Owner’s Manual
USB 3.0 Dual Head Display Adapter
Model: U344-001-HDDVI
Copyright © 2014 Tripp Lite. All trademarks are the property of their respective owners.
Table of Contents
1. Introduction 2
1.1 Features 2
1.2 Package Contents 2
1.3 System Requirements 3
2. Installation 4
3. Using the Adapter 5
3.1 Display Properties 5
3.2 Extending Video to the Add-On Display 7
3.3 Mirroring Video on the Add-On Display 8
3.4 Making the Add-On Display the Primary Display 8
4. Troubleshooting 9
5. Specifications 11
6. Warranty And Product Registration 12
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $50 value!
www.tripplite.com/warranty
14-11-219-9333D8.indd 1 12/5/2014 3:28:22 PM

2
1. Introduction
1.1 Features
• Add an HDMI and DVI monitor to your computer or laptop through a single USB 3.0
port
• DVI-I port allows for the connection of a VGA monitor using a DVI to VGA adapter
• Supports video resolutions up to 2048 x 1152
• Supports video streaming up to 1080p
• Up to 3 adapters can be connected to a single computer, allowing for the addition
of up to 6 displays
• Display video in either mirror or extended modes
• Bus powered, no external power supply required
• USB 3.0 supports data transfer rates up to 5 Gbps
• Backward compatible with USB 2.0
• Automatically resumes from hibernation and suspend modes
1.2 Package Contents
Before installation, please check the items in the package. The package should
contain the following items:
• (1) U344-001-HDDVI
• (1) Driver CD
• (1) USB 3.0 Cable
• (1) Owner's Manual
14-11-219-9333D8.indd 2 12/5/2014 3:28:22 PM

3
1. Introduction
1.3 System Requirements
• Windows®XP (32-bit), Vista (32- and 64-bit), 7 (32- and 64-bit) and
8 (32- and 64-bit)
• USB 2.0 or 3.0 port; USB 3.0 port required for USB 3.0 speeds
• VGA, DisplayPort, DVI or HDMI monitor
Minimum computer requirements when using 1 – 2 monitors:
• 1.2GHz Single Core CPU
• 512MB of RAM
Minimum computer requirements when using 3 monitors:
• 1.6GHz Single Core CPU
• 1GB of RAM
Minimum computer requirements when using 4 – 6 monitors:
• 1.8GHz Core Duo CPU
• 1GB of RAM
Note: Only 1 added monitor can support DVD playback. In order to support
DVD playback, your computer must meet the following minimum requirements:
• 2.0GHz Core Duo CPU
• 1GB of RAM
• Adapter screen resolution must be set to 800 x 600 with 32-bit color
14-11-219-9333D8.indd 3 12/5/2014 3:28:22 PM

4
Note: Install the driver on your computer before connecting the display adapter(s).
1. Insert the driver CD into your computer’s CD-ROM drive. The setup program should
run automatically. If the setup program fails to start on its own, open the CD and
double-click on the appropriate driver file.
Note:
• If you encounter a User Account Control popup, choose to allow the installation
to proceed. This may require an administrator’s password. If you encounter a
driver signature dialog box, choose to continue the installation.
• If a message stating “Display Link software for USB display adapter is already up
to date,” then the necessary software for this unit is already installed and you
can proceed to step 5.
2. Follow the prompts to complete the process.
3. When this process is complete, you will need to restart your computer to finish the
installation.
4. After restarting your computer, connect the included USB cable from an available
USB 2.0 or 3.0 port to the display adapter.
5. Connect displays to the HDMI and DVI-I ports using the appropriate cabling.
Note: The DVI-I connector supports both Digital and Analog video signals, and
allows for a VGA monitor to be connected using a DVI to VGA adapter, such as
Tripp Lite’s P556-Series cables.
6. Once connected, the computer will recognize the display adapter and complete the
installation. The video should now be displayed on the add-on monitors.
Note: It may take a few moments before the screen appears on the add-on
monitors. Also, it is normal for the screen to flicker on and off a few times when
first connected. If the add-on monitors remain blank, you may need to restart your
computer one more time.
2. Installation
14-11-219-9333D8.indd 4 12/5/2014 3:28:22 PM

