TRI tool BEVELMASTER 224B User manual

Oper ation
Manual
92-0763 Rev. 230210
Model 224B BEVELMASTER®

ABOUT TRI TOOL TECHNOLOGIES
At Tri Tool, we are committed to your success through
relentless innovation and powerful partnership. We
insist on developing tools and equipment that exceed
your expectations of performance, precision, safety, and
durability. As a full-service engineering rm, we are here to
support you every step of the way.
For more information on engineered solutions, products,
and trainings, visit tritool.com or contact our engineers at
[phone].

92-0763 Rev. 230210
Model 224B BEVELMASTER®
TABLE OF CONTENTS
Tri Tool Inc. Warranty 4
Tool Bit Resharpening Policy 5
About The Manual 6
Safety 8
General Description 10
 Specications         11
Maintenance 14
Operation 19
Cutting Speeds and Feeds 25
Standard Jaw Blocks, Ramps And Spacers (8" Through 24" Pipe) 27
Extension Kit (24" Through 42" Pipe) 28
Standard Tool Bits 29
Troubleshooting 30
Accessories 32
Illustrated Parts Breakdown 33
ABOUT TRI TOOL TECHNOLOGIES
At Tri Tool, we are committed to your success through
relentless innovation and powerful partnership. We
insist on developing tools and equipment that exceed
your expectations of performance, precision, safety, and
durability. As a full-service engineering rm, we are here to
support you every step of the way.
For more information on engineered solutions, products,
and trainings, visit tritool.com or contact our engineers at
[phone].

TRI TOOL INC.
92-0763 Rev. 230210
4
TRI TOOL INC. Warranty
LIMITED WARRANTY: All products manufactured by Seller are warranted to be free from
defects in materials and workmanship under normal use. The period of this warranty shall
be three years from the date of shipment for all products, except for welding and Non-
Standard Products which shall be one year from the date of shipment. The Buyer shall
bear all shipping, packing and insurance costs and all other costs to and from a designated
repair service center. All return goods must be authorized in advance and communicated
upon issuance of a Return Material Authorization (RMA) by Seller. The product will be
returned to the Seller accompanied by a RMA number and associated paperwork, freight
prepaid and billed to the Buyer. This warranty is not transferable and will not apply to tool
bits or other consumables, or to any Goods to have been (i) mishandled, misused, abused
or damaged by Buyer or any third party; (ii) altered without the express permission in writing
by Seller, (iii) repaired by a party other than Seller without Seller’s prior written approval;
or (iv) improperly stored, installed, operated, or maintained in a manner inconsistent with
Seller’s instructions. This warranty does not apply to defects attributed to (i) normal wear
and tear or (ii) failure to comply with Seller’s safety warnings.
No warranty for any parts or other supplies provided to seller by buyer, whether or not they
are incorporated into goods. Goods supplied by seller which are designed or manufactured
by a third party are subject strictly to the third party’s warranty for those goods. Seller
makes no warranty and disclaims all statutory or implied warranties for these goods,
including the implied warranties of merchantability, freedom from patent infringement and
tnessforaparticularpurpose.
Neither this warranty nor any other warranty, expressed or implied, including implied
warrantiesofmechanicalability,tnessforaparticularuse,ormerchantability,shallextend
beyond the warranty period. No responsibility is assumed for any incidental or consequential
damages. Some states do not allow limitations on how long an implied warranty lasts and
some states do not allow the exclusion or limitations incidental or consequential damages,
so the above limitation of exclusion does not apply to all Buyers. This warranty gives the
Buyerspeciclegalrights.Otherrightsvaryfromstatetostate.
Warranty Claims and Remedies
Buyer must promptly notify Seller in writing during the applicable warranty period, of
any defective Goods covered by Seller’s warranties under the Limited Warranty section
herein,andnolaterthanfteen(15)calendardaysafterdiscoveryofthedefect.Seller
has no obligation to honor any warranty claim made after the expiration of the warranty
period. However, despite the expiration of the warranty period, Seller, at its reasonable
discretion,mayacceptwarrantyclaimssubmitteduptofteen(15)calendardaysafter
the expiration of the warranty period provided that Buyer provides Seller with credible and
persuasive documentary evidence that the defect was discovered during the warranty
period.Nowarrantyclaimssubmittedafterthisfteen(15)daycalendarperiodwillbe
considered by Seller.

