Tripp Lite SmartPro SMART3000RM2UN Installation guide

SmartPro 3kVA 2.25kW Line Interactive Sine Wave
UPS, Pre-installed SNMPWEBCARD, 2U, LCD, USB,
Serial, EPO, 120V
MODEL NUMBER: SMART3000RM2UN
Description
Tripp Lite SmartPro Line Interactive UPS with enhanced LCD interface offers network-grade power protection for
critical server, network and telecommunications equipment. Line Interactive Uninterruptible Power Supply (UPS)
with built-in Auto-Voltage Regulation (AVR) actively corrects brownouts and overvoltages back to usable levels
while maintaining a full battery charge in case of power failure. Tripp Lite's unique configuration excels in
exceptionally poor-power environments with two separate levels of voltage boost to correct both slight
undervoltages and severe brownout conditions. Interactive LCD interface reports UPS operating mode, detailed
UPS and site-power data, plus enables a variety of UPS setup and configuration options. Super-fast switchover
from line to battery power occurs within milliseconds to maintain operation of connected equipment without
interruption or reboot. 98% line-mode efficiency offers reduced heat emissions and operating costs. Network
management interfaces support communications via USB, RS-232 and pre-installed SNMPWEBCARD network
interface. HID-compliant USB interface enables integration with built-in power management and auto shutdown
features of Windows and Mac OS X. Network communications ports enable detailed monitoring of equipment
load levels, self-test data and utility power conditions. Includes PowerAlert monitoring software and complete cabling. Switched output load banks enable
scheduled and real-time remote reboot and load shedding of select outlets. Emergency Power Off (EPO) interface. LCD display panel easily rotates for
viewing in rackmount or tower configurations. Audible alarm with push-button momentary alarm-cancel and silent-mode configuration options. Programmable
self-test. Field-replaceable, hot-swappable battery modules.
Features
Tripp Lite SMART3000RM2UN line interactive 2U rack/tower UPS with 3000VA / 3kVA capacity (1600W maximum load with external battery packs)
Line interactive UPS with Automatic Voltage Regulation (AVR) corrects brownouts and overvoltages from 83 to 145V
NEMA L5-30P input plug; 8 NEMA 5-15/20R and 1 L5-30R output receptacles, Two independently switchable output load banks
Maintains uninterrupted operation of connected networking equipment during blackouts, surges, brownouts and overvoltages
High 98% efficiency rating in line-power mode offers reduced power consumption and BTU emisssions
Internal batteries offer 10 minutes at 50% load (1125W) and 3.5 minutes at 100% load (2250W)
Highlights
3kVA / 3000VA / 2250W line
interactive 2U rack/tower UPS
120V nominal output during
brownouts to 83V and
overvoltages to 145V
Interactive LCD provides UPS
status information and advanced
configuration options
USB, RS232, EPO and
Pre-installed SNMPWEBCARD
interface
Hot-swap batteries, 98%
efficiency, Sine wave output
2 independently switchable
output load banks
NEMA L5-30P input, 8 NEMA
5-15/20R & 1 L5-30R outlets
This product is ENERGY STAR
qualified for its ability to save
customers money while
helping to protect the
environment
Package Includes
SMART3000RM2UN UPS
System with Pre-installed
SNMPWEBCARD
PowerAlert Software with USB,
Serial & EPO cabling
4-post rackmount installation kit
Instruction manual
1 / 6

Extended runtime is available with optional BP48V24-2U (limit 1), BP48V60RT-3U (multi-pack compatible) and BP48V27-2US (multi-pack compatible)
external battery packs (max output de-rates to 1600 watts with external batteries)
External battery configurations require the use of Tripp Lite's External Battery Configuration Software (see manual)
Hot-swappable, user-replaceable internal batteries and external battery packs can be replaced with no disruption to connected equipment
Front panel LCD monitoring screen with MODE and ENTER buttons reports operating mode with 5-bar battery charge graphic, plus 7 selectable screens
of detailed UPS and site power information
LCD interface also supports a number of advanced user setup and operating preferences
Ships with 4 post rackmount installation hardware; Optional 2POSTRMKITWM enables 2 post rackmount/wallmount installation; Optional 2-9USTAND
enables tower placement
Built-in USB, RS-232 and pre-installed SNMPWEBCARD accessory
HID-compliant USB interface enables integration with built-in power management and auto shutdown features of Windows and Mac OS X
Included PowerAlert UPS monitoring software; Built-in Emergency Power Off (EPO) interface with cable
Specifications
OUTPUT
Output Volt Amp Capacity (VA) 3000
Output kVA capacity (kVA) 3
Output Watt Capacity (watts) 2250
Output kW capacity 2.25
Output power factor 0.75
Nominal Output Voltage(s)
Supported 120V
Frequency compatibility 60 Hz
Output voltage regulation (line mode) -14%, +6%
Output voltage regulation (Battery
mode) +/- 5%
Built-in UPS output receptacles 8 5-15/20R outlet(s); 1 L5-30R outlet(s)
Built-in controllable switched load
banks Two switchable single-outlet load banks
Output circuit breaker Two 20A output breakers protect 4 5-15/20R outlets each
Output AC waveform (AC mode) Pure Sine wave
Output AC waveform (battery mode) Pure Sine wave
INPUT
Rated input current (at maximum
load) 24A
Nominal Input Voltage(s) Supported 120V AC
UPS input connection type L5-30P
UPS Input cord length (ft.) 10
2 / 6

