TRENDnet TEG-S16R - DATA SHEETS User manual

TEG-S16R
TEG-S24R
H/W: v1.0R
Quick Installation Guide

Table of Contents
Table of Contents
Version 02.05.2008
Technical Specifications .............................................................................
Troubleshooting ..........................................................................................
1
1
3
4
6
Español .......................................................................................................
1. Antes de iniciar ...................................................................................
2. Instalación del Hardware ....................................................................

1
Español
Contenidos del paquete
?TEG-S16R/TEG-S24R
?
?Cable de alimentación
?
Guía de instalación rápida
Kit para montaje en estante
Requisitos del sistema
?Un PC con adaptador de red instalado correctamente.
?Un cable de red RJ-45
?
?
?
?
La toma de corriente debe estar a 1.82 metros (6 pies) del conmutador
Compruebe que existe una correcta regulación de la temperatura y una
ventilación adecuada alrededor del conmutador
No coloque objetos pesados encima del conmutador
Estructura de nivel y bastidor de 19 pulgadas estándar EIA o robusto
que pueda soportar el peso del chasis
1. Antes de iniciar

Application
2
10/100/1000Mbps
16-Port Compact Gigabit Switch
(TEG-S16R)
Printers
Workstations with PCI Adapter
(TEG-PCITXR)
Laptop with Gigabit PC Card
(TEG-PCBUSR)
Server with Gigabit PCI Adapter
(TEG-PCITXR)
10/100Mbps Multi-Port
Print Server
(TE100-P21)
300Mbps Wireless N
Gigabit Router
(TEW-633GR)
Cable /DSL Modem
Internet
10/100/1000Mbps
24-Port Compact Gigabit Switch
(TEG-S24R)
Printers
Workstations with PCI Adapter
(TEG-PCITXR)
Laptop with Gigabit PC Card
(TEG-PCBUSR)
Server with Gigabit PCI Adapter
(TEG-PCITXR)
10/100Mbps Multi-Port
Print Server
(TE100-P21)
300Mbps Wireless N
Gigabit Router
(TEW-633GR)
Cable /DSL Modem
Internet
Español

3
Español
2. Instalación del Hardware
1. Conecte el Power Cord (Cable de
alimentación) en la parte trasera
del TEG-S16R/TEG-S24R y
después a la toma corriente.
2. Conecte un cable de red RJ-45
CAT-5e del PC a un puerto
Ethernet disponible en el
TEG-S16R/TEG-S24R.
Para montaje en bastidor
El TEG-S16R/TEG-S24R puede montarse sobre un bastidor de 19 pulgadas
tamaño estándar EIA, que puede colocarse en un armario de empalmes junto
con otros equipos.
1. Fije las abrazaderas de sujeción a
ambos lados del TEG-S16R/
TEG-S24R y asegúrelas con los
tornillos suministrados.
2. Coloque el TEG-S16R/TEG-S24R
con cuidado encima del bastidor.
Procure que la abrazadera
coincida con los orificios de los
tornillos del bastidor, luego use los
tornillos suministrados junto con el
bastidor del equipo para montar el
chasis.
Registre su producto
Para asegurar los más altos niveles de servicio y apoyo al cliente, registre su producto
en línea en: www.trendnet.com/register
Gracias por elegir TRENDnet

4
Standards IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
IEEE 802.3ab 1000BASE-T Gigabit Ethernet
Protocol CSMA/CD
Data Transfer Rates
Ethernet: 10Mbps/20Mbps (Half / Full-Duplex)
Fast Ethernet: 100Mbps /200Mbps (Half /
Full-Duplex)
Gigabit Ethernet: 2000Mbps (Full-Duplex)
Network Cables Ethernet: UTP/STP CAT-3, 4, 5
Fast Ethernet: UTP/STP CAT- 3, 4, 5, 5e, 6
Gigabit Ethernet : UTP/STP CAT-5e, 6
Number of Ports
TEG-S16R: 16 x 10/100/1000Mbps
Auto-negotiation, Auto-MDIX ports
TEG-S24R: 24 x 10/100/1000Mbps
Auto-negotiation, Auto-MDIX ports
General
Topology
LEDs
Star
Power, Link/ACT, 10/100Mbps, 1000Mbps
Technical Specifications

