TRENDnet TEW-751DR User manual

TRENDnet User’s Guide Cover Page

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide Table of Contents
2
Table of Contents
Product Overview ...........................................................................4
Package Contents .......................................................................................................... 4
Features ......................................................................................................................... 4
Product Hardware Features........................................................................................... 5
Application Diagram ...................................................................................................... 6
Basic Router Setup ..........................................................................7
Creating a Home Network ............................................................................................. 7
Router Installation ......................................................................................................... 8
Connect additional wired devices to your network..................................................... 11
Wireless Networking and Security .................................................12
How to choose the type of security for your wireless network .................................. 12
Secure your wireless network ..................................................................................... 13
Connect wireless devices to your router ..................................................................... 15
Connect wireless devices using WPS ........................................................................... 15
Basic wireless settings ................................................................................................. 18
Guest Network............................................................................................................. 19
Steps to improve wireless connectivity ....................................................................... 20
Advanced wireless settings.......................................................................................... 21
Access Control Filters ....................................................................22
Access control basics ................................................................................................... 22
MAC Address Filters........................................................................................... 22
Parental Control................................................................................................. 23
Firewall Rules..................................................................................................... 24
Advanced Router Setup.................................................................25
Access your router management page........................................................................ 25
Change your router login password ............................................................................ 25
Change your device name ........................................................................................... 26
Manually configure your Internet connection ............................................................ 26
IPv6 Connection Settings............................................................................................. 27
Clone a MAC address................................................................................................... 28
Change your router IP address.................................................................................... 28
Change your device URL.............................................................................................. 29
Enable DNS relay on your router................................................................................. 29
Change your local domain name................................................................................. 29
Set up the DHCP server on your router....................................................................... 29
Set up DHCP reservation ............................................................................................. 30
Enable/disable UPnP on your router........................................................................... 31
Enable/disable Application Layer Gateways (ALG)...................................................... 32
Allow/deny multicast streaming.................................................................................. 32
Identify your network on the Internet ........................................................................ 33
Set your router date and time..................................................................................... 34
Create schedules ......................................................................................................... 35
Open a device on your network to the Internet.......................................................... 36
DMZ ................................................................................................................... 36
Virtual Server ..................................................................................................... 36
Port Forwarding................................................................................................. 38
Application Rules ............................................................................................... 39
Inbound Filter .................................................................................................... 40
Allow remote access to your router management page ............................................. 41
Set Internet bandwidth ............................................................................................... 41
Add static routes to your router.................................................................................. 42
Router Maintenance & Monitoring ............................................... 43
Reset your router to factory defaults.......................................................................... 43
Router Default Settings ............................................................................................... 43

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide Table of Contents
3
Backup and restore your router configuration settings .............................................. 44
Reboot your router...................................................................................................... 44
Upgrade your router firmware .................................................................................... 45
Allow/deny ping requests to your router from the Internet ....................................... 46
Wireless Client List....................................................................................................... 46
Check the router system information.......................................................................... 47
View your router log .................................................................................................... 50
Configure your router log ............................................................................................ 50
Save your router log .................................................................................................... 51
Router Management Page Structure .............................................53
Technical Specifications.................................................................54
Troubleshooting............................................................................55
Appendix ......................................................................................56

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
4
Product Overview
TEW-751DR
Package Contents
In addition to your router, the package includes:
•Multi-Language Quick Installation Guide
•CD-ROM (User’s Guide)
•Multi-Language Quick Installation Guide
•1 x Network cable (1.5m / 5ft.)
•Power Adapter (12V, 1A)
If any package contents are missing or damaged, please contact the retail store, online
retailer, or reseller/distributor from which the product was purchased.
Features
TRENDnet’s N600 Dual Band Wireless Router, model TEW-751DR, offers proven
concurrent Dual Band 300 Mbps Wireless N networking. Embedded GREENnet
technology reduces power consumption by up to 50%. For your security this router
comes pre-encrypted and features guest networks. Seamlessly stream HD video with
this powerful router.
Ease of Use
Easy Setup
Get up and running in minutes with the intuitive guided setup
One Touch Connection
Securely connect to the router at the touch of the Wi-Fi Protected Setup
(WPS) button
Security
Pre-Encrypted
For your security the router arrives pre-encrypted with its own unique
password
Guest Network
Create a secure isolated network, on each wireless band, for guest
internet access only
Parental Controls
Control access to specific websites

