Tripp Lite PV1000FC Installation and operation manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model Number: PV1000FC
PowerVerter Plus Inverter - Industrial-Strength Power for Heavy-Duty Applications
Highlights
12V DC input; 120V AC output; 2 outlet
1000 watts continuous output
2000 watts peak surge output
High efficiency power conversion
Automatic overload protection
Description
Harness your vehicle's battery to efficiently power office equipment on the road or power tools at a work site. Continuously supplies up to 1000 watts
of 120V AC power to 2 AC outlets from any 12V battery or automotive DC source. Frequency control locks AC output at 60Hz for operating stability
of motor loads. Includes a set of high current DC input terminals for simple, permanent installation. Highly reliable large transformer design
specializes in powering motors and other inductive loads with high-current startup needs.
Applications
Ideal for power tools, pumps, fans, desktop computer systems, laptops, portable electronics, battery chargers for cell phones, pagers,
notepads and games, full size TV-VCR & stereo systems, camcorders, lighting and other AC applications under 1000 watts continuous/2000
watts peak.
Package Includes
PV1000FC inverter
Instruction manual
Features
Allows users to run large, motorized AC appliances from any 12V battery or automotive DC system
Converts 12V DC battery power to 120V AC power
1,000 watts continuous output power
2,000 watts peak output power to startup heavy motorized/inductive loads
2 outlets; DC input terminals for 12V battery connection
Frequency control for operating stability
High-efficiency operation conserves batteries to prolong run time
Diagnostic LEDs indicate load level (high, medium, and low) and battery charge (high, medium, and low)
DC fusing protects inverter against overload
3.5mm port for connecting remote switch (User supplies cable and switch)
Specifications
OUTPUT
Frequency
compatibility
60 Hz

Output watts Continuous - 1000 watts, Overpower (up to 1 hour) - 1500 watts, Double-Boost wattage (up to 10 seconds) - 2000
watts
Output nominal
voltage
120V nominal
Output voltage
regulation
Maintains PWM sine wave output voltage of 120 V AC (+/-5%)
Output frequency
regulation
60 Hz (+/- 0.3 Hz)
Overload protection Circuit breaker
Outlet quantity / type Includes 2 AC outlets (NEMA 5-15R)
INPUT
Recommended
Electrical Service
Requires 12V DC input source capable of delivering 100A for the required duration (when used at full capacity). For
automotive applications, professional hardwire installation with 200A battery system fusing is recommended.
Maximum input amps
/ watts
Full continuous load - 100A at 12V DC, No load - 2.2A at 12V DC
Input connection type Set of 2 DC input terminals
Input cord length
details
User supplies cabling. 4 gauge or larger recommended.
Voltage compatibility
(VDC)
12
BATTERY
DC system voltage
(VDC)
15
LEDS ALARMS & SWITCHES
Switches Lighted on/off power switch, plus 2 conductor 3.5 mm port for connecting remote switch - user supplies switch,
3.5mm plug and cable.
Front panel LEDs Set of 6 LEDs offer continuous status information on load percentage (6 levels reported) and battery charge level (7
levels reported). See manual for sequences.
PHYSICAL
Shipping Dimensions
(HWD/in)
11.63 x 9.5 x 9.5
Shipping Dimensions
(HWD/cm)
29.5 x 24.13 x 24.13
Shipping weight (lbs) 22
Shipping weight (kg) 9.98
Unit Dimensions
(HWD/in)
7 x 8.75 x 7.75
Unit Dimensions
(HWD/cm)
17.8 x 22.23 x 19.7
Unit weight (lbs) 20.4
Unit weight (kg) 9.25
Cooling method Convection
Material of
construction
Polycarbonate

Form factors
supported
Mounting slots enable permanent placement of inverter on any horizontal surface (see manual for additional
mounting information)
ENVIRONMENTAL
Relative Humidity 0-95% non-condensing
SPECIAL FEATURES
Appearance Black color
WARRANTY
Product Warranty
Period (Worldwide)
1-year limited warranty
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
http://www.tripplite.com/sku/PV1000FC.
Copyright © 2014 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