5
Power 100-240VAC. 50/60Hz. Internal Power Supply
Power Consumption TEG-S16R: 14 Watts (Max)
TEG-S24R: 20 Watts (Max)
Temperature Operating: 0 ~ 40 C, Storage: -20 ~ 70 C° ° ° °
Dimensions (L x W x H) 280 x 180 x 45 mm (W x H x D)
Weight TEG-S16R: 1.7kg
TEG-S24R: 1.8kg
Physical and Environmental
Humidity
Certification
Operating: 10% ~ 90%, Storage: 5% ~ 90%
CE, FCC
Transmission Method Store-and-forward
MAC Address Table
RAM Buffer
Switching Fabric
8Kbytes Entries Per Device
500KB
TEG-S16R: 32Gbps
TEG-S24R: 48Gbps
MAC Address Learning Automatic update
Performance

6
Troubleshooting
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
After connecting the Switch to a power outlet, the LEDs do not turn
on.
Check the connection of the external power adapter to the
TEG-S16R/TEG-S24R and the power outlet. Also check that the power
outlet is receiving power.
When I connect a computer to the Switch's port, I am not getting
Gigabit speeds. What should I do?
Check the LED on the Switch. When the LED is off, the computer's
connection speed is 10Mbps. When the LED is green the computer's
connection speed is 100Mbps. The computer's connection speed will be
Gigabit when the LED is amber. Make sure that you have a Gigabit
Ethernet adapter installed. Also make sure to use a Cat-5e or Cat 6
Ethernet cable. Some CAT-5 cables are not rated to run in Gigabit.
After I connect my PCs to the Switch, I am unable to share files.
First, check the LEDs on the Switch. Make sure the Link/Act LED is on.
Second, check the network cable. The minimum length of the cable is 1.5
meters and the maximum length of the cable is 100 meters. Third, disable
any software firewall program. Fourth, verify that you have file sharing
enabled. Please contact your Operating System support for more
information.
After I connect my PCs to the Switch, I can only get onto the Internet
from one computer.
The Switch was not designed to share Internet between multiple
computers. You need to get an Internet router such as the TEW-633GR.
If you still encounter problems or have any questions regarding the
TEG-S16R/TEG-S24R please contact TRENDnet's Technical Support
Department.

Limited Warranty
- 5-Year Warranty
TRENDnet warrants its products against defects in material and workmanship, under
normal use and service, for the following lengths of time from the date of purchase.
TEG-S16R/TEG-S24R
If a product does not operate as warranted above during the applicable warranty period,
TRENDnet shall, at its option and expense, repair the defective product or deliver to
customer an equivalent product to replace the defective item. All products that are
replaced will become the property of TRENDnet. Replacement products may be new or
reconditioned.
TRENDnet shall not be responsible for any software, firmware, information, or memory
data of customer contained in, stored on, or integrated with any products returned to
TRENDnet pursuant to any warranty.
There are no user serviceable parts inside the product. Do not remove or attempt to
service the product through any unauthorized service center. This warranty is voided if
(i) the product has been modified or repaired by any unauthorized service center, (ii) the
product was subject to accident, abuse, or improper use (iii) the product was subject to
conditions more severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet office within the applicable
warranty period for a Return Material Authorization (RMA) number, accompanied by a
copy of the dated proof of the purchase. Products returned to TRENDnet must be pre-
authorized by TRENDnet with RMA number marked on the outside of the package, and
7

WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE
AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT
TRENDNET’S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING
WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF
LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET
NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT
ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.
TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES
NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S
MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED
ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE
RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER
HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET
ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER
BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,
OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE,
PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH
DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND
OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF
LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED
HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of the state of
California.
Note: AC/DC Power Adapter, Cooling Fan, Cables and Power Supply carry a 1-Year
Warranty
8

Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.

Product Warranty Registration
Please take a moment to register your product online.
Go to TRENDnet’s website at http://www.trendnet.com
TRENDnet Technical Support
US Canada
24/7 Tech Support
Toll Free Telephone: [phone]
Europe (Germany France Italy Spain Switzerland UK)
English/Espanol - 24/7
English/Espanol - 24/7
Worldwide
Telephone: +(31) (0) 20 504 05 35
Toll Free Telephone: [phone]
.
. . . . .
Copyright ©2008. All Rights Reserved. TRENDnet.
20675 Manhattan Place
Torrance, CA 90501
USA
