Trolli Master RA66 User manual

1. Install the brake handles
3. Install the shopping bag
2. Install the backstrap
OPERATING MAN AL
Slide the basket hooks into the brackets located under
the seat at the front.
ASSEMBLY
a) Consult your doctor, therapist or other qualified
professional to deter ine if this Rollator RA66 will
suit your particular needs.
b) For proper positioning and use of your Rollator, i agine a
line drawn across the back of the Rear Wheels. Part of one
foot should always be slightly ahead of that line as you walk
c) This rollator is for individual use only.
d) Rollator is designed for indoor & outdoor use.
e) Regularly check the brakes for proper operation. Pulling up
on the brake handle will slow the rollator. Pushing down
on the brake handle will lock the wheels. Pull up on the
brake handle to release the brake lock. (refer “BRAKE
SAGE” on page 2)
f) Do NOT use as a wheelchair or transport chair.
g) Rollator ust be fully opened and locked position
when being used as a walking aid.
h) Wear a proper shoes while using this rollator
i) Follow the instruction "OPENING/FOLDING" to fold or
unfold the rollator (refer page 2).
j) Do NOT sit on rollator and push yourself around using
your feet to propel.
k) Do NOT stand on Seat .
l) Before sitting on seat, be sure the rollator is fully
opened, and the brake is in the locked position.
) Do NOT use on stairs or escalators.
n) Do NOT seat on the rollator if the ground is slopped
or uneven.
o) Exercise caution when walking on sloped surfaces.
p) Do not hang objects fro the backstrap.
q) Do not use if the rollator is not functioning properly.
r) Maxi u user weight 250lbs / 113kg .
s) When storing/transporting your rollator do not
anything on the rollator, as da age ay occur.
t) Make sure your finger are clear of the folding or
pinch point, whenever the product is fold or unfolded.
ATTENTION!
Ensure that all bolts are securely fastened before using this rollator!
Brakes ust be in the parked /locked position before sitting on the rollator!
SAFETY NOTICE & CAUTION
RA66
Loop the strap (velcro)
around the fra e and
insert into wire tab
Fir ly stick the strap
CA TION: DO NOT OVERLOAD
SHOPPING BAG MAX LOAD 11lbs/5kg
Slide backstrap into the
backrest connector. The
padded side of the backstrap
should face the inside of the
rollator.
Secure the backstrap into
position by tightening the
screw and nut.
Rollator should be in the unfolded
position before beginning. Holding the
‘RED’ release lever in the open position.
Slide the Brake handle into the fra e.
Rectangular slots on the brake handle tube
should be facing inwards.
Set the desired handle height, and close
the ‘RED’ release lever. The release lever
should ‘click’ when locked into the closed
position.
The consequences such an adjust ent ay
have on the stability.

Manufactured By :-
TROLLI MASTER SDN. BHD. (209382-P)
Lot 525, Muki Telok Pangli a Garang, 42500 Daerah Kuala Langat,
Selangor Darul Ehsan, Malaysia.
Tel : [phone]
Fax :[phone]
E ail : t @trolli aster.co . y
Website : www.trolli aster.co
Adjust brake tension,
Loosen the locking
nut, and turn the
adjust ent screw
clockwise/ counter
clockwise
locking nut
adjust ent screw
WARRANTY
BRAKE USAGE OPENING/ FOLDING
USAGE
1. Product na e
2. CE- arked
3. Read the anual
4. Seat height
5. Max width
6. Max user weight/basket load
7. Indoor and outdoor use
8. Do not use as wheelchair
PRODUCT LABEL
TROLLI MASTER warrants the Journey (RA66) against defects in aterial and/or work anship for a period of one year fro
date of purchase. Those ite s no warrantied are wear ite s, such as handgrips, brake cables, and wheels. TROLLI MASTER will
not warranty the rollator if it has been da aged due to i proper installation, odification, and/or isuse. Service/Labour
charges are the discretion of the dealer, and are not the responsibility of Trolli Master.
TROLLI MASTER’s sole liability extends to repair or replace ent of parts or co ponents as previously specified. The foregoing
is in lieu of all warranties expressed, i plied or statutory
whether written or oral. TROLLI MASTER shall not be liable for any sequential or incidental da ages whatsoever.
MAINTENANCE
a) Clean the rollator using ild soap and water. Wipe dry.
b) Keep wheels clean.
c) Check screws and handle height adjust ents are tight.
d) If your rollator is not working properly. Contact your dealer.
e) DO NOT USE if the rollator is not functioning properly.
f) Use only authorized parts/accessories with your rollator.
Pull up on brake
handle to slow down
or to release the
parking brake.
Push down on
brake handle to
lock the brake into
PARK.
Do not support your weight on the handle atte pting to sit. Use
the handles to stabilize your body as you carefully turn around.
Keeps your hand on the handles and slowly lower your weight onto
the seat
STORAGE AND TRANSPORATION
Fold your rollator for easier storage and transportation.
Do not rest anything on your folded rollator when being
stored or transported as da age ay occur.
1
5
6
7
4
2
3
To Fold a rollator,
Turn counter clockwise to
open secondary fra e lock
and then fold.
To nfold a rollator,
Push down seat and activate
the secondary fra e lock
(turn clockwise)
* Only for reference
RA66-LOW
54c 74 -
94c
8
