Tripp Lite SmartOnline SU3000RTXL2U User manual

Tripp Lite
1111 West 35th Street
Chicago, IL 60609 USA
Telephone: +[phone]
E-mail: [email protected]
Model #: SU3000RTXL2U
SmartOnline 3kVA On-Line Double-Conversion UPS, 2U Rack/Tower, 100/110/115/120/127V, NEMA outlets
Highlights
3000VA / 3kVA / 2500 watt on-line double-conversion 2U rack/tower UPS
100/110/115/120/127V 50/60Hz output, high efficiency economy mode option
Expandable runtime, Hot-swap batteries, 26 in / 66 cm installed depth
USB, RS232 & EPO ports; support for SNMP/WEB card options
Front panel status LEDs with detailed load and battery metering
2 independently switchable output load banks
NEMA L5-30P input; L5-30R & 5-15/20R outlets
Description
3000VA / 3kVA / 2500 watt on-line, double-conversion UPS system for critical server, network and telecommunications equipment. 2U rackmount
form factor with an installed depth of only 26 inches (66cm). Expandable battery runtime with optional BP72V15-2U (limit 1) and BP72V28RT3U
(multi-pack compatible) external battery packs. Full time sine wave 100/110/115/120/127V output with +/-2% voltage regulation. Uninterruptible
Power Supply (UPS) actively converts raw incoming AC power to DC, then re-converts output back to completely regulated, filtered AC output.
Operates continuously without using battery power during brownouts to 70V and overvoltages to 144V. Up to 97% efficiency in optional economy
mode saves BTU heat output and energy costs. NEMA L5-30P input plug. NEMA L5-30R, NEMA 5-15/20R and NEMA 5-15R output receptacles.
Network-grade AC surge and noise suppression. Zero transfer time between AC and battery operation. Network management interfaces include
USB port, DB9 serial port and SNMPWEBCARD slot. Built-in DB9 port offers both enhanced RS-232 enabled monitoring data, plus contact closure
monitoring ability. HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and
Mac OS X. Supports simultaneous detailed monitoring of equipment load levels, self-test data and mains power conditions via all network interfaces.
Includes PowerAlert monitoring software and complete cabling. Emergency Power Off (EPO) interface. Integrated two bank PDU switching supports
automated load shedding and remote-reboot of connected equipment. Multi-stage metered current monitoring and battery charge status LEDs.
Mains power and voltage regulation LEDs. Audible Alarm. Self-test. Fault-tolerant auto-bypass mode. LED display panel easily rotates for better
viewing in rackmount or tower configurations. Includes 4 post rackmount accessories. 2-9USTAND tower kit and 2POSTRMKITWM two post
rackmount and wall-mount hardware accessories available. Field replaceable, hot swappable internal batteries and external battery packs. $250,000
connected equipment insurance;
Applications
DISTRIBUTED SERVER ROOMS; NETWORK CLOSETS; SMALL BUSINESS NETWORKS; SMALL BUSINESS PHONE SYSTEM
Package Includes
SU3000RTXL2U UPS System
4 post rackmount installation brackets
PowerAlert Software CD and cabling
Owner's manual with warranty information
Features
SmartOnline high-performance UPS system is ideal for critical voice, data, medical and industrial network applications
Optional economy-mode operation with 97% efficiency for reduced power consumption and cooler operation

Optional economy-mode operation with 97% efficiency for reduced power consumption and cooler operation
Economy mode is schedulable via PowerAlert UPS management software for daily or weekly hours of operation to enable precision output
during peak operating hours and high efficiency, low BTU emission operation during off-peak times
Maintains continuous operation through blackouts, voltage fluctuations and surges
On-line, double-conversion mode provides perfectly regulated sine wave output within 2% of 100/110/115/120/127V (user selectable) with
zero transfer time
Supports operation at 50/60Hz (auto-sensing) with the ability for full-time frequency conversion from 50 to 60Hz or 60 to 50Hz (frequency
conversion de-rates UPS capacity by 20%)
Removes harmonic distortion, fast electrical impulses, frequency variations and other hard to solve power problems not addressed by other
UPS types
Corrects line voltage conditions as low as 70V and as high as 144V to within 2% of selected nominal voltage
Standard internal battery set offers 15 minutes runtime at half load (1250W) and 6 minutes at full load (2500W)
Expandable battery runtime with optional BP72V15-2U and BP72V28RT-3U external battery packs
Compact rackmount form factor installs using only 2 rack spaces (2U) with a depth of only 26 inches
Ships with all mounting accessories for 4 post rackmount installation
Optional 2POSTRMKITWM enables 2 post rackmount or wallmount installation
Optional 2-9USTAND accessory enables upright tower placement
Fault tolerant electronic bypass maintains utility output during a variety of UPS fault conditions
Network interfaces support simultaneous communications via built-in USB, DB9 serial / contact-closure and SNMPWEBCARD slot
HID compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X.
Included PowerAlert UPS monitoring software supports safe unattended shutdown, monitoring and control via local connected servers, plus
any number of additional servers over IP
UPS interface supports on-battery, low-battery, power-restored, AC-voltage, DC-voltage, output current monitoring, battery charge current,
battery capacity, AC line frequency, timed inverter shutoff, activate self-test, load bank output power control and remote reboot, UPS
nominal voltage adjustment and UPS line to battery power voltage setpoints
Built-in Emergency Power Off (EPO) interface with cable
NEMA L5-30P input plug / NEMA 5-15/20R & L5-30R output receptacles
Integrated 2 bank switched PDU enables remote outlet management for load shedding or remote reboot of individual load banks (each
bank has 3 outlets)
Front panel LEDs offer current monitoring and battery charge level information
Network grade AC surge suppression
Field replaceable, hot swappable internal batteries and external battery packs
$250,000 Ultimate Lifetime Insurance
Specifications
OUTPUT
Output Volt Amp
Capacity (VA)
3000
Output kVA capacity
(kVA)
3
Output Watt Capacity
(watts)
2500
Output kW capacity 2.5
Output power factor 0.83
Output Capacity
Details
Max output is 3000VA 2400W at 100V, 110V, 115V nominal settings
Crest Factor 3:1
Nominal Output
Voltage(s) Supported
100V; 110V; 115V; 120V; 127V
Nominal Voltage
details
120V default
Frequency
compatibility
50 / 60 Hz