5
2. Installation
3. Using the Adapter
3.1 Display Properties
Once installed, the computer video can be Extended from the primary display to the
add-on display, Mirrored to display the same thing on both, or changed to use the add-
on display as the primary display. This can be done by opening the Display Settings
page on your computer (see below) and changing the settings.
To access the display settings, right-click on your computer’s desktop and select
the Properties or Personalize option, depending on your Windows operating system.
From there you will need to access the Settings or Display option to get to the Display
Settings page. A quick way to access this page is to use the display adapter icon in
the lower-right corner of your computer screen. Right-click on this icon and select the
DisplayLink Manager or Video Setup option to automatically pull up your computer's
Display Settings page.
Using Multiple Display Adapters
When using multiple display adapters, it is only necessary to install the driver software
once. After connecting the first display adapter to the computer, simply move on to
connecting the next display adapter.
Note: When using Windows Vista XDDM mode only one display adapter will be able
to be configured to use Extended mode, and the remaining display adapters will be
forced to use Mirror mode. Windows Vista XDDM mode is a video card driver mode
that provides a Windows XP interface on a Vista computer.
14-11-219-9333D8.indd 5 12/5/2014 3:28:22 PM

6
3. Using the Adapter
Below are additional settings that are available via the display adapter right-click menu.
Note: The settings available in this right-click menu may vary depending on your
operating system.
Option Description
DisplayLink Manager Shows the DisplayLink Manager version number.
Check for Updates Connects to the internet and checks for newer versions of the DisplayLink
software, and downloads them if available.
USB 3.0 Adapter This option provides a list of settings when selected. When multiple
adapters are connected, a separate menu option will be available for each
one.
• Screen Resolution – Click this option to bring up a list of available
screen resolutions for the add-on monitor. Select the desired resolution
from this list.
• Screen Rotation – This setting allows you to rotate the screen
according to your desired orientation.
• Extend To – This setting allows you to select which direction to extend
the add-on monitor to: Right, Left, Up, Down.
• Set as Main Monitor – This setting allows you to make the add-on
monitor the primary display.
• Notebook Monitor Off – This setting appears on laptop computers
only, and allows you to turn off the laptop monitor, leaving only the add-
on monitor displayed.
• Mirror – This setting allows you to mirror the video of the primary display to
your add-on monitor, so that the same thing is displayed on both screens.
• Off – This setting turns off the add-on monitor.
• Optimize for Video – When playing video content on an add-on
monitor, this setting can help to improve playback performance.
Note: Text may appear less clear when this is enabled.
• Fit to TV – When using your display adapter to connect a TV to
your computer, the desktop may not always completely appear on
the screen. This setting can be used to adjust the picture to display
properly.
Audio Setup Opens your computer's sound settings screen.
Note: This function only works in specific models.
Video Setup Opens your computer’s display settings screen.
14-11-219-9333D8.indd 6 12/5/2014 3:28:23 PM

7
In addition to the display adapter right-click menu, Windows Vista and 7 users can
press the [Windows Key] and the [P] key at the same time to pull up the menu below,
which allows display settings to be switched quickly.
Note: Only Mirror mode is supported under Windows Vista Display Driver Model
(WDDM) mode. In addition, the Aero Experience (Flip 3D effect) will be disabled under
Windows Vista Display Driver Model (WDDM) mode as long as the display adapter is
connected.
3.2 Extending Video to the Add-On Display
To extend the video of the primary monitor to the add-on monitor, follow the steps
below:
1. Open your computer’s Display Settings page.
2. Select the monitor icon that represents the add-on display you wish to change, or
choose the add-on display from the drop-down menu. The primary display is always
icon 1.
3. Once you’ve selected the monitor icon for the add-on display, check the checkbox
to extend video onto the monitor, or select the extension option from the drop-down
list.
4. Drag the monitor icons in the Display Settings page so that they are positioned to
replicate the location of the actual displays. For example, if display 1 is directly to
the left of display 2, the monitor icons should be positioned that way. This affects
which side of the screen the mouse is allowed to move to the next display from,
and is therefore essential to ensure smooth mouse movement between displays.
5. Click the Apply button to activate the changes. The computer video will now be
extended from the primary display to the add-on display.
Note: When playing a DVD, it is recommended that you play the DVD on a monitor
connected to the computer via standard cabling and not an add-on monitor
connected via display adapter. If you need to play DVD on an add-on monitor, you
must have a 2.0GHz Core Duo CPU with 1GB of RAM, and the screen resolution
must be set to 800 x 600 with 32-bit color. If multiple display adapters are
connected to a computer, only one of them can play DVD content.
3. Using the Adapter
14-11-219-9333D8.indd 7 12/5/2014 3:28:23 PM

