TEW-452BRP
Quick Installation Guide

Table of Contents
English ...................................................................................................... 1
1
6
2
8
1. Before You Start
2. Install Router .....................................................................................
3. Adding/replacing the router ...............................................................
................................................................................
Table of Contents
Version 11.09.2007
Troubleshooting ........................................................................................

System Requirements
?TEW-452BRP
?Easy Go CD-ROM
?Quick Installation Guide
?RJ-45 Cable
?AC Power Adapter (7.5V, 1A)
Package Contents
1. Before You Start
English
1
?Web Browser: Internet Explorer (5.0 or above)
?Computer with Network adapter installed
?Broadband Internet
?Installed Cable or DSL modem
Important! DO NOT connect the router until instructed to do so. Follow the
steps below before you insert the Easy Go CD-ROM into your computer's
CD-ROM Drive.
1. Verify that you have a direct
connection from your Cable or DSL
modem to your computer. Also
verify that you are connected to the
Internet by browsing to a website,
such as http://www.trendnet.com.
Cable/DSL Modem
Internet

3. Choose the desired language from
the dropdown list and then click
Next.
2. Install Router
English
2
1. Insert the Easy Go CD-ROM in
your computer's CD-ROM Drive
and then click Install Router.
2. Click Start Installation.
4. Click Next.

English
3
6. Follow the Wizard instructions and
continue through the remaining
installation steps. Click Next.
7. Enter a new password for the
router and then click Next. By
default, the password is admin.
5. If this screen appears, go to
Section 3. If not, please continue
to step 6.
8. When the wireless network
screen appears, enter a unique
network name and then click Next.
By default, the SSID is TRENDnet.

10. Please write the settings above in
the space provided on the setup
CD sleeve. Then click Next.
9. Select an Encryption type, enter a
security key for your wireless
network and then click Next.
12. Click Next.
11. Click OK.
English
4

For detailed information regarding the TEW-452BRP configuration and
advanced settings, please refer to the User's Guide included on the Easy Go
Installation CD-ROM or TRENDnet's website at www.trendnet.com.
Your installation is now complete.
13. Click Next.
14. Click Finish.
English
5

English
6
3. Adding/Replacing the router
Note: When this window appears, it means you have a DSL/Cable modem
router. If you are replacing the current router with the wireless TEW-452BRP,
please select Yes and click Next to continue. If you are adding the wireless
router behind the current connection, please select No and click Next to
continue.
2. Follow the Wizard instructions and
continue through the remaining
installation steps. Click Next.
When secure access to your
router window appears, please go
to section 2 step 7 to continue.
1. To replace current router, select
Yes and then click Next.
To replace current router

For detailed information regarding the TEW-452BRP configuration and
advanced settings, please refer to the User's Guide included on the Easy Go
Installation CD-ROM or TRENDnet's website at www.trendnet.com.
Your installation is now complete.
2. Follow the Wizard instructions and
continue through the remaining
installation steps. Click Next.
When secure access to your
router window appears, please go
to section 2 step 7 to continue.
Register Your Product
To ensure the highest level of customer service and support, please take a moment to
register your product Online at: www.TRENDnet.com/register
Thank you for choosing TRENDnet
1. To add the wireless router behind
your current network, select No
and then click Next.
To add the router
English
7

8
Troubleshooting
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
Q5:
A5:
Q6:
A6:
I inserted the Easy Go CD-ROM into my computer's CD-ROM drive and the installation menu does
not appear automatically. What should I do?
If the installation menu does not appear automatically, click Start, click Run, and type D:\Autorun.exe
where "D" in "D:\Autorun.exe" is the letter assigned to your computer's CD-ROM Drive. Then click OK to
start the installation. If your computer is not a Windows-based PC (e.g. Mac, Linux), then you need to
manually configure your Internet connection settings. See Question 4.
How can I get into the TEW-452BRP web configuration page?
After you install the TEW-452BRP Wireless Router, you can access the web configuration page by
opening your web browser and entering http://192.168.10.1 into the web browser's address bar, where
http://192.168.10.1 is the default IP address of the TEW-452BRP Wireless Router. The default user name
and password is admin.
I am not sure what type of Internet Account Type I have for my Cable/DSL connection. How do I find
out?
Contact your Internet Service Provider's (ISP) Customer Service for the correct information.
I received an error while running Easy God Setup. What should I do?
Make sure that your computer's CD-ROM is in working condition. Also verify that all cable connections
are secure and that you are able to connect to the Internet, and then retry installing the router. During
setup, the Easy Go Setup wizard will check the operation of your network adapter and Internet connection.
If the 111 error message appears, you may need to change the IP address of the router.
1) Open up Internet explorer, type into the address bar http://192.168.10.1 and hit enter.
2) Click on Basic -> Network Settings.
3) Under Router Settings, change the Router IP address to 192.168.11.1.
4) Under DHCP Server Settings, change the DHCP IP Address Range to 192.168.11.101 to
192.168.11.200.
5) Click Save Settings.
All the settings are correct, but I can not make a wireless connection to the Router. What should I
do?
First, double check that the WLAN light on the Router is lit. Second, power cycle the TEW-452BRP.
Unplug the power to the TEW-452BRP. Wait 15 seconds, then plug the power back in to the
TEW-452BRP. Third, contact the manufacturer of your wireless network adapter and make sure the
wireless network adapter is configured with the proper SSID and Encryption (if enabled).
After I finish installing the router, then Network Magic Installation Wizard appears. What should I do?
Network Magic is an optional bonus program. It works with your router to setup, manage, repair and
protect your home network. If you do not want to install Network Magic, select Exit TRENDnet Router
Setup and then click Finish.
If you still encounter problems or have any questions regarding the TEW-452BRP, please refer to the User's
Guide included on the Easy Go Setup CD-ROM or contact Trendnet’s Technical Support Department.

Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de alimentacón
necesario para su funcionamiento. El uso de un adaptador distinto al mencionado puede producir
daños fisicos y/o daños al equipo conectado. El adaptador de alimentación debe operar con voltaje y
frecuencia de la energia electrica domiciliaria existente en el pais o zona de instalación.

Copyright ©2007. All Rights Reserved. TRENDnet.
