TRI tool BEVELMASTER 224B User manual

92-0833 Orig. 990603
Model 224B Single Point
TABLEOFCONTENTS
CUSTOMERMESSAGE InsideFrontCover
SAFETYPRECAUTIONS 3
GENERALDESCRIPTION 5
SPECIFICATIONS 6
MAINTENANCE 8
OPERATION 9
INSTALLATION 14
CUTTINGSPEEDS 16
TOOLBITS 18
TROUBLE SHOOTING 19
SPARE PARTS LIST 21
ILLUSTRATEDPARTSBREAKDOWN 22
TOOLBITRESHARPENINGPOLICY InsideBackCover
WARRANTYINFORMATION InsideBack Cover

Copyright 1999 proprietary property of TRI TOOL Inc.
No reproduction, use, or duplication of the information
shown hereon is permitted without the express written
consent of TRI TOOL Inc.

3
92-0833 : Orig. 990603
Model 224B Single Point
WARNING:
SAFETY PRECAUTIONS
Whenusingrotating headcuttingequipment,basic safety precautionsshouldal-
waysbefollowed to reducetheriskof personal injury.
Operatethistool only in accordancewithspecificoperatinginstructions.
Donotoverride the deadman switchonthepowerunit. Locking down, obstruct-
ing,orinanywaydefeating thedeadman switchon thepowerdriveunitmayresult
inserious injury.
Usestandardsafety equipment. Hardhats,safetyshoes, safety harnesses,pro-
tectiveclothes,andothersafetydevicesshouldalwaysbeusedwhenappropriate.
Usesafetyglasses. Do not operate cutting toolswithouteyeprotection.
Dressproperly. Donot wearlooseclothing orjewelry. Theycanbe caughtinrota-
tingand moving parts. Avoidslipperyfloors orwearnonskid footwear. If youhave
longhair, wearprotectivehaircoveringto contain it.
Keeptheworkarea clean. Cluttered work areas and benches inviteinjuries.
Considertheworkareaenvironment. Keeptheareawelllit. Keepelectricalcords,
cables, rags, rigging straps, etc. clear of rotating equipment. Do not use power
cuttinginthepresence of flammable liquids and gasses.
Keepvisitors away. Donotlet visitorsoruntrainedpersonnel atornearoperating
tools. Enforceeyeprotection requirements for allobservers.
Do not over reach. Keep proper footing at all times.
Stay alert. Watchwhat you aredoing. Usecommonsense. Do not operate tools
whenyou aretired.
Maintaintoolswithcare. Keeptoolsingoodoperatingcondition. Sharp tool bits
performbetterandsaferthandull toolbits. Well maintainedtoolsfunctionproperly
whenneeded.
Checkfor damagedparts.Ifa toolhasmalfunctioned, beendroppedor hit,itmust
becheckedfordamage.Runno-load tests and feed function checks. Do a com-
pletevisualinspection.
Electricmotors. UseonlywithproperACvoltagepower sources and observe all
normalelectricshock hazardprocedures.
IN GENERAL:
DRESS CONSIDERATIONS:
WORK AREA:
TOOL CARE:

92-0833 : Orig. 990603
TRI TOOL INC.
4
Donot abuse power and control cords. Pullingor running over cords and cables
canresultinelectricalshockhazards and malfunctions. Keep control and power
cordsoutof all cuttingfluidsandwater.
Hydraulicdrives. Observeproperproceduresforelectricallydrivenpowersources.
Avoiddamagetohydraulic lines. Keep quick-disconnects clean. Gritcontamina-
tioncauses malfunctions.
Airtools. Checkthe exhaust muffler. Brokenordamaged mufflerscan restrict air
floworcauseexcessivenoise. Use air motors only with a filtered, lubricatedand
regulated air supply. Dirty air, low pressure air or over pressure air will cause
malfunctions,including delayedstarting.
Securework. Wheneverpossible use clamps,vises,chainsand straps tosecure
pipe.
Make sure the tool is secured; it is safer to have both hands free to operate the
tool.
Ustheright tool and tool bitforthejob. Do not use a toolwhichisincorrect for the
jobyouaredoing.
Keep the tool bits fully engaged in the tool bit holders. Loose bits are a safety
hazard.
Disconnectpowersupply during setupandmaintenance. Use all stoporshut-off
features available when changing or adjusting tool bits, maintaining the tool, or
whenthetool is notinuse.
Remove adjusting keys and wrenches before applying power to the equipment.
Developahabit of checking thetoolbeforeturningit on to makesurethatallkeys
andwrenches havebeenremoved.
Donotforcetools. Toolsandtoolbitsfunctionbetterandsaferwhenused at the
feedandspeedratefor which they were designed.
Donotreach into rotatingequipment. Donot reach intotherotatinghead stock to
clear chips,tomakeadjustments,or tochecksurfacefinish. Amachine designed
tocutsteelwill not stop for a hand or anarm.
Handle chips with care. Chips have very sharp edges and are hot. Do not try to
pullchips apartwithbare hands;theyarevery tough.
Avoidunintentionalstarts. Donotcarryor handletools withyourhandontheoper-
ating switches or levers. Do not lay the tool down in a manner which will start the
drive.Donot allow thetooltoflip around or movewhenadjustingor changing tool
bits.
Store idle tools properly. Disconnect tools from the power source and store in a
safeplace. Removetoolbitsfor safe handling of the tool.
AREA EQUIPMENT:
TOOL USE:

