TRENDnet TEG-S40SX User manual

TRENDnet's TEG-S40SX provides industry-leading
performance with multiple control mechanisms that manage
bandwidth for real-time and multimedia traffic to be forwarded in
a controllable manner effortlessly. These mechanisms include
IEEE 802.1p with priority queuing, IEEE 802.1Q for network
policing, and IGMP snooping to provide intelligent network
support for multicast applications. Also, the TEG-S40SX
provides link aggregation for increased bandwidth scalability
and fault tolerance. The MultiPoint Link Aggregation (MPLA)
combines link aggregation and resilient links with load sharing in
a point-to-multi-point environment. The TEG-S40SX is a high-
capacity switch that gives you the scalability and flexibility to
deploy cost-effective network environment.
TEG-S40SX
4-port 1000Base-SX Gigabit Ethernet Switch
Supports IEEE 802.1q MAC base VLAN, IEEE 802.1p Traffic
Class Priority, IEEE 802.1d Spanning Tree Protocol
Four 1000Base-SX Gigabit Ethernet SC type fiber ports
Full-duplex mode
Store-and-forward switching scheme
Data filtering eliminates error packets and runts
Integrated flow control
IGMP snooping supports multimedia applications
Broadcast storm control for monitoring and constraining
broadcast traffic level on each port
Extensive management through SNMP, RMON, and MIBs
Monitor status and retrieve data with Web-based Network
Management, Telnet, and Console Port
Flash memory for software upgrade
12K MAC address entry table per device
19-inch rack mountable
5 Year Warranty
BENEFITSFEATURES
Performance:
Reliability:
Flexibility:
Manageability:
The full-duplex Gigabit switch brings
bandwidth to 2000Mbps speed.
The IGMP snooping ensures
uninterrupted multimedia application.
Broadcast Storm Control feature also
prevents unnecessary network
bandwidth absorption.
With IEEE 802.1Q multiple VLAN
support, it enables flexible and secure
network configuration.
Provides the benefit of extensive and
simple management through SNMP,
HTTP, and four RMON groups.
TEG-S40SX (11-17-2002)
TRENDnet
TRENDware, USA
What's Next in Networking

To Order Please Call:
1-888-326-6061
NETWORKING SOLUTIONS
SPECIFICATIONS
PRODUCT INFORMATION
TEG-PCISX 64-bit 1000Base-SX Gigabit Ethernet Adapter with SC Connector
TEG-S40SX 4-port 1000Base-SX Gigabit Ethernet Switch
TEG-S224M 22-port 10/100Mbps Management Stackable Master Switch with
Optional Gigabit Ethernet
TEG-S224S 24-port 10/100Mbps Management Stackable Fast Ethernet Slave
Switch
TEG-M101F 1-port 100Base-FX (SC) Module for TEG-S224M and TEG-S224S
TEG-M102FM 2-port 100Base-FX (MJ-RJ) Module for TEG-S224M and TEG-
S224S
TEG-M3S 3-port SIO Stacking Extension Module forTEG-S224M
TEG-M1G 1-port 1000Base-SX (SC) Gigabit Ethernet Module for TEG-S224M
TEG-M2G 2-port 1000Base-SX (SC) Gigabit Ethernet Module for TEG-S224M
TEG-S40SX
4-port 1000Base-SX Gigabit Ethernet Switch
TEG-S40SX
4-port 1000Base-SX Gigabit Ethernet Switch
Standards:
• IEEE 802.3, IEEE 802.3µ, IEEE 802.3z,
IEEE 802.1p/Q, IEEE 802.3x,
RFC 1213, RFC 1757, RFC 1493
Protocols:
• CSMA/CD
Switching Method:
• Store-and-forward
Cabling:
• Multimode Fiber 50/125
micron-meter, 525 meter max.;
• Multimode Fiber 62.5/125
micron-meter, 275 meter max.
Diagnostic LEDs:
• Per device: Power, Console
• Per port: Link/Activity, full-duplex
Power:
• 100-240VAC, 50/60Hz, 30 W
Dimensions:
• 441 x 207 x 44 mm
(17.3 x 8.1 x 1.7 inches)
Weight:
• 3 kg (6.6 lbs.)
Operating Temperature:
• 0° to 50° C (32° to 122° F)
Humidity:
• 5 % to 95 % non-condensing
Certifications:
• FCC, CE, VCCI Class A, C-tick, BCIQ
TRENDnet is a registered treademark of TRENDware International, Inc. Other Brands and product names are trademarks of their respective holders. Information provided in this
document pertain to TRENDware products and is subject to change at any time, without notice. For the most recent product information please visit ____________________
http://www.TRENDNET.com.
©
Copyright TRENDware International, Inc. 2004. All Rights Reserved.