Model 224B BEVELMASTER®
92-0763 Rev. 230210 5
IfthedefectclaimedbyBuyercannotbereproducedorotherwiseveriedbySeller,the
GoodswillbereturnedtoBuyerunmodiedatBuyer’sexpense.
The warranty period for repaired or replaced Goods shall be (i) ninety (90) days or (ii) the
unexpired portion of the original warranty period. Under no circumstances is Seller liable for
recall, retrieval, removal, dismantling, re-installation, redeployment, or re-commissioning of
any defective Goods or any costs associated therewith.
Tool Bit Resharpening Policy
Buyer’snoticeofadefectiveGoodsmustidentifythespecicGoodsaffected,andthe
nature of the defect. It is required when returning the defective Goods, that it is suitably
packed, fully insured, and transportation and insurance prepaid in accordance with
instructions issued by Seller. Seller, at its sole option, will either repair or replace any
Goods authorized for return to Seller. Such repair, replacement, or credit shall be Buyer’s
sole remedy for defective Goods. Buyer must promptly provide Seller with all information
requestedregardingtheidentieddefect.
Buyer is required to check all tool bits prior to returning and ensure they are packaged well
for shipment. The price structure is available from the Seller’s sales coordinator. Seller
cannot resharpen badly gouged, chipped, or broken tool bits. Seller will return tool bits that
are not suitable for resharpening with the tool bits that were resharpened upon Buyer’s
request. Buyer is responsible for all shipping charges to and from Seller.

TRI TOOL INC.
92-0763 Rev. 230210
6
1. ABOUT THE MANUAL
Copyright
©Copyright Tri Tool Inc. Proprietary property of Tri Tool Inc. No reproduction, use, or
duplication of the information shown hereon is permitted without the express written consent
of Tri Tool Inc.
Disclaimer
The instructions and descriptions in this manual were accurate when the manual was
written. However, the information in the manual is subject to change without notice. Check
for updated information before you start any job. The Tri Tool Inc. website has the most
current information.
Do not operate or work on this equipment unless you have read and understood the
instructions in this Manual. Failure to follow the instructions or follow the safety instructions
could result in serious injury or death. This manual describes conditions and hazards
that are common and anticipated during equipment operation. No manual can address all
conditions which may occur.
Safety Symbols
The manual may contain one or more safety symbols. These symbols and the associated
text warn you of potentially hazardous conditions. Examples of the safety symbols and the
associated text follow:
DANGER
DANGER: Indicates a hazardous situation that, if not avoided, will result in serious
injury or death.
WARNING
WARNING: Indicates a hazardous situation that, if not avoided, could result in serious
injury or death.
CAUTION
CAUTION: Indicates a hazardous situation that, if not avoided, could result in minor or
moderate injury, or cause property damage.

Model 224B BEVELMASTER®
92-0763 Rev. 230210 7
GLASSES
SAFETY GLASSES: Indicates a hazardous situation that requires the use
of safety glasses.
HOT SURFACE
HOT SURFACE: Indicates a hazardous situation that hot
surfaces may be present.
SHOCK HAZARD
ARC FLASH & SHOCK HAZARD: High voltage. Entry by authorized
personnel only. Appropriate PPE and tools required when working on this
equipment.
GLOVES
GLOVES: Indicates a hazardous situation that requires glasses.

