Trinity TR60-2 User manual

OPERATION INSTRUCTIONS
SAVE THESE INSTRUCTIONS
TR60-2 FULL BODY AIR-MASSAGE CHAIR

01
Thanks for purchasing this product. Please read this manual instruction carefully in
order to know how to use this product correctly before operation. Please pay more
attention to some important safety warning and keep this manual book properly for
future use.
Note: Our Company reserves the right to revise the design and description of this
product without any further notice. Please refer to the actual color of this product.
02
04
05
06
17
Safety and maintenance
Name and function of components
Function
Method of usage
Product specification
CONTENTS

0302
Safety And Maintenance Safety And Maintenance
Don t allow children to touch moveable part of this product.
Please use well-grounding power supply suited to this product.
Please pull out the plug after use or before cleaning to avoid injury or
Damage to the product.
Please operate this product according to this manual instruction.
Don t use accessories which are not recommended.
Don t use this product outdoors.
Please read this manual instruction carefully before operation.
Any other usage that is not listed in this manual instruction is forbidden.
20 minutes of usage each time is recommended.
Please don t use it if the leather is broken or damaged.
Please don t use it if the cover or leather is damaged.
Please don t use it if the radiator hole is covered or blocked.
Please don t drop anything into this product.
Please don t fall asleep while using this product.
Please don t use it if drunk or feel unwell.
Please don t use it within one hour after having meal.
Please don t make the massage function too strong for avoiding Injury.
2. Environment for usage.
Please don t use it under high temperature and moist environment such as
bathroom.
Please don t use it immediately while the environmental temperature
changes sharply.
Please don t use it under heavy-dusty or caustic environment.
Please don t use it where there is not enough space or not good ventilation.
3. People who are not suitable to use this product.
People who are suffering from osteoporosis are not suitable to use this product.
People who are suffering from heart disease or carrying electronic medical
equipment such as heart pacemaker are not suitable to use this product.
People who are suffering from fever are not suitable to use this product.
Pregnant women or women that are in menses period are not suitable to use this
product.
People who got injured or skin disease are not suitable to use this product.
Children under 14-year old or people mentally unbalanced without being
Supervised are not allowed to use this machine.
People who are told by doctor to have rest or people who feel unwell are not
suitable to use this product.
People whose bodies are wet are forbidden to use this product.
The appliance has a heated surface.persons insensitive to Heat must be careful
when using the appliance.
4. Safety.
Check the voltage if it is suitable to the specification of this product.
Don t use wet hand to pull the plug.
Don t make water go inside this product to avoid electric shock or cause damage
to this product.
Don t damage the wires or change the circuit of this product.
Don t use wet cloth to clean the electric parts such as switch and plug.
Be away from this product under power cut state to avoid injury if the power
comeback suddenly.
Stop using this product while it works abnormal, and please consult local agent
immediately.
Stop using this product if you feel unwell, and please consult health care doctor.
This appliance is not intended for use by persons (including children) with reduced
physical, sensory or mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction concerning use of the
appliance by a person responsible for their safety.
Children should be supervised to ensure that they do not play with the appliance.
If the supply cord is damaged, it must be replaced by the manufacturer, its Service
agent or similarly qualified persons in order to avoid a hazard.
5. Maintenance.
This product should be maintained by certain appointed agents, users are
prohibited to disassemble or maintain by themselves.
Please don t forget to cut the power after usage.
Don t use this product if the socket looses.
If this product will be left unused for long, please curl up the wires and reserve this
product in dry and dustless environment.
Don t reserve this product under high temperature or near fire and avoid longtime
direct sunshine.
Please clean this product by dry cloth. Don t use thinner, benzene or alcohol.
The mechanical components of this product are specially designed and made, it is
not necessary to be specially maintained.
Don t use edged res to thrust this product.
Don t roll or pull this product above uneven ground, it should be lifted before moving.
Please use it intermittently; don t make this product work continuously for long.
6. Solution of ordinary malfunctions.
It is nature movement voice if the motor sounds while in usage.
If the controller can t work normally, please check the plug and socket if they are
connected strongly and make sure the switch is turned on.
If the rated working time is over, the product will automatically activate the power-
off button; If this product works continuously for long, the temperature protector will
make the product automatically power-off, it should be used again after half an
hour s rest.
If the detachable cord / supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons in order to avoid a
Hazard.
1.IMPORTANT SAFETY WARNING.

04 05
1
3
2
5
9
8
10
6
4
12
11
14
13
15 16
ON/OFF FUSE
17
7
Name And Function Of Components Function
1.Pillow pad
2.Controller
3.Arm air bags assembly
4.Cell phone pocket
5.Legs frame
6.Foot frame
7.Upper arm air bags assembly
8.Back cushion
9.Armrest
10.LED blue light artistic effect
11.Back cover
12.Controller holder
13.Base caster
14.Power line and power plug
15.Power socket
16.Power switch
17.Fuse box
function
Designed with a set of vertically movable, four-wheel driven muted massage
hands.
Programmed with five emulation massage methods of kneading, flapping,
kneading and flapping, shiatsu, knocking.
Automatically scan and positioning of shoulder.
Automatic massage function (seven automatic massage of comfort, relaxed,
ache improving, fatigue recovery, full, neck and shoulder, waist)
Designed with four massage functions: whole body airbag, swing hip, back -
waist twist, and waist stretch.
Designed with three massage memory function.
Manual massage for the upper body with three options overall, partial and fixed
massage, each with five levels of speed adjustable, in the state of fixed
massage, the massage hands can be moved up and down, in the state of
flapping, shiatsu and knocking, the width between the two kneading balls is
adjustable with three levels: wide, medium and narrow.
Air pressure massage for the arms (8pcs built-in airbags), air pressure massage
for the upper arm (4pcs built-in airbags)with three air pressure intensity options.
Air pressure massage for the lower body: back air pressure massage (4pcs
built-in airbags).buttock air pressure massage (5pcs built-in airbags), calf air
pressure massage (32pcs built-in airbags), with three air pressure intensity
options.
Rotatable upper arms, suit for different height of people.
The sole designed with sole rolling function, with three levels of speed
adjustable.
The calf rest length can be adjusted according to the user's height.
Calf rest and backrest can be reclined and declined, lying mode can be adjusted.
Automatically sit up and restore the massage hands when shut off the machine.
VFD display.
Armrest with LED light .

0706
Method Of UsageMethod Of Usage Method Of UsageMethod Of Usage
ON/OFF FUSE
ABC
NOTE: this is for reference only, please take practicality as standard