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
5
Performance
N600 Wireless
Proven concurrent dual band 300 Mbps Wireless N
Wireless Coverage
Extensive wireless coverage with MIMO antenna technology
Compatibility
Compatible with older Wireless G devices
Energy Savings
Embedded GREENnet technology reduces power consumption by up to
50%
IPv6
IPv6 network support
*Maximum wireless signal rates are referenced from IEEE 802.11 theoretical
specifications. Actual data throughput and coverage will vary depending on
interference, network traffic, building materials and other conditions
Product Hardware Features
Rear View
•Reset Button – Press and hold this button for 10 seconds to reset the router.
•WPS Button (Wi-Fi Protected Setup) –Push and hold this button for 5 seconds
to activate WPS. The Power LED will blink when WPS is activated.
•LAN Ports 1-4 – Connect Ethernet cables (also called network cables) from your
router LAN ports to your wired network devices.
•Internet Port – Connect an Ethernet cable from your router Internet port to
your modem.
•Power Port – Connect the included power adapter from your router power
port and to an available power outlet.
•On/Off Power Switch – Push the router On/Off power switch to turn your
router “On” (Inner position) or “Off” (Outer position).
Reset Button
10/100Mbps LAN
Ports 1-4
Internet Port
Power Port
WPS Button
On/Off Power Switch

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
6
Front View
•WPS LED: The indicator will blink when WPS is activated. The LED will
stop blinking and remain solid green automatically once WPS process is
completed.
•Wireless (Link/Activity) LED: The indicator turns on solid green when
wireless is enabled on your router. The indicator will blink during when
data is transmitted or received by your wireless client devices connected
to your router.
•LAN Ports 1-4 (Link/Activity) LED: These LED indicators are solid green
when the LAN ports 1-4 are physically connected to your wired network
devices (which are turned on) with a network or Ethernet cable. These
LED indicators will blink green while data is transmitted or received
through your router’s LAN ports.
•Internet Port (Link/Activity) LED – This LED indicator is solid green when
your router Internet port is physically connected to the modem network
or Ethernet port with a network or Ethernet cable (modem turned on).
The LED indicator will be blinking green while data is transmitted or
received through the Internet port of your router.
•Power LED:The indicator is solid green when your router is powered on.
Otherwise if this LED indicator is off, there is no power to your router.
The indicator will also blink when WPS is activated. The LED will stop
blinking and remain solid green automatically once WPS process is
completed.
Application Diagram
The router is installed near the modem (typically supplied by your ISP “Internet Service Provider”)
and physically connected to it from the router’s Internet port to the modem’s network port which
connects to the Internet. 2.4GHz wireless signals from the router are broadcasted to wireless
clients such as laptops (with wireless capability) and the less congested 5GHz wireless signals from
the router are broadcasted to other wireless client devices such as TVs, game consoles, or media
bridges thereby providing Internet access for all wireless client devices.
Wireless LED
WPS LED
LAN Ports 1-4 LEDs
Internet Port LED
Power LED

