TRENDnet TK-401R User manual

INTRODUCTIONINTRODUCTION
FEATURESFEATURES
PACKAGE CONTENTSPACKAGE CONTENTS
TECHNICAL SPECIFICATIONSTECHNICAL SPECIFICATIONS
SYSTEM REQUIREMENTSYSTEM REQUIREMENT
PRODUCT DETAILSPRODUCT DETAILS
HARDWARE INSTALLATIONHARDWARE INSTALLATION
USAGEUSAGE
TROUBLESHOOTINGTROUBLESHOOTING
CERTIFICATESCERTIFICATES
1
1
2
3
5
3
6
9
10
7
4
CABLE DIAGRAMSCABLE DIAGRAMS
Table Of Contents

Thank you for purchasing KVMswitch. KVM switch cansave
your MONEY,TIME, SPACE, EQUIPMENTand POWER.
You can controlmultiple PCs from a singleKeyboard, Mouse and
VGA monitor. KVM switch is loadedwith features such as 19"
Rack Mount Size, Hot keyControl, Front Panel Push Buttonand
Auto Scan Control. Ithas complete keyboard and mouse
emulation for simultaneous PCs boot-upprocess.
Introduction
4/8/16 port KVM switch is19" rack mount size design.
Support Microsoft Intellimouse, Microsoft Intellimouse Explorer,
Logitech Net Mouse or theother fully compatible MS mouse.
Support DOS, Win3.X, Win95/98/98SE/2000/XP, WinXP,WinNT,
Netware, Unix, Linux.
Hot Pluggable: Add/remove any PC without powering down the
switch or other PCs.
Support Ultra High Video Resolution Up To 1920X1440
resolution.
LED Display: Two LEDs for each port
No Software Required - PC selection via "Select" Buttonson
the switch or "Hot Keys."
Auto Scan Mode for monitoringPCs and flexible Scan timefrom
5~99 seconds. Keyboard status restoredwhen switching PCs.
Buzzer sound for switching portconfirmation.
Using Standard Keyboard, VGA, and Mouse cable.
Features
~1~

~2~
1 pcs
1 pcs
optional
optional
1 pcs
1 pcs
1 pcs
1set
1 pcs
1 pcs
1 pcs
1set
Model No.: TK-401RModel No.: TK-401R
4 port KVM Switch
User's Guide
AC to DC Power Adapter
Rack Mount Kit
Model No.: TK-801RModel No.: TK-801R
8 port KVM Switch
User's Guide
AC to DC Power Adapter
Rack Mount Kit
Model No.: TK-1601RModel No.: TK-1601R
16 port KVM Switch
User's Guide
AC to DC Power Adapter
Rack Mount Kit
Package Contents

Cable Diagrams
System Requirements
4 HDB 15 pin male to male VGA cables
4 PS/2 cable male to male for Keyboard
4 PS/2 cables male to male for Mouse
8 HDB 15 pin male to male VGA cables
8 PS/2 cable male to male for Keyboard
8 PS/2 cables male to male for Mouse
Model NoModel No Computer sideComputer side
TK-401RTK-401R
TK-801RTK-801R
TK-1601RTK-1601R
One VGA Monitor
One PS/2 Keyboard
One PS/2 Mouse
One VGA Monitor
One PS/2 Keyboard
One PS/2 Mouse
Console sideConsole side
One VGA Monitor
One PS/2 Keyboard
One PS/2 Mouse
16 HDB 15 pin male to male VGA cables
16 PS/2 cable male to male for Keyboard
16 PS/2 cables male to male for Mouse
~3~
PS/2 Cable:PS/2 Cable:
Mini Din 6 pin Male to Male
VGA Cable:VGA Cable:
HDB15 pin Male to Male
AT to PS/2 keyboard adapter:AT to PS/2 keyboard adapter:
Din 5 pin Female to Mini Din 6 pin Male

Product Details
Front Panel & Rear Panel of TK-401R:Front Panel & Rear Panel of TK-401R:
Front Panel & Rear Panel of TK-801R:Front Panel & Rear Panel of TK-801R:
Front Panel & Rear Panel of TK-1601R:Front Panel & Rear Panel of TK-1601R:
~5~

