TREX The Sweeper User manual

SWEEPER
USER MANUAL

CONGRATULATIONS
on your purchase of The Sweeper, our classic chorus pedal for the bass
guitar.
The Sweeper is a premium-quality chorus pedal custom engineered
for the BASS ONLY. This means that no matter what rate or depth you
set, you’ll get a phenomenal-sounding chorus effect – in stereo. The
Sweeper is intuitively designed and easy to use. Just turn the page to
get started.

BACK TO BASSICS
The Sweeper has everything you need to get the full range of classic
bass chorus sounds – using just a few simple controls.
DEPTH controls the amount of chorus effect. Turn it down for a subtle
chorus, crank it up for that great full sweep.
Use the RATE control to set the speed of your sweep. A fast rate com-
bined with a low depth level gives you a light shimmering sound, while
the slower rate and higher depth creates a dramatic chorus effect.
VOLUME controls the overall output of The Sweeper, and the INPUT
LEVEL on the side of the unit helps you avoid overdrive distortion by
turning down the input signal. If the red overload light comes on, the
input level is too high.
Note: If you’re in the studio or have a stereo live setup, try using The
Sweeper’s stereo outputs for a truly mind-blowing stereo chorus!
TECHNICAL SPECIFICATIONS
Input Impedance@1KHz 470 KOhm
Output Impedance@1KHZ 35 Ohm
Power supply 9V DC (Power tool 9)
Minimum Power supply Voltage 8,5V DC
Maximum Power supply Voltage 12,5V DC
Current Draw @ 9V DC 90 mA
Maximum Input signal Vp/p Adjustable
Battery Type 9 V battery 6F22
Battery Life 30 - 60 min.
External connectors Input Jack. Output Jack, 9V DC
Jack
Controls On/Off, Depth, Volume, Rate
Depth 120 mm
Width 100 mm
Height 55 mm
Weight (excl. battery) 0,430 kg

RoHS
REACh
T-REX WARRANTY CONDITIONS
T-Rex oers a 2-year warranty on all our products. In the unlikely event of a
malfunction, please contact our technical support at service@t-rex-eects.
com before sending us the product for repair. When the product has been
sent to us at sender’s cost, we will repair or replace your product and send
it back to you - free of charge and usually within 3 weeks (shipping not
included). The product needs to be accompanied by a copy of your receipt,
serial number, return address, phone number, e-mail address and a brief
explanation of the problem. Please note that we cannot replace a product
until we have received it here in Denmark.
The warranty is lost if the product has been damaged by alteration, misuse,
accident, or neglect; or if the product has been repaired or serviced by
persons not authorized by T-Rex. Read more about warranty conditions at
www.t-rex-eects.com.