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
7
Basic Router Setup
Creating a Home Network
What is a network?
A network is a group of computers or devices that can communicate with each other. A
home network of more than one computer or device also typically includes Internet
access, which requires a router.
A typical home network may include multiple computers, a media player/server, a
printer, a modem, and a router. A large home network may also have a switch,
additional routers, access points, and many Internet-capable media devices such as TVs,
game consoles, and Internet cameras.
•Modem – Connects a computer or router to the Internet or ISP (Internet Service
Provider).
•Router – Connects multiple devices to the Internet.
•Switch –Connect several wired network devices to your home network. Your
router has a built-in network switch (the LAN port 1-4). If you have more wired
network devices than available Ethernet ports on your router, you will need an
additional switch to add more wired connections.
How to set up a home network
1. For a network that includes Internet access, you’ll need:
•Computers/devices with an Ethernet port (also called network port) or wireless
networking capabilities.
•A modem and Internet service to your home, provided by your ISP (modem
typically supplied by your ISP).
•A router to connect multiple devices to the Internet.
2. Make sure that your modem is working properly. Your modem is often provided by
your Internet Service Provider (ISP) when you sign up for Internet service. If your
modem is not working contact your ISP to verify functionality.
3. Set up your router. See “How to setup your router” below.
4. To connect additional wired computers or wired network devices to your network,
see “Connect additional wired devices to your network” on page 11.
5. To set up wireless security on your router, see “Wireless Networking and Security” on
page 12.
How to setup your router
Refer to the Quick Installation Guide or continue to the next section “Router
Installation” on page 8 for more detailed installation instructions.
Where to find more help
In addition to this User’s Guide, you can find help below:
•http://www.trendnet.com/support (documents, downloads, and FAQs are
available from this Web page)

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
8
Router Installation
Before you Install
Many Internet Service Providers (ISPs) allow your router to connect to the Internet
without verifying the information fields listed below. Skip this section for now and if
your router cannot connect to the Internet using the standard installation process, come
back to this page and contact your ISP to verify required ISP specification fields listed
below.
1. Obtain IP Address Automatically (Dynamic IP DHCP)
Host Name:_______________ (Optional, if required by ISP for Compatibilty)
Use Unicasting: Enabled / Disabled (Optional, if required by ISP for compatibility)
Primary DNS Server Address: _____. _____._____._____ (Optional)
Secondary DNS Servers Address : _____. _____._____._____ (Optional)
MTU:_______ (Default: 1500, change if required by ISP)
MAC Address: ___:___:___:___:___:___ Clone your PC MAC Address (Optional)
2. Static IP/Fixed IP address
IP Address: _____. _____._____._____ (e.g. 215.24.24.129)
Subnet Mask: _____. _____._____._____
Default Gateway IP Address: _____. _____._____._____
Primary DNS Server Address: _____. _____._____._____
Secondary DNS Servers Address : _____. _____._____._____ (Optional)
MTU:_______ (Default: 1500, change if required by ISP)
MAC Address: ___:___:___:___:___:___ Clone your PC MAC Address (Optional)
3. PPPoE Dynamic IP (DHCP) / PPPoE Static IPto obtain IP automatically
Type (Dynamic IP/DHCP or Static IP)
IP Address (Static IP): _____. _____._____._____ (e.g. 215.24.24.129)
Username: _________
Password: ________________
Service Name: _________________ (Optional)
DNS Servers Address 1 (Static IP): _____. _____._____._____
DNS Servers Address 2 (Static IP): _____. _____._____._____ (Optional)
Reconnect Mode: Always / On Demand / Manual (Optional)
MTU:_______ (Default: 1500, change if required by ISP)
MAC Address: ___:___:___:___:___:___ Clone your PC MAC Address (Optional)
4. PPTP
Type (Dynamic IP/DHCP or Static IP)
PPTP IP Address: _____. _____._____._____ (e.g. 215.24.24.129)
PPTP Subnet Mask: _____. _____._____._____ (e.g. 255.255.255.0)
PPTP Gateway:_____. _____._____._____ (e.g. 215.24.24.1)
PPTP Server: _____________________ (e.g. 215.24.24.150)
Username: _________
Password: ________________
Reconnect Mode: Always / On Demand / Manual (Optional)
DNS Servers Address 1 (Static IP): _____. _____._____._____
DNS Servers Address 2 (Static IP): _____. _____._____._____ (Optional)
MTU:_______ (Default: 1500, change if required by ISP)
MAC Address: ___:___:___:___:___:___ Clone your PC MAC Address (Optional)
5. L2TP
Type (Dynamic IP/DHCP or Static IP)
L2TP IP Address: _____. _____._____._____ (e.g. 215.24.24.129)
L2TP Subnet Mask: _____. _____._____._____ (e.g. 255.255.255.0)
L2TP Gateway:_____. _____._____._____ (e.g. 215.24.24.1)
L2TP Server: _____________________ (e.g. 215.24.24.150)
Username: _________
Password: ________________
Reconnect Mode: Always / On Demand / Manual (Optional)
DNS Servers Address 1 (Static IP): _____. _____._____._____
DNS Servers Address 2 (Static IP): _____. _____._____._____ (Optional)
MTU:_______ (Default: 1500, change if required by ISP)
MAC Address: ___:___:___:___:___:___ Clone your PC MAC Address (Optional)
5. DS-Lite
Type (DS-Lite DHCP IPv6 or Manual)
Check with your ISP for the required settings.