Hardware Installation
Before installation, please make sure all of peripherals and
computers have been turned off.
1.Install the Switch in a fairly cool and dry place; see the
Technical Specifications section for the acceptable operating
temperature and humidity ranges. The installation site must be
free from strong electromagnetic field generators,
vibration, dust, and direct exposure to sunlight. Install
the Switch on a sturdy, level surface that can support its weight,
or in a standard EIA 19" equipment rack. To mount the Switch on
the rack, install the included mounting brackets to the sides of
the Switch, secure them with the screws, and then mount the
Switch to the rack with the hardware provided by the rack
manufacturer.
2.Connect the Keyboard, VGA, Mouse cables to the console
ports of KVM switch
3.Connect the Keyboard, VGA monitor, and Mouse to the
computer port of KVM switch
4.In some cases, KVM switch gets the power from computer port
by PC's Keyboard or Mouse port. However, we recommend using
the AC Adapter as the power source.
5.After Powering on computers and finishing the boot-up process,
you can start operating the KVM switch.
Note:
Please don't switch the PC port (i.e. Don't press the push
button of KVM switch or run "Hot-Key") when the computers
are booting up.
~6~

The Push Buttons:
Pressing the button to changethe ports.
TK-801R (8 Port)
LED Indication:
Red LED light - KVMcable is connected and PCpower support
KVM switch.
Green LED light - theselected PC port inActive (On Line) mode.
Green LED flash - theselected PC port under scanmode.
- or, No PC power support
Note:
In some cases, when youconnected the computer to theKVM
Switch, even if the computeris not powered on, theRED LED
will still light.
Keyboard Hot Key Commands:
You can alsoconveniently command KVM switch byswitching
ports through simple key sequences. Tosend commands to
KVM switch, the Scroll Lock (ScrLk) keymust be pressed twice
within 2 seconds. You will hear a beepfor confirmation and the
keyboard is in "Hot-Key" mode. If you have not pressed any key
in "Hot-Key" mode within 2seconds, the keyboard will return
to the operation system controlstate.
RED-ON LINE
GREEN-SELECT
12345678
TK-801RTK-801R
PC ON LINE
(GREEN) LED
PC's POWER
(RED) LED
PUSH
Usage
~7~

Below are the available "Hot-Key" commands:
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
==
,,
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
==
Within 2 seconds
(Note: You can also press up arrow key or down arrow key
longer time to speed up selecting the destination port)
~8~
To select specific PC port:
To cancel out of Auto Scan Mode, press any key or SPACE bar.
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
==
BB
Port No.
1~4(4 port)
1~8(8port)
Port No.
1~4(4 port)
1~8(8port)
(Note: The default Beeper functionis OFF)
SS
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
==
Scan
Interval
1~99
Scan
Interval
1~99
Scroll
Lock
Scroll
Lock
Scroll
Lock
Scroll
Lock
==
ENDEND
,,
,,,,
Previous Port
Next Port
,,
,,,,
,,,,,,
Beeper On
Auto Scan Mode
,,,,

Troubleshooting
Ensure that all cables arewell seated. Label all of cables with
the number for each respectivecomputer to avoid confusion.
1.The Power Jack polarity iscenter positive and you canuse
power adapter with DC12V, 1A or DC9V, 1A output.
2.Don't press any keys onthe keyboard while the selected
computer is booting up. Otherwise,it might cause the
keyboard error or keyboard isnot detected at PC side.
3.If The computer boots up fine, but the keyboard doesn't work,
make sure the keyboard workswhen it is directly plugged into the
computer. You can also try adifferent keyboard, but use only 101,
102 or 104-key keyboard.
4.If the Mouse is notdetected during PC boot up,make sure the
mouse works when directly pluggedinto the computer.
Also, make sure the mouseis a true PS/2 mouse.A combo mouse
will work, as long asit is set to PS/2mode with the correct
adapter. If possible please try a different mouse.
5.Avoid moving the mouse or pressing the mouse buttons
when switching ports.
6.Avoid switching ports when the PC is shutting down. In auto
scan mode, it is betterto set the scan intervalto at least 5 seconds.
7.Normally, it takesone or two seconds forthe VGA monitor to
change from one resolution modeto another. So, we do not
recommend setting the scan intervalbelow 5 seconds.
~9~

Certifications
This equipment has been testedand found to comply withPart
15 of the FCC Rules. Operation is subject to the following two
conditions:
(1) This device may not cause harmful interference.
(2) This device must accept any interference received.
Includinginterference that may cause undesiredoperation.
This equipment is in compliancewith the requirements of the
following regulations: EN 55 022:CLASS B