Frequency
compatibility details
Output frequency matches input nominal on startup, defaults to 60 Hz on cold-start. Frequency conversion from 60
to 50 Hz -or- 50 to 60 Hz supported. Output capacity de-rates by 25% during frequency conversion operation.
Output voltage
regulation (line mode)
+/- 2%
Output voltage
regulation (Economy
line mode)
-12%, + 10%
Output voltage
regulation (Battery
mode)
+/- 2%
Built-in UPS output
receptacles
6 5-15/20R outlet(s); 1 L5-30R outlet(s)
Built-in controllable
switched load banks
Two switchable three-outlet load banks
Output circuit breaker 20A (x2) - each breaker protects 3 5-15/20R outlets, L5-30R outlet is un-breakered
Output AC waveform
(AC mode)
Pure Sine wave
Output AC waveform
(battery mode)
Pure Sine wave
INPUT
Rated input current
(at maximum load)
24A
Nominal Input
Voltage(s) Supported
100V AC; 110V AC; 115V AC; 120V AC; 127V AC
UPS input connection
type
L5-30P
Recommended
Electrical Service
30A 120V
Input cord length (ft.) 10
Input cord length (m) 3
BATTERY
Full load runtime
(minutes)
6 min. (2500w)
Half load runtime
(minutes)
15 min. (1250w)
Expandable battery
runtime
Supports extended runtime with optional external battery packs
External battery pack
compatibility
BP72V15-2U (limit 1); BP72V28RT-3U (multi-pack compatible)
DC system voltage
(VDC)
72
Battery recharge rate
(included batteries)
Less than 4.8 hours from 10% to 90%
Replacement battery
cartridge (internal
UPS battery
replacement)
RBC96-2U
Battery Access Front panel battery access door

Battery replacement
description
Hot-swappable, user replaceable batteries
VOLTAGE REGULATION
Voltage regulation
description
Online, double-conversion power conditioning
Overvoltage
correction
2% output voltage regulation during overvoltages to 144
Undervoltage
correction
2% output voltage regulation during undervoltages to 80
Severe undervoltage
correction
2% output voltage regulation during undervoltages to 70V (under 66% load only) or 60V (under 33% load only)
LEDS ALARMS & SWITCHES
LED Indicators 14 LEDs indicate line power, online mode, economy/bypass mode, on-battery, overload, battery low, replace battery
and fault status information; 4-LED meter displays load and battery charge levels; LED panel rotates for viewing in
rack/tower formats
Alarms Audible alarm indicates power failure, low battery, overload, replace battery and EPO operation
Alarm cancel
operation
Power-fail alarm can be silenced using alarm-cancel switch
Switches 2 Switches control off/on power status and alarm-cancel/self-test operation
SURGE / NOISE SUPPRESSION
UPS AC suppression
joule rating
504 joules
EMI / RFI AC noise
suppression
Yes
AC suppression
response time
Instantaneous
PHYSICAL
Installation form
factors supported
with included
accessories
4 post 19 inch rackmount (mounting rail kit included)
Installation form
factors supported
with optional
accessories
2 post rackmount (2POSTRMKITWM); Wallmount (2POSTRMKITWM); Tower (2-9USTAND)
Primary form factor Rackmount
UPS / Power Module
dimensions in
primary form factor
(height x width x
depth / inches)
3.5 x 17.3 x 26
UPS / Power Module
dimensions in
primary form factor
(height x width x
depth / cm)
8.9 x 43.9 x 66
Installed whole
system total rack
space height (rack
spaces)
2U
Secondary form factor Tower (requires 2-9USTAND)