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
9
Hardware Installation
1. Verify that you have an Internet connection when connecting your computer directly
to your modem.
2. Turn off your modem.
3. Disconnect the Network cable from your computer to your modem.
4. Connect your modem to the router Internet port (yellow).
5. Connect your computer to one of the router LAN ports.
6. Connect the power adapter to the router and then to a power outlet.
7. Turn on your modem.
8. Verify that the status LED indicators on the front of the router are illuminated: Power,
Internet, and one of the LAN ports (1,2,3,4) port where your computer is connected.

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
10
Setup Wizard
1. Open your web browser (e.g. Internet Explorer, Firefox, Safari, Chrome, or Opera) and
the wizard will automatically appear.
Note: If you have already configured your router before, the wizard will no longer
appear automatically. In your web browser, go to http://tew-751dr or you can access
the router management using the default IP address http://192.168.10.1. Your router
will prompt you for a user name and password. Enter your user name and password
and click Main > Wizard.
2. Select your Language and click Next..
3. If the wizard is unable to detect your Internet connection type, you will be prompted
to select it. Select your Internet connection type and click Next.
Note: Dynamic IP (DHCP) is typical for most Internet services. You can verify your
settings with your Internet Service Provider.
4. Confirm your settings. This window displays your predefined router wireless settings
and click Exit to complete the wizard.
Note: For added security, the router wireless network is pre-encrypted with its own
unique wireless network security key. You can find the unique network security key and
the pre-assigned network name (SSID) on a sticker on the side of the router and on a
label on the bottom of the router. You will need this information to connect to the
router. To change the network security key, refer to page 12. If the router is reset to
factory defaults, the wireless encryption will reset to the network security key printed
on the product labels of the router.

© Copyright 2013 TRENDnet. All Rights Reserved.
11
TRENDnet User’s Guide TEW-751DR
Connect additional wired devices to your network
You can connect additional computers or other network enabled devices to your network by using Ethernet cables to connect them to one of the available LAN ports labeled 1,2,3,4 on
your router. Check the status of the LED indicators (1, 2, 3, or 4) on the front panel of your router to ensure the physical cable connection from your computer or device.
Note: If you encounter issues connecting to your network, there may be a problem with your computer or device network settings. Please ensure that your computer or device network
settings (also called TCP/IP settings) are configured to obtain IP address settings automatically (also called dynamic IP address or DHCP) and to Obtain DNS Server address settings
automatically.

