Owner’s Manual
HDMI + IR over Dual
Cat5/Cat6 Extender Kit
Model: B125-101-60-IR
1111 W. 35th Street, Chicago, IL 60609 USA • www.tripplite.com/support
Copyright © 2016 Tripp Lite. All rights reserved.
PROTECT YOUR INVESTMENT!
Register your product for quicker service
and ultimate peace of mind.
You could also win an ISOBAR6ULTRA
surge protector—a $100 value!
www.tripplite.com/warranty
16-04-148-9334B1-EN.indd 1 5/2/2016 3:03:01 PM

2
Features
Package Includes
Optional Accessories
• Extend a 1920 x 1080 (1080p) @ 60Hz signal up to 150 ft. using
Cat5/Cat6 cabling
• IR control allows you to use your HDMI source’s remote control in the
same location as your extended monitor
• Supports 7.1 Channel Surround Sound, DTS-HD and Dolby®TrueHD
audio
• Receiver unit features built-in Equalization control to adjust video image
• Supports EDID passthrough; HDCP and 3D compatible
• External power supply can be used with either the transmitter or receiver
side to free up an available unit on one of the ends
• Plug-and-play; no software required
• Transmitter and Receiver Units
• IR-TX and IR-RX Cables
• External Power Supply: (Input: 100-240V, 50/60Hz, 0.5A Output: 9V, 1A)
• Screwdriver for Equalization adjustment
• Owner’s Manual
• N202-Series Cat6 24 AWG Solid Wire Patch Cables
• P568-Series High Speed HDMI Cables
16-04-148-9334B1-EN.indd 2 5/2/2016 3:03:01 PM

3
Installation
Refer to the installation diagram below as you perform these steps.
Notes:
1. Test to make sure the entire installation works properly before pulling cables
through ceilings/walls.
2. To achieve maximum distance and performance, 24 AWG solid wire Cat5e/6 cable
must be used. The use of stranded wire Cat5e/6 cable or cable with a gauge size
higher than 24 AWG will result in shorter extension distance. All Tripp Lite
N202-Series Cat6 cables are made with 24 AWG, solid wire cabling.
7
83
4
6
5
CH1
CH2
TRANSMITTER RECEIVER
Blu-ray™ PLAYER
1080p (60 Hz)
DISPLAY
1080p (60 Hz)
Up to 150 ft. Cat5e/6
2
4
1. Make sure all equipment being connected is powered off.
2. Connect the HDMI source to the HDMI input on the transmitter unit.
3. Connect the IR-TX cable to the IR port on the transmitter unit.
Note: The IR-TX cable transmits the IR signal to the device being controlled.
Locate the IR-TX unit in an area with clear line of sight to the source
(e.g. Blu-ray player).
4. External power can be supplied to either the transmitter or receiver unit.
If connecting the external power supply to the receiver is preferred,
perform this step on the receiver after Step 8. Otherwise, connect the
external power supply to the transmitter, then plug it into a Tripp Lite
Surge Protector, Uninterruptible Power Supply (UPS), or Power
Distribution Unit (PDU). The green LEDs on both the transmitter and
receiver units will illuminate to indicate that power is being received.
The orange LED on the receiver unit will illuminate to indicate that a
connection has been made with the transmitter unit via Cat5e/6 cable.
16-04-148-9334B1-EN.indd 3 5/2/2016 3:03:01 PM

4
Installation
5. Connect the CH1 RJ45 port on the transmitter to the CH1 RJ45 port on
the receiver using Cat5e/6 cable.
Note: See the installation diagram for maximum extension distance at 1080p
(60Hz) video resolutions.
6. Connect the CH2 RJ45 port on the transmitter to the CH2 RJ45 port on
the receiver using Cat5e/6 cable.
Note: See the installation diagram for maximum extension distance at 1080p
(60Hz) video resolutions.
7. Connect the HDMI input on the receiver to the HDMI monitor.
8. Connect the IR-RX cable to the IR port on the receiver unit.
Note: The IR-RX cable receives the IR signal from a remote control. Locate the
IR-RX unit in an area with a clear line of sight to the remote control.
9. Turn on the connected equipment. The orange LED on the transmitter
unit will illuminate to indicate it is receiving a signal from the source.
10. If necessary, use the equalization control to adjust the video image.
Note: An improper Equalization setting can result in no image being displayed at
all. If no image is displayed on your monitor, try adjusting the Equalization.
16-04-148-9334B1-EN.indd 4 5/2/2016 3:03:01 PM