8
3.3 Mirroring Video on the Add-On Display
To display the same thing on both the primary and add-on display, follow the steps
below:
1. Open your computer’s Display Settings page.
2. Select the monitor icon that represents the add-on display you wish to change, or
choose the add-on display from the drop-down menu. The primary display is always
icon 1.
3. Un-check the box next to Extend the desktop onto this monitor, or select the option
from the drop-down menu to duplicate the display and then click the apply button.
Note: In Mirror mode, the add-on display settings are limited by those of the
primary display. If the primary display only supports a resolution of 1280 x 1024,
the add-on monitor will be limited to a resolution of 1280 x 1024 or less.
3.4 Making the Add-On Display the Primary Display
To make the add-on display the primary display for the computer, follow the steps
below:
1. Open your computer’s Display Settings page
2. Select the monitor icon that represents the add-on display you wish to change, or
choose the add-on display from the drop-down menu. The primary display is always
icon 1.
3. Check the box next to This is my main monitor and click the Apply button to make
the add-on display the primary display for the computer.
Note:
• Some computers require you to first un-select the original primary display before
setting a new primary display.
• Once set as the primary display, the add-on display will continue to be the primary
display as long as it is connected to the computer. Once disconnected, the primary
display will default back to the monitor connected to the computer via standard
cable.
3. Using the Adapter
14-11-219-9333D8.indd 8 12/5/2014 3:28:23 PM

9
Q: Why is the display on the add-on monitor blank?
A: If the monitor power LED is Green, wait a moment for the monitor to display
the video, as it may take some time for the video to be displayed on the add-on
monitor. If after a few minutes the video does not display, restart your computer.
Also, make sure the computer is not in standby or hibernation mode, which will
cause the add-on monitor to be blank.
If the monitor power LED is Red, check if the connection is properly made. If the
connection is fine and the problem still exists, uninstall the driver, unplug the
adapter and reinstall the driver.
Q: Why is the add-on monitor flickering?
A: This is usually caused by a low refresh rate. When in Mirror mode, increase the
refresh rate of the main monitor. This will in turn increase the refresh rate of
the add-on monitor, which should stop the flickering. When in Extended mode,
increase the refresh rate of the add-on monitor.
Q: When I play an MPEG file on a Windows Media Player on the extended
monitor, why does the display become abnormal when I switch it to
Full-Screen mode?
A: If your system is Windows XP SP1, upgrading to SP2 will solve this problem.
Q: Why does the video not display properly when in Full-Screen mode?
A: Try the following tips to improve the smoothness of the movie playback:
• Reduce the resolution of the display to 640 x 480 or 800 x 600.
• Use the adapter in extended mode.
• Terminate any other CPU intensive applications running on the computer.
• As some media players require DirectX hardware support to correctly operate,
try a different media player which requires less DirectX support.
• Drag the media player to the add-on screen and close the player. Restart the
player and it should open on the add-on monitor. Now try playing the media file
again.
• Try reducing the hardware acceleration level of the primary display (NOT
the add-on monitor) to levels 1, 2 or 3 and restarting the media player. The
hardware acceleration can be found by right-clicking on your desktop and
clicking “Properties > Settings > Advanced > Troubleshoot.”
• The video playback may be unusual when the add-on monitor is mirroring
the primary display and there is another extended screen connected to the
computer. The extended screen must be disabled before the content will be
correctly cloned to the add-on monitor.
4. Troubleshooting
14-11-219-9333D8.indd 9 12/5/2014 3:28:23 PM

10
4. Troubleshooting
Q: In Extended mode, why does the add-on monitor have a black border
around the desktop?
A: This happens when the resolution used by the add-on monitor is larger than the
resolution used by the primary monitor. To solve this problem, configure the add-
on monitor to use the same resolution as the primary monitor.
Q: In Extended mode, why does the cursor disappear?
A: If you’re in extended mode but have not yet connected the add-on monitor, the
desktop will still pan to the add-on monitor. It’s possible that your cursor has
moved to the extended desktop and is no longer visible on the primary display.
When this occurs, try the following:
• Connect the add-on monitor to the display adapter. You should be able to see
the mouse cursor once the computer screen is displayed.
• Move your mouse to try and drag the cursor back onto the primary monitor.
• Unplug the display adapter from the computer to restore the cursor.
14-11-219-9333D8.indd 10 12/5/2014 3:28:23 PM