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
12
Wireless Networking and Security
How to choose the type of security for your wireless network
Setting up wireless security is very important. Leaving your wireless network open and
unsecure could expose your entire network and personal files to outsiders. TRENDnet
recommends reading through this entire section and setting up wireless security on your
new router.
There are a few different wireless security types supported in wireless networking each
having its own characteristics which may be more suitable for your wireless network
taking into consideration compatibility, performance, as well as the security strength
along with using older wireless networking hardware (also called legacy hardware).
It is strongly recommended to enable wireless security to prevent unwanted users from
accessing your network and network resources (personal documents, media, etc.).
In general, it is recommended that you choose the security type with the highest
strength and performance supported by the wireless computers and devices in your
network. Please review the security types to determine which one you should use for
your network.
Wireless Encryption Types
•WEP: Legacy encryption method supported by older 802.11b/g hardware. This is
the oldest and least secure type of wireless encryption. It is generally not
recommended to use this encryption standard, however if you have old 802.11 b or
802.11g wireless adapters or computers with old embedded wireless cards(wireless
clients), you may have to set your router to WEP to allow the old adapters to
connect to the router.
Note: This encryption standard will limit connection speeds to 54Mbps.
•WPA: This encryption is significantly more robust than the WEP technology. Much
of the older 802.11g hardware was been upgraded (with firmware/driver upgrades)
to support this encryption standard. Total wireless speeds under this encryption
type however are limited to 54Mbps.
•WPA-Auto: This setting provides the router with the ability to detect wireless
devices using either WPA or WPA2 encryption. Your wireless network will
automatically change the encryption setting based on the first wireless device
connected. For example, if the first wireless client that connects to your wireless
network uses WPA encryption your wireless network will use WPA encryption. Only
when all wireless clients disconnect to the network and a wireless client with WPA2
encryption connects your wireless network will then change to WPA2 encryption.
Note: WPA2 encryption supports 802.11n speeds and WPA encryption will limit
your connection speeds to 54Mbps
•WPA2: This is the most secure wireless encryption available today, similar to WPA
encryption but more robust. This encryption standard also supports the highest
connection speeds. TRENDnet recommends setting your router to this encryption
standard. If you find that one of your wireless network devices does not support
WPA2 encryption, then set your router to either WPA or WPA-Auto encryption.
Note: Check the specifications of your wireless network adapters and wireless
appliances to verify the highest level of encryption supported.Below is brief
comparison chart of the wireless security types and the recommended
configuration depending on which type you choose for your wireless network.
Security Standard
WEP
WPA
WPA2
Compatible
Wireless
Standards
IEEE 802.11a/b/g
(802.11n devices
will operate at
802.11g to connect
using this standard)
IEEE 802.11a/b/g
(802.11n devices
will operate at
802.11g to connect
using this
standard)
IEEE 802.11a/b/g/n
Highest
Performance
Under This
Setting
Up to 54Mbps
Up to 54Mbps
Up to 450Mbps
Encryption
Strength
Low
Medium
High
Additional
Options
Open System or
Shared Key,
HEX or ASCII,
Different key sizes
TKIP or AES,
Preshared Key or
RADIUS
TKIP or AES,
Preshared Key or
RADIUS
Recommended
Configuration
Open System ASCII
13 characters
TKIP
Preshared Key
8-63 characters
AES
Preshared Key
8-63 characters
*Dependent on the maximum 802.11n data rate supported by the device (150Mbps,
300Mbps, 450Mbps)

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
13
Secure your wireless network
Wireless > Basic
After you have determined which security type to use for your wireless network (see
“How to choose the security type for your wireless network” on page 12), you can set up
wireless security.
Note: By default, your router is configured with a predefined wireless network name
(SSID) and security key using WPA2-Personal. The predefined wireless network name and
security can be found on the sticker on the side of the router or on the device label at the
bottom of the router.
1. Log into your router management page (see “Access your router management page”
on page 25).
2. Click on Wireless, and click on Basic.
4. Under Wireless Security Mode (2.4GHz or 5GHz), click on the Security Mode drop-
down list to select your wireless security type.
Selecting WEP:
If selecting WEP (Wired Equivalent Privacy), please review the WEP settings to configure
and click Save Settings to save the changes.
•WEP Key Length: Choose the key length 64-bit or 128-bit .
Note: It is recommended to use 128-bit because it is more secure to use a key that
consists of more characters.
•Authentication: Choose Both or Shared.
Note: It is recommended to use Both which includes both Open and Shared. Open
is known to be more secure than Shared Key.
oWEP Key:Enter the WEP key. This is the password or key that is used to connect
your computer to this router wirelessly.
WEP Key Format HEX ASCII
Character set 0-9 & A-F, a-f only Alphanumeric (a,b,C,?,*, /,1,2, etc.)
64-bit key length 10 characters 5 characters
128-bit key length 26 characters 13 characters