5
92-0833 : Orig. 990603
Model 224B Single Point
GENERAL DESCRIPTION
The Model 224B Single Point is supplied as a kit with modular components as-
sembledonto thefaceof the224BBEVELMASTER™.The 224Bthenmounts on
theflangeor pipe I.D. When used inconjunctionwiththe224BMiter Mandrel, the
224B Single Point / Flange Facer Kit miters to align to the flange face.
GeneralNomenclature:
Autofeed
Manual Radial
Positioning
Tilt
Positioning
Tool
Rotation

92-0833 : Orig. 990603
TRI TOOL INC.
6
SPECIFICATIONS
INGENERAL:
Easy to assemble 224B SP Kit bolts directly to the face of the 224B without any
modificationtothe machine.
The 224B SP is equipped with 5” (127mm) of feed length for heavy wall pipe and
flangefaces.
Theslide assembly hasinfinitelyvariablebevel angleadjustmentsbetween0 and
371/2°.
The224BSPhas atotalradialtravelof18.23”(463.0mm)andadjustment forlarge
pipeandflange cutting ranges.
EnvelopeDrawing,224BSinglePoint
( 1543.8 MM)
MAX. ROTATING DIA.
60.78 "
( 587.2 MM )
23.12"
( 1009.65 MM )
39.75"
5.00"
( 127.0 MM )
FEED TRAVEL
37 1/2
( 688.8 MM )
27.12"

7
92-0833 : Orig. 990603
Model 224B Single Point
Range,Beveling: 7.00” (177.8mm) diameter to 42.00” (1066.8mm) diam-
etercuttingrange at 37.1/2°.
BevelAngles: 0°to 37 1/2°graduatedbevelangle adjustment.
Range,FlangeFacing: 12.00” (304.8mm)diameterto50.00”(1,270.0mm)diame-
tercutting range.
FeedTravel: 5.0”(127.0mm)nominal (radial).
Alignment: Whenused in conjunctionwiththe 224B MiterMandrel
Head:
Angular- plus orminus5°
Offset- plus or minus.19”(4.83mm)
Feed: 8selectablepositions between .005” (.127mm) rev.
and.032”(.803mm) /rev.inclusive
Cutting:
.200max.cut depth / pass.
63RMSfinishmaybeobtaineddependingonmaterial.
Spiralgroovesascoarseas31groovesper inch when grooving.
Machinesstainlessand carbon.

92-0833 : Orig. 990603
TRI TOOL INC.
8
Allcomponentsshouldbecleanedandcoated with a light film of oil prior to use.
If the Model 224B is operated in the vertical position (headstock facing Up), the
chipsand/orother debris should be removedaftereachbevelcuthas been com-
pleted.
Tool life may be severely shortened, unless chips and/or other debris that have
beendepositedonoraround the headstock during the machining operationare
removed.
Dailymaintenanceshould include a visual inspectionofallpartsfor damage due
to chips, impact or improper use.
Repair or replace broken or damaged parts as necessary.
Wipethe machinecleanof cuttingfluids,dirt andgrimeand thencoatit withalight
filmofoil.
For complete weekly maintenance procedures, see the Model 224B
BEVELMASTER™manual.
MAINTENANCE

9
92-0833 : Orig. 990603
Model 224B Single Point
NOTE:
OPERATION
Read the operating instructions carefully before attempting to operate the Model
224B SP.
UseeyeprotectionatalltimeswhenoperatingtheModel224BSP.
Configurethemachinefortheproper mountingdiameter.(RefertotheModel224B
Operator’smanual)
AttachtheModel224B SP to the Model 224B.(RefertoInstallationsection.)
Installthemandrel inside the pipe andtightenthedrawnut to force thejawblocks
out against the inside diameter of the pipe.
Inordertoavoidcuttingthejaw blocksduringthemachiningoperation,themandrel
mustbeinstalled beyond thefinalendpreparation location.
Tool Bit Clearance
Final Prep Location
Clearance
Set Screw
(Feed Lock)
Feed Handle
Plate
Pipe
Jaw Block
Mandrel Head