TRI TOOL INC.
92-0763 Rev. 230210
8
2. SAFETY PRECAUTIONS
In General
Use standard safety equipment such as: hard hats, safety shoes, safety harnesses,
protective clothes, and other safety devices when appropriate.
Operatethistoolonlyinaccordancewithspecicoperatinginstructions.
WARNING
WARNING: Do not override the dead-man switch on the power unit. Locking down,
obstructing, or in any way defeating the dead-man switch on the power drive unit may
result in serious injury.
Personal Protective Equipment
Use standard safety equipment such as: hard hats, safety shoes, safety harnesses,
protective clothes, and other safety devices when appropriate.
Wear safety glasses.
Do not wear loose clothing or jewelry.
Wear nonskid footwear.
Put long hair in a cap or a net to make sure hair does not get tangled in equipment.
Personnel
Only personnel who are trained or are being trained may operate the equipment.
Keep the operation manual available where the equipment is used.
The operator must read the operation manual before using the equipment.
The equipment must be operated in accordance with the manual information.
The operator must follow the safety precautions in this manual and good engineering
practices to reduce the risk of injury.
Before using the equipment, the operator must ensure that all safety messages on the
equipment are legible.
Work Area
Keep the work area clean.
Keep the area well lit.
Keep items such as electrical cords, cables, rags, rigging straps, away from rotating
equipment.

Model 224B BEVELMASTER®
92-0763 Rev. 230210 9
Donotusepower-cuttingtoolsinthepresenceofammableliquidsandgases.
Do not let visitors or untrained personnel near tools that are in use.
Ensure all observers wear eye protection.
Keep proper footing at all times.
Area Equipment
Secure the pipe with clamps, vises, chains or straps.
Ensure that both sides of the pipe at the cut site is fully supported so that the pipe will not
move after the cut is completed. Long lengths of pipe may be under load and the separation
of the pipe can release pressure. This pressure can cause both sides of the pipe to move.
Tool Care
Keep tools in good operating condition. Sharp tool bits perform better and are safer than dull
tool bits.
Do not use damaged tools. Always check your tools for damage especially if a tool has
malfunctioned, been dropped or hit, check it for damage.
Before you start operating the equipment, do no-load tests and feed function checks.
Tool Use
Use the right tool and tool bit for the job. Contact Tri Tool to help with your application.
Keep the tool bits fully engaged in the tool bit holders. Loose bits are sharp and can cause
cuts or punctures.
Disconnect power supply during setup and maintenance. Use all ‘Stop’ or Shut off’ features
available when changing or adjusting tool bits, maintaining the tool, or when the tool is not in
use.
Remove adjusting keys and wrenches before applying power to the equipment. Check the
tool before turning it on to make sure that all keys and wrenches have been removed.
Do not force tools. Tools and tool bits function better and safer when used at the
recommended speeds.
Do not reach into rotating equipment.
Do not reach into the rotating head stock to remove chips, to make adjustments, or to check
thesurfacenish.
Handle chips with care. Chips have very sharp edges and are hot. Do not try to pull chips
apart with bare hands.
Store tools properly. Disconnect tools from the power source, remove the tool bits, and store
in a safe place.

TRI TOOL INC.
92-0763 Rev. 230210
10
3. GENERAL DESCRIPTION
The Model 224B BEVELMASTER®is a Portable ID Mount Machine Tool for beveling, facing
and/orcounterboring8"through24"pipe.ThetoolisconguredwithaninlineFeedKnob
and Pneumatic or Hydraulic Drive Motor at right angle to the Lathe Head.
.

Model 224B BEVELMASTER®
92-0763 Rev. 230210 11
4. SPECIFICATIONS
Design and operating features
The Model 224B BEVELMASTER®is designed for facing, beveling and/or counterboring the
ends of pipe or tubing in preparation for welding.
These machining operations may be performed either simultaneously or separately.
Pipe weld preparations that meet all existing conventional codes including the more
stringent nuclear codes may be machined using the Model 224B BEVELMASTER®.
The various interchangeable Jaw Blocks, Ramps and Spacers will secure the Model
224B BEVELMASTER®to pipe and tubing having an inside diameter of 6.813" (173.0 mm)
minimum, with a maximum outside diameter of 24.00" (609.6 mm).
The expanding Mandrel provides fast, accurate self-centering and alignment to the pipe or
tubing to be machined.
The Lathe accepts it’s own torque through the Mandrel generated by machining operations.
No additional torque restraining devices are required.
The Model 224B is provided with a Lathe Lifting Frame Assembly.
Various attachments are available to further enhance the capabilities of the Machine.
In specic
Weight (w/Mandrel, Drive Motor and Lifting Frame.)
420 lbs (190 kg)
Cutting Capacities
Basic Pipe Sizes
8" through 24" pipe - All schedules.
Basic Tube Sizes
Up to 2.34" (59.4 mm) wall tubing with a maximum OD of 24.00” (609.6 mm) and a
minimum ID of 6.813" (173.0 mm) may be beveled with the Standard Mandrel.
Wall Thickness Capacity
Wall thickness of all standard pipe schedules 2.34" (59.4 mm) maximum in the
range listed. Tubing or pipe with a greater wall thickness may be handled provided
the ID is greater than 6.813" (173.0 mm) and the OD is less than 24.00" (609.6
mm). Contact TRI TOOL Inc. for heavier wall procedures.