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
14
Selecting WPA-Personal with Auto (WPA or WPA2)/WPA Only/WPA2 Only
(WPA2 Only recommended):
In the Security Mode drop-down list, select WPA-Personal. Please review the WPA-
Personal settings to configure and click Save Settings to save the changes.
Selecting WPA-Enterprise with Auto (WPA or WPA2)/WPA Only/WPA2 Only
(WPA2 Only recommended):
The following section outlines options when selecting WPA-Enterprise (EAP or RADIUS).
This security type is also known as EAP (Extensible Authentication Protocol) or Remote
Authentication Dial-In User Service or RADIUS.
Note: This security type requires an external RADIUS server, Pre-Shared Key only requires
you to create a passphrase.
•RADIUS Server Address:Enter the IP address of the RADIUS server. (e.g.
192.168.10.250)
•RADIUS Port: Enter the port your RADIUS server is configured to use for RADIUS
authentication.
Note: It is recommended to use port 1812 which is typical default RADIUS port.
•RADIUS Server Shared Secret:Enter the shared secret used to authorize your
router with your RADIUS server.
•Advance Setting – Click this option to set up an additional backup RADIUS server.

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
15
Connect wireless devices to your router
A variety of wireless network devices can connect to your wireless network such as:
•Gaming Consoles
•Internet enabled TVs
•Network media players
•Smart Phones
•Wireless Laptop computers
•Wireless IP cameras
Each device may have its own software utility for searching and connecting to available
wireless networks, therefore, you must refer to the User’s Manual/Guide of your
wireless client device to determine how to search and connect to this router’s wireless
network.
See the “Appendix” on page 56 for general information on connecting to a wireless
network.
Connect wireless devices using WPS
WPS (Wi-Fi Protected Setup) is a feature that makes it easy to connect devices to your
wireless network. If your wireless devices support WPS, you can use this feature to
easily add wireless devices to your network.
Note: You will not be able to use WPS if you set the SSID Broadcast setting to Disabled or
if you are using WEP security.
There are two methods the WPS feature can easily connect your wireless devices to
your network.
•Push Button Configuration (PBC) method
o(RECOMMENDED) Hardware Push Button method–with an external button
located physically on your router and on your client device
oWPS Software/Virtual Push Button - located in router management page
•PIN (Personal Identification Number) Method - located in router management page
Note: Refer to your wireless device documentation for details on the operation of
WPS.
Recommended Hardware Push Button (PBC) Method
•Note: It is recommended that a wireless key (passphrase or password) is created
before connecting clients using the PBC method. By default your router is
preconfigured with a wireless encryption key. If no wireless key is defined when
connecting via PBC, the router will automatically create an encryption key that is 64
characters long. This 64 character key will then have to be used if one has to
connect computers to the router using the traditional connection method.
To add a wireless device to your network, simply push the WPS button on the wireless
device you are connecting (consult client device User’s Guide for length of time), then
push and hold the WPS button located on your router for 3 seconds and release it. The
WPS LED will blink to indicate WPS has been activated on your router. (See “Product
Hardware Features” on page 5)
For connecting additional WPS supported devices, repeat this process for each
additional device.

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
16
PBC (Software/Virtual Push Button)
Wireless > Wi-Fi Protected Setup
In addition to the hardware push button located physically on your router, the router
management page also has push button which is a software or virtual push button you
can click to activate WPS on your router.
1. Log into your router management page (see “Access your router management page”
on page 25).
2. Click on Wireless, and click on Wi-Fi Protected Setup.
3. To add a wireless device to your network, click the Connect button in the router
management page.
4. Make sure Auto is selected and click Next.
5. Select PBC and click Connect. Then push the WPS button on the wireless device
(consult wireless device’s User’s Guide for length of time) you are connecting.
6. Wait for your router to finsh the WPS process.
7. If successful, you will receive the message below. Click on Wireless Status to view the
information about the current wireless client devices connected to your router.