92-0833 : Orig. 990603
TRI TOOL INC.
10
CAUTION:
NOTE:
NOTE:
Ifamitermandrelistobeused,pleaserefer tothe Operator’sManualforthatmiter
mandrelinstallation.
Install the Model 224B with the Model 224B SP attached onto the installed man-
drel.
Checkforcorrectangleoftheslide.
Setthecamfollowerintheproperholeontheindexplatefor therequired feedrate.
Checkforpropersettingofthefeeddirection.
Move the Model 224B with the Model 224B SP into position to begin the cut by
rotatingthefeedknob clockwise.
Verifyaminimum clearanceof.125”(3.2mm)betweenthetool bitand thepipeOD
atthe highest point.
Lockthe BEVELMASTER™ inplaceto prevent axialmovementby tightening the
setscrewonthe back of the Feed Handle Plate untilitistightenedsecurely.
Attach the proper power supply line to the drive assembly. If using a pneumatic
driveassembly,use anadequatein-linefilter,regulator,andlubricator(FRL).
TheTriToolAirCaddy,a portablecombinationfilter,regulator, andlubricator(FRL)
unitisrecommended.
Turnthemotoron.
Letthemachinerotateveryslowly forone revolutiontoverifythatthetoolbitclears
theOD of the pipe.
Adjust the cutting speed by opening the Flow Control Valve at the power supply
connection.
Theactualmachining operation will beginwhenthetool bit contacts thepipe.
Ifthepipe end is notsquarewiththe pipe axis, thetoolbitwillcontact only a small
segmentofthe pipe duringeachrevolution.
To avoid tool bit damage, the feed rate should be very slow until the tool bit has
contactedthe pipecontinuallyfor atleastone fullrevolution.
Afterthecut is finished,turnthemotor off to stopthecuttinghead rotation.
Loosenthefeedlocksetscrew.
Rotatethefeedknob counter-clockwise to separate the headstock fromthepipe.
Loosenthedraw nut onthemandrelcounter-clockwise to release thepipe.

11
92-0833 : Orig. 990603
Model 224B Single Point
Removethemachine from thepipe.
Checktoseeif any of the tool bits are dull or broken.
Damaged or worn tool bits are evidenced by increased feed pressure, visual ob-
servations,poorsurface finish,etc.
Ifthe nextbevelistobe thesameendpreparationas thepreviousbevel, installthe
machineandmandrelin the pipe and follow thesequencestartingonpage9.
If the next bevel is to be different than the previoys bevel, follow the sequencr in
Adjustmentofthe BolckAssemblysection.
For changeing the tool bit, follow the sequence in the Counter Boring Function
section.
While holding the tool block slide assembly, loosen the (6) screws on the base of
theslide.
Reposition the slide assembly and tighten the (6) screws. This will hold the slide
firmlyagainst theplate.
Toadjustthebevelangleoftheslide,loosenthelockingscrewson thesidesof the
slide,pulltheslideuptotherequiredangle andtighten thescrews,maximumangle
is 37° 30’.
To select the appropriate toolholderandInsert,seesection on cutting speeds.
Use of a dull Insert or Inserts not manufactured byTri Tool Inc. may result in poor
performanceand mayconstituteabuseof thismachineand thereforevoidstheTri
ToolInc.factorywarranty.
SlidetheassembledtoolholderwithInsertintothetoolholderslotonthetoolblock.
Installthe toolholderwith theInsertwith thecuttingedge towardthemandrel .
Lockthetool holder into positionwiththesetscrews on the sideofthetool holder.
Putthe gearboxintoneutral.
Selectthe properholelocationon thepositionindex plateandtheactuator armfor
therequiredfeed.
Set the feed direction by pulling out the knob (for feeding toward the mandrel), in
the center position (for neutral or no feed) or by pushing in the knob (for feeding
awayfrom themandrel).
Adjustment of the Tool Block Assembly:
Installation of the Tool Holder and Insert:
Adjustment of the Feed:
Setting Feed Direction:

92-0833 : Orig. 990603
TRI TOOL INC.
12
Actuator Arm
Feed Out
Neutral

Feed In
Feed Knob
3
1
4
2
Index Plate
BA
FeedSystemSet-up
Counterboring Function:
Lockthetoolslideintheflatposition.
Replacethe tool holderandthe Insert withthecounterbore tool bit.
Insurethat the cuttingedgeis facing outfromthe center.
Setthefeeddirection to neutral by moving the feedknobtothecenterposition.
Index Plate Positions
1234
Actuator A .005" / rev .010" / rev .014" / rev .019" / rev
Arm (.13mm / rev) (.25mm / rev (.36mm / rev) (.48mm / rev)
Position B* .009" / rev .016" / rev .025" / rev .032" / rev
(.23mm / rev) (.41mm / rev) (.61mm / rev) (.81mm / rev)
*Position B should be used for flange facing only
Feed rates

13
92-0833 : Orig. 990603
Model 224B Single Point
NOTE:
Feed in of a Counterbore Tool Bit
Installthe mandrel insidethepipe and tightenthedraw nuttoforcethe jawblocks
out against the inside diameter of the pipe.
Inordertoavoid cutting the jaw blocks during the machiningoperation,theman-
drelmustbe installed beyondthefinalend preparation location.
Advancethemachinebyturningthefeedknobclockwiseuntil thetool bitis slightly
inside the pipe.
Movethetoolslide out until the tool bit contacts theIDofthepipeandtighten the
slide.
Turn the manual feed knob on the tool slide so that the tool bit clears the bore ID
andbackthemachineoutof the pipe.
Securelylockthetoolslideinpositionbytighteningall(6)oftheradialadjustscrews
ontheslide assembly.
Turnthemotoron.
Letthemachinerotateveryslowlyforonerevolutiontoverifythatthetoolbitclears
theIDofthe pipe.
Adjust the tool bit into the cutting position, use the manual feed knob on the tool
slide.
Tightenthedovetailslidelock screwinthetoolblock whendesiredtoolbitposition
hasbeenachieved.
This screw must be loosened and re-tightened whenever the dovetail slide re-
quiresrepositioning.
Ifitis not securelytightened,the tool bitmaywalkout of thecut.
Plungecutto desired depth.

92-0833 : Orig. 990603
TRI TOOL INC.
14
Attaching the Model 224B SP Kit to the Model 224B.
Removethe MandrelAssembly,DustCover,Tool HolderAssembly,Adjustment
RodAssembly andtheCoverPlate fromtheModel224BMachine.
INSTALLATION
Tool configuration prior toSinglePointinstallation.
Cover Plate
Adjustment Rod
Assembly
Tool Holder
Assembly
Mandrel Assembly Dust Cover
SecuretheHousingAssembly, FeedGear(P/N19-0839)to the MainPlate,using
supplied cap screws (P/N 33-0041).
InstallPlateAssembly,Adaptor(P/N24-0721)ontoMainPlate(flat),secureinplace
withretainedcapscrews.
Slide the CutterAssembly intoT-slots onAdaptor PlateAssembly to position de-
siredand secure the (6) cap screws on the base.
SecuretheGearAssembly, Feed (P/N 33-0330)totheFrontLockingPlateusing
supplied cap screws (P/N 33-0032).

15
92-0833 : Orig. 990603
Model 224B Single Point
Installationofthe 224B SinglePoint
Index Plate
Radial Adjustment
Screws (6)
Angular Adjustment
Screw (both sides)
Manual Directional
Feed Knob
Dovetail Slide
Lock Screw
VariousAdjustmentlocations
Housing Assembly,
Feed Gear
Cutter Assembly
Main Plate
Front Locking Plate
Plate Assembly,
Adaptor
Gear Assembly,
Feed (P/N 39-0330)

Cap Screws
(P/N 33-0041) Cap Screws
(P/N 33-0032)

