Triton RT2000 Manual

1TDN 07103-00162
HEATER UPGRADE PROCEDURE (MODEL RT2000)
TOOLS REQUIRED: Diagonal cutters, phillips-head screwdriver.
NOTE: If the unit is ON, enter MANAGEMENT FUNCTIONS > SYSTEM PARAMETERS > SHUT DOWN THE TERMINAL.When prompted on the
screen, turn the power switch on the power supply to the OFF (0) position.
Step 1:
ENSURE POWER SWITCH IS OFF! Using the diagonal
cutters, cut the ty-wraps that secure the AC power cables
near the power supply. Next, unplug all the AC power cables
from the power supply.
Power switch
Step 2:
Using a phillips screwdriver, remove the top screw that se-
cures the fan assembly cover. Next, remove the cover.
)0002TR(stiKedargpUylbmessAretaeH
)V511(12180-00260N/P
)V032(22180-00260N/P
rebmuNtraP noitpircseD ytitnauQ
1
28000-00290 )V511(,ylbmessAretaeH1
2
38000-00290 )V032(,ylbmessAretaeH1
40000-42620)mm021(,retliFnaF1
33070-02190rewoP,elbaC1
51000-27030parWyT3
33001
-00250noitallatsnI,DC1
1
12180-00260N/PtiknidedulcnI
2
22180-00260N/PtiknidedulcnI

2
TDN 07103-00162
Step 3:
Loosen the three (3) screws shown (yellow). Remove the
screw in the lower right corner (blue). Note: This screw se-
cures the ground wire lug. Retain this screw.
Step 4:
Remove the fan assembly (with its power cable).
Step 5:
INSTALL THE HEATER ASSEMBLY:
!Remove and retain the top screw that secures the
front cover. Next, remove the cover.
!Mount heater assembly on the three (3) screws.
Note: The AC power cable connector will be facing Left
when assembly is mounted.
!Reinstall the screw previously removed in the lower
right corner. Note: There is NO ground wire that will be
secured. Tighten all screws.
Step 6:
Reinstall the heater assembly cover and secure on top with
the screw previously removed.
Step 7:
Install the new power cable provided to the heater assembly
and the other end to the power supply. Reconnect the rest of
the AC power cables to the power supply. Secure these cables
with the ty-wraps provided.
HEATER UPGRADE PROCEDURE (MODEL RT2000)
Step 8:
Remove and replace the filter.