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
17
PIN (Personal Identification Number)
Wireless > Wi-Fi Protected Setup
If your wireless device has WPS PIN (typically an 8-digit code printed on the wireless
device product label or located in the wireless device wireless software utility), you can
use this method.
1. Log into your router management page (see “Access your router management page”
on page 25).
2. Click on Wireless, and click on Wi-Fi Protected Setup.
3. To add a wireless device to your network, click the Connect button in the router
management page.
4. Make sure Auto is selected and click Next.
5. Select PIN and enter the 8-digit numeric PIN number of the wireless client device and
click Connect.
Note: You may need to initiate the WPS PIN on your wireless device first when using this
method. Refer to your wireless device documentation for details on the operation of
WPS.
6. Wait for your router to finsh the WPS process.
7. If successful, you will receive the message below. Click on Wireless Status to view the
information about the current wireless client devices connected to your router.

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
18
Basic wireless settings
Wireless > Basic
This section outlines available management options under basic wireless sub tab for
both 2.4GHz and 5GHz wireless sections.
1. Log into your router management page (see “Access your router management page”
on page 25).
2. Click on Wireless and click on Basic scroll down to Wireless Network Settings (2.4GHz
or 5GHz)
3. To save changes to this section, click Save Settings when finished.
•Enable Wireless – Check the option to enable the wireless or uncheck to disable.
Note: It is recommended to leave this setting checked.
oNew Schedule –The schedule function allows you to define a schedule when the
wireless should be turned on. To define a new schedule, click New Schedule and
refer to page 35. After you have created a new schedule, click the drop-down list
and the new schedule will be available for selection.
•Wireless Network Name (SSID): Enter the wireless name (SSID) for your wireless
network. This acronym stands for Service Set Identifier and is the name of your
wireless network. It differentiates your wireless network from others around you.
By default, the router’s wireless name is unique to the device. If you choose to
change the SSID, change it to a name that you can easily remember.
When applying the 802.11 Mode setting, please keep in mind the following:
•Wireless devices that support 802.11n are backwards compatible and can connect
wirelessly at 802.11g or 802.11b.
•Connecting at 802.11b or 802.11g will limit the capability of your 802.11n
supported wireless devices from obtaining higher performance and data rates.
•Allowing 802.11b or 802.11g devices to connect to an 802.11n capable wireless
network may degrade the wireless network performance below the higher
performance and data rates of 802.11n.
•Wireless devices that only support 802.11b or 802.11g will not be able to connect
to a wireless network that is set to 802.11n only mode.
•Wireless devices that only support 802.11b will not be able to connect to a wireless
network that is set to 802.11g only mode.
•Enable Auto Channel Scan – Check this option to set your router to scan for which
wireless channels to use automatically.
•Wireless Channel – Unchecking the Enable Auto Channel Scan option will you to
manually set the channel on which the router will broadcast. Click the drop-down
list and select the desired Channel for wireless communication. The goal is to select
the Channel that is least used by neighboring wireless networks.
•Transmission Rate – Allows you to lock down the wireless transmission rate.
Note: This feature is only available when using 802.11 n only mode.

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
19
•Channel Width: Select the appropriate channel width for your wireless network.
This setting only applies to 802.11n. For greater 802.11n performance, select
20/40MHz (Auto) (Options: 20MHz or 20/40MHz (Auto)). It is recommended to use
the default channel bandwidth settings.
Note: Please note that this setting may provide more stability than the higher
channel bandwidth settings such as 20/40MHz (Auto) for connectivity in busy
wireless environments where there are several wireless networks in the area.
o20 MHz – This mode operates using a single 20MHz channel for
wireless devices connecting at 802.11n on both 2.4GHz and 5GHz. This
setting may provide more stability than 20/40MHz (Auto) for
connectivity in busy wireless environments where there are several
neighboring wireless networks in the area.
o20/40MHz (Auto) –When 20/40MHz (Auto) is active, this mode is
capable of providing higher performance only if the wireless devices
support the channel bandwidth settings. Enabling 20/40MHz (Auto)
typically results in substantial performance increases when connecting
an 802.11n client.
•Visibility Status
oVisible - allows wireless devices to search and discover your wireless network
name (also called SSID) broadcasted by your router.
oInvisible -Turns off the ability for wireless devices to find your network. It is still
possible for wireless devices to be configured to connect to your wireless
network. Disabling this setting will disable WPS functionality.
•WMM:Wi-Fi Multimedia is a Quality of Service (QoS) feature which prioritizes
audio and video data packets. This feature requires the wireless device to also
support WMM. Click Enabled (recommended) or Disabled to turn this feature on
or off on your router. Note: This feature can only be disabled in 802.11b/g modes.
Guest Network
Access > Guest Zone
Creating an isolated and separate wireless guest network (2.4GHz or 5GHz) allows
wireless clients to connect to your network for Internet access only and keep your local
LAN network safe by restricting guest access to your LAN network resources such as
shared documents and media files on your computers, network storage, and printers.
1. Log into your router management page (see “Access your router management page”
on page 25).
2. Click on Access and click on Guest Zone.
3. Review the Guest Zone settings, click Save Settings when finished.

