TRENDnet TV-H400 User manual

TV-H400
H/W: V2
Quick Installation Guide

Table of Contents
Version 10.09.2008
English ...................................................................................................... 1
1
2
1. Before You Start
2. Hardware Installation .........................................................................
................................................................................
Troubleshooting ........................................................................................ 11

English
1
1. Before you start
Installation Requirements
Package Contents
The following items below are not included. Users must provide the items
themselves. Make sure to have each item on hand before installation.
?
?
?Power Adapter (12V DC, 0.6A)
?1 x Wall Mount Bracket
?Allen wrench (4mm)
?Screws and lock washers
?Rubber seal
TV-H400
Quick Installation Guide
?
?Mounting screws and screw anchors (for wall mounting)
?Dry wall or wood surface
?Phillips screwdriver
?RJ-45 Ethernet cable
Pan and tilt Internet camera

2. Hardware Installation
English
2
Note: Configure your Internet Camera Server to match your network before
installing the device.
Bracket:BR001
Bracket:BR002
Q6
Round Head x 5pcsScrew
Bracket:BR003
Q4
3.5cm Hex x 2pcsScrew
Q1
Flat Head Screw x 3pcs
Q5
Washer x 3pcs
Hex Nut Top x 3pcs
Q7
Rubber x 1pcsSeal
Q3
5cm Hex x 3pcsScrew

English
3
3. Run all necessary cables (Ethernet
cable, power adapter cable, and
the power terminals) through the
wall mount bracket.
2. Unscrew the thumbscrew. Save
this screw. You will need to use this
screw later.
1. Rotate the TV-H400's cover
counter clockwise and remove the
cover.

English
4
4. Connect the power terminal to the
provided 12V DC, 0.6A power
adapter.
5. Run each cable through the
opening located at the top of the
TV-H400.
6. After inserting the appropriate
cables, extend each cable to 6
inches for camera installation.
7. Use the provided rubber seal to
seal the housing.

English
5
8. Secure the protective plating into
the wall mount bracket using the
thumb screw.
10. Connect the three 5 cm Hex
screws to the circular base
bracket. Secure the Hex screws
with the nuts and washers. The
5cm Hex screws are in the plastic
bag labeled Q3. The nuts and
washers are in the plastic bag
labeled Q5.
9. Screw the wall mount bracket on
top of the TV-H400 with the
provided Allen wrench and three
hexagon socket screws. The
screws are in the plastic bag
labeled Q2.

6
English
12. Use three round head screws to
mount bracket BR002 on top of
the 3 Hex screws. The three
round head screws are in the
plastic bag labeled Q6.
11. Mount bracket BR003 to the
camera enclosure using the three
flat head screws. These screws
are in the plastic bag labeled Q1.
13. Connect the two 3.5 cm hex
screws to this bracket. These
screws are in the plastic bag
labeled Q4.

7
English
15. Use the two round head screws to
mount bracket BR001 to the two
hex screws. The two round head
screws are in the plastic bag
labeled Q6.
16. Connect the Ethernet cable and
power adapter to the Internet
Camera Server.
14. Attach bracket BR001 to the
camera with 3 small screws.
These screws should come with
the Internet Camera Server.

8
English
18. Plug the power to the Internet
Camera Server and the camera
enclosure into an available power
outlet.
17. Place the TV-H400's cover over
the camera and rotate the cover
clock-wise.
