tape for outdoor installations
If your surge arrestor is installed outdoors, remember to wrap both connectors
tightly with the enclosed weatherproofing tape.

English
6
4. Indoor Antenna Installation
Before installation, please ensure you have the required products and that the
contents of each product are complete.
One of the following Antennas:
Note: The following Indoor Antennas come with cables or connect directly to
your Wi-Fi Device. No additional cable assemblies are required:
TEW-L202 – cable (2 meter)
TEW-L208 – cable (8 Meter)
TEW-L202/TEW-L208
TEW-AO09D
TEW-AI86DB
TEW-AO14D
TEW-AI75O
TEW-AO19D
TEW-AI75OB
TEW-AO08O TEW-AO10O
TEW-AI86D

English
7
1. Disconnect the dipole antenna from
your access point or router.
2. Attach the blue sleeve (Reverse SMA)
of the indoor cable (TEW-L202/
TEW-L208) directly to the Wi-Fi
Device.
3. Connect the remaining black sleeve
(N-Type) of the antenna cable to the
blue sleeve of the (N-type) antenna.
4. Your Indoor Antenna installation is
now complete.

8