© Copyright 2013 TRENDnet. All Rights Reserved.
TRENDnet User’s Guide TEW-751DR
20
•Enable Routing Between Zones: If checked, allows wireless clients connected to the
guest network access to your private LAN network.
Choose which band to enable the Guest Network (Wireless – 2.4GHz or 5GHz):
•Enable Guest Zone - Check the option to enable the guest network.
•New Schedule: Click the drop-down list to select the pre-defined schedule to apply.
The filter will only be active during the time period defined in the pre-defined
schedule. (See “Create Schedule” section on page 35).
Note: Before applying scheduling, please ensure your Time settings are configured
correct and you have defined a schedule. See page 34 to configure Time Settings and
see page 35 to create a schedule.
•Wireless Network Name (SSID) - This acronym stands for Service Set Identifier and
is the name of your wireless network. It differentiates your wireless network from
others around you. It is recommended to use a different name from your primary
wireless network to a name that you can easily identify and differentiate from the
primary. You can reference your guests to access this network instead of the
primary.
•Security Mode – Select the wireless security to use for the guest network.
4. Under Security Mode, you can apply a different wireless security type and key to the
guest network. Please refer to page 12 to find out about different security types and
page 13 for wireless security configuration.
Steps to improve wireless connectivity
There are a number of factors that can impact the range of wireless devices. Follow
these tips to help improve your wireless connectivity:
1. Keep the number of obstructions to a minimum. Each obstruction can reduce
the range of a wireless device. Position the wireless devices in a manner that
will minimize the amount of obstructions between them.
a. For the widest coverage area, install your router near the center of
your home, and near the ceiling, if possible.
b. Avoid placing the router on or near metal objects (such as file cabinets
and metal furniture), reflective surfaces (such as glass or mirrors), and
masonry walls.
c. Any obstruction can weaken the wireless signal (even non-metallic
objects), so the fewer obstructions between the router and the
wireless device, the better.
d. Place the router in a location away from other electronics, motors,
and fluorescent lighting.
e. Many environmental variables can affect the router’s performance, so
if your wireless signal is weak, place the router in several locations and
test the signal strength to determine the ideal position.
2. Building materials can have a large impact on your wireless signal. In an indoor
environment, try to position the wireless devices so that the signal passes
through less dense material such as dry wall. Dense materials like metal, solid
wood, glass or even furniture may block or degrade the signal.
3. Antenna orientation can also have a large impact on your wireless signal. Use
the wireless adapter’s site survey tool to determine the best antenna
orientation for your wireless devices.
4. Interference from devices that produce RF (radio frequency) noise can also
impact your signal. Position your wireless devices away from anything that
generates RF noise, such as microwaves, radios and baby monitors.
If possible, upgrade wireless network interfaces (such as wireless cards in computers)
from older wireless standards to 802.11n or 802.11ac. If a wirelessly networked device
uses an older standard, the performance of the entire wireless network may be slower.
If you are still experiencing low or no signal consider repositioning the wireless devices,
installing additional access points or wireless extenders.