5
Troubleshooting
If you are unable to get an acceptable image after following the installation
instructions, try the troubleshooting tips below.
1. Is the external power supply that came with the product
connected and plugged into a working power source? For the
product to function properly, the transmitter or receiver must be
connected to and receiving power from an external power supply.
2. Was the power to the HDMI source turned off prior to
installation? If not, restart.
3. What resolution are you trying to reach? See the Product Features
and Installation sections in this manual for details on maximum
distance and resolution. The shorter the extension distance, the higher
the resolution you will be able to obtain. If you are not able to get an
acceptable image, try lowering your computer’s video resolution or
adjusting the refresh rate.
4. What type of cabling are you using? Inferior cabling can result in
poor performance, so it is important that you use cables that can
support the video resolution you are trying to obtain. To achieve
maximum distance and resolution, 24 AWG solid-wire UTP cable (such
as Tripp Lite’s N202-Series cables) must be used.
5. Test your cables to ensure they are working properly. For example,
connect your Cat5e/6 cable between a computer and a network to
verify that it establishes a network connection.
6. Do you have any patch panels or other devices in between the
transmitter and receiver units? Tripp Lite’s HDMI over Cat5 extender
kits are designed to be connected directly from the transmitter to the
receiver via UTP cable. The more connection points that are between
the source and the remote monitor, the more likely signal degradation
will occur, causing poor performance. If you have a patch panel or other
device in between, it should be removed from the installation.
16-04-148-9334B1-EN.indd 5 5/2/2016 3:03:01 PM

6
Troubleshooting
7. Do you have a splitter, switch or other device in between the
computer and transmitter, or in between the receiver and
display? Tripp Lite’s HDMI over Cat5 extender kits were designed for
the transmitter to connect directly with the source computer, and for
the receiver to connect directly to the display. If you have a splitter,
switch, or other device in between, it should be removed from the
installation.
8. Check your cabling for any damage that may have occurred
during installation. If a cable connector is loosened from pulling
through ceilings/walls or the cable jacket is damaged, causing the
wiring to be exposed, you will not be able to achieve maximum
performance.
9. Are the transmitter and/or receiver units located in an area that
exposes them to elevated temperatures? If the product is
overheating, it will not function properly.
10. Make sure that the CH1 RJ45 port on the transmitter is
connected to the CH1 RJ45 port on the receiver, and CH2 is
connected to CH2. If you have CH1 and CH2 connected, you will not
be able to get a signal.
16-04-148-9334B1-EN.indd 6 5/2/2016 3:03:01 PM

7
Warranty and Product Registration
1-YEAR LIMITED WARRANTY
TRIPP LITE warrants its products to be free from defects in materials and workmanship for
a period of one (1) year from the date of initial purchase. TRIPP LITE’s obligation under this
warranty is limited to repairing or replacing (at its sole option) any such defective products. To
obtain service under this warranty, you must obtain a Returned Material Authorization (RMA)
number from TRIPP LITE or an authorized TRIPP LITE service center. Products must be
returned to TRIPP LITE or an authorized TRIPP LITE service center with transportation charges
prepaid and must be accompanied by a brief description of the problem encountered and proof
of date and place of purchase. This warranty does not apply to equipment, which has been
damaged by accident, negligence or misapplication or has been altered or modified in any way.
EXCEPT AS PROVIDED HEREIN, TRIPP LITE MAKES NO WARRANTIES, EXPRESS
OR IMPLIED, INCLUDING WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A
PARTICULAR PURPOSE.
Some states do not permit limitation or exclusion of implied warranties; therefore, the aforesaid
limitation(s) or exclusion(s) may not apply to the purchaser.
EXCEPT AS PROVIDED ABOVE, IN NO EVENT WILL TRIPP LITE BE LIABLE FOR DIRECT,
INDIRECT, SPECIAL, INCIDENTAL OR CONSEQUENTIAL DAMAGES ARISING OUT OF THE
USE OF THIS PRODUCT, EVEN IF ADVISED OF THE POSSIBILITY OF SUCH DAMAGE.
Specifically, TRIPP LITE is not liable for any costs, such as lost profits or revenue, loss of
equipment, loss of use of equipment, loss of software, loss of data, costs of substitutes, claims by
third parties, or otherwise.
PRODUCT REGISTRATION
Visit www.tripplite.com/warranty today to register your new Tripp Lite product. You'll be
automatically entered into a drawing for a chance to win a FREE Tripp Lite product!*
* No purchase necessary. Void where prohibited. Some restrictions apply. See website for details.