UPS / Power Module
weight (lbs)
68.8
UPS / Power Module
weight (kg)
31.2
UPS Shipping
dimensions (height x
width x depth / inches)
9 x 22 x 32.8
UPS Shipping
dimensions (height x
width x depth / cm)
22.9 x 55.9 x 83.3
Shipping weight (lbs) 78.3
Shipping weight (kg) 35.5
UPS housing material Steel
Cooling method Fan
ENVIRONMENTAL
Operating
Temperature Range
+32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius.
Storage Temperature
Range
+5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius.
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr.
(full load)
1000
AC economy mode
BTU / hr. (full load)
241
Battery mode BTU /
hr. (full load)
1500
AC economy mode
efficiency rating
(100% load)
97%
COMMUNICATIONS
Communications
interface
USB (HID enabled); DB9 Serial; Contact closure; EPO (emergency power off); Slot for SNMP/Web interface
Network monitoring
port description
Supports detailed monitoring of UPS and site power conditions; DB9 port supports RS232 and contact closure
communications
PowerAlert software Included
Communications
cable
USB and DB9 cabling included
WatchDog
compatibility
Supports Watchdog application, OS and hard-reboot restart options for remote applications
LINE / BATTERY TRANSFER
Transfer time No transfer time (0 ms.) in online, double-conversion mode
Low voltage transfer
to battery power
(setpoint)
80V (100% load), 70V (66% load), 60V (33% load)
High voltage transfer
to battery power
(setpoint)
144

SPECIAL FEATURES
Cold Start (startup in
battery mode during
a power failure)
Cold-start operation supported
High availability UPS
features
Automatic inverter bypass; Hot swappable batteries
Green & high
efficiency features
High efficiency economy mode operation; Individually controllable load banks; Schedulable daily hours of economy
mode operation
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A (EMI)
WARRANTY
Product Warranty
Period (Worldwide)
2-year limited warranty
Connected
Equipment Insurance
(U.S., Canada &
Puerto Rico)
$250,000 Ultimate Lifetime Insurance
Related Items
Optional Products
Product Type Related Model Description Qty.
Extended Warranties WEXT3-2200-3000 3-Year Extended Warranty - For Smart Line-Interactive and Online
Tower or Rack models, 2200-3000VA
1
Extended Warranties WEXT5-2200-3000 5-Year Extended Warranty - For Smart Line-Interactive and Online
Tower or Rack models, 2200-3000VA or less
1
External Battery Packs BP72V15-2U BP72V15-2U - External Battery Pack for UPS System 1
External Battery Packs BP72V28RT-3U BP72V28RT-3U - External Battery Pack for UPS System 1
Power Cables P043-002 2-ft. 10AWG Heavy Duty Power Cord with 20 AMP Breaker, (NEMA
L5-30P to NEMA L5-20R)
1
Power Cables P044-06I 6-inch 12AWG Heavy Duty Power Adapter cord
(NEMA-L5-20R to NEMA-5-20P)
1
Power Cables P049-010 10-ft. 12AWG Heavy Duty Power cord
(IEC-320-C19 to NEMA 5-20P)
1
Power Distribution PDU2430 Basic PDU / Power Distribution Unit - Safe, reliable power distribution
for critical networking equipment
1
Power Distribution PDUB30 Dual source Power Distribution Unit / PDU with Manual Transfer Switch
enables Hot-swappable UPS Replacement in Critical Network
Applications
1
Power Distribution PDUMH30NET Switched, Metered PDU with Remote Monitoring - 2U Rackmount
Power Distribution Unit for Networks with Individually Switchable
Outlets, Current Metering, Remote Monitoring and Control
1
Power Distribution PDUMNV30 Monitored PDU / Power Distribution Unit supports real-time remote
monitoring of load level, voltage and frequency with options for remote
environmental and security monitoring
1
Power Distribution PDUMV30 Metered 0U Vertical Rack PDU - Metered Power Distribution Unit for
Network Applications
1
Power Distribution PDUMV30NET Switched, Metered PDU with Remote Monitoring - 0U Vertical
Rackmount Power Distribution Unit for Networks with Individually
Switchable Outlets, Current Metering, Remote Monitoring and Control
1
Rackmount/Wallmount Kits 2POSTRMKITWM Enables 2-Post Rackmount or Wallmount Installation of Select
Rackmount UPS Systems
1

Shutdown Cable Kits AS400CABLE KIT Power Management Tools - UPS Communication Cable Kit for System
i / AS400 / iSeries Servers
1
SNMP Accessories ENVIROSENSE Monitors temperature, humidity and contact-closure inputs. (Requires
SNMPWEBCARD or switched PDU.)
1
SNMP Accessories RELAYIOCARD Programmable Relay I/O Card 1
SNMP Accessories SNMPWEBCARD For remote monitoring and control via SNMP, Web, or Telnet. 1
Tower Stands 2-9USTAND Enables Tower Placement of Rackmount UPS Systems 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at
www.tripplite.com/en/products/model.cfm?txtModelID=4210.
Copyright © 2012 Tripp Lite. All rights reserved. All trademarks are the sole property of their respective owners. Tripp Lite has a policy of continuous
improvement. Specifications are subject to change without notice. Photos may differ slightly from final products.
