TRENDnet TE-800 User manual

TRENDware Small Business Solutions series palmtop hubs
provide a cost effective connectivity solution and plug-and-
play solution for small departmental networks and
workgroups. Their compact size and lightweight design
provide easy installation and portability. The TE-800 is
equipped with an uplink port (shared with the last RJ45 port),
which makes connecting to another 10 Base-T hub effortless.
For added durability these hubs are protected by heavy gauge
aluminum chassises. These hubs are also UL, CSA and FCC
Class A approved, and features a 5 Year Parts and Labor
Warranty.
TE-800
8-Port 10Base-T Ethernet Hub
IEEE 802.3 10 Base-T Ethernet Standard
CSMA/CD protocol for complete data integrity
Easy to Read LED’s for Global Power, Collision,
Link/Activity indicators
Auto-Partitioning
Uplink port (shared with the last RJ45 port) provides
easy expansion to another hub
10Mbps transfer rate
Heavy duty aluminum chassis
Compact, lightweight, and portable
UL & CSA Certified, FCC Class A
5 Year Warranty
FEATURES
TE-800 (11-17-2002)
TRENDnet
TRENDware, USA
What's Next in Networking

SPECIFICATIONS
PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
TE-500: 5-Port 10Base-T Hub
AD-0730: 120V AC power adapter for TE-500
AD-0730B: 230V AC power adapter for TE-500
TE-800: 8 RJ45 ports Ethernet hub
TE-900: 10Base-T Ethernet Hub with 9 UTP
Ports
TE-910: 10Base-T Ethernet Hub with 8 UTP
and 1 BNC Ports
TE-910plus: 8 RJ45 ports + 1 BNC Ethernet
hub
TE-1710: 16 RJ45 ports + 1 BNC Ethernet hub
ORDERING INFORMATIONORDERING INFORMATION
TRENDnet
TRENDware, USA
R
TE-800
8-Port 10Base-T Ethernet Hub
TE-800
8-Port 10Base-T Ethernet Hub
Standards:
• IEEE 802.3 10 Base-T
Speed:
• 10Mbps
Ports:
• 8 RJ45 UTP/STP port
Power:
• 7.5 VDC, 1A
Dimensions:
• 165 x 102 x 30 (mm)
6.5"x4.0"x1.18" (L x W x H)
Weight:
• 340g / 0.75 lb
Temperature:
• Operating: 0°C ~ 50°C (32°F ~ 122°F)
• Storage: -20°C ~ 70°C (-4°F ~ 158°F)
Humidity:
• Operating: 10% ~ 80%
• Storage: 5% ~ 90%
Certifications:
• FCC, UL, CE
U
L
R
TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this
document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit ____________________
http://www.TRENDNET.com.
©
Copyright TRENDware International, Inc. 2004. All Rights Reserved.