UPS Input cord length (m) 3
Recommended Electrical Service 30A 120V
Phase Single-Phase
BATTERY
Full load runtime (minutes) 3.5 min. (2250w)
Half load runtime (minutes) 10 min. (1125w)
Expandable battery runtime Output with external battery pack configurations is limited to 1600 watts maximum
External battery pack compatibility BP48V24-2U (limit 1); BP48V60RT-3U (multi-pack compatible); BP48V27-2US (multi-pack compatible)
DC system voltage (VDC) 48
Battery recharge rate (included
batteries) Less than 4.5 hours from 10% to 90%
Replacement battery cartridge
(internal UPS battery replacement) RBC94-2U
Battery Access Front panel battery access door
Battery replacement description Hot-swappable, user replaceable batteries
VOLTAGE REGULATION
Voltage regulation description Automatic voltage regulation (AVR) maintains line power operation with an input voltage range of 83 to 145
Overvoltage correction Input voltages between 127 and 145 are reduced by 12%
Undervoltage correction Input voltages between 108 and 96 are boosted by 12%
Severe undervoltage correction Input voltages between 83 and 95 are boosted by 24%
LEDS ALARMS & SWITCHES
Front panel LCD display
Front panel LCD information and configuration screen offers detailed UPS and site power status and operating
data, plus configuration of voltage, operating mode, alarm function and a variety of additional options (see manual
for detailed LCD configuration and monitoring options)
Alarms Audible alarm indicates UPS startup, power-failure, low-battery, overload, UPS fault and remote shutdown conditions
Alarm cancel operation Power-fail alarm can be temporarily silenced using alarm-cancel switch; silent mode alarm configuration option
available
Switches 3 pushbutton switches control OFF / ON power status, MODE selection and MUTE / ENTER control functions
SURGE / NOISE SUPPRESSION
UPS AC suppression joule rating 570
UPS AC suppression response time Instantaneous
EMI / RFI AC noise suppression Yes
PHYSICAL
3 / 6

Installation form factors supported
with included accessories 4 post 19 inch rackmount
Installation form factors supported
with optional accessories 2 post rackmount (2POSTRMKITWM); Wallmount (2POSTRMKITWM); Tower (2-9USTAND)
Primary form factor Rackmount
UPS / Power Module dimensions in
primary form factor (height x width x
depth / inches)
3.5 x 17.5 x 19.5
UPS / Power Module dimensions in
primary form factor (height x width x
depth / cm)
8.9 x 44.4 x 49.5
Rack Height 2U
Secondary form factor Tower (requires 2-9USTAND)
UPS / Power Module weight (lbs) 62.8
UPS / Power Module weight (kg) 28.5
UPS Shipping dimensions (height x
width x depth / inches) 7.9 x 21.7 x 24.2
UPS Shipping dimensions (height x
width x depth / cm) 20.1 x 61.5 x 62
Shipping weight (lbs) 73.8
Shipping weight (kg) 33.5
Cooling method Fan
UPS housing material Steel
ENVIRONMENTAL
Operating Temperature Range +32 to +104 degrees Fahrenheit / 0 to +40 degrees Celsius
Storage Temperature Range +5 to +122 degrees Fahrenheit / -15 to +50 degrees Celsius
Relative Humidity 0 to 95%, non-condensing
AC mode BTU / hr. (full load) 189
AC mode efficiency rating (100%
load) 98%
Operating Elevation (ft.) 0-3000m / 0-10,000 ft.
COMMUNICATIONS
Communications interface USB (HID enabled); DB9 Serial; Slot for SNMP/Web interface
Network monitoring port description Includes pre-installed SNMPWEBCARD interface; Supports detailed monitoring of UPS and site power conditions
PowerAlert software Included
Communications cable USB and DB9 cabling included
WatchDog compatibility Supports Watchdog application, OS and hard-reboot restart options for remote applications
4 / 6

