TRENDnet TE100-S16V User manual

TRENDnet’s TE100-S16V 16-Port 10/100Mbps Smart Switch
is the ideal switch for network segmenting. It has an optional
fiber optic module that makes the switch flexible enough for
mid-sized companies and branch offices to meet their high
bandwidth requirements. By using standard auto-negotiation,
it provides a cost-effective way of integrating 10Mbps
segments with 100Mbps Fast Ethernet networks, and is ideal
for extending distances between two 100Mbps network
segments. Supporting Virtual Local Area Networking (VLAN),
it is powerful and easy-to-use in reducing unnecessary
broadcast traffic and enhance network security.
TE100-S16V
16-port 10/100Mbps Smart Switch
16 10/100Mbps Auto-negotiation, Auto-MDIX Fast Ethernet Ports
1 expansion slot for optional 100Base-FX fiber module
Full/Half-Duplex transfer mode for each port
Wire Speed reception and transmission
Store and Forward switching method
Supports 512K bytes RAM data buffering
Extensive diagnostic LED’s on the front panel
Broadcast storm protection
IEEE 802.3x flow control for half-duplex mode
Back pressure flow control for half-duplex mode
Supports Port-Based VLAN (17 groups) and Port-Based / IEEE 802.1p
QoS (high or low)
Integrated address Look-Up Engine with 4K entries MAC address table
Support Port setting function allow user setting each port
disable/enable, speed, duplex mode, and device flow control
Supports RS-232 Console port in front panel for configuration
Standard 19” Rack-mount design
5-Years Warranty
BENEFITSFEATURES
Easy Upgrade:
Expandability:
Flexibility:
Performance:
Cost-Effectiveness:
Ethernet workgroups are able to
upgrade to Fast Ethernet by changing
adapters and a hub without changing
switches.
Expand the connection up to 2Km with
optional fiber module (50/125 or
62.5/125um multimode fiber with SC
type connector).
Port-based VLAN reduces broadcast
traffic and enhance network security.
Provides non-blocking high performance
with internal switch controller.
The TE100-S16V presents 10/100Mbps
of Fast Ethernet at an affordable rate.
TE100-S16V (11-17-2002)
TRENDnet
TRENDware, USA
What's Next in Networking

PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
TE100-S16V
16-Port 10/100Mbps Smart Switch
TE100-S24V
24-Port 10/100Mbps Smart Switch
NETWORKING SOLUTIONS
SPECIFICATIONS
LAN Standards:
IEEE 802.3 10Base-T, IEEE 802.3u
100Base-TX, 100Base-FX
Network Media:
Ethernet: UTP/STP Cat. 3, 4, 5Fast
Ethernet: UTP/STP Cat. 5Fiber
Module: 50/125 or 62.5/125um
multimode fiber
Protocol:
CSMA/CD
Topology:
Star
LAN Port:
16 x 10/100Mbps Auto-MDIX ports,
1 expansion slot for 100Base-FX
fiber module
Address Table:
4K entries per device
•
•
•
•
•
•
•
•
•
Data Transfer Rate:
Ethernet: 10/20Mbps – Half/Full-Duplex
Fast Ethernet: 100/200Mbps –
Half/Full Duplex
Diagnostic LEDs:
Per Unit: Power, System,
Per Port:
TX: Link/Activity, Speed,
FX: Link/Activity. FDX
Power Consumption:
12 Watts. Max
Dimensions:
440 x 200 x 44 mm
(17.32 x 7.87 x 1.73 inches)
(W x H x D)
Temperature:
Operating: 0° ~ 40°C (32° ~ 104°F)
Storage: -10° ~ 70°C (14° ~ 158°F)
•
•
•
•
•
•
•
•
•
•
Humidity:
10% ~ 90% (no-condensing)
Emission:
FCC Class A, CE Mark A, VCCI-A
•
•
TE100-S16V
16-port 10/100Mbps Smart Switch
TE100-S16V
16-port 10/100Mbps Smart Switch
