TRENDnet TE100-DM24 User manual

The TE100-DM24 dual speed SNMP stackable master hub provides a
phenomenal level of flexibility and ease of use for migration to higher
bandwidth network environments. Each port auto-senses between
10Mbps Ethernet and 100Mbps Fast Ethernet. Once the port speed is
determined, the hub creates independent segments for the 10Mbps and
100Mbps ports. Linking the 10Mbps and 100Mbps segments together is
achieved through an optional switch module.
The optional TE100-DSM switch module can be installed in any hub in the
stack, making it possible to transparently bridge between 10Mbps and 100Mbps segments. In a managed hub stack, more than
one TE100-DSM module can be used to provide automatic redundancy.
The TE100-DM24 is a SNMP Master hub which will control up to four TE100-DS24 stackable hubs via integrated management
ports.A stack of TE100-DM24/DS24 hubs operates as a class II Fast Ethernet repeater, allowing linkage to another Class II Fast
Ethernet Stack in the same collision domain.
One 100Base-TX switched port module and one switched 100Base-FX port are also available, in addition to the TE100-DSM
switch module, for greater configuration flexibility.
TE100-DM24
24-port 10/100Mbps Dual Speed SNMP Stackable Master Hub
Plug and Play installation with automatic port configuration
Supports 24 10/100Mbps auto-sensing and auto-negotiation
ports
Uplink port provides easy expansion to another hub
Stackable to five units for a total of 120 ports
Scalable expansion of up to two stacks for a total 238 ports
One management hub) controls an entire stack of dual speed
hubs (max. four hubs)
TE100-DM24 stacks can make use of additional switch
modules for redundancy
EIA-19" rack mountable
High visibility LED indicators provide status for each port
Bandwidth utilization LED array for traffic volume display
Automatic Hub ID assignment and front panel display
Built-in auto-partitioning instantly isolates network failures
One RS-232 port allows local terminal access to hub
configuration, diagnosis, and firmware upgrade
Slide-in switch module allows bridging between 10Mbps and
100Mbps segments, just one switch module is required for
entire stack
Slide-in switch module for one 100Base-TX connections or one
100Base-FX connection
5 Year Warranty
FEATURES BENEFITS
Upgradable:
Expandable:
Flexible:
Cost Effective:
Performance:
Ethernet workgroups can be upgraded
to Fast Ethernet without changing
hubs.
Connect up to 120 users per stack.
Also stackable with TE100-D16s hubs.
All 10 and 100Mbps users can exist
on one hub.
Provides 10Mbps and 100Mbps
SNMP stackable hub, and
10/100Mbps switch functionality in
one unit.
Full 100Mbps connectivity significantly
boosts network performance.
TE100-DM24 (11-17-2002)
TRENDnet
TRENDware, USA
What's Next in Networking

PRODUCT INFORMATION
To Order Please Call:
1-888-326-6061
TE100-DM24: 24-port 10/100Mbps dual speed
SNMP stackable Master hub
TE100-DS24: 24-port 10/100Mbps dual speed
stackable hub
TE100-DSM: 10/100Mbps switch slide-in
module
TE100-DFXM: Switch 100Base-FX slide-in
module
TE100-DTXM: Switch 100Base-TX slide-in
module
NETWORKING SOLUTIONS
SPECIFICATIONS
Standards:
• IEEE 802.3µ 100Base-TX/100Base-FX,
and IEEE 802.3 10Base-T
Protocol:
• CSMA/CD
Speed:
• 10Mbps for 10Base-T
• 100Mbps for 100Base-TX
Cabling:
• CAT 3, 4, 5 UTP/STP for 10Base-T
• CAT 5 UTP/STP for 100Base-FX 62.5/125
micron multi mode SC fiber (2km)
Daisy-Chain Port:
• SCSI 50 pin x 2
Console Port:
• DB-9 (9 pin) DCE RS-232 x 1
Power:
• Internal Power Supply, (100 - 240V, 50/60Hz)
LED’s:
• Per Hub: Power, Collision (10, 100) Slot 1 or 2,
Hub ID, Bandwidth Utilization %,
Console and SNMP
• Per Port: Link/Rx, Auto Partition,
Disable, Port Speed (10Mbps, 100Mbps)
Dimensions:
• 441 x 237 x 55 mm
17.36" x 9.33" x 2.17" (L x W x H)
Weight:
• 3.87 kg / 8.53 lb.
Temperature:
• Operating: -10° to 55° C / 14° to 131°F
• Storage: -25° to 80° C / -13° to 176°F
Humidity:
• 5% to 95% (non-condensing)
Certification:
• FCC, UL, VCCI, CSA, C-tick, TUV, CE
TE100-DM24
24-port 10/100Mbps Dual Speed SNMP Stackable Master Hub
TE100-DM24
24-port 10/100Mbps Dual Speed SNMP Stackable Master Hub
®
U
L
R
