TRENDnet TE100-S5Pplus User manual

TE100-S5Pplus
TE100-S8P
Quick Installation Guide

Table of Contents
Table of Contents
Version 07.26.2006
Español .......................................................................................................
Technical Specifications .............................................................................
Troubleshooting ..........................................................................................
1
1
2
3
5
1. Antes de iniciar ...................................................................................
2. Instalación del Hardware ....................................................................

Español
1
1. Antes de iniciar
Un PC con adaptador de red instalado correctamente.
La superficie debe soportar al menos 0.5 Kg para el conmutador.
La toma de corriente debe estar a 1.82 metros (6 pies) del conmutador.
Contenidos del paquete
TE100-S5Pplus/TE100-S8P
Adaptador de alimentación AC
Guía de instalación rápida
Inspeccione visualmente el jack de corriente DC para comprobar que
está conectado al adaptador de corriente.
Compruebe que existe una correcta regulación de la temperatura y una
ventilación adecuada alrededor del conmutador.
No coloque objetos pesados encima del conmutador.
Aplicación
Requisitos del sistema
Cable/DSL
Modem Router
10/100Mbps
Multi-Port Print Server
(TE100-P21)
5/8 Ports 10/100Mbps
Fast Ethernet Switch
(TE100-S5Pplus or TE100-S8P)
Server with
PCI Adapter
(TE100-PCIWA)
Printers
100Mbps
Workstation with
PCI Adapter
(TE100-PCIWN)
Internet
Laptop with PC Card
(TE100-PCBUSR)

Español
2
2. Instalación del Hardware
2. Conecte un cable de red RJ-45
CAT-5 del PC a un puerto Ethernet
disponible en el
TE100-S5Pplus/TE100-S8P.
1. Conecte el adaptador de
alimentación AC al
TE100-S5Pplus/TE100-S8P y
luego a una toma de corriente.
La instalación ha sido completada

3
Standards
IEEE 802.3 10BASE-T Ethernet
IEEE 802.3u 100BASE-TX Fast Ethernet
ANSI/IEEE 802.3 NWay Auto-negotiation
IEEE 802.3x Full-Duplex Flow Control
Protocol CSMA/CD
Data Transfer Rates
Ethernet: 10Mbps (Half-Duplex),
20Mbps (Full-Duplex)
Fast Ethernet: 100Mbps (Half-Duplex),
200Mbps (Full-Duplex)
Network Cables Ethernet: UTP/STP CAT-3, 4, 5
Fast Ethernet: UTP/STP CAT-5, 5e , 6
Number of Ports 5 or 8 x 10/100Mbps Auto-negotiation,
Auto-MDIX ports
General
Topology Star
Technical Specifications
Transmission Method Store-and-Forward
MAC Address Table TE100-S5Pplus: 1K Entries Per Device
TE100-S8P: 1K Entries Per Device
MAC Address Learning Automatic update
Performance

4
DC inputs DC 7.5V 1A
Power Consumption TE100-S5Pplus: 2.5W (Max.)
TE100-S8P: 2.8W (Max.)
Temperature Operating: 0 ~ 40 C, Storage: -10 ~ 70 C° ° ° °
Dimensions (L x W x H) TE100-S5Pplus: 165 x 73 x 33 mm
TE100-S8P: 165 x 73 x 33 mm
Weight TE100-S5Pplus: 145g
TE100-S8P: 170g
Physical and Environmental
Humidity
Certification
Operating: 10% ~ 90%, Storage:5% ~ 90%
FCC, CE

5
Troubleshooting
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
After connecting the Switch to a power outlet, the LEDs do not turn on.
Check the connection of the external power adapter to the
TE100-S5Pplus/TE100-S8P and the power outlet. Also check that the power outlet
is receiving power.
When I connect a computer to the Switch's port, the LINK/ACT LED turns on,
but the 100Mbps LED remains off.
When the 100Mbps LED remains off, the computer's connection speed is
10Mbps.
After I connect my PCs to the Switch, I am unable to share files.
First, check the LEDs on the Switch. Make sure the LINK/ACT LED is on.
Second, check the network cable. The minimum length of the cable is 1.5 meters
and the maximum length of the cable is 100 meters. Third, disable any software
firewall program. Fourth, verify that you have file and printer sharing enabled.
Please contact Microsoft support for more information.
After I connect my PCs to the Switch, I can only get onto the Internet from one
computer.
The Switch was not designed to share Internet between multiple computers.
You need to get an Internet router.
If you still encounter problems or have any questions regarding the
TE100-S5Pplus/TE100-S8P please contact Trendnet's Technical Support Department.