92-0833 : Orig. 990603
TRI TOOL INC.
16
CUTTING SPEEDS
The chart shows RPM to obtain specified tool bit surface cutting speed on the
surfaceofthepipe.
Use200surfaceinchesperminute(508surfacecentimetersperminute)for: Stain-
lesssteelsin general whennocoolantis allowed, allheavy-walltubeand some of
thechrome/molybdenumsteels.
Use250surface inches per minute(635surfacecentimeters per minute) for:Mild
steels and some thin-wall stainless steels when coolants are permitted and ap-
plied.
Use300surfaceinches per minute (762 surfacecentimetersperminute)for:Alu-
minumand some thin-wallmildsteel andtubewithcoolants.
RPM for RPM for RPM for
Pipe True Dia 200 in/ min 250 in/ min 300 in/ min
Size (508cm / min) (635cm / min) (762cm / min)
42" 42.00" 1067 mm 2 2 2
40" 40.00" 1016 mm 2 2 2
38" 38.00" 965 mm 2 2 3
36" 36.00" 914 mm 2 2 3
34" 34.00" 854 mm 2 2 3
32" 32.00" 813 mm 2 2 3
30" 30.00" 762 mm 2 3 3
28" 28.00" 711 mm 2 3 3
26" 26.00" 660 mm 2 3 4
24" 24.00" 610 mm 3 3 4
22" 22.00" 559 mm 3 4 4
20" 20.00" 508 mm 3 4 5
18" 18.00" 457.2 mm 4 4 5
16" 16.00" 406.4 mm 4 5 6
14" 14.00" 356.6 mm 5 6 7
12" 12.75" 324.9 mm 5 6 7
10" 10.75" 273.1 mm 6 7 9
8" 8.63" 219.1 mm 7 9 11
Cutting Speed (approximately)

17
92-0833 : Orig. 990603
Model 224B Single Point
Basic Feed Recommendations are:
Useverylight feed for initialbevelingoruntil a continuous cutisestablished.
Thisis veryimportant forlongertoolbitlife whencuttingthroughflamecut oroutof
square pipe ends.
Useadequatefeed,.003” to .006” (.08mm to.15mm)perrevolutionthereafter,to
establisha continuous chipcut.
Ifthefeed is too light,onlystringerchipswill be removed.
Ifthe feed istooheavy thedrivewillstart tooverloadand thechipwillstart tohave
aroughor torn appearance.
Stainlesssteel, whichworkhardens, mustbeworked withaheavy enoughfeedto
stayundertheworkhardenedsurface.003”to.006”(.08mmto.15mm)feed.Never
allowthe tool bittoburnish the surface.
Reducedfeedsand speeds will normallyminimizechatterproblems.

92-0833 : Orig. 990603
TRI TOOL INC.
18
TOOL BITS
49-0060 ToolHolder
30-0554 Insert,Triangular,.030R
30-2822 Insert,Traingular,.015R
99-1666 Tool Bit,Counterbore
StandardSelection
Tool Bitsforspecialapplicationsarequoteduponrequest.

19
92-0833 : Orig. 990603
Model 224B Single Point
Problem: The Tool Bit Chatters.
Thetoolbitislooseor overextended.
The tool bit is damaged.
The tool holder is too loose in the slides.
Thecuttingspeedistoofast.
The Jaw blocks are loose on the pipe or tube.
Cuttingfluidisrequired.
The main bearing pre-load is loose.
Problem: There is excessive Tool Bit wear.
The pipe or tube material is too hard or abrasive.
Thecuttingspeedistoo fast.
Cuttingfluidis required.
Adulltoolbit is causing surface hardening conditions (stainless pipeortub-
ing). Thereis scaleorotherforeign matteronthe pipeortube,which isdulling
thetoolbit at the startofthecut.
Thetoolbitisincorrect for the material being cut.
Problem: The surface finish is rough.
Thetoolbitisdull, chipped, etc.
Metalbuild/uponthe cuttingedgeofthetoolbitiscreatinga falsecuttingedge.
Cuttingfluidis required.
Thecuttingspeed is incorrect.
Problem: The tool holder is not feeding.
The feed screw is stripped.
Thefeednutis stripped.
Thesliderailsaretootight.
TROUBLE SHOOTING
Problem: There is a loss of air power.
Theairsupply pressure is too low.
Theairfilterisplugged.
Theairline size is insufficient.
Theairlineistoolong.

92-0833 : Orig. 990603
TRI TOOL INC.
20
Problem: There is a loss of hydraulic power.
Thehydraulic supplypressureistoo low.
Thehydraulic filterisplugged.
Thehydraulic linesizeisinsufficient.
Thehydraulic line istoolong.
Problem: The tool bit will not reach the work.
Incorrecttoolblocks are installed for thesizeofthepipe or tube being worked
onincorrecttoolbitis installed.
Problem: The air motor will not start.
Theairpower supply isshutoff.
Theairmotorisdamagedand willnot runfree.Theairmotorneedslubrication.
Addlubrication and donotrun the airmotorfor a fewminutes,then try running
themotor.Tap on the side of the air motor casing lightly with a piece of wood
orwithasoft rubber mallet just incasethevanesmaybe sticking.
Sandorotherforeignmaterial may be in the vanes of theairmotor.
Problem: The hydraulic motor will not start.
Thehydraulic powersupplyis shutoff.
Thehydraulicmotor isdamagedandwill not runfree.