TRI TOOL INC.
92-0763 Rev. 230210
12
39.75"
(1009.7 mm)
20.90"
(530.9 mm)
5.38"
(136.7 mm)
Travel
Adjustable C.G. Lifting Eye
27.00"
(685.8 mm)
Rotating DIA.
OPTIONAL: Floor Stand
Power Requirements
Pneumatic Motor
95 cfm at 90 psi (44.8 L/s at 621 kPa)
Hydraulic Motor
20 GPM at 1250 psi (1.3 L/s at 8619 kPa)
Feed Rate
.083" (2.1 mm) per rev of the Feed Handle
Feed Travel
5.38" (136.7 mm)
Rotating DIA
27.00" (685.8 mm)
Figure 1: Model 224B BEVELMASTER®

Model 224B BEVELMASTER®
92-0763 Rev. 230210 13
Cutting Head Speeds
High Speed Socket
Maximum Cutting Head Speed 18 rpm
Cutting Head Speed @ Maximum H.P. 9 rpm
Functional Speed Range 6 to 18 rpm
Low Speed Socket
Maximum Cutting Head Speed 9 rpm
Cutting Head Speed @ Maximum H.P. 4.5 rpm
Functional Speed Range 3 to 9 rpm
Counterboring Operations
The tool will counterbore pipe and tubing with an ID range of 8.500" (216.0 mm) to
24.00" (609.6 mm).

TRI TOOL INC.
92-0763 Rev. 230210
14
5. MAINTENANCE
Model 224B Maintenance Schedule
Step Hours of
Operation
Maintenance Activity Note
No.
Maintenance
Picture No.
1 2 Clean all debris from tool. 2
2 8 Spray all bare metal with light oil. A 2
350 Grease Mandrel. (As required) B 2
450 Grease Main Bearing. (As required) B 2
550 Grease Main Gear. (As required) B 1
650 Grease Gearbox Assembly. (As required) B 1
NOTES:
A Use SAE 10W light machine oil.
B Use Chevron ultra-duty grease "EP NLGI2." (TRI TOOL INC. P/N 68-0024)
Grease Fitting (Main Gear) Grease Fitting (Gear Box)
Figure 2: Maintenance — Picture 1

Model 224B BEVELMASTER®
92-0763 Rev. 230210 15
Clean and Spray Oil
Grease Fitting (Main Bearing)
Grease Fitting (Mandrel)
Clean and Spray Oil
Figure 3: Maintenance — Picture 2

TRI TOOL INC.
92-0763 Rev. 230210
16
Main Torque
Housing
Set Screws
Lock Nut
Dust Cover
Bushing, Split
Tightening the Front Bushing
When the Mandrel Shaft is loose, the Tapered Split Bushing can be tightened.
Rotate the Feed Handle to extend the Mandrel outward to the limit line.
Unbolt the Dust Cover and slide it down the Mandrel to provide access to the Locknut and
Bushing.
Loosen the eight (8) Set Screws in the Locknut on the front of the Main Torque Housing.
Tighten the Locknut on the front of the Main Torque Housing, using the Spanner Wrench
provided, approximately 75 ft-lbs (102 N m).
Tighten the eight (8) Set Screws in the Lock Nut, approximately 1 ft-lbs (1.36 N m).
Figure 4: Tightening the Split Bushing

