TRENDnet TK-205K - PS/2 KVM Switch User manual

TK-205K
Quick Installation Guide

Table of Contents
Table of Contents
Version 02.08.2006
English .....................................................................................................
Specifications ............................................................................................
Troubleshooting .........................................................................................
1
1
2
3
5
6
1. Before You Start
2. How to Install .....................................................................................
3. Operation ...........................................................................................
................................................................................

System Requirements
Application
TK-205
Quick Installation Guide
KVM cables (two)
PS/2 Keyboard
PS/2 Mouse
VGACompatible Monitor
Windows XP/2000/ME/98SE, Unix or Linux
Package Content
1. Before You Start
English
1
PC 1 PC 2
LCD Monitor
2-Port PS/2
KVM Switch
(TK-205K)
PS/2 Keyboard PS/2 Mouse
Cable Cable

2. How to Install
English
2
Note: TheTK-205 PS/2 KVM Switch does not require any drivers or software.
1. Turn OFF all computers and their
peripherals, and then disconnect all
power cords.
3. Use the KVM cables to connect
each computer to the KVM switch.
Your installation is now complete.
4. Turn ON the connected computers
one-by-one and wait until each
computer's desktop appears.
2. Connect the shared keyboard,
monitor, and mouse to the KVM
switch's Console Port.

English
3
3. Operation
Note:
3.1 The Push Buttons
To switch between computers, you can use the front-panel push buttons
or the "Hot-Key" commands.
Press the corresponding push
buttons to select your PC.
3.2 Hot-Key Commands
Akeyboard hot-key command consists of three keystrokes:
Hot-Key command = ScrLk + ScrLk + Command key(s)
After pressing the ScrLk key, you have 2 seconds to press the ScrLk key again.
You then have another 2 seconds to press a command key. If you do not press
a key within 2 seconds, the switch will exit hot-key mode.
Command Hot-Keys Description
Quick Reference Sheet for TK-205
Select PC
Next higher PC channel
Next lower PC channel
Autoscan
Stop Autoscan
ScrLk ScrLk X
+ +
(x is a top-row number key)
x = 1 ~ 2 for PC channel number
ScrLk ScrLk
+ + (Arrow up)
ScrLk ScrLk
+ + (Arrow down)
ScrLk ScrLk
+ + S
Press any key on keyboard
Select the active PC channel.
Select the next higher connected
PC channel.
Select the next lower connected
PC channel.
Autoscan through every channel for quick
screen browsing of each channel.
Terminate Autoscan activity.
ScrLk ScrLk
+ + (key)
Hot-Key Convention: The hotkey notation ,
denotes that you should hit the individual key consecutively one at a time, not
simultaneously.

Computer Connections 2
Cable Interface (all male)
KVM Cable 2 Sets of 1.2M (4ft) KVM Cables
Console Connectors
(all female)
Mouse: PS/2 6-pin Mini Din
Keyboard: PS/2 6-pin Mini Din
Monitor: VGA/SVGAHDB 15-pin
To Console:
1 x VGA/SVGAHDB 15-pin
To PC:
1 x PS/2 Mouse 6-pin Mini Din
1 x PS/2 Keyboard 6-pin Mini Din
1 x VGA/SVGAHDB 15-pin
Port Selection Push Button or Hot-Key Commands
Auto-Scan Interval 10 seconds
Keyboard State Saved and restored
Power Supply Bus-Powered
Dimensions 95 x 65 x 30 mm (3.7 x 2.6 x 1.2 in.)
Weight 85g (3oz)
0º ~ 40ºC (32º ~104º F)Operating Temperature
-20º ~ 60ºC (-4º ~ 140º F)Storage Temperature
0%~80%, Non-Condensing
Humidity
CE, FCCCertifications
4
Specifications

Certifications
This equipment has been tested and found to comply with FCC and CE Rules.
Operation is subject to the following two conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received. Including interference that may cause
undesired operation.
NOTE: THE MANUFACTURER IS NOT RESPONSIBLE FORANY RADIO ORTV INTERFERENCE
CAUSED BY UNAUTHORIZED MODIFICATIONS TOTHIS EQUIPMENT. SUCH MODIFICATIONS
COULD VOID THE USER’SAUTHORITY TO OPERATETHE EQUIPMENT.
5
Troubleshooting
Waste electrical and electronic products must not
be disposed of with household waste. Please
recyclewherefacilitiesexist. CheckwithyouLocal
AuthorityorRetailerforrecyclingadvice.
Q1:
A1:
Q2:
A2:
Q3:
A3:
Q4:
A4:
Q5:
A5:
Where is the AC adapter? I did not find one in the box.
I have the KVM switch connected properly, but my keyboard and mouse don't
work. Please make sure your PS/2 ports are working properly by testing it with
another mouse or keyboard. Once you confirm that the PS/2 ports are functional,
please reboot your computers, and try to use the KVM switch again.
Can I connect or disconnect the KVM cables while the computers are turned
on? Yes, you can connect or disconnect the KVM cables while the computers are
turned on, because the interface is Hot-Pluggable.
Will the KVM switch remember the keyboard settings between computers?
Yes, the KVM switch will remember the keyboard settings when switching
between your computers. (i.e.: Caps lock, Num key, etc.)
How do I switch from one computer to another with the KVM switch?
Because the TK-205 KVM switch supports Hot-Key commands, you can use
Hot-Key commands to switch between 2 computers.
The TK-205 does not require anAC adapter. It draws power from your
computer's keyboard port.As long as your KVM switch is connected to the
keyboard port, it will receive the necessary power to function.
If you still encounter problems or have any questions regarding the TK-205K, please
contact Trendnet's Technical Support Department.