Limited Warranty
- 5 Years Warranty
TRENDnet warrants its products against defects in material and workmanship, under
normal use and service, for the following lengths of time from the date of purchase.
TE100-S5Pplus/TE100-S8P
If a product does not operate as warranted above during the applicable warranty period,
TRENDnet shall, at its option and expense, repair the defective product or deliver to
customer an equivalent product to replace the defective item. All products that are
replaced will become the property of TRENDnet. Replacement products may be new or
reconditioned.
TRENDnet shall not be responsible for any software, firmware, information, or memory
data of customer contained in, stored on, or integrated with any products returned to
TRENDnet pursuant to any warranty.
There are no user serviceable parts inside the product. Do not remove or attempt to
service the product through any unauthorized service center. This warranty is voided if
(i) the product has been modified or repaired by any unauthorized service center, (ii) the
product was subject to accident, abuse, or improper use (iii) the product was subject to
conditions more severe than those specified in the manual.
Warranty service may be obtained by contacting TRENDnet office within the applicable
warranty period for a Return Material Authorization (RMA) number, accompanied by a
copy of the dated proof of the purchase. Products returned to TRENDnet must be pre-
authorized by TRENDnet with RMA number marked on the outside of the package, and
sent prepaid, insured and packaged appropriately for safe shipment.
6

WARRANTIES EXCLUSIVE: IF THE TRENDNET PRODUCT DOES NOT OPERATE
AS WARRANTED ABOVE, THE CUSTOMER’S SOLE REMEDY SHALL BE, AT
TRENDNET’S OPTION, REPAIR OR REPLACEMENT. THE FOREGOING
WARRANTIES AND REMEDIES ARE EXCLUSIVE AND ARE IN LIEU OF ALL OTHER
WARRANTIES, EXPRESSED OR IMPLIED, EITHER IN FACT OR BY OPERATION OF
LAW, STATUTORY OR OTHERWISE, INCLUDING WARRANTIES OF
MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE. TRENDNET
NEITHER ASSUMES NOR AUTHORIZES ANY OTHER PERSON TO ASSUME FOR IT
ANY OTHER LIABILITY IN CONNECTION WITH THE SALE, INSTALLATION,
MAINTENANCE OR USE OF TRENDNET’S PRODUCTS.
TRENDNET SHALL NOT BE LIABLE UNDER THIS WARRANTY IF ITS TESTING AND
EXAMINATION DISCLOSE THAT THE ALLEGED DEFECT IN THE PRODUCT DOES
NOT EXIST OR WAS CAUSED BY CUSTOMER’S OR ANY THIRD PERSON’S
MISUSE, NEGLECT, IMPROPER INSTALLATION OR TESTING, UNAUTHORIZED
ATTEMPTS TO REPAIR OR MODIFY, OR ANY OTHER CAUSE BEYOND THE
RANGE OF THE INTENDED USE, OR BY ACCIDENT, FIRE, LIGHTNING, OR OTHER
HAZARD.
LIMITATION OF LIABILITY: TO THE FULL EXTENT ALLOWED BY LAW TRENDNET
ALSO EXCLUDES FOR ITSELF AND ITS SUPPLIERS ANY LIABILITY, WHETHER
BASED IN CONTRACT OR TORT (INCLUDING NEGLIGENCE), FOR INCIDENTAL,
CONSEQUENTIAL, INDIRECT, SPECIAL, OR PUNITIVE DAMAGES OF ANY KIND,
OR FOR LOSS OF REVENUE OR PROFITS, LOSS OF BUSINESS, LOSS OF
INFORMATION OR DATE, OR OTHER FINANCIAL LOSS ARISING OUT OF OR IN
CONNECTION WITH THE SALE, INSTALLATION, MAINTENANCE, USE,
PERFORMANCE, FAILURE, OR INTERRUPTION OF THE POSSIBILITY OF SUCH
DAMAGES, AND LIMITS ITS LIABILITY TO REPAIR, REPLACEMENT, OR REFUND
OF THE PURCHASE PRICE PAID, AT TRENDNET’S OPTION. THIS DISCLAIMER OF
LIABILITY FOR DAMAGES WILL NOT BE AFFECTED IF ANY REMEDY PROVIDED
HEREIN SHALL FAIL OF ITS ESSENTIAL PURPOSE.
Governing Law: This Limited Warranty shall be governed by the laws of the state of
California.
Note: AC/DC Power Adapter, Cooling Fan, and Power Supply carry 1-Year Warranty
7

Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may
cause undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FOR ANY RADIO OR TV
INTERFERENCE CAUSED BY UNAUTHORIZED MODIFICATIONS TO THIS
EQUIPMENT. SUCH MODIFICATIONS COULD VOID THE USER’S AUTHORITY TO
OPERATE THE EQUIPMENT.
Waste electrical and electronic products must not
be disposed of with household waste. Please
recycle where facilities exist. Check with you Local
Authority or Retailer for recycling advice.
ADVERTENCIA
En todos nuestros equipos se mencionan claramente las caracteristicas del adaptador de
alimentacón necesario para su funcionamiento. El uso de un adaptador distinto al
mencionado puede producir daños fisicos y/o daños al equipo conectado. El adaptador
de alimentación debe operar con voltaje y frecuencia de la energia electrica domiciliaria
existente en el pais o zona de instalación.