Model 224B BEVELMASTER®
92-0763 Rev. 230210 17
Storage and Torque Specications
Remove the Tool Bits from the Tool Holders before storing the machine.
WhentheModel224Bistobestoredorifitwillremainoutofserviceforasignicantperiod
of time, 30 days or more, it should be thoroughly cleaned, lubricated and sprayed with a rust
preventative prior to storage.
The twelve (12) Cap Screws that hold the Main Plate to the Main Shaft are torqued to
100 ft-lbs (136 N m).
The eight (8) Cap Screws that hold the Main Torque Housing to the Main Housing are
torqued to 25 ft-lbs (34 N m).
The eight (8) Cap Screws that hold the Model 224B BEVELMASTER® to the Mounting
Bracket are torqued to 45 ft-lbs (61 N m).
The eight (8) Cap Screws that hold the Gear Cover to the Main Housing are torqued to
45 ft-lbs (61 N m).
Main Torque Housing
Lifting Bracket
Mounting Bracket
Main Plate
Gear Cover
Figure 5: Storage and Torque Specications

TRI TOOL INC.
92-0763 Rev. 230210
18
LUBRICATION
The Drive Gears require a grease such as “Chevron Ultra-Duty Grease EP NLGI 2”
(P/N 68-0024).
The T-Slot Plates and Tool Blocks require a light oil such as SAE 10 light machine oil.
The Feed Screw for the Tool Blocks require a SAE 10 light machine oil for normal conditions
andunderdustyconditionsasilicone,graphiteormolybdenumdisulde‘dry’lubricant.
NOTE: A light lm of all purpose grease may be used, but it must be checked for grit
contamination frequently.
The Air Motor requires a Class 2 lubricant, viscosity of 100 to 200 SSU at 100° F
(38° C) minimum aniline point of 200° F (93° C).
NOTE: When using a Pneumatic Drive Assembly, use an adequate in line lter,
regulator, and lubricator (FRL).
TheTriToolAirCaddy,aportablecombinationlter,regulator,andlubricator(FRL)unitis
recommended. (P/N 75-0114)
• TRI TOOL Inc. - Air Tool Lubricant (P/N 68-0022)
• AMOCO - American Industrial Oil No. 32
• AtlanticRicheld-DuroOilS-150
• Chevron - A.W. Machine Oil 32
• Shell - Tellus Oil 32
The bearings in the Air Motor are sealed and do not require any lubrication.

Model 224B BEVELMASTER®
92-0763 Rev. 230210 19
6. OPER ATION
Tool Bit, Counterboring
Rotation
Tool Bit, Facing
Tool Bit, Beveling
Headstock
Set Screws
Adjustment Screw
Preparation
Read the operating instructions carefully before attempting to operate the Model 224B
BEVELMASTER®.
Use eye protection at all times when operating the Model 224B.
Tool Holders
The Tool Holders may be positioned in various locations on the Headstock in order to
accommodate any particular pipe size and prep geometry.
Tool Block Set
In general the Counterbore Tool Block should lead the Bevel Tool Block.
Figure 6: Tool Bit Position in the Headstock

TRI TOOL INC.
92-0763 Rev. 230210
20
Installation of the Tool Bits
To select the appropriate Tool Bits refer to the ‘Tool Bits’ section of this manual to help with
your choice.
CAUTION
CAUTION: Use of a dull Tool Bit(s) or Tool Bit(s) not manufactured by TRI TOOL Inc.
may result in poor performance and may constitute abuse of this machine and therefore
voids the TRI TOOL Inc. factory warranty.
The three (3) Tool Blocks have been optimized for the various operations and to reduce Tool
Bit wear, thus the Tool Bit(s) must be installed in the correct Tool Block(s).
BesurethattheToolBit(s)sitsushagainsttheSlotandthentightentheLockingSet
Screws.
Be sure that the cutting edge of the Beveling Tool Bit is along the Radial Centerline of the
Headstock, advance into the cut.
Tool Bit
Hex Wrench
Tool Block
Set Screw
Rotation
Figure 7: Position the Tool Bit in the Slot