LINE / BATTERY TRANSFER
Transfer time 5 milliseconds (AC to battery); 1 millisecond (battery to AC)
Low voltage transfer to battery
power (setpoint) 83
High voltage transfer to battery
power (setpoint) 145
SPECIAL FEATURES
Grounding lug Includes back panel grounding lug
Cold Start (startup in battery mode
during a power failure) Cold-start operation supported
High availability UPS features Hot swappable batteries
Green & high efficiency features Greater than 95% efficiency - GREEN UPS; Individually controllable load banks
CERTIFICATIONS
UPS Certifications Tested to UL1778 (USA); Tested to CSA (Canada); Tested to NOM (Mexico); Meets FCC Part 15 Category A
(EMI); ENERGY STAR Qualified
WARRANTY
Product Warranty Period (Worldwide) 2-year warranty, 3 year with registration. Note: Registration is required for 3-year warranty.
Connected Equipment Insurance
(U.S., Canada & Puerto Rico) $250,000 Ultimate Lifetime Insurance
Related Items
Optional Products
Model Number Description Qty.
WEXT5-2200-3000 5-Year Extended Warranty - For Smart Line-Interactive and Online Tower or Rack models,
2200-3000VA or less 1
BP48V27-2US BP48V27-2US - 2U External 48V Rack/Tower Battery pack for select Tripp Lite UPS Systems 1
BP48V24-2U External Battery Pack for UPS System 1
BP48V60RT-3U External Battery Pack and Cable. 3U, Expandable, Blue 2-Point Connector 1
ENVIROSENSE Monitors temperature, humidity and contact-closure inputs. (Requires UPS with SNMPWEBCARD,
monitored PDU or switched PDU.) 1
SRSWITCH Magnetic Door Switch Kit for front and rear doors; requires ENVIROSENSE 1
2-9USTAND Enables Tower Placement of Rackmount UPS Systems 1
2POSTRMKITWM Enables 2-Post Rackmount or Wallmount Installation of Select Rackmount UPS Systems 1
WATCHDOGSW WatchDog Service Monitoring / Reboot Software 1
5 / 6

PDU1220 Single-Phase Basic PDU, 20A 120V, 1U Horizontal Rackmount, 13 NEMA 5-15/20R outlets, NEMA
5-20P input plug 1
PDUV20 Single-Phase Basic PDU, 20A 120V, 0U Vertical Rackmount, 14 NEMA 5-15/20R outlets, NEMA
L5-20P input with 5-20P adapter 1
PDUMH20 Single-Phase Metered PDU, 20A 120V, 1U Horizontal Rackmount, 12 NEMA 5-15/20R outlets,
NEMA L5-20P input with 5-20P adapter 1
PDUNV Single-Phase Basic PDU, 16A 100-240V, 1U Rackmount, C13 C19 outlets, C20 input and C14,
L6-20P, L5-20P, 5-20P and 5-15P adapters 1
PDUMV20 Single-Phase Metered PDU, 20A 120V, 0U Vertical Rackmount, 28 NEMA 5-15/20R outlets, NEMA
L5-20P input with 5-20P adapter 1
PDUMNV20 Single-Phase Monitored PDU, 20A 120V, 70 in. 0U Vertical Rackmount, 24 NEMA 5-15/20R outlets,
NEMA L5-20P input with 5-20P adapter 1
PDUMNH20 Single-Phase Monitored PDU, 20A 120V, 1U Horizontal Rackmount, 8 NEMA 5-15/20R outlets,
NEMA L5-20P input with 5-20P adapter 1
PDUMV20NET Single-Phase Switched PDU, 20A 120V, 0U Vertical Rackmount, 24 NEMA 5-15/20R outlets, NEMA
L5-20P input with 5-20P adapter 1
PDUMH20AT Single-Phase Auto Transfer Switch / Metered PDU, 20A 120V, 1U Horizontal Rackmount, 16
5-15/20R outlets, 2 L5-20P / 5-20P adapters 1
PDUMH20ATNET Single-Phase Auto Transfer Switch / Switched PDU 20A 120V, 1U Horizontal Rackmount, 16
5-15/20R outlets, 2 L5-20P / 5-20P inputs 1
PDUB20 Single-Phase Hot-Swap PDU, 20A 120V, 2U Horizontal Rackmount, 4 NEMA 5-15R & 4 NEMA
5-15/20R outlets, 2 NEMA 5-20P input plugs 1
More information, including related products, owner's manuals, and additional technical specifications, can be found online at:
http://www.tripplite.com/sku/SMART3000RM2UN.
